基于熵权-TOPSIS的山区乡镇通达性研究——以重庆市石柱县为例

doi:10.18306/dlkxjz.2016.09.009

Abstract

Abstract:

Transportation is one of the foundations to support economic and social development of a region, and accessibility is an important indicator of the level of development of transportation facilities. In this study, we used spatial and survey data to construct an indicator system that considers internal accessibility, external accessibility, and terrain impedance based on the entropy-weight TOPSIS method for Shizhu County, Chongqing Municipality. This study explores mountain transport accessibility condition and can provide some references for mountain transport planning. The results indicate that: (1) The degree of impact of accessibility indicators on regional comprehensive accessibility ranks as: transport facilities technology (C₄) > frictional impedance (C₅) > equivalent road density (C₂) > internal connectivity (C₁) > degree of connectivity with main roads (C₃). (2) The variation coefficient of closeness degree was 0.5410, indicating that the level of transport accessibility of towns in the study area was very different. (3) Accessibility decreased from the three core areas in Nanbin, Xituo, and Yue Lai. The spatial pattern of accessibility is high in the west and low in the east, with high accessibility areas mainly distributed in places of flat terrain, and low accessibility areas mainly distributed in mountainous areas. (4) The area of high accessibility forms a "double axes", which is closely associated with main roads. (5) The spatial distribution of transport accessibility is clearly correlated with economic development level and the total area of land use right transfer. The results can provide some theoretical and practical guidance for the regional coordinated development and transportation planning.

Key words: transportation accessibility, spatial variability, passing-blocking effect, entropy-weight TOPSIS method, the mountainous area, Shizhu County, Chongqing Municipality

Xueying MA, Jing'an SHAO, Xinliang XU. Rural transportation accessibility in mountainous areas based on the entropy-weight TOPSIS method: A case study of Shizhu County, Chongqing Municipality[J].PROGRESS IN GEOGRAPHY, 2016, 35(9): 1144-1154.

Figures/Tables 10

Fig.1

Tab.1

Accessibility indictors and calculation steps and formulas in study area"

目标	因子	指标	指标含义及计算步骤	指标获取公式
乡镇综合通达度(A)	内部通达性(B₁)	乡镇内部连通度(C₁)	反映乡镇内部各村联系紧密度,任意两村最短通行时间可直观表明联系程度,采用乡镇内部各村到其他村最短时间平均值表示。首先,计算乡镇内部各村到其他村最短时间之和,再求其平均值,得到各村最短时间平均值;其次,求各村最短时间平均值之和再求平均值,得到乡镇内部连通度。最短时间计算参考时速见表2。	$K = (∑ [∑ t ij / (n - 1)]) / n$ 式中：t_ij为乡镇内村i到村j最短时间/h;n为村个数;K为乡镇内部连通度。
	内部通达性(B₁)	等效道路密度(C₂)	直观地反映乡镇内部路网分布,使用等效道路密度表示。利用ArcGIS 10.2计算各乡镇不同等级道路的总长度,根据表2将实际道路长度换算为等效道路长度;计算各乡镇等效道路长度与乡镇行政面积之比,得到等效道路密度。	$D = L / S$ 式中：D为等效道路密度/(km/km²);L为等效道路总长/km;S为乡镇区域面积/km²。
	对外通达性(B₂)	与省干道衔接度(C₃)	乡镇内各村通过乡村路网到达干道的最短时间,反映乡镇对外集散程度,使用衔接度表示。计算乡镇内部各村通过乡村路网到达省、县干道最短时间之和求平均值,得到与乡镇与干道衔接度。	$C = ∑ c min n$ 式中：C为与省干道衔接度;c_min为村到省干道最短时间/h;n为村个数。
	对外通达性(B₂)	交通设施技术等级(C₄)	交通基础设施的优劣决定乡镇对外通行能力强弱。结合样区现有交通技术设施采用0.5间隔赋值法(表3)对乡镇不同交通设施赋值。高速公路、铁路港口为封闭性路段,按节点对待;最后对各乡镇各交通设施分值累加,得到乡镇交通设施综合值。	$T = ∑ S iu$ (i=1,2,…,n),(u=1,2,…,m) 式中：T为交通设施综合值;S_iu为i乡镇u类节点或线路对应赋值。
	摩擦阻抗(B₃)	摩擦阻抗(C₅)	不同地形对道路的影响程度不同,摩擦系数反映地形对路段的阻碍程度。基于ArcGIS 10.2计算样区及各乡镇高程、坡度平均值,利用地形位公式得到摩擦系数值。	$Te = log [(E / E ? + 1) (S / S ? + 1)]$ 式中：Te为乡镇摩擦系数;E为高程/m;S为坡度/°; $E ?$ 为平均高程/m; $S ?$ 为平均坡度/°。

