IPCC AR5全球气候模式对1996-2005年中国气温模拟精度评价

doi:10.18306/dlkxjz.2015.10.003

Abstract

Abstract:

This article evaluates the precision of the temperature simulated by nine IPCC AR5 (the Fifth Assessment Report of the Intergovernmental Panel on Climate Change) GCMs (Global Climate Models) and the multi-model ensemble (MME), based on the observed temperature of 660 stations in China from 1996 to 2005. The results show that the correlation coefficients between the average daily temperature simulated by GCMs and station observations in China during 1996-2005 were very high, all above 0.86. The precision of the simulated average daily temperature in the southeast by the 10 models was higher than that in the west, judged by the lower Biases, mean relative errors (MREs), mean absolute errors (MAEs), and root mean square errors (RMSEs) in the southeast as compared to those in the west. The precision of the simulated temperature by IPSL-CM5A-LR, MRI-CGCM3, and NorESM1-M was poorer than that of the others—specially, the Biases, MREs, and RMSEs of the simulation result by IPSL-CM5A-LR , the Biases and RMSEs of the simulation result by MRI-CGCM3, and MREs and RMSEs of the simulation result by NorESM1-M, were larger. Taken into account the Biases, MREs, MAEs, and RMSEs, the simulation precision of MME was the highest.

Key words: IPCC AR5, Global Climate Models, temperature, precision, daily scale

Zhen SUN, Shaofeng JIA, Aifeng LV, Wenbin ZHU, Yanchun GAO. Assesment on precision of temperature simulated by the IPCC AR5 GCMs in China, 1996-2005[J].PROGRESS IN GEOGRAPHY, 2015, 34(10): 1229-1240.

Figures/Tables 7

Tab.1

Fig.1

Fig.2

Tab.2

Precision evaluation results of average daily temperature simulated by the IPCC AR5 GCMs in China/%, 1996-2005"

Models	$r > 0.98$	$r < 0.92$	$\| Bias \| < 0.5$	$\| Bias \| > 1.5$	$MRE < 0.2$	$MRE > 0.6$	$MAE < 2$	$MAE > 4$	$RMSE < 2$	$RMSE > 6$
BCC	67.9	0.9	70.2	6.2	70.9	1.1	24.5	31.4	11.7	16.4
BNU	44.8	0	73.9	5.6	79.4	0.9	31.7	24.5	18.5	12.4
CanESM2	56.4	1.2	77.4	6.2	82.9	1.1	38.8	23.6	14.5	14.2
CCSM4	68.5	0.3	81.7	7.3	82.9	2.9	40.8	19.8	16.5	11.4
MPI-ESM-LR	63.8	3.0	82.3	7.1	82.1	2.9	54.7	16.1	31.2	10.3
MRI-CGCM3	68.2	0	69.2	10.8	78.6	3.5	16.1	28.8	8.0	17.1
NorESM1-M	69.1	0.3	71.4	7.7	76.5	2.3	17.1	30.8	7.4	17.6
GISS-E2-R	36.8	0.5	82.3	7.0	73.8	3.9	33.5	22.4	13.2	14.5
IPSL-CM5A-LR	55.5	0.2	62.1	9.7	74.5	3.6	26.1	36.1	10.5	20.0
MME	88.0	0	78.6	6.4	80.6	1.8	47.9	22.0	37.0	12.0

