考虑季节性的青藏高原地区公路可达性评价

doi:10.18306/dlkxjz.2023.04.006

Abstract

Abstract:

Accessibility is one of the most important concepts in transportation geography. Accurate evaluation of accessibility is of great significance for transportation planning and development. However, there is a lack of literature on accessibility assessment that considered seasonal variation and mountainous terrain influence. The Qinghai-Tibet Plateau is characterized by distinct rainy season and snow season, as well as high altitude and complex terrain. Therefore, this study fully considered seasonal and terrain influences in the evaluation of accessibility. Combined with multi-source data, the cost-distance model was adopted in this study to evaluate the road accessibility in the Qinghai-Tibet Plateau region. The results are as follows: 1) The shortest time to basic service facilities in the Qinghai-Tibet Plateau region during the rainy season considering the influence of precipitation had little change compared with the situation without considering the influence of precipitation. In the rainy season, the average value of the total accessibility of the whole region increased by 0.011 hours, and more than 0.021% of the areas could not reach the nearest service facilities within 8 hours because of the impact of rainfall. 2) Affected by snow cover, the total accessibility of the Qinghai-Tibet Plateau region became worse, and the minimum road accessibility time in the snow season increased by 2.04 hours on average. Given the effect of snowfall, more than 5.41% of the areas could not reach the nearest service facility within 2 hours, and more than 5.54% of the areas could not reach the nearest service facility within 2-4 hours. 3) According to the seasonal change of accessibility affected by precipitation and snow cover in the rainy season and snow season, the fluctuation range of accessibility in the snow season was larger. The areas with the greatest impact on accessibility by precipitation mainly concentrated near the Mount Qomolangma and the Yarlung Zangbo River Grand Canyon, while the areas that were most seriously affected by snow cover mainly concentrated in the eastern part of Tibet Autonomous Region, the southern part of Qinghai Province, and the western part of Sichuan Province, which are mainly distributed in the Hengduan Mountainous area, Tanggula Mountains range, Bayan Har Mountains range, and other topographic areas.

Key words: road accessibility, rainy season and snow season, cost-distance model, Qinghai-Tibet Plateau region

LIU Qingfang, LU Wenqing, DAI Teqi, SONG Jinping, LIU Yufan, LI Jie. Evaluation of road accessibility in the Qinghai-Tibet Plateau regionconsidering seasonality[J].PROGRESS IN GEOGRAPHY, 2023, 42(4): 687-700.