Tab.1

Tab.2

Fig.2

Tab.3

Fig.3

Tab.4

Tab.5

Tab.6

Fig.4

References 30

1	曹小曙, 薛德升, 阎小培. 2005. 中国干线公路网络联结的城市通达性[J]. 地理学报, 60(6): 903-910.
	[Cao X S, Xue D S, Yan X P.2005. A study on the urban accessibility of national trunk highway system in China[J]. Acta Geographica Sinica, 60(6): 903-910.]
2	曹小曙, 阎小培. 2003. 经济发达地区交通网络演化对通达性空间格局的影响: 以广东省东莞市为例[J]. 地理研究, 22(3): 305-312.
	[Cao X S, Yan X P.2003. The impact of the evolution of land network on spatial structure of accessibility in the developed areas: The case of Dongguan City in Guangdong Province[J]. Geographical Research, 22(3): 305-312.]
3	陈静云. 2009. 区域综合交通网络通达性研究[D]. 北京: 北京交通大学.
	[Chen J Y. 2009. Study on regional comprehensive traffic network accessibility[D]. Beijing, China: Beijing Jiaotong University.]
4	陈少沛. 2013. 城市轨道交通网络通达性度量与空间特征分析: 以广州市为例[J]. 地理与地理信息科学, 29(3): 109-113. doi: 10.7702/dlydlxxkx20130324
	[Chen S P.2003. Urban rail transit network accessibility measure and spatial characteristics analysis: A case study of Guangzhou[J]. Geography and Geo-Information Science, 29(3): 109-113.] doi: 10.7702/dlydlxxkx20130324
5	程钰, 刘雷, 任建兰, 等. 2013. 县域综合交通可达性与经济发展水平测度及空间格局研究: 对山东省91个县域的定量分析[J]. 地理科学, 33(9): 1058-1065.
	[Cheng Y, Liu L, Ren J L, et al.2013. The measuring and spatial structure between comprehensive transportation accessibility and the level of economic development at county level: Case of 91 counties in Shandong Province[J]. Scientia Geographica Sinica, 33(9): 1058-1065.]
6	邓丽, 邵景安, 郭跃, 等. 2015. 基于改进的两步移动搜索法的山区医疗服务空间可达性: 以重庆市石柱县为例[J]. 地理科学进展, 34(6): 716-725. doi: 10.18306/dlkxjz.2015.06.007
	[Deng L, Shao J A, Guo Y, et al.2015. Spatial accessibility of medical services in mountainous regions based on modified two-step floating catchment area method: A case study of Shizhu County, Chongqing[J]. Progress in Geography, 34(6): 716-725.] doi: 10.18306/dlkxjz.2015.06.007
7	段德忠, 刘承良. 2015. 基于城市腹地的乡镇通达性的时空格局及其演化: 以湖北荆州市112个乡镇为例[J]. 长江流域资源与环境, 24(4): 548-556. doi: 10.11870/cjlyzyyhj201504003
	[Duan D Z, Liu C L.2015. Spatial-temporal pattern and evolution of township accessibility based on city hinterland: A case study of 112 towns of Jingzhou City, Hubei Province[J]. Resources and Environment in the Yangtze Basin, 24(4): 548-556.] doi: 10.11870/cjlyzyyhj201504003
8	封志明, 刘东, 杨艳昭. 2009. 中国交通通达度评价: 从分县到分省[J]. 地理研究, 28(2): 419-429.
	[Feng Z M, Liu D, Yang Y Z.2009. Evaluation of transportation ability of China: From county to province level[J]. Geographical Research, 28(2): 419-429.]
9	郭丽娟, 王如渊. 2009. 四川盆地城市群主要城市通达性及空间联系强度研究[J]. 人文地理, 24(3): 42-48.
	[Guo L J, Wang R Y.2009. Study on accessibility and spatial connecting among the cities in Sichuan Basin Urban Agglomeration[J]. Human Geography, 24(3): 42-48.]
10	黄晓燕, 曹小曙, 李涛. 2011. 海南省区域交通优势度与经济发展关系[J]. 地理研究, 30(6): 985-999.
	[Huang X Y, Cao X S, Li T.2011. The relationship between regional transport superiority and regional economic performance in Hainan[J]. Geographical Research, 30(6): 985-999.]
11	蒋海兵, 张文忠, 祁毅, 等. 2013. 区域交通基础设施可达性研究进展[J]. 地理科学进展, 32(5): 807-817. doi: 10.11820/dlkxjz.2013.05.012
	[Jiang H B, Zhang W Z, Qi Y, et al.2013. Research progress on accessibility to regional transportation infrastructure[J]. Progress in Geography, 32(5): 807-817.] doi: 10.11820/dlkxjz.2013.05.012
12	金凤君, 王成金, 李秀伟. 2008. 中国区域交通优势的甄别方法及应用分析[J]. 地理学报, 63(8): 787-798.
	[Jin F J, Wang C J, Li X W.2008. Discrimination method and its application analysis of regional transport superiority[J]. Acta Geographica Sinica, 63(8): 787-798.]
13	李灿, 张凤荣, 朱泰峰, 等. 2013. 基于熵权TOPSIS模型的土地利用绩效评价及关联分析[J]. 农业工程学报, 29(5):217-227. doi: 10.3969/j.issn.1002-6819.2013.05.029
	[Li C, Zhang F R, Zhu T F, et al.2013. Evaluation and correlation analysis of land use performance based on entropy-weight TOPSIS method[J]. Transactions of the Chinese Society of Agricultural Engineering, 29(5): 217-227.] doi: 10.3969/j.issn.1002-6819.2013.05.029
