库布齐沙漠南缘抛物线形沙丘表面风沙流结构变异

doi:10.18306/dlkxjz.2016.01.011

Abstract

Abstract:

The airflow and sediment transport rate on the parabolic dune and the aeolian sediment flux profiles were examined in details in the southern Hobq desert in late April 2010 when the wind was strong and sediment movement was intense. The analyses show that 71%~91% sediments moved in the space between 0 and 0.10 m above surface. This confirms the results of previous research that blown sand activity occurs near bed. Due to the difference of wind velocity, underlying surface conditions, and slope profiles, sediment transport rate and relative sediment transport rate vary, so do the aeolian sediment flux profiles. At the measurement spots where wind velocity and sediment transport rate are small, such as the toe and the lower part of the windward slope, the aeolian sediment flux profiles vary considerably. Underlying surface condition is a vital factor influencing aeolian sediment flux profile. At the windward toe that suffers deflation, the gravelly surface is hard. This contributes to sediments’ saltaltion, so sediment transport rate is relatively high at the upper layer of the aeolian sediment flux profile. Along the windward slope, sediments move upward and have a lower saltation height. Therefore sediment transport is relatively high near surface. In contrast, sediments move downward at brink-line on the leeward slope with higher height and the trajectories deform, so the saltation height is higher. Affected by the difference of windward slope profile shape, the aeolian sediment flux profiles at the crest vary markedly among the measurement spots. In spite of the variation of the aeolian sediment flux profiles, they can still be well described by the exponential decay law at the windward slope and crest. In the equation Q=aexp(-z/b), the coefficient a has an apparent power function correlation with sediment transport rate and increases simultaneously with wind velocity, but there is no clear correlation between them. The coefficient b has no significant correlation with these two factors. At the brink-line, the profiles were segmented at the 0.10 m height: the profiles of near surface follow exponential decay while the upper layers obey power function.

Key words: parabolic dune, aeolian sediment flux profile, function fitting, Hobq Desert

Binbin TAO, Dan LIU, Chao GUAN, Eerdun HASI. Variation of aeolian sediment flux profiles on a parabolic dune at the southern fringe of the Hobq Desert[J].PROGRESS IN GEOGRAPHY, 2016, 35(1): 98-107.