Tab.2

Fig.3

Fig.4

Fig.5

References 29

1	巢清尘, 周波涛, 孙颖, 等. 2014. IPCC气候变化自然科学认知的发展[J]. 气候变化研究进展, 10(1): 7-13.
	[Chao Q C, Zhou B T, Sun Y, et al.2014. The cognition development of the climate change physical sciences on IPCC[J]. Progressus Inquisitiones de Mutatione Climatis, 10(1): 7-13.]
2	冯靖. 2012. 多全球模式对中国区域气候的模拟评估和预估[D]. 南京: 南京信息工程大学.
	[Feng J.2012. Simulation and projection for regional climate in China by multiple global climate models[D]. Nanjing, China: Nanjing University of Information Science & Technology.]
3	郭彦, 董文杰, 任福民, 等. 2013. CMIP5模式对中国年平均气温模拟及其与CMIP3模式的比较[J]. 气候变化研究进展, 9(3): 81-186.
	[Guo Y, Dong W J, Ren F M, et al.2013. Assessment of CMIP5 simulations for China annual average surface temperature and its comparison with CMIP3 simulations[J]. Progressus Inquisitions de Mutatione Climatis, 9(3): 181-186.]
4	黄传江, 乔方利, 宋亚娟, 等. 2014. CMIP5模式对南海SST的模拟和预估[J]. 海洋学报, 36(1): 38-47.
	[Huang C J, Qiao F L, Song Y J, et al.2014. The simulation and forecast of SST in the south China sea by CMIP5 models[J]. Acta Oceanologica Sinica, 36(1): 38-47.]
5	胡亚南, 刘颖杰. 2013. 2011-2050年RCP4.5 新情景下东北春玉米种植布局及生产评估[J].中国农业科学, 46(15): 3105-3114.
	[Hu Y N, Liu Y J.2013. Planting distribution of spring maize and its productivity under RCP4.5 scenario in Northeast China in 2011-2050[J]. Scientia Agricultura Sinica, 46(15): 3105-3114.]
6	姜会飞. 2008. 农业气象学 [M]. 北京: 科学出版社.
	[Jiang H F.2008. Nongye qixiangxue[M]. Beijing, China: Science Press.]
7	金之庆, 方娟, 葛道阔, 等. 1994. 全球气候变化影响我国冬小麦生产之前瞻[J]. 作物学报, 20(2): 186-196.
	[Jin Z Q, Fang J, Ge D K, et al.1994. Prospect to the impacts of climate change on winter wheat production in China[J]. Acta Agronomica Sinica, 20(2): 186-196.]
8	李振朝, 韦志刚, 吕世华, 等. 2013. CMIP5部分气候模式气温和降水模拟结果在北半球及青藏高原的检验[J]. 高原气象, 32(4): 921-928.
	[Li Z C, Wei Z G, Lv S H, et al.2013. Verifications of surface air temperature and precipitation from CMIP5 model in northern hemisphere and Qinghai-Xizang Plateau[J]. Plateau Meteorology, 32(4): 921-928.]
9	刘敏, 江志红. 2009. 13个IPCC AR4模式对中国区域近40 a气候模拟能力的评估[J]. 南京气象学院学报, 32(2): 256-268.
	[Liu M, Jiang Z H.2009. Simulation ability evaluation of surface temperature and precipitation by thirteen IPCC AR4 coupled climate models in China during 1961-2000[J]. Journal of Nanjing Institute of Meteorology, 32(2): 256-268.]
10	秦大河, Stocker T, 259名作者和TSU(驻伯尔尼和北京). 2014. IPCC第五次评估报告第一工作组报告的亮点结论[J]. 气候变化研究进展, 10(1): 1-6.
	[Qin D H, Stocker T, 259 Authors and TSU(Bern & Beijing). 2014. Highlights of the IPCC working group I Fifth Assessment Report[J]. Progressus Inquisitiones de Mutatione Climatis, 10(1): 1-6.]
11	沈永平, 王国亚. 2013. IPCC第一工作组第五次评估报告对全球气候变化认知的最新科学要点[J]. 冰川冻土, 35(5): 1068-1076.
	[Shen Y P, Wang G Y.2013. Key findings and assessment results of IPCC WGI Fifth Assessment Report[J]. Journal of Glaciology and Geocryology, 35(5): 1068-1076.]
12	王绍武, 罗勇, 赵宗慈, 等. 2013. IPCC第5次评估报告问世[J]. 气候变化研究进展. 9(6): 436-439.
	[Wang S W, Lou Y, Zhao Z C, et al.2013. The Fifth IPCC Assessment Report hits the streets[J]. Progressus Inquisitiones de Mutatione Climatis, 9(6): 436-439.]
13	王淑瑜, 熊喆. 2004. 5个海气耦合模式模拟东亚区域气候能力的初步分析[J]. 气候与环境研究, 9(2): 240-250.
	[Wang S Y, Xiong Z.2004. The preliminary analysis of 5 coupled ocean-atmosphere global climate models simulation of regional climate in Asia[J]. Cliamtic and Environmental Research, 9(2): 240-250.]