14	李九全. 2008. 陕西省城市竞争力及其通达性比较研究[J]. 地理科学, 28(4): 471-477.
	[Li J Q.2008. A study of comparisons of urban competitiveness and accessibility in Shanxi Province[J]. Scientia Geographica Sinica, 28(4): 471-477.]
15	李沛权, 曹小曙. 2011. 广佛都市圈公路网络通达性及其空间格局[J]. 经济地理, 31(3): 371-378.
	[Li P Q, Cao X S.2011. The road network accessibility and spatial pattern of Guangzhou-Foshan Metropolitan Area[J]. Economic Geography, 31(3): 371-378.]
16	刘承良, 余瑞林, 段德忠. 2014. 1989-2010年武汉城市圈县域通达性的空间演化及对称性[J]. 人文地理, 29(3): 69-75.
	[Liu C L, Yu R L, Duan D Z.2014. The spatial evolution and symmetry of accessibility of intra-county in Wuhan Metropolitan Area based on road network from 1989 to 2010[J]. Human Geography, 29(3): 69-75.]
17	刘承良, 余瑞林, 熊剑平, 等. 2009. 武汉都市圈路网空间通达性分析[J]. 地理学报, 64(12): 1488-1498.
	[Liu C L, Yu R L, Xiong J P, et al.2009. Spatial accessibility of road network in Wuhan Metropolitan Area[J]. Acta Geographica Sinica, 64(12): 1488-1498.]
18	刘传明, 曾菊新. 2011. 县域综合交通可达性测度及其与经济发展水平的关系: 对湖北省79个县域的定量分析[J]. 地理研究, 30(12): 2209-2221.
	[Liu C M, Zeng J X.2011. The calculating method about the comprehensive transport accessibility and its correlation with economic development at county level: The statistical analysis of 79 counties in Hubei Province[J]. Geographical Research, 30(12): 2209-2221.]
19	刘望保, 周永杰. 2012. 基于干线公路和铁路网的中国省会城市的交通通达性研究[J]. 华南师范大学学报: 自然科学版, 44(1): 124-128.
	[Liu W B, Zhou Y J.2012. A study of Chinese provincial cities' accessibility based on national trunk highway system and railway network[J]. Journal of South China Normal University: Natural Science Edition, 44(1): 124-128.]
20	梅志雄, 徐颂军, 欧阳军. 2013. 珠三角公路通达性演化及其对城市潜力的影响[J]. 地理科学, 33(5): 513-520.
	[Mei Z X, Xu S J, Ouyang J.2013. Road network accessibility and its influence on city potential in Zhujiang River Delta[J]. Scientia Geographica Sinica, 33(5): 513-520.]
21	赵丽, 朱永明, 付梅臣, 等. 2012. 主成分分析法和熵值法在农村居民点集约利用评价中的比较[J]. 农业工程学报, 28(7): 235-242.
	[Zhao L, Zhu Y M, Fu M C, et al.2012. Comparative study on intensive use of rural residential land based on principal component analysis and entropy method[J]. Transactions of the Chinese Society of Agricultural Engineering, 28(7): 235-242.]
22	朱兵, 张小雷, 桂东伟, 等. 2010. 新疆城镇发展与交通可达性相互影响[J]. 地理科学进展, 29(10): 1239-1248. doi: 10.11820/dlkxjz.2010.10.012
	[Zhu B, Zhang X L, Gui D W, et al.2010. The relationship between urban development and transport accessibility in Xinjiang[J]. Progress in Geography, 29(10): 1239-1248.] doi: 10.11820/dlkxjz.2010.10.012
23	Hansen W G.1959. How accessibility shapes land use[J]. Journal of the American Institute of Planners, 25(2): 73-76. doi: 10.1080/01944365908978307
24	Holl A.2004. Manufacturing location and impacts of road transport infrastructure: Empirical evidence from Spain[J]. Regional Science and Urban Economics, 34(3): 341-363. doi: 10.1016/S0166-0462(03)00059-0
25	Johnston R J.1994. Dictionary of human geography[M]. 3rd ed. Oxford, UK: Basil Blackwell.
26	Linneker B, Spence N.1996. Road transport infrastructure and regional economic development: The regional development effects of the M25 London orbital motorway[J]. Journal of Transport Geography, 4(2): 77-92. doi: 10.1016/0966-6923(96)00001-4
27	Moseley M J.1979. Accessibility: The rural challenge[M]. London, UK: Methuenand Company Limited.
28	Owen S H, Daskin M S.1998. Strategic facility location: A review[J]. European Journal of Operational Research, 111(3): 423-447. doi: 10.1016/S0377-2217(98)00186-6
29	Sasaki K, Ohashi T, Ando A.1997. High-speed rail transit impact on regional systems: Does the Shinkansen contribute to dispersion[J]. The Annals of Regional Science, 31(1): 77-98. doi: 10.1007/s001680050040
30	Wang Z B, Xu J G, Fang C L, et al.2011. The study on county accessibility in China: Characteristics and effects on population agglomeration[J]. Journal of Geographical Sciences, 21(1): 18-34. doi: 10.1007/s11442-011-0826-9