Figures/Tables 12

Fig.1

Tab.1

Fig.2

Tab.2

Fig.3

Tab.3

Fig.4

Fig.5

Tab.4

Fig.6

Tab.5

Fig.7

References 38

[1]	冯凤江, 程新平, 孙晓宁. 高速公路雾天人工和智能网联车混行交通流仿真[J]. 中国安全科学学报, 2022, 32(7): 158-164. doi: 10.16265/j.cnki.issn1003-3033.2022.07.1109
	[ Feng Fengjiang, Cheng Xinping, Sun Xiao-ning. Simulation of mixed traffic flow with HVs and CAVs on freeways in foggy weather. China Safety Science Journal, 2022, 32(7): 158-164. ] doi: 10.16265/j.cnki.issn1003-3033.2022.07.1109
[2]	何杰, 张长健, 严欣彤, 等. 基于微观动力学参数的高速公路特征路段事故风险分析[J/OL]. 吉林大学学报(工学版), 2022. http://kns.cnki.net/kcms/detail/22.1341.t.20220802.1255.006.html.
	[ He Jie, Zhang Changjian, Yan Xintong, et al. Analyzing traffic crash risk of freeway characteristics based on micro-kinetic parameters. Journal of Jilin University (Engineering and Technology Edition), 2022. http://kns.cnki.net/kcms/detail/22.1341.t.20220802.1255.006.html. ]
[3]	苗毅, 卢文清, 戴特奇, 等. 青藏高原市域综合交通优势度评价及空间特征: 以林芝市为例[J]. 地理科学进展, 2021, 40(8): 1332-1343. doi: 10.18306/dlkxjz.2021.08.007
	[ Miao Yi, Lu Wenqing, Dai Teqi, et al. Comprehensive traffic advantage degree and its spatial characteristics at the prefecture level on the Qinghai-Tibet Plateau: A case study of Linzhi City. Progress in Geography, 2021, 40(8): 1332-1343. ] doi: 10.18306/dlkxjz.2021.08.007
[4]	汪双杰, 陈建兵, 章金钊, 等. 青藏高原多年冻土区公路修筑技术之进展[J]. 中国科学(技术科学), 2009(1): 8-15.
	[ Wang Shuangjie, Chen Jianbing, Zhang Jinzhao, et al. Advances in road construction technology in the permafrost region of the Qinghai-Tibet Plateau. Scientia Sinica (Technologica), 2009(1): 8-15. ]
[5]	Hansen W G. How accessibility shapes land use[J]. Journal of the American Institute of Planners, 1959, 25(2): 73-76. doi: 10.1080/01944365908978307
[6]	Dalvi M Q, Martin K M. The measurement of accessibility: Some preliminary results[J]. Transportation, 1976, 5(1): 17-42. doi: 10.1007/BF00165245
[7]	Zhang Q Y, Northridge M E, Jin Z, et al. Modeling accessibility of screening and treatment facilities for older adults using transportation networks[J]. Applied Geography, 2018, 93: 64-75. doi: 10.1016/j.apgeog.2018.02.013 pmid: 29556112
[8]	陈卓, 金凤君, 王姣娥. 基于高速公路流的东北大都市区边界识别与结构特征研究[J]. 地理科学, 2019, 39(6): 929-937. doi: 10.13249/j.cnki.sgs.2019.06.008
	[ Chen Zhuo, Jin Fengjun, Wang Jiao'e. Spatial boundaries and structural characteristics of metropolitan areas in northeast China: A study using the data of expressway flows. Scientia Geographica Sinica, 2019, 39(6): 929-937. ] doi: 10.13249/j.cnki.sgs.2019.06.008
[9]	Tiznado-Aitken I, Muoz J C, Hurtubia R. Public transport accessibility accounting for level of service and competition for urban opportunities: An equity analysis for education in Santiago de Chile[J]. Journal of Transport Geography, 2021, 90(1): 102919. doi: 10.1016/j.jtrangeo.2020.102919. doi: 10.1016/j.jtrangeo.2020.102919
[10]	王菲, 李善同. 交通发展、时空压缩与产业区位效应: 以公路建设为例[J]. 上海经济研究, 2022, 34(4): 88-98.
	[ Wang Fei, Li Shantong. Transport development, time-space compression and industrial location effect: Evidence from highway construction. Shanghai Journal of Economics, 2022, 34(4): 88-98. ]
[11]	Acheampong R A, Asabere S B. Urban expansion and differential accessibility by car and public transport in the Greater Kumasi city-region, Ghana: A geospatial modelling approach[J]. Journal of Transport Geography, 2022, 98: 103257. doi: 10.1016/j.jtrangeo.2021.103257. doi: 10.1016/j.jtrangeo.2021.103257
[12]	Bhuiya M M R, Hasan M M U, Jones S. Accessibility of movement challenged persons and challenges faced by their escorting family members: A case study of Dhaka, Bangladesh[J]. Journal of Transport & Health, 2022, 24: 101323. doi: 10.1016/j.jth.2021.101323. doi: 10.1016/j.jth.2021.101323
