社会—生态脆弱性相互关系的计量推断方法

doi:10.18306/dlkxjz.2016.02.008

Abstract

Abstract:

This study systematically analyzed the results of current integrated method for social-ecological vulnerability research and found that the comprehensive index method can represent the overall level of social and ecological vulnerabilities using indicators of the two particular aspects of vulnerability in certain time period. But such method cannot reflect the degree of interaction and direction of influence of indicators. Correlation analysis can indicate a quantitative relationship between indicators, but is unable to identify causality. Least square method can generate variable coefficient of explanatory indicators when the indicators have changed, but due to the subjectivity in selecting indicators as explanatory variables or explained variables, the direction of influence between variables still cannot be determined. Given these problems, this article explores the feasibility of using instrumental variable (IV) method to reveal interactions between social and ecological vulnerabilities. By application in a case study at the country level in China , the result shows that the IV method can reveal the direction of influence between indicators of social vulnerability and ecological vulnerability, which overcomes the problem identified above. From 1980s to 2000s, the impact of ecological vulnerability on social vulnerability (NPPI→SoVI) decreased, the corresponding significant impact provinces decreased from 5 to 2; the impact of social vulnerability on ecological vulnerability (SoVI→NPPI) increased, and the corresponding significant impact provinces increased from 1 to 7. A quantitative method that indicates the direction of influence is expected to explain how social vulnerability and ecological vulnerability interact and affect one another.

Key words: social vulnerability, ecological vulnerability, interaction, instrumental variable estimation

Ning LI, Zhengtao ZHANG, Xiaolin HAO. Quantitative inference method for the relationship between social and ecological vulnerabilities[J].PROGRESS IN GEOGRAPHY, 2016, 35(2): 214-222.

Figures/Tables 7

Tab.1

Fig.1

Fig.2

Tab.2

Tab.3

Tab.4

Fig.3

References 20

[1]	陈云松. 2012. 逻辑、想象和诠释: 工具变量在社会科学因果推断中的应用[J]. 社会学研究, (6): 192-216.
	[Chen Y S.2012. Logic, imagination and interpretation: The application of instrumental variables for causal inference in the social sciences[J]. Sociological Studies, (6): 192-216.]
[2]	封珊, 徐长乐. 2014. 全球气候变化及其对人类社会经济影响研究综述[J]. 中国人口·资源与环境, 24(5): 6-10.
	[Feng S, Xu C L.2014. Summary of development of global climate change and its effects on social economy[J]. China Population, Resources and Environment, 24(5): 6-10.]
[3]	高吉喜, 潘英姿, 柳海鹰, 等. 2004. 区域洪水灾害易损性评价[J]. 环境科学研究, 17(6): 30-34. doi: 10.3321/j.issn:1001-6929.2004.06.008
	[Gao J X, Pan Y Z, Liu H Y, et al.2004. Assessment on regional vulnerability to flood[J]. Research of Environmental Sciences, 17(6): 30-34.] doi: 10.3321/j.issn:1001-6929.2004.06.008
[4]	李鹤, 张平宇, 程叶青. 2008. 脆弱性的概念及其评价方法[J]. 地理科学进展, 27(2): 18-25. doi: 10.11820/dlkxjz.2008.02.003
	[Li H, Zhang P Y, Cheng Y Q.2008. Concepts and assessment methods of vulnerability[J]. Progress in Geography, 27(2): 18-25.] doi: 10.11820/dlkxjz.2008.02.003
[5]	马世骏, 王如松. 1984. 社会-经济-自然复合生态系统[J]. 生态学报, 4(1): 1-9.
	[Ma S J, Wang R S.1984. The social-economic-natural complex ecosystem[J]. Acta Ecologica Sinica, 4(1): 1-9.]
[6]	欧英娟, 彭晓春, 周健, 等. 2012. 气候变化对生态系统脆弱性的影响及其应对措施[J]. 环境科学与管理, 37(12): 136-141. doi: 10.3969/j.issn.1673-1212.2012.12.035
	[Ou Y J, Peng X C, Zhou J, et al.2012. Influences of climate change on ecosystem vulnerability and countermeasures[J]. Environmental Science and Management, 37(12): 136-141.] doi: 10.3969/j.issn.1673-1212.2012.12.035
[7]	王俊, 杨新军, 刘文兆. 2010. 半干旱区社会-生态系统干旱恢复力的定量化研究[J]. 地理科学进展, 29(11): 1385-1390. doi: 10.11820/dlkxjz.2010.11.028
	[Wang J, Yang X J, Liu W Z.2010. A quantitative research on the resilience of social-ecological system to drought in the semiarid area[J]. Progress in Geography, 29(11): 1385-1390.] doi: 10.11820/dlkxjz.2010.11.028
[8]	王琦妍. 2011. 社会-生态系统概念性框架研究综述[J]. 中国人口·资源与环境, 21(S1): 440-443.
	[Wang Q Y.2011. Review of the research on social-ecologicalsystemsconceptualframework[J]. China Population, Resources and Environment, 21(S1): 440-443.]
[9]	王如松, 欧阳志云. 2012. 社会—经济—自然复合生态系统与可持续发展[J]. 中国科学院院刊, 27(3): 337-345. doi: 10.3969/j.issn.1000-3045.2012.03.012
	[Wang R S, Ouyang Z Y.2012. Social-economic-natural complex ecosystem and sustainability[J]. Bulletin of Chinese Academy of Sciences, 27(3): 337-345.] doi: 10.3969/j.issn.1000-3045.2012.03.012
[10]	余中元, 李波, 张新时. 2014. 社会生态系统及脆弱性驱动机制分析[J]. 生态学报, 34(7): 1870-1879. doi: 10.5846/stxb201210231472
	[Yu Z Y, Li B, Zhang X S.2014. Social ecological system and vulnerability driving mechanism analysis[J]. Acta Ecologica Sinica, 34(7): 1870-1879.] doi: 10.5846/stxb201210231472
[11]	周扬, 李宁, 吴文祥. 2014. 自然灾害社会脆弱性研究进展[J]. 灾害学, 29(2): 128-135. doi: 10.3969/j.issn.1000-811X.2014.02.025
	[Zhou Y, Li N, Wu W X. Research progress on social vulnerability to natural disasters[J]. Journal of Catastrophology, 29(2): 128-135.] doi: 10.3969/j.issn.1000-811X.2014.02.025
[12]	Cumming G S, Barnes G, Perz S, et al.2005. An exploratory framework for the empirical measurement of resilience[J]. Ecosystems, 8(8): 975-987. doi: 10.1007/s10021-005-0129-z
[13]	Cutter S L, Boruff B J, Shirley W L.2003. Social vulnerability to environmental hazards[J]. Social Science Quarterly, 84(2): 242-261.
[14]	De Chazal J, Quétier F, Lavorel S, et al.2008. Including multiple differing stakeholder values into vulnerability assessments of socio-ecological systems[J]. Global Environmental Change, 18(3): 508-520. doi: 10.1016/j.gloenvcha.2008.04.005
[15]	Dunbar R I M.1988. Socio-ecological systems[M]//Dunbar R I M. Primate social system. NewYork: Springer:262-291.
[16]	Liu W, Mochizuki J, Keating A, et al.2014. Diagnosing Disaster resilience of communities as multi-scale complex socio-ecological systems[C]//EGU General Assembly Conference Abstracts. Vienna, Austria: EGU: 16.
[17]	Liu Y P, Yu D Y, Su Y, et al.2014. Quantifying the effect of trend, fluctuation, and extreme event of climate change on ecosystem productivity[J]. Environmental Monitoring and Assessment, 186(12): 8473-8486. doi: 10.1007/s10661-014-4031-z pmid: 25208518
[18]	Ostrom E.2009. A general framework for analyzing sustainability of social-ecological systems[J]. Science, 325: 419-422.
[19]	Qiu P H, Xu S J, Xie G Z, et al.2007. Analysis of the ecological vulnerability of the western Hainan Island based on its landscape pattern and ecosystem sensitivity[J]. Acta Ecologica Sinica, 27(4): 1257-1264. doi: 10.1016/S1872-2032(07)60026-2
[20]	Zhou Y, Li N, Wu W X, et al.2014. Local spatial and temporal factors influencing population and societal vulnerability to natural disasters[J]. Risk Analysis, 34(4): 614-639. doi: 10.1111/risa.12193 pmid: 24673569

