PROGRESS IN GEOGRAPHY ›› 2023, Vol. 42 ›› Issue (1): 131-144.doi: 10.18306/dlkxjz.2023.01.011
• Articles • Previous Articles Next Articles
QIU Xinye1(), CHEN Shuang2,*(
), LIU Zhennan2
Received:
2022-06-02
Revised:
2022-08-19
Online:
2023-01-28
Published:
2023-03-28
Contact:
CHEN Shuang
E-mail:qxy010106@163.com;schens@nuist.edu.cn
Supported by:
QIU Xinye, CHEN Shuang, LIU Zhennan. Town formation and development potential of East African countries based on maximum entropy model[J].PROGRESS IN GEOGRAPHY, 2023, 42(1): 131-144.
Tab.2
Natural environment variables, socioeconomic variables, and data sources
变量 | 描述 | 单位 | 来源 |
---|---|---|---|
自然环境变量 | |||
prec | 降水 | mm | |
dem | 高程 | m | |
slope | 坡度 | (°) | |
water | 距水体距离 | km | |
forest | 距森林距离 | km | |
ndvi | 归一化植被指数 | — | |
soil | 土壤湿度(地下10 cm) | — | |
社会经济变量 | |||
primary | 距全国性主要交通干线距离 | km | |
secondary | 距区域性主要交通干线距离 | km | |
railway | 距主要铁路距离 | km | |
farmland | 距耕地距离 | km | |
medium | 距中等城市距离 | km | |
large | 距大城市距离 | km |
Tab.3
Descriptive statistics for Tanzanian variables
变量 | 城镇 | 小城市 | |||||||
---|---|---|---|---|---|---|---|---|---|
最小值 | 最大值 | 平均值 | 标准差 | 最小值 | 最大值 | 平均值 | 标准差 | ||
dem/m | 14.00 | 1825.00 | 1003.36 | 448.85 | 21.00 | 1947.00 | 942.85 | 541.46 | |
farmland/km | 0 | 119.54 | 33.38 | 28.97 | 0 | 137.59 | 28.88 | 30.36 | |
forest/km | 2.00 | 219.27 | 31.40 | 35.63 | 1.00 | 255.33 | 31.94 | 46.89 | |
large/km | 23.09 | 1096.18 | 618.92 | 303.98 | 32.57 | 1017.79 | 547.16 | 265.68 | |
medium/km | 4.12 | 454.25 | 93.43 | 82.88 | 22.09 | 471.30 | 99.45 | 90.94 | |
ndvi | 0.21 | 0.69 | 0.42 | 0.10 | 0.25 | 0.64 | 0.41 | 0.09 | |
prec/mm | 42.75 | 197.25 | 83.25 | 22.00 | 52.00 | 206.42 | 89.49 | 29.45 | |
primary/km | 0 | 211.09 | 52.16 | 48.25 | 0 | 234.00 | 58.77 | 53.51 | |
railway/km | 0 | 410.10 | 92.54 | 94.43 | 0 | 389.65 | 81.93 | 98.91 | |
secondary/km | 0 | 77.41 | 9.79 | 14.53 | 0 | 53.25 | 8.31 | 13.22 | |
slope/(°) | 0 | 20.08 | 2.15 | 2.33 | 0 | 17.13 | 2.09 | 2.73 | |
soil | 0 | 0.36 | 0.26 | 0.07 | 0 | 0.34 | 0.25 | 0.07 | |
water/km | 0 | 47.85 | 5.00 | 6.68 | 0 | 33.24 | 3.11 | 5.82 |
Tab.4
Descriptive statistics for Ugandan variables
变量 | 城镇 | 小城市 | |||||||
---|---|---|---|---|---|---|---|---|---|
最小值 | 最大值 | 平均值 | 标准差 | 最小值 | 最大值 | 平均值 | 标准差 | ||
dem/m | 621.00 | 1944.00 | 1167.25 | 192.93 | 814.00 | 1831.00 | 1174.68 | 186.92 | |
farmland/km | 1.00 | 95.08 | 23.14 | 20.51 | 1.00 | 34.18 | 10.14 | 8.85 | |
forest/km | 1.00 | 49.65 | 12.20 | 10.17 | 1.41 | 26.68 | 8.74 | 6.15 | |
large/km | 26.17 | 379.10 | 174.62 | 101.28 | 15.65 | 385.59 | 177.28 | 119.24 | |
medium/km | 10.00 | 175.14 | 73.56 | 46.07 | 16.00 | 182.28 | 69.06 | 36.99 | |
ndvi | 0.32 | 0.75 | 0.56 | 0.08 | 0.37 | 0.62 | 0.51 | 0.05 | |
prec/mm | 58.75 | 125.00 | 99.88 | 14.71 | 66.17 | 125.33 | 105.00 | 13.87 | |
primary/km | 0 | 20.62 | 4.48 | 6.03 | 0 | 15.23 | 2.29 | 3.78 | |
railway/km | 0 | 354.20 | 78.54 | 78.94 | 0 | 323.15 | 66.75 | 80.42 | |
secondary/km | 0 | 71.85 | 15.34 | 18.10 | 0 | 33.73 | 7.64 | 10.90 | |
slope/(°) | 0.07 | 7.79 | 1.11 | 1.17 | 0.06 | 3.85 | 1.14 | 0.85 | |
soil | 0 | 0.38 | 0.30 | 0.07 | 0.26 | 0.37 | 0.32 | 0.03 | |
