中学生地理空间思维能力提高的影响因素——基于甘肃省白银市第一中学高一学生的实证研究

doi:10.18306/dlkxjz.2017.07.007

Abstract

Abstract:

Spatial thinking ability is the basic ability of understanding geographical environment and a key geographic competence of students. Its influencing factors and mechanism need urgent attention for advancing spatial thinking theory. This study hypothesized that seven factors affect spatial thinking ability, including general intelligence level, living environment, interest in geography study, habit of using maps, interest in geographical problems, sensitivity about directions, and specialized geography knowledge. The level of spatial thinking ability and the seven hypothesized influencing factors of 126 samples from the Baiyin No.1 Middle School were measured by the spatial thinking ability test (STAT) measurement scales and factors’ measurement scales. The SPSS 23.0 software was used to analyze the related data. The samples were first divided into high, medium, and low score groups according to the level of spatial thinking ability, and general intelligence level, habit of using maps, and geography knowledge showed significant differences between the high and low score groups using independent sample T test. Then the samples were divided into high, medium, and low factor score groups, and general intelligence level, habit of using maps, specialized geography knowledge, and interest in geography study showed significant differences between the high and low factor score groups. The results indicate that general intelligence level, habit of using maps, and geography knowledge were necessary conditions of sample students’ high spatial thinking ability, and interest in geography study was also an important condition. The four factors were proven to be the main influencing factors of spatial thinking ability, and the level of influence from high to low was general intelligence, specialized geography knowledge, habit of using maps, and interest in geography study based on the result of the single factor linear regression analysis. The stepwise regression analysis result showed that general intelligence level and specialized geography knowledge had stronger influence on spatial thinking ability

Key words: spatial thinking ability, influencing factors, empirical research, Baiyin No.1 Middle School, Gansu Provincestar warehouses

Jingyi WAN, Xiaoxu LU, Yuqi LU, Fengzhen DU, Jun WANG, Beini JU. Influencing factors of middle school students' spatial thinking ability:A case study on senior one students of Baiyin No. 1 Middle School in Gansu Province[J].PROGRESS IN GEOGRAPHY, 2017, 36(7): 853-863.

