基于居住空间属性的人口数据空间化方法研究

doi:10.18306/dlkxjz.2016.11.002

Abstract

Abstract:

Fine spatial scale population distribution has increasingly become a research hotspot yet a difficult question in the field of population geography. It has practical values in application and scientific significance for relevant research, such as disaster risk and impact assessment, resource allocation, and construction of smart cities. Residential building scale is considered an important part of fine spatial scales for population distribution. Research on the spatialization of population data at this scale has increasingly attracted academic attention. In this study, a population distribution vector data set at the residential building scale was established for six residential committees in Xuanzhou District, Anhui Province in 2015 based on residential space attribute data. Data used in the study include residential building patch area, percentage of housing area within residential building patches, building floor number, and public area rate. The method takes residential space attributes as variables for spatializing population data and treats residential building patches as population distribution location in geographical space with town boundary and town-level demographic data as controls. The spatialization method used in this study reveals detailed information about population distribution in urban areas. The results show that: (1) The population distribution data, obtained by using residential space attributes, are proved to be of high accuracy and reliability. The mean absolute relative error for 29 communities (villages) is less than 7%. The absolute relative error of 25 out of 29 communities (villages) is less than 10%. The proportion of patches whose estimated number of people is in reasonable range is higher than 74% in a total of 1102 residential building patches. The proportion of patches whose relative error is in slightly underestimated area (-10%, 0) and overestimated area (0, 10%) is higher than 9%. (2) Building volume , defined by residential building patch area and building floor number, is a key factor to estimate accurately the number of people within a residential building. The percentage of housing area can further improve model accuracy. Public area rate plays an important role to increase estimated number of people in underestimated area and decrease that in overestimated area, but is too weak to adjust the estimated number of people to reasonable range. In conclusion, spatialization based on residential space attributes can be an important method for population spatialization research at the residential building scale.

Key words: population, spatialization, residential space, residential building, patch, Xuanzhou District of Xuancheng City

Nan DONG, Xiaohuan YANG, Hongyan CAI. A method for demographic data spatialization based on residential space attributes[J].PROGRESS IN GEOGRAPHY, 2016, 35(11): 1317-1328.

Figures/Tables 15

Fig.1

Fig.2

Tab.1

Tab.2

Tab.3

Models for demographic data spatialization based on residential space attributes

模型名称	回归模型
类型1	$P^= a × Area + b$
类型2	$P^= a × Area × PHA + b$
类型3	$P^= a × Area × BFN + b$
类型4	$P^= a × Area × PHA × BFN + b$
类型5	$P^= a × Area × PHA × BFN × (1 - k 1) + b$
类型6	$P^= a × Area × PHA × BFN × (1 - k 2) + b$