[13]	商硕, 蒋海兵, 韦胜. 人口流动视角下中国地级以上城市空间联系格局与影响因素[J]. 智库理论与实践, 2022, 7(2): 117-129.
	[ Shang Shuo, Jiang Haibing, Wei Sheng. The spatial contact pattern and influencing factors of cities above the prefecture level in China from the perspective of population mobility. Think Tank: Theory & Practice, 2022, 7(2): 117-129. ]
[14]	刘建荣, 郝小妮. 到达车站的步行时间对老年人公交选择的影响[J]. 交通运输系统工程与信息, 2020, 20(1): 124-129.
	[ Liu Jianrong, Hao Xiaoni. Effect of bus stop walking time on elderly's bus choice. Journal of Transportation Systems Engineering and Information Technology, 2020, 20(1): 124-129. ]
[15]	吕彪, 刘一骝, 刘海旭. 协同考虑脆弱性与可靠性的城市道路网络设计[J]. 西南交通大学学报, 2019, 54(5): 1093-1103.
	[ Lv Biao, Liu Yiliu, Liu Haixu. Urban road network design with balance between vulnerability and reliability. Journal of Southwest Jiaotong University, 2019, 54(5): 1093-1103. ]
[16]	Datla S, Sharma S. Impact of cold and snow on temporal and spatial variations of highway traffic volumes[J]. Journal of Transport Geography, 2008, 16(5): 358-372. doi: 10.1016/j.jtrangeo.2007.12.003
[17]	Yuan Q W, Jing L. Study of rainfall impacts on freeway traffic flow characteristics[J]. Transportation Research Procedia, 2017, 25: 1533-1543. doi: 10.1016/j.trpro.2017.05.180
[18]	张存保, 万平, 梅朝辉, 等. 雨天环境下高速公路交通流特性及模型研究[J]. 武汉理工大学学报, 2013, 35(3): 63-67.
	[ Zhang Cunbao, Wan Ping, Mei Zhaohui, et al. Traffic flow characteristics and models of freeway under rain weather. Journal of Wuhan University of Technology, 2013, 35(3): 63-67. ]
[19]	龚大鹏, 宋国华, 黎明, 等. 降雨对城市道路行程速度的影响[J]. 交通运输系统工程与信息, 2015, 15(1): 218-225.
	[ Gong Dapeng, Song Guohua, Li Ming, et al. Impact of rainfalls on travel speed on urban roads. Journal of Transportation Systems Engineering and Information Technology, 2015, 15(1): 218-225. ]
[20]	孙洪运, 杨金顺, 吴兵. 暴雨对快速路速度—密度关系影响的实证分析[J]. 交通运输系统工程与信息, 2016, 16(3): 221-227.
	[ Sun Hongyun, Yang Jinshun, Wu Bing. Empirical analysis of speed-density relationships for urban expressway under rainstorm condition. Journal of Transportation Systems Engineering and Information Technology, 2016, 16(3): 221-227. ]
[21]	戢晓峰, 张琪, 覃文文, 等. 恶劣天气对高原山区高速公路交通流特征的影响分析[J]. 交通信息与安全, 2020, 38(4): 10-16.
	[ Ji Xiaofeng, Zhang Qi, Qin Wenwen, et al. An impact analysis of bad weather on traffic flow characteristics of plateau mountain expressway. Journal of Transport Information and Safety, 2020, 38(4): 10-16. ]
[22]	龚开江, 王洪亮, 柏小俊, 等. 降雨强度对山区高速公路运行车速的影响研究[J]. 价值工程, 2021, 40(15): 197-199.
	[ Gong Kaijiang, Wang Hongliang, Bai Xiaojun, et al. Study of the effect of rainfall intensity on operating speeds on mountain highways. Value Engineering, 2021, 40(15): 197-199. ]
[23]	金凤君, 刘毅. 青藏高原产业发展的交通运输门槛研究[J]. 自然资源学报, 2000, 15(4): 363-368.
	[ Jin Fengjun, Liu Yi. Threshold study on transportation and industrial development in Qinghai-Tibet Plateau. Journal of Natural Resources, 2000, 15(4): 363-368. ] doi: 10.11849/zrzyxb.2000.04.009
[24]	朱燕, 侯光良, 兰措卓玛, 等. 基于GIS的青藏高原史前交通路线与分区分析[J]. 地理科学进展, 2018, 37(3): 438-449. doi: 10.18306/dlkxjz.2018.03.014
	[ Zhu Yan, Hou Guangliang, Lan Cuozhuoma, et al. GIS-based analysis of traffic routes and regional division of the Qinghai-Tibetan Plateau in prehistoric period. Progress in Geography, 208, 37(3): 438-449. ]
[25]	高兴川, 曹小曙, 李涛, 等. 1976—2016年青藏高原地区通达性空间格局演变[J]. 地理学报, 2019, 74(6): 1190-1204. doi: 10.11821/dlxb201906009
	[ Gao Xingchuan, Cao Xiaoshu, Li Tao, et al. Evolution of accessibility spatial pattern of the Qinghai-Tibet Plateau in 1976-2016. Acta Geographica Sinica, 2019, 74(6): 1190-1204. ] doi: 10.11821/dlxb201906009