Figures/Tables 11

Tab.1

Fig.1

Fig.2

Tab. 2

Fig.3

Tab.3

Tab.4

Tab.5

Tab.6

Tab.7

Tab.8

References 39

1	柴彦威. 2010. 城市空间与消费者行为[M]. 南京: 东南大学出版社. [Chai Y W. 2010. Chengshi kongjian yu xiaofeizhe xingwei[M]. Nanjing, China: Southeast University Press.]
2	冯健. 2005. 北京城市居民的空间感知与意象空间结构[J]. 地理科学, 25(2): 142-154. doi: 10.3969/j.issn.1000-0690.2005.02.003
	[Feng J.2005. Spatial cognition and the image space of Beijing's residents[J]. Scientia Geographica Sinica, 25(2): 142-154.] doi: 10.3969/j.issn.1000-0690.2005.02.003
3	顾朝林, 宋国臣. 2001. 北京城市意象空间及构成要素研究[J]. 地理学报, 56(1): 64-74.
	[Gu C L, Song G C.2001. Urban image space and main factors in Beijing[J]. Acta Geographica Sinica, 56(1): 64-74.]
4	侯雪姣, 徐梦洁. 2014. 南京城市意象空间及其影响因素分析[J]. 甘肃科技, 30(16): 36-40. doi: 10.3969/j.issn.1000-0952.2014.16.014
	[Hou X J, Xu M J.2014. Nanjing chengshi yixiang jiqi yingxiang yinsu fenxi[J]. Gansu Science and Technology, 30(16): 36-40.] doi: 10.3969/j.issn.1000-0952.2014.16.014
5	霍婷婷, 王茂军. 2009. 基于地名认知率的北京城市认知空间结构[J]. 地理科学进展, 28(4): 519-525. doi: 10.11820/dlkxjz.2009.04.006
	[Huo T T, Wang M J.2009. An analysis of spatial cognitive structure in Beijing City based on the cognitive rate of place names[J]. Progress in Geography, 28(4): 519-525.] doi: 10.11820/dlkxjz.2009.04.006
6	李屏. 2015. GIS在中学生地理空间思维能力培养中的应用[D]. 福州: 福建师范大学. [Li P. 2015. The application of GIS in developing high school student’s geospatial thinking ability[D]. Fuzhou, China: Fujian Normal University.]
7	刘金花. 2006. 儿童发展心理学[M]. 3版. 上海: 华东师范大学出版社. [Liu J H. 2006. Ertong fazhan xinlixue[M]. 3rd ed. Shanghai, China: East China Normal University Press.]
8	卢万合. 2005. 中学生地理空间思维能力及其培养[D]. 长春: 东北师范大学. [Lu W H. 2005. The geography special thinking of middle school students and its training tactics[D]. Changchun, China: Northeast Normal University.]
9	鲁学军, 周成虎, 龚建华. 1999. 论地理空间形象思维: 空间意象的发展[J]. 地理学报, 54(5): 401-408. doi: 10.3321/j.issn:0375-5444.1999.05.003
	[Lu X J, Zhou C H, Gong J H.1999. On geographic spatial thinking in images: The development of spatial mental images[J]. Acta Geographica Sinica, 54(5): 401-408.] doi: 10.3321/j.issn:0375-5444.1999.05.003
10	单华. 2013. 高中地理学科能力培养的研究[D]. 烟台: 鲁东大学. [Shan H. 2013. Research on cultivating geography subject ability of high school students[D]. Yantai, China: Ludong University.]
11	万刚, 高俊, 刘颖真. 2008. 基于阅读实验方法的认知地图形成研究[J]. 遥感学报, 12(2): 339-346. doi: 10.3321/j.issn:1007-4619.2008.02.021
	[Wan G, Gao J, Liu Y Z.2008. Research of cognitive map formation based on reading experiments[J]. Journal of Remote Sensing, 12(2): 339-346.] doi: 10.3321/j.issn:1007-4619.2008.02.021
12	王茂军, 柴彦威, 高宜程. 2007. 认知地图空间分析的地理学研究进展[J]. 人文地理, 22(5): 10-18.
	[Wang M J, Chai Y W, Gao Y C.2007. The progress of geographical study on the spatial analysis of cognitive map[J]. Human Geography, 22(5): 10-18.]
13	王茂军, 苏海威, 霍婷婷. 2010. 北京城市空间认知扭曲特征[J]. 地理科学进展, 29(10): 1185-1192. doi: 10.11820/dlkxjz.2010.10.005
	[Wang M J, Su H W, Huo T T.2010. The characteristics of urban spatial cognitive distortion in Beijing[J]. Progress in Geography, 29(10): 1185-1192.] doi: 10.11820/dlkxjz.2010.10.005
14	王启军. 2008. 初中生地理空间能力的性别差异研究[D]. 长春: 东北师范大学. [Wang Q J. 2008. Gender difference research of junior middle school student geography ability[D]. Changchun, China: Northeast Normal University.]
15	王晓明, 刘瑜, 张晶. 2005. 地理空间认知综述[J]. 地理与地理信息科学, 21(6): 1-10.
	[Wang X M, Liu Y, Zhang J.2005. Geo-spatial cognition: An overview[J]. Geography and Geo-Information Science, 21(6): 1-10.]
16	徐志梅, 袁孝亭. 2010. 运用GIS培养中学生地理空间能力[J]. 中国电化教育, (8): 96-100.
	[Xu Z M, Yuan X T.2010. Yunyong GIS peiyang zhongxuesheng dili kongjian nengli[J]. China Educational Technology, (8): 96-100.]
17	徐志梅, 袁孝亭. 2011. 高中生地理空间能力水平差异研究[J]. 内蒙古师范大学学报: 教育科学版, 24(12): 90-94.
	[Xu Z M, Yuan X T.2011. Gaozhongsheng dili kongjian nengli shuiping chayi yanjiu[J]. Journal of Inner Mongolia Normal University: Educational Science, 24(12): 90-94.]
18	徐志梅, 袁孝亭. 2012. 运用心理地图培养学生地理空间能力[J]. 中学地理教学参考, (5): 12-13.
	[Xu Z M, Yuan X T.2012. Yunyong xinli ditu peiyang xuesheng dili kongjian nengli[J]. Teaching Reference of Middle School Geography, (5): 12-13.]