Tab.3

Tab.4

Tab.5

Fig.3

Fig.4

Fig.5

Tab.6

Tab.8

Fig.6

Tab.7

Tab.8

References 40

[1]	柏中强, 王卷乐, 姜浩, 等. 2015. 基于多源信息的人口分布格网化方法研究[J]. 地球信息科学学报, 17(6): 653-660. doi: 10.3724/SP.J.1047.2015.00653
	[Bai Z Q, Wang J L, Jiang H, et al.2015. The gridding approach to redistribute population based on multi-source data[J]. Journal of Geo-Information Science, 17(6): 653-660.] doi: 10.3724/SP.J.1047.2015.00653
[2]	柏中强, 王卷乐, 杨飞. 2013. 人口数据空间化研究综述[J]. 地理科学进展, 32(11): 1692-1702. doi: 10.11820/dlkxjz.2013.11.012
	[Bai Z Q, Wang J L, Yang F.2013. Research progress in spatialization of population data[J]. Progress in Geography, 32(11): 1692-1702.] doi: 10.11820/dlkxjz.2013.11.012
[3]	陈振拓, 李志强, 丁文秀, 等. 2012. 面向防震减灾的人口数据空间化研究: 以2007年宁洱地震灾区为例[J]. 震灾防御技术, 7(3): 273-284.
	[Chen Z T, Li Z Q, Ding W X, et al.2012. Study of spatial population distribution in earthquake disaster reduction: A case study of 2007 Ning'er earthquake[J]. Technology for Earthquake Disaster Prevention, 7(3): 273-284.]
[4]	杜国明, 张树文. 2007. 面向防洪救灾的人口统计数据空间化研究: 以扶余县为例[J]. 长江流域资源与环境, 16(2): 265-268. doi: 10.3969/j.issn.1004-8227.2007.02.027
	[Du G M, Zhang S W.2007. Spatial distribution in population statistics in relation to flood prevention and rescue: A case study in Fuyu County[J]. Resources and Environment in the Yangtze Basin, 16(2): 265-268.] doi: 10.3969/j.issn.1004-8227.2007.02.027
[5]	杜国明, 张树文, 张有全. 2007. 城市人口密度的尺度效应分析: 以沈阳市为例[J]. 中国科学院研究生院学报, 24(2): 186-192. doi: 10.3969/j.issn.1002-1175.2007.02.008
	[Du G M, Zhang S W, Zhang Y Q.2007. Analyzing scale effects of population density with Shenyang City as a case[J]. Journal of the Graduate School of the Chinese Academy of Sciences, 24(2): 186-192.] doi: 10.3969/j.issn.1002-1175.2007.02.008
[6]	符海月, 李满春, 赵军, 等. 2006. 人口数据格网化模型研究进展综述[J]. 人文地理, 21(3): 115-119, 114. doi: 10.3969/j.issn.1003-2398.2006.03.025
	[Fu H Y, Li M C, Zhao J, et al.2006. Summary of grid transformation models of population data[J]. Human Geography, 21(3): 115-119, 114.] doi: 10.3969/j.issn.1003-2398.2006.03.025
[7]	谷国梁, 王晓蕾, 李雅静, 等. 2016. 天津市面向震害快速评估的房屋和人口空间化研究[J]. 地震, 36(2): 149-158.
	[Gu G L, Wang X L, Li Y J, et al.2016. Spatialization of population and housing data in Tianjin oriented to rapid earthquake loss assessment[J]. Earthquake, 36(2): 149-158.]
[8]	何莲娜. 2011. 基于城市布局要素的人口数据空间化研究[J]. 测绘科学, 36(1): 38-41.
	[He L N.2011. A discussion of population spatial distribution based on urban layout parameter[J]. Science of Surveying and Mapping, 36(1): 38-41.]
[9]	胡长菊. 2015. 国家建设部规定高层住宅楼公摊系数是多少[EB/OL]. 华律网, 2015-06-07[2016-09-21]. .
	[Hu C J. 2015. Guojia jianshebu guiding gaoceng zhuzhailou gongtan xishu shi duoshao[EB/OL]. Hualv Network, 2015-06-07[2016-09-21]. . ]
[10]	胡焕庸. 1936. 句容县之人口分布[J]. 地理学报,(3): 621-627, 14. doi: 10.11821/xb193603008
	[Hu H Y.1936. The distribution of population in Chuyung District[J]. Acta Geographica Sinica,(3): 621-627, 14.] doi: 10.11821/xb193603008
[11]	胡焕庸. 1983. 论中国人口之分布[M]. 上海: 华东师范大学出版社.
	[Hu H Y. 1983. Lun Zhongguo renkou zhi fenbu[M]. Shanghai, China: East China Normal University Press.]
[12]	江东, 杨小唤, 王乃斌, 等. 2002. 基于RS、GIS的人口空间分布研究[J]. 地球科学进展, 17(5): 734-738. doi: 10.3321/j.issn:1001-8166.2002.05.016
	[Jiang D, YangX H, Wang N B, et al.2002. Study on spatial distribution of population based on remote sensing and GIS[J]. Advance in Earth Sciences, 17(5): 734-738.] doi: 10.3321/j.issn:1001-8166.2002.05.016