water/km | 0 | 15.23 | 2.90 | 3.60 | 0 | 10.05 | 2.75 | 2.93 |
Tab.5
Ranking of the contribution of factors influencing the formation and development of towns and small cities in Tanzania (%)
贡献率排名 | 城镇 | 小城市 | |||||
---|---|---|---|---|---|---|---|
变量 | 贡献率 | 累积贡献率 | 变量 | 贡献率 | 累积贡献率 | ||
1 | secondary | 45.4 | 45.4 | secondary | 41.6 | 41.6 | |
2 | primary | 15.1 | 60.5 | ndvi | 15.5 | 57.1 | |
3 | ndvi | 11.4 | 71.9 | water | 12.1 | 69.2 | |
4 | railway | 7.7 | 79.6 | prec | 7.0 | 76.2 | |
5 | large | 6.4 | 86.0 | railway | 5.7 | 81.9 | |
6 | farmland | 3.6 | 89.6 | primary | 4.2 | 86.1 | |
7 | prec | 3.3 | 92.9 | large | 4.0 | 90.1 | |
8 | medium | 1.5 | medium | 3.5 | |||
9 | water | 1.4 | farmland | 3.4 | |||
10 | slope | 1.3 | dem | 1.6 | |||
11 | soil | 1.2 | forest | 1.3 | |||
12 | dem | 1.1 | slope | 0.3 | |||
13 | forest | 0.9 | soil | 0.1 |
Tab.6
Ranking of the contribution of factors influencing the formation and development of towns and small cities in Uganda (%)
贡献率排名 | 城镇 | 小城市 | |||||
---|---|---|---|---|---|---|---|
变量 | 贡献率 | 累积贡献率 | 变量 | 贡献率 | 累积贡献率 | ||
1 | secondary | 32.7 | 32.7 | ndvi | 33.7 | 33.7 | |
2 | primary | 23.1 | 55.8 | secondary | 24.9 | 58.6 | |
3 | ndvi | 22.6 | 78.4 | farmland | 14.7 | 73.3 | |
4 | large | 8.9 | 87.3 | primary | 12.6 | 85.9 | |
5 | medium | 2.8 | 90.1 | large | 6.3 | 92.2 | |
6 | railway | 2.3 | medium | 2.8 | |||
7 | prec | 2.1 | prec | 1.5 | |||
8 | farmland | 1.3 | railway | 1.3 | |||
9 | forest | 1.3 | slope | 1.2 | |||
10 | slope | 1.3 | soil | 0.9 | |||
11 | water | 0.9 | water | 0.1 | |||
12 | soil | 0.5 | forest | 0.1 | |||
13 | dem | 0.2 | dem | 0 |
[1] | Knox L P, McCarthy L M. 城市化: 城市地理学导论[M]. 姜付仁, 万金红, 董磊华, 等译. 3版. 北京: 电子工业出版社, 2016. |
[Knox L P, McCarthy L M. Urbanization:An introduction to urban geography. Translated by Jiang Furen, Wan Jinhong, Dong Leihua, et al. 3rd ed. Beijing, China: Publishing House of Electronics Industry, 2016. ] | |
[2] | 李晶, 车效梅, 贾宏敏. 非洲城市化探析[J]. 现代城市研究, 2012, 27(2): 96-104. |
[Li Jing, Che Xiaomei, Jia Hongmin. Research on the status of urbanization in Africa. Modern Urban Research, 2012, 27(2): 96-104. ] | |
[3] | AfDB (African Development Bank), OECD (Organisation for Economic Co-operation and Development), UNDP (United Nations Development Programme). African economic outlook 2016: Sustainable cities and structural transformation[M]. France: OECD Publishing, 2016. |
[4] | 亚瑟·敏赛特. 中小城市是非洲可持续发展成败的关键[J]. 曹康, 刘梦琳, 译. 国际城市规划, 2018, 33(5): 1-28. |
[Minsat A. Small and intermediary cities will make or break the sustainable development goals in Africa. Translated by Cao Kang, Liu Menglin. Urban Planning International, 2018, 33(5): 1-28. ] | |
[5] | Angel S, Parent J, Civco D L, et al. A planet of cities:Urban land cover estimates and projections for all countries, 2000-2050[R]. Working Papers, No. WP10SA3. Cambridge, USA: Lincoln Institute of Land and Policy, 2010. |
[6] |
Peter L L, Yang Y Z. Urban planning historical review of master plans and the way towards a sustainable city: Dar es Salaam, Tanzania[J]. Frontiers of Architectural Research, 2019, 8(3): 359-377.