19	徐志梅, 袁孝亭. 2013. 高中生地理空间能力测量量表初步编制[J]. 内蒙古师范大学学报: 教育科学版, 26(8): 139-143. doi: 10.3969/j.issn.1671-0916.2013.08.040
	[Xu Z M, Yuan X T.2013. Gaozhongsheng dili kongjian nengli celiang liangbiao chubu bianzhi[J]. Journal of Inner Mongolia Normal University: Educational Science, 26(8): 139-143.] of senior high school student doi: 10.3969/j.issn.1671-0916.2013.08.040
20	许燕, 张厚粲. 2000. 小学生空间能力及其发展倾向的性别差异研究[J]. 心理科学, 23(2): 160-164.
	[Xu Y, Zhang H C.2000. Primary school pupils' gender differences in special abilities[J]. Psychological Science, 23(2): 160-164.]
21	袁孝亭. 2009. 利用地理空间要素发展学生空间思维[J]. 课程·教材·教法, 29(8): 62-67.
	[Yuan X T.2009. Developing students' spatial thinking by using geo-spatial elements[J]. Curriculum, Teaching Material and Method, 29(8): 62-67.]
22	张厚粲, 龚耀先. 2012. 心理测量学[M]. 杭州: 浙江教育出版社. [Zhang H C, Gong Y X. 2012. Psychometrics[M]. Hangzhou, China: Zhejiang Education Press.]
23	赵叶珠, 林钟敏. 1993. 大学生空间思惟的性别差异研究[J]. 心理科学, 16(2): 80-83.
	[Zhao Y Z, Lin Z M.1993. A study of sex differences in college-students' spatial thinking[J]. Psychological Science, 16(2): 80-83.]
24	周洁, 柴彦威. 2013. 中国老年人空间行为研究进展[J]. 地理科学进展, 32(5): 722-732. doi: 10.11820/dlkxjz.2013.05.004
	[Zhou J, Chai Y W.2013. Research progress on spatial behaviors of the elderly in China[J]. Progress in Geography, 32(5): 722-732.] doi: 10.11820/dlkxjz.2013.05.004
25	周加仙, 蔡永华. 2013. 空间思维能力的认知机制及其对STEM教学的启示: 与美国Nora S. Newcombe院士的对话[J]. 全球教育展望, 42(2): 3-11.
	[Zhou J X, Cai Y H.2013. The cognitive mechanism of spatial thinking and its implications for STEM instruction: Interview with Prof. Nora S. Newcombe[J]. Global Education, 42(2): 3-11.]
26	Cheung Y, Pang M, Lin H, et al.2011. Enable spatial thinking using GIS and satellite remote sensing: A teacher-friendly approach[J]. Procedia-Social and Behavioral Sciences, 21: 130-138. doi: 10.1016/j.sbspro.2011.07.014
27	Cohen C A, Hegarty M.2012. Inferring cross sections of 3D objects: A new spatial thinking test[J]. Learning and Individual Differences, 22(6): 868-874. doi: 10.1016/j.lindif.2012.05.007
28	Cohen C A, Hegarty M.2014. Visualizing cross sections: Training spatial thinking using interactive animations and virtual objects[J]. Learning and Individual Differences, 33: 63-71. doi: 10.1016/j.lindif.2014.04.002
29	Golledge R G, Dougherty V, Bell S.1995. Acquiring spatial knowledge: Survey versus route-based knowledge in unfamiliar environments[J]. Annals of the Association of American Geographers, 85(1): 134-158. doi: 10.1111/j.1467-8306.1995.tb01798.x
30	Harvey D.1971. Explanation in geography[M]. London, UK: Edward Arnold Publisher.
31	Hauptman H.2010. Enhancement of spatial thinking with Virtual Spaces 1.0[J]. Computers & Education, 54(1): 123-135. doi: 10.1016/j.compedu.2009.07.013
32	Ishikawa T.2013. Geospatial thinking and spatial ability: An empirical examination of knowledge and reasoning in geographical science[J]. The Professional Geographer, 65(4): 636-646. doi: 10.1080/00330124.2012.724350
33	Kitchin R M.1996. Are there sex differences in geographic knowledge and understanding[J]. The Geographical Journal, 162(3): 273-286. doi: 10.2307/3059650
34	Lee J, Bednarz R.2009. Effect of GIS learning on spatial thinking[J]. Journal of Geography in Higher Education, 33(2): 183-198. doi: 10.1080/03098260802276714 pmid: 14110195
35	Lee J, Bednarz R.2012. Components of spatial thinking: Evidence from a spatial thinking ability test[J]. Journal of Geography, 111(1): 15-26. doi: 10.1080/00221341.2011.583262
36	Lloyd R.1997. Spatial cognition: Geographic environments[M]. Boston, America: Kluwer Academic Publishers.
37	Lynch K.1960. The image of the city Cambridge[M]. Cambridge, MA: MIT Press.
38	Manson S, Shannon J, Eria S, et al.2014. Resource needs and pedagogical value of web mapping for spatial thinking[J]. Journal of Geography, 113(3): 107-117. doi: 10.1080/00221341.2013.790915
39	Tomaszewski B, Vodacek A, Parody R, et al.2015. Spatial thinking ability assessment in Rwandan secondary schools: Baseline results[J]. Journal of Geography, 114(2): 39-48. doi: 10.1080/00221341.2014.918165