14	许崇海, 沈新勇, 徐影. 2007. IPCC AR4模式对东亚地区气候模拟能力的分析[J]. 气候变化研究进展, 3(5): 287-292.
	[Xu C H, Shen X Y, Xu Y.2007. An analysis of climate change in east Asia by using the IPCC AR4 simulations[J]. Advances in Climate Change Research, 3(5): 287-292.]
15	杨绚, 汤绪, 陈葆德, 等. 2014. 利用CMIP5多模式集合模拟气候变化对中国小麦产量的影响[J]. 中国农业科学, 47(15): 3009-3024.
	[Yang X, Tang X, Chen B D, et al.2014. Impacts of climate change on wheat yield in China simulated by CMIP5 Multi-Model Ensemble projections[J]. Scientia Agricultura Sinica, 47(15): 3009-3024.]
16	姚遥, 罗勇, 黄建斌. 2012. 8个CMIP5模式对中国极端气温的模拟和预估[J]. 气候变化研究进展, 8(4): 250-256.
	[Yao Y, Luo Y, Huang J B.2012. Evaluation and projection of temperature extremes over China based on 8 modeling data from CMIP5[J]. Progressus Inquisitiones de Mutatione Climatis, 8(4): 250-256.]
17	张超. 2004. 地理信息系统实习教程[M]. 北京: 高等教育出版社.
	[Zhang C.2004. Dili xinxi xitong shixi jiaocheng[M]. Beijing, China: Higher Education Press.]
18	中国农林作物气候区划协作组. 1987. 中国农林作物气候区划[M]. 北京: 气象出版社.
	[Chinese Collaboration of Climatic Divisions of Main Agricultural and Forest Crops. 1987. Zhongguo nonglin zuowu qihou quhua[M]. Beijing, China: China Meteorological Press.]
19	中国农业科学院. 1999. 中国农业气象[M]. 北京: 中国农业出版社. [Chinese Academy of Agricultural Science. 1999. Zhongguo nongye qixiang[M]. Beijing, China: Chinese Agricultural Press.]
20	赵宗慈, 丁一汇, 李晓东, 等. 1995. 海气耦合模式在东亚地区的可靠性评估[J]. 应用气象学报, 6(S1): 9-18.
	[Zhao Z C, Ding Y H, Li X D, et al.1995. Evaluation of CGCM climate simulation in East Asia region[J]. Quarterly Journal of Applied Meteorology, 6(S1): 9-18.]
21	赵宗慈. 1990. 全球环流模式在中国部分模拟效果评估[J]. 气象, 16(9): 13-17.
	[Zhao Z C.1990. Assessment on validation of general circulation models (GCMs) in China[J]. Meteorological Monthly, 16(9): 13-17.]
22	Challinor A J, Wheeler T, Hemming D, et al.2009. Ensemble yield simulations: crop and climate uncertainties, sensitivity to temperature and genotypic adaptation to climate change[J]. Climate Research, 38(2): 117-127.
23	Fowler H J, Blenkinsop S, Tebaldi C.2007. Linking climate change modelling to impacts studies: recent advances in downscaling techniques for hydrological modelling[J]. International Journal of Climatology, 27(12): 1547-1578.
24	IPCC. 2007. Climate change 2007: the physical science basis[R]. New York, NY: Cambridge University Press.
25	IPCC.2013. Climate Change 2013: the physical science basis [R]. Work Group ⅠContribution to the IPCC Fifth Assessment Report (AR5). Stockholm, Sweden: IPCC.
26	Jacob D J, Winner D A.2009. Effect of climate change on air quality[J]. Atmospheric Environment, 43(1): 51-63.
27	Parry M L, Rosenzweig C, Iglesias A, et al.2004. Effects of climate change on global food production under SRES emissions and socio-economic scenarios[J]. Global Environmental Change, 14(1): 53-67.
28	Verburg P H, Soepboer W, Veldkamp A, et al.2002. Modeling the spatial dynamics of regional land use: the CLUE-S model[J]. Environmental Management, 30(3): 391-405.
29	Zhou T J, Yu R C.2006. Twentieth-century surface air temperature over China and the globe simulated by coupled climate models[J]. Journal of Climate, 19(22): 5843-5858.

模式名称	国家	研究机构	空间分辨率(纬向格点数×经向格点数)
BCC	中国	国家气候中心	64×128
BNU	中国	北京师范大学	64×128
CanESM2	加拿大	CCCma	64×128
CCSM4	美国	NCAR	192×288
GISS-E2-R	美国	GISS/ NASA	90×144
IPSL-CM5A-LR	法国	IPSL	96×96
MPI-ESM-LR^*	德国	MPI	96×192
MRI-CGCM3^*	日本	MRI	160×320
NorESM1-M	挪威	NCC	96×144