doi: 10.1016/j.foar.2019.01.008 |
[7] |
Fahmi F Z, Hudalah D, Rahayu P, et al. Extended urbanization in small and medium-sized cities: The case of Cirebon, Indonesia[J]. Habitat International, 2014, 42. doi: 10.1016/j.habitatint.2013.10.003.
doi: 10.1016/j.habitatint.2013.10.003 |
[8] | Setyono J S, Yunus H S, Giyarsih S R. The spatial pattern of urbanization and small cities development in central Java: A case study of Semarang-Yogyakarta-Surakarta region[J]. Geoplanning: Journal of Geomatics and Planning, 2016, 3(1): 53-66. |
[9] | 辜胜阻, 李华, 易善策. 均衡城镇化: 大都市与中小城市协调共进[J]. 人口研究, 2010, 34(5): 3-11. |
[Gu Shengzu, Li Hua, Yi Shance. Balancing urbanization by coordinated development between megacities and medium and small cities. Population Research, 2010, 34(5): 3-11. ] | |
[10] | 任致远. 试论我国大城市与中小城市发展走势[J]. 城市发展研究, 2010, 17(9): 1-7. |
[Ren Zhiyuan. On the trend of the development of great and small cities of China. Urban Development Studies, 2010, 17(9): 1-7. ] | |
[11] | 任航, 张振克, Priyanko Das, 等. 基于人口规模的肯尼亚城市体系演变及空间联系[J]. 经济地理, 2022, 42(5): 56-65. |
[Ren Hang, Zhang Zhenke, Das P, et al. Evolution characteristics of urban system and spatial connections of cities in Kenya based on population scale. Economic Geography, 2022, 42(5): 56-65. ] | |
[12] |
张家旗, 陈爽, Mapunda D W. 坦桑尼亚人口分布空间格局及演变特征[J]. 地理科学进展, 2017, 36(5): 610-617.
doi: 10.18306/dlkxjz.2017.05.008 |
[Zhang Jiaqi, Chen Shuang, Mapunda D W. Spatial pattern and its evolution of population in Tanzania. Progress in Geography, 2017, 36(5): 610-617. ]
doi: 10.18306/dlkxjz.2017.05.008 |
|
[13] |
金淑婷, 李博, 杨永春, 等. 中国城市分布特征及其影响因素[J]. 地理研究, 2015, 34(7): 1352-1366.
doi: 10.11821/dlyj201507014 |
[Jin Shuting, Li Bo, Yang Yongchun, et al. The distribution of cities in China and its influencing factors. Geographical Research, 2015, 34(7): 1352-1366. ]
doi: 10.11821/dlyj201507014 |
|
[14] | 郐艳丽. 东北地区城市空间形态研究[D]. 长春: 东北师范大学, 2004. |
[Kuai Yanli. A study on the spatial morphology of northeast cites. Changchun, China:: Northeast Normal University, 2004. ] | |
[15] |
孙斌栋, 金晓溪, 林杰. 走向大中小城市协调发展的中国新型城镇化格局: 1952年以来中国城市规模分布演化与影响因素[J]. 地理研究, 2019, 38(1): 75-84.