Figures/Tables 10

Fig.1

Fig.2

Tab.1

Fig.3

Tab.2

Tab.3

Fig.4

Tab.4

Fig.5

References 42

[1]	包岩峰, 丁国栋, 吴斌, 等. 2013. 毛乌素沙地风沙流结构的研究[J]. 干旱区资源与环境, 27(2): 118-123.
	[Bao Y F, Ding G D, Wu B, et al.2013. Study on the wind-sand flow structure in Mu Us sand land[J]. Journal of Arid Land Resources and Environment, 27(2): 118-123.]
[2]	陈方, 贺辉扬. 1997. 海岸沙丘沙运动特征若干问题的研究: 以闽江口南岸为例[J]. 中国沙漠, 17(4): 355-361.
	[Chen F, He H Y.1997. Research of several problems on movement characteristics of coastal dune sand: An example from the south coast of Min Jiang Estuary[J]. Journal of Desert Research, 17(4): 355-361. ]
[3]	陈智, 麻硕士, 赵永来, 等. 2010. 保护性耕作农田地表风沙流特性[J]. 农业工程学报, 26(1): 118-122. doi: 10.3969/j.issn.1002-6819.2010.01.020
	[Chen Z, Ma S S, Zhao Y L, et al.2010. Characteristics of drifting sand flux over conservation tillage field[J]. Transactions of the CSAE, 26(1): 118-122.] doi: 10.3969/j.issn.1002-6819.2010.01.020
[4]	董玉祥, Hesp P A, Namikas S L, 等. 2008. 海岸横向沙脊表面风沙流结构的野外观测研究[J]. 地理科学, 28(4): 507-512. doi: 10.3969/j.issn.1000-0690.2008.04.009
	[Dong Y X, Hesp P A, Namikas S L, et al.2008. Field measurements of structure of wind-sand flow on coastal transverse ridge in China[J]. Scientia Geographica Sinica, 28(4): 507-512. ] doi: 10.3969/j.issn.1000-0690.2008.04.009
[5]	董玉祥, 马骏. 2009. 风速对海岸沙丘表面风沙流结构影响的实证研究[J]. 干旱区资源与环境, 23(9): 179-183.
	[Dong Y X, Ma J.2009. Field measurements of influence of total sand transport rate on the structure of wind-sand flow on the coastal transverse ridge[J]. Journal of Arid Land Resources and Environment, 23(9): 179-183.]
[6]	杜鹤强, 韩致文, 王涛, 等. 2012. 新月形沙丘表面风速廓线与风沙流结构变异研究[J]. 中国沙漠, 32(1): 9-16.
	[Du H Q, Han Z W, Wang T, et al.2012. Variation of wind profile and sand flow structure above Barchan Dune[J]. Journal of Desert Research, 32(1): 9-16. ]
[7]	哈斯. 1997. 河北坝上高原土壤风蚀物垂直分布的初步研究[J]. 中国沙漠, 17(1): 9-14.
	[Hasi E.1997. Preliminary study on the vertical distributions of wind dust over Bashang plateau, Hebei Province[J]. Journal of Desert Research, 17(1): 9-14.]
[8]	哈斯. 2004. 腾格里沙漠东南缘沙丘表面风沙流结构变异的初步研究[J]. 科学通报, 49(11): 1099-1104. doi: 10.3321/j.issn:0023-074X.2004.11.015
	[Hasi E.2004. Structural variations of sand-bearing airflow over dune at southeastern fringe of Tengger Desert[J]. Chinese Science Bulletin, 49(11):1099-1104.] doi: 10.3321/j.issn:0023-074X.2004.11.015
[9]	韩致文, 缑倩倩, 杜鹤强, 等. 2012. 新月形沙丘表面100cm高度内风沙流输沙量垂直分布函数分段拟合[J]. 地理科学, 32(7): 892-897.
	[Han Z W, Gou Q Q, Du H Q, et al.2012. The piecewise fitting of sand flux vertical distribution of wind-sand flow within 100-cm height above the Barchan Dune Surface[J]. Scientia Geographica Sinica, 32(7): 892-897. ]
[10]	何京丽, 郭建英, 邢恩德, 等. 2012. 黄河乌兰布和沙漠段沿岸风沙流结构与沙丘移动规律[J]. 农业工程学报, 28(17): 71-77. doi: 10.3969/j.issn.1002-6819.2012.17.011
	[He J L, Guo J Y, Xing E D, et al.2012. Structure of wind-sand flow and law of dune movement along bank of Yellow River in Ulan Buh desert[J]. Transactions of the CSAE, 28(17): 71-77. ] doi: 10.3969/j.issn.1002-6819.2012.17.011
[11]	刘芳, 郝玉光, 辛智鸣, 等. 2014. 乌兰布和沙漠东北缘地表风沙流结构特征[J]. 中国沙漠, 34(5): 1200-1207. doi: 10.7522/j.issn.1000-694X.2014.00096
	[Liu F, Hao Y G, Xin Z M, et al.2014. The surface Aeolian-sand flow structure in the Northeastern margin of the Ulanbuh Desert[J]. Journal of Desert Research, 34(5): 1200-1207. ] doi: 10.7522/j.issn.1000-694X.2014.00096
[12]	刘树林, 王涛, 郭坚. 2006. 浑善达克沙地春季风沙活动特征观测研究[J]. 中国沙漠, 26(3): 356-361. doi: 10.3321/j.issn:1000-694X.2006.03.007
	[Liu S L, Wang T, Guo J.2006. Characteristics of blown sand activities in Hunshandake sandy land in spring[J]. Journal of Desert Research, 26(3): 356-361.] doi: 10.3321/j.issn:1000-694X.2006.03.007
[13]	牛艳频. 2011. 河北坝上农田风沙流结构特征研究: 以康保县为例[D]. 石家庄: 河北师范大学.
	[Niu Y P. 2011. A study on the characteristics of sand flow structure in farmland of Bashang, Hebei Province: taking Kang Bao County for example[D]. Shijiazhuang, China: Hebei Normal University. ]
[14]	屈建军, 黄宁, 拓万全, 等. 2005. 戈壁风沙流结构特性及其意义[J]. 地球科学进展, 20(1): 19-23. doi: 10.3321/j.issn:1001-8166.2005.01.005
	[Qu J J, Huang N, Ta W Q, et al.2005. Structural characteristics of Gobi sand-drift and its significance[J]. Advances in Earth Science, 20(1): 19-23. ] doi: 10.3321/j.issn:1001-8166.2005.01.005
[15]	王洪涛, 董治宝, 张晓航. 2004. 风沙流中沙粒浓度分布的实验研究[J]. 地球科学进展, 19(5): 732-735. doi: 10.3321/j.issn:1001-8166.2004.05.007
	[Wang H T, Dong Z B, Zhang X H.2004. A study of the particle concentration in the sand flux-a wind tunnel investigation[J]. Advances in Earth Science, 19(5): 732-735.] doi: 10.3321/j.issn:1001-8166.2004.05.007
[16]	王仁德, 邹学勇, 吴晓旭, 等. 2009. 半湿润区农田风蚀物垂直分布特征[J]. 水土保持学报, 23(5): 39-43.
	[Wang R D, Zou X Y, Wu X X, et al.2009. The vertical distribution characteristics of farmland wind-erosion dust over semi-humid region[J]. Journal of Soil and Water Conservation, 23(5): 39-43. ]
[17]	王训明, 董治宝, 陈广庭. 2001. 塔克拉玛干沙漠中部部分地区风沙环境特征[J]. 中国沙漠, 21(1): 56-61. doi: 10.3321/j.issn:1000-694X.2001.01.011
	[Wang X M, Dong Z B, Chen G T.2001. Characteristics of blown sand environment in Middle Taklimakan Desert[J]. Journal of Desert Research, 21(1): 56-61.] doi: 10.3321/j.issn:1000-694X.2001.01.011
[18]	吴霞, 哈斯, 杜会石, 等. 2012. 库布齐沙漠南缘抛物线形沙丘表面粒度特征[J]. 沉积学报, 30(5): 937-944.
	[Wu X, Hasi E, Du H S, et al.2012, Grain size distribution of parabolic dunes on the Southern fringe of Hobq Desert[J]. Acta Sedimentologica Sinica, 30(5): 937-944. ]