[13]	康停军, 张新长, 赵元, 等. 2012. 基于多智能体的城市人口分布模型[J]. 地理科学, 32(7): 790-797.
	[Kang T J, Zhang X C, Zhao Y, et al.2012. Agent-based urban population distribution model[J]. Scientia Geographica Sinica, 32(7): 790-797.]
[14]	李月娇, 杨小唤, 王静. 2014. 基于景观生态学的人口空间数据适宜格网尺度研究: 以山东省为例[J]. 地理与地理信息科学, 30(1): 97-100. doi: 10.7702/dlydlxxkx20140120
	[Li Y J, Yang X H, Wang J.2014. Grid size suitability of population spatial distribution in Shandong Province based on landscape ecology[J]. Geography and Geo-Information Science, 30(1): 97-100.] doi: 10.7702/dlydlxxkx20140120
[15]	廖顺宝, 孙九林. 2003. 基于GIS的青藏高原人口统计数据空间化[J]. 地理学报, 58(1): 25-33. doi: 10.3321/j.issn:0375-5444.2003.01.004
	[Liao S B, Sun J L.2003. GIS based spatialization of population census data in Qinghai-Tibet Plateau[J]. Acta Geographica Sinica, 58(1): 25-33.] doi: 10.3321/j.issn:0375-5444.2003.01.004
[16]	林丽洁, 林广发, 颜小霞, 等. 2010. 人口统计数据空间化模型综述[J]. 亚热带资源与环境学报, 5(4): 10-16. doi: 10.3969/j.issn.1673-7105.2010.04.002
	[Lin L J, Lin G F, Yan X X, et al.2010. Spatialization models of census data: A review[J]. Journal of Subtropical Resources and Environment, 5(4): 10-16.] doi: 10.3969/j.issn.1673-7105.2010.04.002
[17]	刘焕金. 2012. 基于多源数据的太湖流域人口空间化研究[D]. 南京: 南京农业大学.
	[Liu H J. 2012. Research on the population specialization basic on mutil-source data in Lake-Tai Basin[D]. Nanjing, China: Nanjing Agricultural University.]
[18]	王磊, 蔡运龙. 2011. 人口密度的空间降尺度分析与模拟: 以贵州猫跳河流域为例[J]. 地理科学进展, 30(5): 635-640. doi: 10.11820/dlkxjz.2011.05.017
	[Wang L, Cai Y L.2011. Spatial down-scaling analysis and simulation of population density in Maotiaohe Basin, Guizhou Province[J]. Progress in Geography, 30(5): 635-640.] doi: 10.11820/dlkxjz.2011.05.017
[19]	王立新. 2014. 专家给出银川住宅楼公摊率参考[N/OL]. 银川晚报, 2014-08-26[2016-9-21]. .
	[Wang L X. 2014. Zhuanjia geichu Yinchuan zhuzhailou gongtanlv cankao[N/OL]. Yinchuan Evening News, 2014-08-26[2016-9-21]. .]
[20]	王培震, 石培基, 魏伟, 等. 2012. 基于空间自相关特征的人口密度格网尺度效应与空间化研究: 以石羊河流域为例[J]. 地球科学进展, 27(12): 1363-1372. doi: 10.11867/j.issn.1001-8166.2012.12.1363
	[Wang P Z, Shi P J, Wei W, et al.2012. Grid scale effect and spatialization of population density based on the characteristic of spatial autocorrelation in Shiyang River Basin[J]. Advances in Earth Science, 27(12): 1363-1372.] doi: 10.11867/j.issn.1001-8166.2012.12.1363
[21]	杨小唤, 江东, 王乃斌, 等. 2002. 人口数据空间化的处理方法[J]. 地理学报, 57(S1): 70-75.
	[Yang X H, Jiang D, Wang N B, et al.2002. Method of pixelizing population data[J]. Acta Geographica Sinica, 57(S1): 70-75.]
[22]	杨小唤, 刘业森, 江东, 等. 2006. 一种改进人口数据空间化的方法: 农村居住地重分类[J]. 地理科学进展, 25(3): 62-69. doi: 10.3969/j.issn.1007-6301.2006.03.008
	[Yang X H, Liu Y S, Jiang D, et al.2006. An enhanced method for spatial distributing census data: Reclassifying of rural residential[J]. Progress in Geography, 25(3): 62-69.] doi: 10.3969/j.issn.1007-6301.2006.03.008
[23]	叶靖, 杨小唤, 江东. 2010. 乡镇级人口统计数据空间化的格网尺度效应分析: 以义乌市为例[J]. 地球信息科学学报, 12(1): 40-47.
	[Ye J, Yang X H, Jiang D.2010. The grid scale effect analysis on town leveled population statistical data spatialization[J]. Journal of Geo-Information Science, 12(1): 40-47.]
[24]	有哈相伴. 2009. 套内面积售房对买房的影响[EB/OL]. 新浪博客, 2009-08-28[2016-09-21]. . ]
	[Youhaxiangban. 2009. Taonei mianji shoufang dui maifang de yingxiang[EB/OL]. Sina Blog, 2009-08-28[2016-09-21]. .]
[25]	卓莉, 陈晋, 史培军, 等. 2005. 基于夜间灯光数据的中国人口密度模拟[J]. 地理学报, 60(2): 266-276. doi: 10.3321/j.issn:0375-5444.2005.02.010
