中国城市空气污染时空分布格局和人口暴露风险

doi:10.18306/dlkxjz.2021.10.004

Abstract

Abstract:

In recent years, the spatiotemporal distribution and its hazards to republic health of air pollution in China have shown new characteristics. Using hourly air quality monitoring data for five years (2015-2019) in 332 Chinese cities, this study analyzed the spatiotemporal distribution characteristics of air quality and urban population exposure risks by different methods. The results suggest that: 1) Air quality in Chinese urban areas has improved in recent years. Ambient Air Quality Index (AQI) decreased in 303 cities (91.3%). The concentrations of PM_2.5, PM₁₀, SO₂, and CO declined while the concentrations of NO₂ and O₃ increased. 2) The hotspots of PM_2.5, PM₁₀, SO₂, and CO concentration change rates were distributed in Xinjiang and Yunnan-South China. The hotspots of NO₂ concentration change rate were in the Xinjiang area and the Hetao Plain. The hotspots of O₃ concentration change rate were from the North China Plain to the middle and lower reaches of the Yangtze River. The trends of air quality change in the Northwest and South China were relatively slow. 3) Nine cities were exposed to PM_2.5, PM₁₀, SO₂, NO₂, O₃, and CO pollution, which were located in Shanxi, Hebei, and Shandong provinces; 12 cities had no exposure risks to these six pollutants, which were distributed in Xinjiang, Yunnan, Guizhou, Sichuan, Guangdong, Fujian, and Heilongjiang provinces. These conclusions are of important reference value for collaborative treatment of cross-regional air pollution and formulating spatially diffenrentiated population flow management policies in China.

Key words: cities, air pollution, hotspot analysis, exposure risks, China

XIAO Jiayu, HE Chao, MU Hang, YANG Lu, HUANG Jiayi, XIN Aixuan, TU Peiyue, HONG Song. Spatiotemporal pattern and population exposure risks of air pollution in Chinese urban areas[J].PROGRESS IN GEOGRAPHY, 2021, 40(10): 1650-1663.