	主成分因子排序及命名(方差解释率大于66.95%)
社会脆弱性指数SoVI	人口年龄、教育和总人口;农村状况、城市化;经济状况;性别;粮食保障等
生态脆弱性指数NPPI	年平均降水量,年平均气温,光合有效辐射;NDVI指数;土地覆盖等

内生变量	省份	残差系数	P值
SoVI	甘肃	-1.487	0.093
NPPI	甘肃	-0.49	0.051
SoVI	青海	0.402	0.051
NPPI	河南	-3.118	0.022
SoVI	吉林	0.779	0.000
SoVI	辽宁	0.865	0.052
NPPI	贵州	1.723	0.090
NPPI	四川	1.978	0.062
NPPI	云南	-1.363	0.001
SoVI	山西	0.338	0.007
NPPI	浙江	-2.502	0.042
SoVI	山东	-1.462	0.005
NPPI	江西	-4.439	0.041
NPPI	黑龙江	3.099	0.026
SoVI	黑龙江	0.0966	0.073

内生变量	SoVI(IV: Nei, City)
Sargan 显著水平	1980s	1990s	2000s
Sargan 显著水平	2.80298 (0.0941)	1.37466 (0.2410)	2.12708 (0.1447)
内生变量	NPPI(IV: P、T)
Sargan 显著水平	1980s	1990s	2000s
Sargan 显著水平	9.33124 (0.0023)	1.51412 (0.2185)	0.957537 (0.3278)

地区	SoVI→NPPI(β₁)			NPPI→SoVI(β₂)
地区	1980s	1990s	2000s	1980s	1990s	2000s
河南	-0.00914	0.058	-0.141^*	8.089^***	2.143	2.023
吉林	0.698	-0.459^*	-0.42^***	-1.323	0.562	-1.278
青海	-0.261	-0.988	0.163^*	1.513^***	1.304^***	1.217^***
甘肃	2.122	1.013	2.429	0.81	0.399^*	0.733
辽宁	-0.463	-0.0908	0.528	-1.005	5.356	0.376^*
云南	-0.0235	0.0437	-0.101	1.054^**	0.679	0.992
贵州	0.143^**	0.16	0.0745	-2.169	-0.2	-4.274
山西	-0.122	-0.0227	-0.451^***	1.347	0.891	-0.985
四川	0.103	0.154^*	-0.0256	0.332	-1.667	0.374
山东	-0.00341	0.104	0.457^***	0.0859	1.322	0.113