	[Zhuo L, Chen J, Shi P J, et al.2005. Modeling population density of China in 1998 based on DMSP/OLS nighttime light image[J]. Acta Geographica Sinica, 60(2): 266-276.] doi: 10.3321/j.issn:0375-5444.2005.02.010
[26]	卓莉, 黄信锐, 陶海燕, 等. 2014. 基于多智能体模型与建筑物信息的高空间分辨率人口分布模拟[J]. 地理研究, 33(3): 520-531. doi: 10.11821/dlyj201403011
	[Zhou L, Huang X R, Tao H Y, et al.2014. High spatial resolution population distribution simulation based on building information and multi-agent[J]. Geographical Research, 33(3): 520-531.] doi: 10.11821/dlyj201403011
[27]	Bhaduri B, Brigh E, Coleman P, et al.2007. LandScan USA: A high-resolution geospatial and temporal modeling approach for population distribution and dynamics[J]. GeoJournal, 69(1-2): 103-117. doi: 10.1007/s10708-007-9105-9
[28]	Dmowska A, Stepinski T F.2014. High resolution dasymetric model of U.S demographics with application to spatial distribution of racial diversity[J]. Applied Geography, 53: 417-426. doi: 10.1016/j.apgeog.2014.07.003
[29]	Dong P L, Ramesh S, Nepalia A.2010. Evaluation of small-area population estimation using LiDAR, Landsat TM and parcel data[J]. International Journal of Remote Sensing, 31(21): 5571-5586.
[30]	Gallego F J.2010. A population density grid of the European Union[J]. Population and Environment, 31(6): 460-473. doi: 10.1007/s11111-010-0108-y
[31]	Gaughan A E, Stevens F R, Huang Z J, et al.2016. Spatiotemporal patterns of population in mainland China, 1990 to 2010[J]. Scientific Data, 3: doi: 10.1038/sdata.2016.5. doi: 10.1038/sdata.2016.5 pmid: 26881418
[32]	Jia P, Gaughan A E.2016. Dasymetric modeling: A hybrid approach using land cover and tax parcel data for mapping population in Alachua County, Florida[J]. Applied Geography, 66: 100-108.
[33]	Lung T, Lübker T, Ngochoch J K, et al.2013. Human population distribution modelling at regional level using very high resolution satellite imagery[J]. Applied Geography, 41: 36-45. doi: 10.1016/j.apgeog.2013.03.002
[34]	Lwin K, Murayama Y.2009. A GIS approach to estimation of building population for micro-spatial analysis[J]. Transactions in GIS, 13(4): 401-414. doi: 10.1111/j.1467-9671.2009.01171.x
[35]	Mennis J.2003. Generating surface models of population using dasymetric mapping[J]. The Professional Geographer, 55(1): 31-42. doi: 10.1111/0033-0124.10042
[36]	Patel N N, Stevens F R, Huang Z J, et al.2016. Improving large area population mapping using geotweet densities[J]. Transactions in GIS, doi: 10.1111/tgis.12214. doi: 10.1111/tgis.12214
[37]	Silván-Cárdenas J L, Wang L, Rogerson P, et al.2010. Assessing fine-spatial-resolution remote sensing for small-area population estimation[J]. International Journal of Remote Sensing, 31(21): 5605-5634. doi: 10.1080/01431161.2010.496800
[38]	Stevens F R, Gaughan A E, Linard C, et al.2015. Disaggregating census data for population mapping using random forests with remotely-sensed and ancillary data[J]. PLoS One, 10(2): doi: 10.1371/journal.pone.0107042. doi: 10.1371/journal.pone.0107042 pmid: 25689585
[39]	Ural S, Hussain E, Shan J.2011. Building population mapping with aerial imagery and GIS data[J]. International Journal of Applied Earth Observation and Geoinformation, 13(6): 841-852. doi: 10.1016/j.jag.2011.06.004
[40]	Zhang Y, Dong C, Liu J P, et al.2015. Gridded population distribution map for the Hebei Province of China[J]. Environmental Engineering and Management Journal, 14(3): 673-680.