[19]	吴晓旭, 邹学勇, 王仁德, 等. 2011. 毛乌素沙地不同下垫面的风沙运动特征[J]. 中国沙漠, 31(4): 828-835.
	[Wu X X, Zou X Y, Wang R D, et al.2011. Aeolian movement characteristics over different underlying surfaces in Mu Us Sandy Land[J]. Journal of Desert Research, 31(4): 828-835. ]
[20]	吴正, 等. 2010. 风沙地貌与治沙工程学[M]. 北京: 科学出版社.
	[Wu Z, et al. 2010. Geomorphology of wind-drift sands and their controlled engineering[M]. Beijing, China: Science Press. ]
[21]	杨兴华, 何清, 阿吉古丽·沙依提, 等. 2012. 塔克拉玛干沙漠北缘荒漠过渡带风沙流结构特征分析[J]. 干旱区研究, 29(4): 699-704.
	[Yang X H, He Q, Ajiguli S, et al.2012. Study on structure of wind-blown sand flow over the desert ecotone in the Northern marginal zone of the Taklimakan desert[J]. Arid Zone Research, 29(4): 699-704. ]
[22]	尹永顺. 1989. 砾漠大风地区风沙流研究[J]. 中国沙漠, 9(4): 30-39.
	[Yin Y S.1989. Study on sand drift in strong wind region in Gravel Desert[J]. Journal of Desert Research, 9(4): 30-39. ]
[23]	张广, 武俊瑛, 惠彦君, 等. 2006. 浑善达克沙地公路综合防护技术及其效益分析[J]. 干旱区资源与环境, 20(5): 189-196. doi: 10.3969/j.issn.1003-7578.2006.05.037
	[Zhang G, Wu J Y, Hui Y J, et al.2006. Benefit analysis and integrated preservation technology system of the shelter belt of highway in Otindag Sandy Land[J]. Journal of Arid Land Resources and Environment, 20(5): 189-196. ] doi: 10.3969/j.issn.1003-7578.2006.05.037
[24]	张华, 李锋瑞, 张铜会, 等. 2002. 科尔沁沙地不同下垫面风沙流结构与变异特征[J]. 水土保持学报, 16(2): 20-23, 28. doi: 10.3321/j.issn:1009-2242.2002.02.006
	[Zhang H, Li F R, Zhang T H, et al.2002. Wind-Sand flow structure and its variation under different surface conditions in Korqin sandy land[J]. Journal of Soil and Water Conservation, 16(2): 20-23, 28. ] doi: 10.3321/j.issn:1009-2242.2002.02.006
[25]	张克存, 屈建军, 俎瑞平, 等. 2005. 戈壁风沙流结构和风速廓线特征研究[J]. 水土保持研究, 12(1): 54-55, 58. doi: 10.3969/j.issn.1005-3409.2005.01.016
	[Zhang K C, Qu J J, Zu R P, et al.2005. Research on the characteristics of structure of drifting sand flux and wind velocity profile over Gobi[J]. Research of Soil and Water Conservation, 12(1): 54-55, 58. ] doi: 10.3969/j.issn.1005-3409.2005.01.016
[26]	张伟民, 汪万福, 张克存, 等. 2009. 不同沙源供给条件下砾石床面的风沙流结构与蚀积量变化风洞实验研究[J]. 中国沙漠, 29(6): 1015-1020.
	[Zhang W M, Wang W F, Zhang K C, et al.2009. Wind tunnel experiments on sand-laden wind structure and sand erosion-deposit budget over Gravel bed under abundant and deficient sand supplies[J]. Journal of Desert Research, 29(6): 1015-1020.]
[27]	张正偲, 董治宝. 2013. 腾格里沙漠东南部野外风沙流观测[J]. 中国沙漠, 33(4): 973-980. doi: 10.7522/j.issn.1000-694X.2013.00089
	[Zhang Z C, Dong Z B.2013. Field observation of Aeolian sediment flux in the southeast Tengger Desert[J]. Journal of Desert Research, 33(4): 973-980. ] doi: 10.7522/j.issn.1000-694X.2013.00089
[28]	邹学勇, 董光荣, 王周龙. 1995. 戈壁风沙流若干特征研究[J]. 中国沙漠, 15(4): 368-373.
	[Zou X Y, Dong G R, Wang Z L.1995. A study on some characteristics of drifting sand flux over Gobi[J]. Journal of Desert Research, 15(4): 368-373. ]
[29]	Anderson R S, Haff P K.1988. Simulation of eolian saltation[J]. Science, 241: 820-823. doi: 10.1126/science.241.4867.820 pmid: 17829176
[30]	Baas A C W.2008. Challenges in aeolian geomorphology: investigating Aeolian streamers[J]. Geomorphology, 93(1-2): 3-16. doi: 10.1016/j.geomorph.2006.12.015
[31]	Baas A C W, Sherman D J.2005. Formation and behavior of aeolian streamers[J]. Journal of Geophysical Research: Earth Surface (2003-2012), 110(F3): F03011. doi: 10.1029/2004JF000270
[32]	Butterfield G R.1999. Near-bed mass flux profiles in Aeolian sand transport: high-resolution measurements in a wind tunnel[J]. Earth Surface Processes and Landforms, 24(5): 393-412. doi: 10.1002/(SICI)1096-9837(199905)24:5<393::AID-ESP996>3.0.CO;2-G
[33]	Dong Z B, Liu X P, Wang H T, et al.2002. The flux profile of a blowing sand cloud: a wind tunnel investigation[J]. Geomorphology, 49(3-4): 219-230. doi: 10.1016/S0169-555X(02)00170-8
[34]	Dong Z B, Qian G Q.2007. Characterizing the height profile of the flux of wind-eroded sediment[J]. Environmental Geology, 51(5): 835-845. doi: 10.1007/s00254-006-0363-5
[35]	Dong Z B, Lv P, Zhang Z C, et al.2014. Aeolian transport over a developing transverse dune[J]. Journal of Arid Land, 6(3): 243-254. doi: 10.1007/s40333-013-0243-2
[36]	Fryrear D W, Stout J E, Hagen L J, et al.1991. Wind erosion: field measurement and analysis[J]. Transactions of the ASAE, 34(1): 155-160. doi: 10.13031/2013.31638
[37]	Iversen J D, Rasmussen K R.1994. The effect of surface slope on saltation threshold[J]. Sedimentology, 41(4): 721-728. doi: 10.1111/j.1365-3091.1994.tb01419.x
[38]	Lancaster N, Baas A.1998. Influence of vegetation cover on sand transport by wind: field studies at Owens Lake, California[J]. Earth Surface Processes and Landforms, 23(1): 69-82. doi: 10.1002/(SICI)1096-9837(199801)23:1<69::AID-ESP823>3.0.CO;2-G
[39]	Ni J R, Li Z S, Mendoza C.2003. Vertical profiles of aeolian sand mass flux[J]. Geomorphology, 49(3-4): 205-218. doi: 10.1016/S0169-555X(02)00169-1
[40]	Rotnicka J.2013. Aeolian vertical mass flux profiles above dry and moist sandy beach surfaces[J]. Geomorphology, 187: 27-37. doi: 10.1016/j.geomorph.2012.12.032
[41]	Williams G.1964. Some aspects of the eolian saltation load[J]. Sedimentology, 3(4): 257-287. doi: 10.1111/j.1365-3091.1964.tb00642.x
[42]	Zheng X J, He L H, Wu J J.2004. Vertical profiles of mass flux for windblown sand movement at steady state[J]. Journal of Geophysical Research: Solid Earth (1978-2012), 109(B1): B01106. doi: 10.1029/2003JB002656