doi: 10.11821/dlyj020180443 |
[Sun Bindong, Jin Xiaoxi, Lin Jie. China's new pattern of urbanization toward coordinated development of large, medium and small cities: Evolution and determinants of city size distribution since 1952. Geographical Research, 2019, 38(1): 75-84. ]
doi: 10.11821/dlyj020180443 |
|
[16] | 高鸿鹰, 武康平. 我国城市规模分布Pareto指数测算及影响因素分析[J]. 数量经济技术经济研究, 2007(4): 43-52. |
[Gao Hongying, Wu Kangping. The estimates and the influential factors of the pareto exponent of city size distributions in China. The Journal of Quantitative & Technical Economics, 2007(4): 43-52. ] | |
[17] |
高超, 金凤君, 傅娟, 等. 1996—2011年南非人口空间分布格局与演变特征[J]. 地理科学进展, 2013, 32(7): 1167-1176.
doi: 10.11820/dlkxjz.2013.07.019 |
[Gao Chao, Jin Fengjun, Fu Juan, et al. Spatial pattern of population and its evolution in South Africa during 1996-2011. Progress in Geography, 2013, 32(7): 1167-1176. ]
doi: 10.11820/dlkxjz.2013.07.019 |
|
[18] |
Agyemang F S K, Silva E, Poku-Boansi M. Understanding the urban spatial structure of Sub-Saharan African cities using the case of urban development patterns of a Ghanaian city-region[J]. Habitat International, 2019, 85: 21-33.
doi: 10.1016/j.habitatint.2019.02.001 |
[19] | 张家旗, 陈爽, Mapunda D W. 坦桑尼亚城市体系演变与空间分布特征[J]. 世界地理研究, 2018, 27(1): 22-33. |
[Zhang Jiaqi, Chen Shuang, Mapunda D W. Evolution and spatial distribution of the urban system in Tanzania. World Regional Studies, 2018, 27(1): 22-33. ] | |
[20] | 刘振生, 高惠, 滕丽微, 等. 基于MAXENT模型的贺兰山岩羊生境适宜性评价[J]. 生态学报, 2013, 33(22): 7243-7249. |
[Liu Zhensheng, Gao Hui, Teng Liwei, et al. Habitat suitability assessment of blue sheep in Helan Mountain based on MAXENT modeling. Acta Ecologica Sinica, 2013, 33(22): 7243-7249. ]
doi: 10.5846/stxb201207221041 |
|
[21] | 车乐, 曹博, 白成科, 等. 基于MaxEnt和ArcGIS对太白米的潜在分布预测及适宜性评价[J]. 生态学杂志, 2014, 33(6): 1623-1628. |
[Che Le, Cao Bo, Bai Chengke, et al. Predictive distribution and habitat suitability assessment of Notholirion bulbuliferum based on MaxEnt and ArcGlS. Chinese Journal of Ecology, 2014, 33(6): 1623-1628. ] | |
[22] |
Banavar J R, Maritan A, Volkov I. Applications of the principle of maximum entropy: From physics to ecology[J]. Journal of Physics: Condensed Matter, 2010, 22(6): 063101. doi: 10.1088/0953-8984/22/6/063101.
doi: 10.1088/0953-8984/22/6/063101 |
[23] |
Dunne J A, Williams R J, Martinez N D. Food-web structure and network theory: The role of connectance and size[J]. PNAS, 2002, 99(20): 12917-12922.
doi: 10.1073/pnas.192407699 pmid: 12235364 |
[24] | 吴瑞婵, 甘淑, 于丽君, 等. 最大熵模型的巴基斯坦遗址预测分布研究[J]. 测绘科学, 2021, 46(3): 96-103. |
[Wu Ruichan, Gan Shu, Yu Lijun, et al. The study of predictive distribution of Pakistani sites based on Maxent model. Science of Surveying and Mapping, 2021, 46(3): 96-103. ] | |
[25] |
Song L Y, Zhang A. Predict the suitable places to run in the urban area of Beijing by using the maximum entropy model[J]. ISPRS International Journal of Geo-Information, 2021, 10(8): 534. doi: 10.3390/ijgi10080534.
doi: 10.3390/ijgi10080534 |
[26] |
Yan Y W, Kuo C L, Feng C C, et al. Coupling maximum entropy modeling with geotagged social media data to determine the geographic distribution of tourists[J]. International Journal of Geographical Information Science, 2018, 32(9): 1699-1736.