Figures/Tables 13

Fig.1

Tab.1

Tab.2

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Tab.3

Tab.4

Fig.9

References 33

[1]	Chan C K, Yao X H. Air pollution in mega cities in China[J]. Atmospheric Environment, 2008, 42(1):1-42. doi: 10.1016/j.atmosenv.2007.09.003
[2]	Guo S, Hu M, Zamora M L, et al. Elucidating severe urban haze formation in China[J]. PNAS, 2014, 111(49):17373-17378. doi: 10.1073/pnas.1419604111
[3]	Shi X Q, Zhao C F, Jiang J H, et al. Spatial representativeness of PM_2.5 concentrations obtained using observations from network stations[J]. Journal of Geophysical Research: Atmospheres, 2018, 123(6):3145-3158. doi: 10.1002/jgrd.v123.6
[4]	Guo H, Cheng T H, Gu X F, et al. Assessment of PM_2.5 concentrations and exposure throughout China using ground observations[J]. Science of the Total Environment, 2017, 601/602:1024-1030. doi: 10.1016/j.scitotenv.2017.05.263
[5]	Cao S S, Zhao W J, Guan H L, et al. Comparison of remotely sensed PM_2.5 concentrations between developed and developing countries: Results from the US, Europe, China, and India[J]. Journal of Cleaner Production, 2018, 182:672-681. doi: 10.1016/j.jclepro.2018.02.096
[6]	Han L J, Zhou W Q, Pickett S T A, et al. Risks and causes of population exposure to cumulative fine particulate (PM_2.5) pollution in China[J]. Earth's Future, 2019, 7(6):615-622. doi: 10.1029/2019EF001182
[7]	Song C B, Wu L, Xie Y C, et al. Air pollution in China: Status and spatiotemporal variations[J]. Environmental Pollution, 2017, 227:334-347. doi: 10.1016/j.envpol.2017.04.075
[8]	Zhao X L, Zhou W Q, Han L J, et al. Spatiotemporal variation in PM_2.5 concentrations and their relationship with socioeconomic factors in China's major cities[J]. Environment International, 2019, 133:105145. doi: 10.1016/j.envint.2019.105145. doi: 10.1016/j.envint.2019.105145
[9]	Cai S Y, Wang Y J, Zhao B, et al. The impact of the 'Air Pollution Prevention and Control Action Plan' on PM_2.5 concentrations in Jing-Jin-Ji region during 2012-2020[J]. Science of the Total Environment, 2017, 580:197-209. doi: 10.1016/j.scitotenv.2016.11.188
[10]	Fang X K, Park S, Saito T, et al. Rapid increase in ozone-depleting chloroform emissions from China[J]. Nature Geoscience, 2019, 12(2):89-93. doi: 10.1038/s41561-018-0278-2
[11]	Li K, Jacob D J, Liao H, et al. Anthropogenic drivers of 2013-2017 trends in summer surface ozone in China[J]. PNAS, 2019, 116(2):422-427. doi: 10.1073/pnas.1812168116
[12]	Zhang Y Z, Wang Y H. Climate-driven ground-level ozone extreme in the fall over the Southeast United States[J]. PNAS, 2016, 113(36):10025-10030. doi: 10.1073/pnas.1602563113
[13]	彭远新, 林振山. 能源消费产生的SO₂和工业烟尘排放量时空演变分析[J]. 自然资源学报, 2010, 25(1):52-59.
	[ Peng Yuanxin, Lin Zhenshan. Analysis of temporal and spatial evolution of SO₂ and industrial dust emissions of energy consumption. Journal of Natural Resources, 2010, 25(1):52-59. ]
[14]	周亮, 周成虎, 杨帆, 等. 2000—2011年中国PM_2.5时空演化特征及驱动因素解析[J]. 地理学报, 2017, 72(11):2079-2092. doi: 10.11821/dlxb201711012
	[ Zhou Liang, Zhou Chenghu, Yang Fan, et al. Spatio-temporal evolution and the influencing factors of PM_2.5 in China between 2000 and 2011. Acta Geographica Sinica, 2017, 72(11):2079-2092. ]
[15]	Wang Z B, Fang C L. Spatial-temporal characteristics and determinants of PM_2.5 in the Bohai rim urban agglomeration[J]. Chemosphere, 2016, 148:148-162. doi: 10.1016/j.chemosphere.2015.12.118
[16]	Zhang B L, Tsunekawa A, Tsubo M. Identification of dust hot spots from multi-resolution remotely sensed data in Eastern China and Mongolia[J]. Water, Air, & Soil Pollution, 2015, 226:117. doi: 10.1007/s11270-015-2300-2. doi: 10.1007/s11270-015-2300-2
[17]	Chen D S, Liu X X, Lang J L, et al. Estimating the contribution of regional transport to PM_2.5 air pollution in a rural area on the North China Plain[J]. Science of the Total Environment, 2017, 583:280-291. doi: 10.1016/j.scitotenv.2017.01.066
[18]	Chen Y, Ebenstein A, Greenstone M, et al. Evidence on the impact of sustained exposure to air pollution on life expectancy from China's Huai River policy[J]. PNAS, 2013, 110(32):12936-12941. doi: 10.1073/pnas.1300018110
[19]	Kuerban M, Waili Y, Fan F, et al. Spatio-temporal patterns of air pollution in China from 2015 to 2018 and implications for health risks[J]. Environmental Pollution, 2020, 258:113659. doi: 10.1016/j.envpol.2019.113659. doi: 10.1016/j.envpol.2019.113659
[20]	Shi Y S, Matsunaga T, Yamaguchi Y, et al. Long-term trends and spatial patterns of satellite-retrieved PM_2.5 concentrations in South and Southeast Asia from 1999 to 2014[J]. Science of the Total Environment, 2018, 615:177-186. doi: 10.1016/j.scitotenv.2017.09.241
[21]	韩立建. 城市化与PM_2.5时空格局演变及其影响因素的研究进展[J]. 地理科学进展, 2018, 37(8):1011-1021. doi: 10.18306/dlkxjz.2018.08.001
	[ Han Lijian. Relationship between urbanization and urban air quality: An insight on fine particulate dynamics in China. Progress in Geography, 2018, 37(8):1011-1021. ]
[22]	van Donkelaar A, Martin R V, Brauer M, et al. Global estimates of fine particulate matter using a combined geophysical-statistical method with information from satellites, models, and monitors[J]. Environmental Science & Technology, 2016, 50(7):3762-3772. doi: 10.1021/acs.est.5b05833
[23]	He C Y, Han L J, Zhang R Q. More than 500 million Chinese urban residents (14% of the global urban population) are imperiled by fine particulate hazard[J]. Environmental Pollution, 2016, 218:558-562. doi: 10.1016/j.envpol.2016.07.038
[24]	环境保护部, 国家质量监督检验检疫总局. 环境空气质量标准(GB 3095—2012)[S]. 北京: 中国环境科学出版社, 2016.
	[Ministry of Environment Protection of the People's Republic of China, General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China. Ambient air quality standards, GB 3095-2012. Beijing, China: China Environment Science Press, 2016. ]
[25]	Environmental Protection Agency, USA. NAAQS table[EB/OL]. 2015 [2020-12-06]. https://www.epa.gov/criteria-air-pollutants/naaqs-table.
[26]	邹滨, 彭芬, 焦利民, 等. 高分辨率人口空气污染暴露GIS空间区划研究[J]. 武汉大学学报(信息科学版), 2013, 38(3):334-338.
	[ Zou Bin, Peng Fen, Jiao Limin, et al. GIS aided spatial zoning of high-resolution population exposure to air pollution. Geomatics and Information Science of Wuhan University, 2013, 38(3):334-338. ]
[27]	张亮林, 潘竟虎. 中国PM_2.5人口暴露风险时空格局[J]. 中国环境科学, 2020, 40(1):1-12.
	[ Zhang Lianglin, Pan Jinghu. Spatial-temporal pattern of population exposure risks to PM_2.5 in China. China Environmental Science, 2020, 40(1):1-12. ]
[28]	Guo H, Gu X F, Ma G X, et al. Spatial and temporal variations of air quality and six air pollutants in China during 2015-2017[J]. Scientific Reports, 2019, 9:15201. doi: 10.1038/s41598-019-50655-6. doi: 10.1038/s41598-019-50655-6
[29]	Wise E K, Comrie A C. Meteorologically adjusted urban air quality trends in the southwestern United States[J]. Atmospheric Environment, 2005, 39(16):2969-2980. doi: 10.1016/j.atmosenv.2005.01.024
[30]	程雪雁, 朱磊, 周艺萱. 2015—2018年京津冀城市群空气污染时空变化特征[J]. 北京师范大学学报(自然科学版), 2019, 55(4):523-531.
	[ Cheng Xueyan, Zhu Lei, Zhou Yixuan. Temporal and spatial characteristics of pollution in Beijing-Tianjin-Hebei urban agglomeration 2015-2018. Journal of Beijing Normal University (Natural Science), 2019, 55(4):523-531. ]
[31]	蔺雪芹, 王岱. 中国城市空气质量时空演化特征及社会经济驱动力[J]. 地理学报, 2016, 71(8):1357-1371. doi: 10.11821/dlxb201608006
	[ Lin Xueqin, Wang Dai. Spatio-temporal variations and socio-economic driving forces of air quality in Chinese cities. Acta Geographica Sinica, 2016, 71(8):1357-1371. ]
[32]	刘欢, 席鹏辉. 中国存在环境移民吗? 来自空气质量指数测算改革的自然实验[J]. 经济学动态, 2019(12):38-54.
	[ Liu Huan, Xi Penghui. Are there environmental migrants in China? Natural experiments from the reform of air quality index. Economic Perspectives, 2019 (12):38-54. ]
[33]	洪大用, 范叶超, 李佩繁. 地位差异、适应性与绩效期待: 空气污染诱致的居民迁出意向分异研究[J]. 社会学研究, 2016, 31(3):1-24, 242.
	[ Hong Dayong, Fan Yechao, Li Peifan. Socio-economic status, behavioral adaptation, and expectation for government performance: An analysis of the differentiation of residents' smog-related out-migration intetion. Sociological Studies, 2016, 31(3):1-24, 242. ]