高度 /m	前端活动区相对输沙率/%						脊线相对输沙率/%
高度 /m	H^*		I	J	K	L	A	B	C	D	E	F	G
0.01	29.94	44.88	43.18	41.07	49.80		40.77	29.85	54.42	53.17	22.12	56.91	33.83
0.03	18.29	22.89	27.71	27.28	21.79		21.07	22.29	24.57	19.75	19.59	19.40	18.41
0.05	13.16	12.10	12.26	13.08	10.67		13.77	15.18	10.77	11.38	16.54	9.01	10.95
0.07	9.30	6.98	6.07	6.95	5.83		8.94	10.21	4.90	5.81	12.95	4.97	7.77
0.09	7.41	4.14	3.60	3.93	3.42		5.71	7.15	2.50	3.37	9.65	3.19	6.15
0.11	6.66	2.72	2.36	2.60	2.35		3.51	5.29	1.25	2.23	6.70	2.26	5.20
0.13	4.77	2.10	1.60	1.78	1.82		2.48	3.66	0.67	1.53	4.63	1.50	5.25
0.15	3.85	1.57	1.25	1.34	1.60		1.67	2.75	0.42	1.16	3.44	1.10	4.35
0.17	3.39	1.34	1.03	1.05	1.41		1.18	2.03	0.28	0.88	2.48	0.94	4.04
0.19	3.22	1.28	0.94	0.91	1.33		0.91	1.58	0.23	0.71	1.91	0.72	4.04
总输沙率/(g·m^-1·s^-1)	2.85	7.04	13.50	16.94	9.72		0.97	1.75	5.53	2.40	8.66	4.33	0.64