doi: 10.1080/13658816.2018.1458989 |
[27] |
Wachtel I, Zidon R, Shelach-Lavi G. Using the maximal entropy modeling approach to analyze the evolution of sedentary agricultural societies in Northeast China[J]. Entropy, 2020, 22(3): 307. doi: 10.3390/e22030307.
doi: 10.3390/e22030307 |
[28] |
Wang H J, Zhang B, Xia C, et al. Using a maximum entropy model to optimize the stochastic component of urban cellular automata models[J]. International Journal of Geographical Information Science, 2020, 34(5): 924-946.
doi: 10.1080/13658816.2019.1687898 |
[29] |
Cabrera J S, Lee H S. Flood risk assessment for Davao Oriental in the Philippines using geographic information system-based multi-criteria analysis and the maximum entropy model[J]. Journal of Flood Risk Management, 2020, 13(2): e12607. doi.org/10.1111/jfr3.12607.
doi: doi.org/10.1111/jfr3.12607 |
[30] |
Bajat B, Hengl T, Kilibarda M, et al. Mapping population change index in Southern Serbia (1961-2027) as a function of environmental factors[J]. Computers, Environment and Urban Systems, 2011, 35(1): 35-44.
doi: 10.1016/j.compenvurbsys.2010.09.005 |
[31] |
Cardona-Almeida C, Obregón N, Canales F A. An integrative dynamic model of Colombian population distribution, based on the maximum entropy principle and matter, energy, and information flow[J]. Entropy, 2019, 21(12): 1172. doi: 10.3390/e21121172.
doi: 10.3390/e21121172 |
[32] | 刘凌波, 彭正洪, 吴昊. 熵模型及其在城市研究中的应用[J]. 城市规划, 2021, 45(12): 27-39. |
[Liu Lingbo, Peng Zhenghong, Wu Hao. Entropy models and their application in urban studies. City Planning Review, 2021, 45(12): 27-39. ] | |
[33] | 姜忠尽, 王婵婵, 朱丽娜. 非洲城市化特征与驱动力因素浅析[J]. 西亚非洲, 2007(1): 21-26, 79. |
[Jiang Zhongjin, Wang Chanchan, Zhu Lina. The features of urbanization in Africa and its dynamic elements. West Asia and Africa, 2007(1): 21-26, 79. ] | |
[34] | UNDAES (United Nations Department of Economic and Social Affairs). World urbanization prospects 2018: Highlights[M]. New York, USA: United Nations, 2019. |
[35] | 国家发展改革委, 外交部, 商务部. 推动共建丝绸之路经济带和 21 世纪海上丝绸之路的愿景与行动[M]. 北京: 外交出版社, 2015. |
[National Development and Reform Commission, Ministry of Foreign Affairs, Ministry of Commerce of China, Vision and actions on jointly building Silk Road Economic Belt and 21st-century Mari-time Silk Road. Beijing, China: Foreign Languages Press, 2015. ] | |
[36] | 杨思灵, 高会平. “一带一路”: 中国与东非国家合作的挑战与路径[J]. 印度洋经济体研究, 2017(6): 15-27, 138. |
[Yang Siling, Gao Huiping. The Belt and Road Initiative: Challenges and cooperation between China and East African countries. Indian Ocean Economic and Political Review, 2017(6): 15-27, 138. ] | |
[37] | 杨郁卉. 非洲是建设“一带一路”的重要方向和落脚点[N]. 天津日报, 2016-08-29(9). |
[Yang Yuhui. Africa is an important direction and landing point for the construction of the Belt and Road Initiative. Tianjin Daily, 2016-08-29(9). ] | |
[38] |
Jaynes E T. Information theory and statistical mechanics[J]. Physical Review, 1957, 106: 620-630.
doi: 10.1103/PhysRev.106.620 |
[39] |
Phillips S J, Anderson R P, Schapire R E. Maximum entropy modeling of species geographic distributions[J]. Ecological Modelling, 2006, 190(3): 231-259.
doi: 10.1016/j.ecolmodel.2005.03.026 |
[40] |
Swets J A. Measuring the accuracy of diagnostic systems[J]. Science, 1988, 240: 1285-1293.
doi: 10.1126/science.3287615 pmid: 3287615 |
[41] | Abdallah Y B, 黄新民. 坦桑尼亚交通调查研究[J]. 中国商界, 2010(12): 444. |
[Abdallah Y B, Huang Xinmin. Tanzania traffic survey study. Business China, 2010(12): 444. ] |
|