交通线等级	时速/(km/h)	实际长度/km	等效道路长度/km
省道	40	1	1.000
县道	30	1	0.750
乡道	25	1	0.625
农村硬化道路	20	1	0.500
农村石垫路	15	1	0.375

类型	子类型	标准	赋值	类型	子类型	标准	赋值
公路	高速公路省道县道乡道	高速口最高级别为省道最高级别为县道最高级别为乡道	2.0 1.5 1.0 0.5	客运站	—	一级	2.5 2.0 1.5
						二级
						三级
						四级	1.0
						五级	0.5
						简易	0.1
铁路	—	距离车站1 h以内	2.0	港口	—	枢纽	1.5
		距离车站2 h以内	1.5			一般	1.0
		其他	1.0			其他	0.5

	内部通达性		对外通达性		摩擦阻抗
	乡镇内部连通度C₁	等效道路密度C₂	与省干道衔接度C₃	交通设施技术C₄	摩擦阻抗C₅
o_i⁺	0.1288	0.1628	0.0799	0.3731	0.2553
o_i^-	0.0000	0.0000	0.0000	0.0000	0.0000
E_j	0.9712	0.9636	0.9821	0.9166	0.9430
w_i	0.1288	0.1628	0.0799	0.3731	0.2553

优劣测度	最大值	最小值	极差	平均值	标准差	变异系数
距离最优值测度(r_j⁺)	0.1555	0.0403	0.1152	0.1007	0.0334	0.3316
距离最劣值测度(r_j^-)	0.1431	0.0083	0.1349	0.0616	0.0343	0.5569
贴近度(C_j)	0.7801	0.0509	0.7292	0.3783	0.2046	0.5410

乡镇	贴近度	排序	乡镇	贴近度	排序	乡镇	贴近度	排序	乡镇	贴近度	排序
南宾镇	0.7801	1	黎场乡	0.5383	9	石家乡	0.3563	17	马武镇	0.2366	25
悦崃镇	0.7053	2	鱼池镇	0.5241	10	临溪镇	0.3432	18	龙潭乡	0.2193	26
西沱镇	0.6788	3	黄水镇	0.4992	11	三星乡	0.3199	19	三益乡	0.1746	27
下路镇	0.6347	4	龙沙镇	0.4341	12	河嘴乡	0.2988	20	中益乡	0.1300	28
沿溪镇	0.6084	5	冷水镇	0.4249	13	王家乡	0.2676	21	新乐乡	0.0786	29
三河镇	0.6010	6	王场镇	0.4237	14	桥头镇	0.2659	22	金铃乡	0.0666	30
大歇镇	0.5940	7	六塘乡	0.3942	15	黄鹤乡	0.2407	23	洗新乡	0.0518	31
沙子镇	0.5563	8	万朝镇	0.3669	16	枫木乡	0.2400	24	金竹乡	0.0509	32