高度/m	北翼相对输沙率平均值/%						南翼相对输沙率平均值/%
高度/m	P		Q	R	S	T	p	q	r	s	t
0.01	0.293	0.326	0.445	0.610	0.352		0.224	0.386	0.335	0.397	0.452
0.03	0.233	0.226	0.265	0.193	0.216		0.162	0.226	0.218	0.297	0.185
0.05	0.128	0.152	0.130	0.083	0.135		0.126	0.130	0.147	0.123	0.095
0.07	0.084	0.095	0.065	0.040	0.086		0.100	0.085	0.099	0.064	0.068
0.09	0.065	0.060	0.035	0.024	0.064		0.100	0.058	0.067	0.039	0.048
0.11	0.048	0.046	0.021	0.016	0.044		0.062	0.039	0.045	0.027	0.040
0.13	0.043	0.032	0.013	0.011	0.034		0.052	0.029	0.034	0.018	0.032
0.15	0.039	0.025	0.010	0.009	0.027		0.057	0.021	0.023	0.014	0.030
0.17	0.034	0.021	0.008	0.007	0.024		0.063	0.015	0.018	0.012	0.026
0.19	0.033	0.018	0.007	0.007	0.019		0.055	0.012	0.013	0.009	0.025
总输沙率/(g·m^-1·s^-1)	0.91	9.88	13.45	7.57	2.44		0.32	5.71	26.14	21.30	3.76