空间思维的组成成分	对应题号
(1) 对方向的理解	1、2
(2) 对地图信息的比较	3
(3) 根据空间要素选择最佳位置	4
(4) 根据地形图想象剖面图	5
(5) 寻找空间相关性	6、7
(6) 根据二维信息想象三维图象	8
(7) 图层的覆盖和叠加	9、10、11、12
(8) 理解地理事物的表达	13、14、15、16

假设影响因素	题号
生活环境特征	1、13、14、15、16
地理学习兴趣	2、11
地图使用习惯	3、4、5
地理问题关注习惯	6
方向敏感程度	7、8、9、10

假设影响因素	地理空间思维能力
假设影响因素	相关系数	P值	显著性
一般智力水平	0.480^**	0.000	极其显著
生活环境特征	0.005	0.959	不显著
地理学习兴趣	0.163	0.068	不显著
地图使用习惯	0.198^*	0.026	显著
地理问题关注习惯	0.120	0.182	不显著
方向敏感程度	0.036	0.690	不显著
地理专业知识	0.438^**	0.000	极其显著

假设影响因素	假设因素平均值		均值差距	T值	P值	显著性
假设影响因素	地理空间思维高分组(N=34)		均值差距	T值	P值	地理空间思维低分组(N=34)
一般智力水平	0.676	0.523	0.153	-5.947	0.000	极其显著
生活环境特征	0.612	0.600	0.012	-0.417	0.678	不显著
地理学习兴趣	0.682	0.600	0.082	-1.748	0.085	不显著
地图使用习惯	0.454	0.331	0.123	-3.292	0.002	极其显著
地理问题关注习惯	0.571	0.524	0.047	-0.787	0.434	不显著
方向敏感程度	0.588	0.551	0.036	-0.837	0.405	不显著
地理专业知识	0.770	0.629	0.141	-4.081	0.000	极其显著

假设影响因素	地理空间思维平均值		均值差距	T值	P值	显著性
假设影响因素	假设影响因素高分组(N=34)		均值差距	T值	P值	假设影响因素低分组(N=34)
一般智力水平	0.768	0.539	0.229	-6.428	0.000	极其显著
生活环境特征	0.684	0.717	-0.033	0.871	0.387	不显著
地理学习兴趣	0.702	0.608	0.094	-2.173	0.034	显著
地图使用习惯	0.715	0.623	0.092	-2.231	0.030	显著
地理问题关注习惯	0.671	0.614	0.057	-1.273	0.207	不显著
方向敏感程度	0.695	0.673	0.022	-0.600	0.550	不显著
地理专业知识	0.743	0.526	0.217	-5.965	0.000	极其显著

Influencing factors of middle school students' spatial thinking ability:A case study on senior one students of Baiyin No. 1 Middle School in Gansu Province

RichHTML

PDF (PC)

Like

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 11

References 39

Related Articles 15

Metrics

Comments

Recommended 0

影响因素	常量	系数	R²	F值	P值	显著性
一般智力水平	0.259	0.672	0.230	37.065	0.000	极其显著
地理专业知识	0.299	0.512	0.192	29.404	0.000	极其显著
地图使用习惯	0.578	0.214	0.039	5.050	0.026	显著
地理学习兴趣	0.566	0.148	0.027	3.382	0.068	不显著

影响因素	标准系数	非标准化系数	标准误差	T值	P值	显著性
常量		0.101	0.077	1.311	0.192
一般智力水平	0.368	0.516	0.113	4.558	0.000	极其显著
地理专业知识	0.301	0.353	0.094	3.733	0.000	极其显著

	平均值		均值差距	T值	P值	显著性
	男生(N=54)		均值差距	T值	P值	女生(N=72)
地理空间思维	0.676	0.659	0.017	0.563	0.574	不显著
一般智力水平	0.588	0.617	-0.029	-1.305	0.195	不显著
生活环境特征	0.607	0.593	0.014	0.786	0.433	不显著
地理学习兴趣	0.681	0.671	0.010	0.333	0.740	不显著
地图使用习惯	0.432	0.401	0.031	1.097	0.275	不显著
地理问题关注习惯	0.596	0.561	0.035	0.820	0.414	不显著
方向敏感程度	0.584	0.566	0.182	0.536	0.593	不显著
地理专业知识	0.733	0.704	0.029	1.129	0.261	不显著