[26]	Che T, Li X, Jin R, et al. Snow depth derived from passive microwave remote-sensing data in China[J]. Annals of Glaciology, 2008, 49: 145-154. doi: 10.3189/172756408787814690
[27]	Banick R, Heyns A M, Regmi S. Evaluation of rural roads construction alternatives according to seasonal service accessibility improvement using a novel multi-modal cost-time model: A study in Nepal's remote and mountainous Karnali Province[J]. Journal of Transport Geography, 2021, 93: 103057. doi: 10.1016/j.jtrangeo.2021.103057. doi: 10.1016/j.jtrangeo.2021.103057
[28]	蒋海兵, 张文忠, 祁毅, 等. 区域交通基础设施可达性研究进展[J]. 地理科学进展, 2013, 32(5): 807-817. doi: 10.11820/dlkxjz.2013.05.012
	[ Jiang Haibing, Zhang Wenzhong, Qi Yi, et al. Research progress on accessibility to regional transportation infrastructure. Progress in Geography, 2013, 32(5): 807-817. ] doi: 10.11820/dlkxjz.2013.05.012
[29]	Tobler W. Three presentations on geographical analysis and modeling:Non-isotropic geographic modeling; speculations on the geometry of geography; and global spatial analysis[R]. Santa Barbara, USA: National Center for Geographic Information and Analysis, 1993.
[30]	冉逸箫, 张凤荣, 张佰林, 等. 贫困山区农村衰落的特征及诊断: 以重庆市酉阳县为例[J]. 资源科学, 2017, 39(6): 999-1012. doi: 10.18402/resci.2017.06.02
	[ Ran Yixiao, Zhang Fengrong, Zhang Bailin, et al. Characterization and diagnosis of rural decline in poor mountainous areas. Resources Science, 2017, 39(6): 999-1012. ] doi: 10.18402/resci.2017.06.02
[31]	曾冰, 张艳, 胡亚光. 基于交通可达性与城市竞争力的城市腹地范围识别: 以长江中游城市群为例[J]. 热带地理, 2020, 40(1): 119-127. doi: 10.13284/j.cnki.rddl.003177
	[ Zeng Bing, Zhang Yan, Hu Yaguang. Recognition of urban hinterland based on transportation accessibility and urban competitiveness: A case study on the middle reaches of the Yangtze River. Tropical Geography, 2020, 40(1): 119-127. ] doi: 10.13284/j.cnki.rddl.003177
[32]	国家统计局. 中国城市统计年鉴 2021 [M]. 北京: 中国统计出版社, 2021.
	[National Bureau of Statistics. China City Statistical Yearbook 2021. Beijing: China Statistics Press, 2021. ]
[33]	湛东升, 谢春鑫, 张文忠, 等. 基于累计机会可达性的北京城市公共服务设施复合功能识别[J]. 地球信息科学学报, 2020, 22(6): 1320-1329. doi: 10.12082/dqxxkx.2020.190717
	[ Zhan Dongsheng, Xie Chunxin, Zhang Wenzhong, et al. Identifying mixed functions of urban public service facilities in Beijing by cumulative opportunity accessibility method. Journal of Geo-information Science, 2020, 22(6): 1320-1329. ]
[34]	除多, 洛桑曲珍, 林志强, 等. 近30年青藏高原雪深时空变化特征分析[J]. 气象, 2018, 44(2): 233-243.
	[ Chu Duo, Luosang Quzhen, Lin Zhiqiang, et al. Spatio-temporal variation of snow depth on Tibetan Plateau over the last 30 years. Meteorological Monthly, 2018, 44(2): 233-243. ]
[35]	任园园. 冰雪条件下城市道路交通流特性及管理对策研究[D]. 长春: 吉林大学, 2008.
	[ Ren Yuanyuan. Study on the characteristics of traffic stream and management countermeasure at urban road under condition of snow and ice. Changchun, China: Jilin University, 2008. ]
[36]	马筱栎, 樊博. 降雨对山区高速公路运行车速的影响研究[J]. 公路与汽运, 2020(5): 33-36.
	[ Ma Xiaoli, Fan Bo. Study of the effect of rainfall on operating speeds on mountain highways. Highways & Automotive Applications, 2020(5): 33-36. ]
[37]	Esfeh M A, Kattan L, Lam W H K, et al. Road network vulnerability analysis considering the probability and consequence of disruptive events: A spatiotemporal incident impact approach[J]. Transportation Research Part C: Emerging Technologies, 2022, 136: 103549. doi: 10.1016/j.trc.2021.103549. doi: 10.1016/j.trc.2021.103549
[38]	王姣娥, 陈娱, 戴特奇, 等. 中国交通地理学的传承发展与创新[J]. 经济地理, 2021, 41(10): 59-69.
	[ Wang Jiao'e, Chen Yu, Dai Teqi, et al. Inheritance, development and innovation of transport geography in China. Economic Geography, 2021, 41(10): 59-69. ]