沙丘部位	观测点位	V/(m^-1·s^-1)	Q_m/(g·m^-1·s^-1)	a	b	Q_C₁	Q_C₁-Q_m	R²
北断面	H	6.22	5.51	1.918	0.056	5.214	-0.301	0.95
	I	6.57	7.35	5.295	0.027	6.934	-0.419	1.00
	J	7.03	9.48	5.114	0.038	9.537	0.058	0.98
	K	7.86	21.92	12.035	0.037	21.967	0.043	0.99
	L	7.31	10.97	7.531	0.028	10.145	-0.828	0.99
中轴断面	H	6.63	2.80	0.828	0.071	2.757	-0.047	0.99
	I	6.96	9.87	6.301	0.030	9.362	-0.507	1.00
	J	7.23	11.98	7.637	0.032	11.977	-0.001	0.99
	K	7.45	15.01	9.740	0.030	14.548	-0.462	1.00
	L	7.14	9.48	6.513	0.028	8.996	-0.485	1.00
南断面	H	6.35	0.25	0.079	0.062	0.235	-0.011	0.95
	I	7.32	3.90	1.882	0.041	3.759	-0.144	0.99
	J	8.00	19.05	9.379	0.040	18.370	-0.676	1.00
	K	8.41	13.89	5.921	0.048	14.007	0.112	0.96
	L	7.17	8.70	4.724	0.036	8.269	-0.435	0.99
北翼	P	5.54	0.91	0.333	0.055	0.883	-0.024	0.97
	Q	5.94	9.88	3.989	0.050	9.739	-0.137	1.00
	R	6.37	13.45	8.402	0.032	13.335	-0.116	1.00
	S	5.82	7.57	7.409	0.020	7.030	-0.545	1.00
	T	5.59	2.44	1.012	0.048	2.363	-0.077	0.99
南翼	p	5.64	0.32	0.072	0.104	0.318	-0.001	0.99
	q	7.66	5.71	2.711	0.041	5.482	-0.224	0.99
	r	8.93	26.14	10.396	0.052	26.081	-0.063	1.00
	s	7.05	21.30	12.075	0.035	20.986	-0.312	0.99
	t	3.48	3.76	2.219	0.030	3.244	-0.520	0.96
脊线	A	4.70	0.97	0.473	0.041	0.950	-0.021	1.00
	B	4.92	1.75	0.619	0.059	1.749	0.003	1.00
	C	6.15	5.53	4.428	0.025	5.493	-0.039	1.00
	D	5.86	2.40	1.910	0.024	2.229	-0.173	0.99
	E	5.98	8.66	2.290	0.085	8.806	0.147	0.97
	F	6.04	4.33	3.937	0.021	3.962	-0.371	0.99
	G	5.06	0.64	0.253	0.047	0.583	-0.061	0.93

观测断面		连续函数		分段函数
观测断面	Q_m	0~0.20 m 指数	Q_c₁	0~0.10 m 指数	0.10~0.20 m 幂函数	Q_c₂
N	10.797	0.992	10.145	0.998	0.969	10.886
M	9.367	0.996	8.996	0.999	0.952	9.426
S	8.563	0.991	8.269	0.993	0.973	8.656

观测点位	V/(m·s^-1)	Q/(g·m^-1·s^-1)	a	b
H	6.40	2.85	0.942	0.063
I	6.95	7.04	4.493	0.033
J	7.42	13.50	7.377	0.037
K	7.91	16.94	9.232	0.039
L	7.21	9.72	6.256	0.030