指标	单位	平均时间	浓度限值	备注
PM_2.5	μg·m^-3	年平均	35	—
PM_2.5	μg·m^-3	24 h平均	75	—
PM₁₀	μg·m^-3	年平均	70	—
PM₁₀	μg·m^-3	24 h平均	150	—
SO₂	μg·m^-3	年平均	60	—
SO₂	μg·m^-3	24 h平均	150	—
NO₂	μg·m^-3	年平均	40	—
NO₂	μg·m^-3	24 h平均	80	—
O₃	μg·m^-3	日最大8 h平均	160	每年第四高的O₃日最大8 h平均浓度达标,则该年O₃浓度达标
CO	mg·m^-3	24 h平均	4	每年超标天数≤1,则该年CO浓度达标

指标	2015年	2016年	2017年	2018年	2019年	ROC/%
AQI	79.2	75.1	74.8	70.8	64.7	-18.4
PM_2.5/(μg·m^-3)	49.7	45.9	43.5	39.1	40.2	-19.1
PM₁₀/(μg·m^-3)	87.0	82.2	79.2	75.9	72.9	-16.3
SO₂/(μg·m^-3)	25.0	21.6	18.0	13.6	11.2	-55.2
NO₂/(μg·m^-3)	28.8	29.1	30.1	27.3	32.6	13.2
O₃/(μg·m^-3)	83.7	87.5	93.4	95.3	92.3	10.3
CO/(mg·m^-3)	1.08	1.04	0.97	0.85	0.81	-24.8