设施类型	包含的POI类型	POI数量/个
医疗服务设施	诊所	2915
医疗服务设施	综合医院	1538
商业服务设施	购物服务：商场、超级市场、便民商店/便利店	17211
商业服务设施	金融保险服务：银行	2202
城市功能服务	县级政府驻地	161
城市功能服务	地级市政府驻地	19
交通设施服务	火车站站点	64
交通设施服务	机场	19

设施类别	可达性范围/h	占青藏全域总面积的比重/%
设施类别	可达性范围/h	未考虑降水影响	考虑降水影响	降水影响的变化
医疗服务设施	[0, 2)	21.827	21.814	-0.013
	[2, 4)	17.678	17.676	-0.002
	[4, 6)	11.821	11.822	0.001
	[6, 8)	7.763	7.762	-0.001
	≥8	40.911	40.926	0.014
商业服务设施	[0, 2)	25.887	25.875	-0.013
	[2, 4)	19.969	19.970	0.001
	[4, 6)	11.581	11.578	-0.002
	[6, 8)	6.995	6.994	-0.001
	≥8	35.568	35.584	0.015
城市功能服务设施	[0, 2)	3.912	3.911	-0.001
	[2, 4)	9.978	9.976	-0.003
	[4, 6)	12.116	12.105	-0.011
	[6, 8)	11.124	11.113	-0.011
	≥8	62.870	62.896	0.026
交通服务设施	[0, 2)	7.700	7.700	0
	[2, 4)	15.989	15.989	0
	[4, 6)	16.018	16.014	-0.003
	[6, 8)	14.851	14.833	-0.017
	≥8	45.443	45.464	0.021

可达性/h	占青藏全域总面积的比重/%
可达性/h	未考虑降水影响	考虑降水影响	降水影响的变化
[0, 2)	16.237	16.235	-0.002
[2, 4)	26.394	26.369	-0.025
[4, 6)	15.784	15.789	0.005
[6, 8)	7.997	7.998	0.001
≥8	33.589	33.609	0.021

设施类别	可达性范围/h	占青藏全域总面积的比重/%
设施类别	可达性范围/h	未考虑积雪影响	考虑积雪影响	积雪影响的变化
医疗服务设施	[0, 2)	21.83	17.40	-4.43
	[2, 4)	17.68	15.72	-1.96
	[4, 6)	11.82	11.72	-0.10
	[6, 8)	7.76	8.33	0.57
	≥8	40.91	46.83	5.92
商业服务设施	[0, 2)	25.89	20.16	-5.73
	[2, 4)	19.97	18.65	-1.32
	[4, 6)	11.58	12.37	0.79
	[6, 8)	6.99	8.00	1.00
	≥8	35.57	40.83	5.26
城市功能服务设施	[0, 2)	3.91	2.63	-1.28
	[2, 4)	9.98	6.32	-3.66
	[4, 6)	12.12	8.84	-3.28
	[6, 8)	11.12	9.35	-1.77
	≥8	62.87	72.85	9.98
交通服务设施	[0, 2)	7.70	5.68	-2.02
	[2, 4)	15.99	11.72	-4.27
	[4, 6)	16.02	11.61	-4.41
	[6, 8)	14.85	11.87	-2.98
	≥8	45.44	59.13	13.68

可达性/h	占青藏全域总面积的比重/%
可达性/h	未考虑积雪影响	考虑积雪影响	积雪影响的变化
[0, 2)	16.24	10.83	-5.41
[2, 4)	26.39	20.85	-5.54
[4, 6)	15.78	18.14	2.36
[6, 8)	7.99	10.55	2.56
≥8	33.59	39.62	6.03

Evaluation of road accessibility in the Qinghai-Tibet Plateau regionconsidering seasonality