类型	解译标志描述
类型	颜色	形状	相关布局	地域分布
1~2层居住建筑	屋顶以暗红、灰色为主;阴影不明显	房屋朝向不一致;房屋大小不一,几何形状规则	房屋排列无序,房屋间距不等,周围为绿色植被、耕地等	城乡结合处,城中村
3层及以上居住建筑	屋顶以暗红、暗灰、灰白色为主;阴影显著,并随楼房的变高而变长	方向特征显著,并且一致;几何形状规则且明显	房屋排列有序,与其他居住建筑呈近似等间距关系,周围绿化带及道路明显	城市市区

公摊率(k)	层数
公摊率(k)	1~3	4~6	7~18	19~
方案k¹	0.0	0.10	0.15	0.20
方案k²	0.0	0.08	0.18	0.22

模型名称	相关系数	决定系数	校正决定系数	估计值误差标准差
类型1	0.173	0.030	-0.006	8097.17
类型2	0.438	0.192	0.162	7388.19
类型3	0.956	0.914	0.911	2405.26
类型4	0.985	0.970	0.969	1430.66
类型5	0.982	0.965	0.963	1548.80
类型6	0.983	0.965	0.964	1530.76

模型名称	变差来源	平方和	自由度	均方	F统计量	显著性水平(Sig.)
类型4	回归	1.769E+09	1	1.769E+09	864.431	0.000
	残差	55263490	27	2046795.9	—	—
	总离差	1.825E+09	28	—	—	—
类型5	回归	1.760E+09	1	1.760E+09	733.626	0.000
	残差	64767166	27	2398783.9	—	—
	总离差	1.825E+09	28	—	—	—
类型6	回归	1.761E+09	1	1.761E+09	751.662	0.000
	残差	63266949	27	2343220.3	—	—
	总离差	1.825E+09	28	—	—	—

类别	计算值减真实值	斑块个数比重/%	相对误差平均值/%	描述
人均居住面积	<0	25.9	-5.8	人均居住面积计算值偏小
人均居住面积	>0	74.1	15.5	人均居住面积计算值偏大
建筑面积	<0	22.2	-8.2	矢量化提取的建筑面积偏小
建筑面积	>0	77.8	13.1	矢量化提取的建筑面积偏大

A method for demographic data spatialization based on residential space attributes

RichHTML

PDF (PC)

Like

Knowledge

Cited

Abstract

Cite this article

share this article

Figures/Tables 15

References 40

Related Articles 15

Metrics

Comments

Recommended 0

层数/层	合理区内斑块个数比重/%
层数/层	类型4	类型5	类型6
1~3	18.9	16.9	16.9
4~6	49.5	49.3	49.4
7~18	6.3	6.8	7.3
19~33	0.2	1.1	1.2

层数/层	类型5与类型4			类型6与类型4
层数/层	估算人数之差	人数之差平均值	斑块个数比重/%	估算人数之差	人数之差平均值	斑块个数比重/%
1~3	>0	6.8	18.7	>0	6.5	18.1
	=0	0.0	6.4	=0	0.0	7.2
	<0	-1.0	0.1	<0	—	0.0
4~6	>0	1.1	8.2	>0	1.8	40.9
	=0	0.0	32.3	=0	0.0	20.5
	<0	-1.1	21.2	<0	-1.0	0.3
7~18	>0	—	0.0	>0	—	0.0
	=0	—	0.0	=0	—	0.0
	<0	-13.1	11.6	<0	-21.9	11.6
19~33	>0	—	0.0	>0	—	0.0
	=0	—	0.0	=0	—	0.0
	<0	-44.1	1.5	<0	-54.0	1.5
