华北平原玉米播种期和品种变化对冠层温度的影响及地表生物物理机理

doi:10.18306/dlkxjz.2022.04.012

Abstract

Abstract:

By changing the surface energy and water exchange at the land-atmosphere interface, farmland management change becomes an important feedback process of climate change. The planting date and growing degree day of maize on the North China Plain have changed, which is a potential feedback process for regional climate by influencing leaf area index (LAI), surface albedo (α), net radiation (R_n), latent heat (LH), and canopy temperature (T_c). The SiBcrop model was used to simulate the seasonal dynamics of LAI, α, R_n, LH and T_c under three maize planting scenarios (spring maize, summer maize, and potential maize). The results show that spring maize had the characteristics of early planting, early harvest, and early LAI peak; summer maize was characterized by late planting, late harvest, and late LAI peak; potential maize was characterized by early planting, late harvest, and high LAI. The differences between the simulated scenarios were ±2.5 m²·m^-2 for LAI and ±0.5 ℃ for T_c. The main determinants of T_c difference between the three scenarios were α and surface energy partitioning. The cooling effect of delayed planting was dominated by the increased α; and the cooling effect of prolonged growing degree day was mainly due to the increased LH partitioning. Spring maize had the highest T_c, while summer maize and potential maize had lower T_c with little difference. The results of this study have certain significance for farmland management change for the adaptation to regional climate change and mitigation.

Key words: maize, agricultural phenology, SiBcrop, surface energy balance, North China Plain

LIU Fengshan, GE Quansheng, TAO Fulu, CAI Yangxing, BU Jianchao, BAI Nini. Impacts of maize planting date and variety on canopy temperature on the North China Plain and surface biophysical mechanism[J].PROGRESS IN GEOGRAPHY, 2022, 41(4): 682-692.

Figures/Tables 9

Fig.1

Tab.1

Tab.2

Tab.3

Fig.2

Fig.3

Tab.4

Fig.4

Tab.5

References 36

[1]	Mahmood R, Pielke Sr R A, Hubbard K G, et al. Land cover changes and their biogeophysical effects on climate[J]. International Journal of Climatology, 2014, 34(4): 929-953. doi: 10.1002/joc.3736
[2]	Erb K-H, Luyssaert S, Meyfroidt P, et al. Land management: Data availability and process understanding for global change studies[J]. Global Change Biology, 2017, 23(2): 512-533. doi: 10.1111/gcb.13443
[3]	Luyssaert S, Jammet M, Stoy P C, et al. Land management and land-cover change have impacts of similar magnitude on surface temperature[J]. Nature Climate Change, 2014, 4(5): 389-393. doi: 10.1038/nclimate2196
[4]	Davin E L, Seneviratne S I, Ciais P, et al. Preferential cooling of hot extremes from cropland albedo management[J]. PNAS, 2014, 111(27): 9757-9761. doi: 10.1073/pnas.1317323111
[5]	刘巽浩, 韩湘玲, 赵明斋, 等. 华北平原地区麦田两熟的光能利用、作物竞争与产量分析[J]. 作物学报, 1981, 7(1): 63-72.
	[ Liu Xunhao, Han Xiangling, Zhao Mingzhai, et al. Studies on solar energy utilization, crop competition and yield analysis in double cropped wheat fields in the North China Plain. Acta Agronomica Sinica, 1981, 7(1): 63-72. ]
[6]	Tao F L, Zhang S, Zhang Z, et al. Maize growing duration was prolonged across China in the past three decades under the combined effects of temperature, agronomic management, and cultivar shift[J]. Global Change Biology, 2014, 20(12): 3686-3699. doi: 10.1111/gcb.12684
[7]	Tao F L, Zhang S, Zhang Z. Spatiotemporal changes of wheat phenology in China under the effects of temperature, day length and cultivar thermal characteristics[J]. European Journal of Agronomy, 2012, 43: 201-212. doi: 10.1016/j.eja.2012.07.005
[8]	Sacks W J, Kucharik C J. Crop management and phenology trends in the US Corn Belt: Impacts on yields, evapotranspiration and energy balance[J]. Agricultural and Forest Meteorology, 2011, 151(7): 882-894. doi: 10.1016/j.agrformet.2011.02.010
[9]	刘凤山, 陈莹, 史文娇, 等. 农业物候动态对地表生物物理过程及气候的反馈研究进展[J]. 地理学报, 2017, 72(7): 1139-1150. doi: 10.11821/dlxb201707001
	[ Liu Fengshan, Chen Ying, Shi Wenjiao, et al. Influences of agricultural phenology dynamics on land surface biophysical processes and climate feedback: A review. Acta Geographica Sinica, 2017, 72(7): 1139-1150. ] doi: 10.11821/dlxb201707001
[10]	Zhang X Z, Tang Q H, Zheng J Y, et al. Warming/cooling effects of cropland greenness changes during 1982-2006 in the North China Plain[J]. Environmental Research Letters, 2013, 8(2): 024038. doi: 10.1088/1748-9326/8/2/024038. doi: 10.1088/1748-9326/8/2/024038
[11]	Ho C-H, Park S-J, Jeong S-J, et al. Observational evidences of double cropping impacts on the climate in the Northern China Plains[J]. Journal of Climate, 2012, 25(13): 4721-4728. doi: 10.1175/JCLI-D-11-00224.1
[12]	Bagley J E, Miller J, Bernacchi C J. Biophysical impacts of climate-smart agriculture in the Midwest United States[J]. Plant, Cell & Environment, 2015, 38(9): 1913-1930.
[13]	Oguntunde P G, van de Giesen N. Crop growth and development effects on surface albedo for maize and cowpea fields in Ghana, West Africa[J]. International Journal of Biometeorology, 2004, 49(2): 106-112. pmid: 15278686
[14]	Jeong S-J, Ho C-H, Piao S L, et al. Effects of double cropping on summer climate of the North China Plain and neighbouring regions[J]. Nature Climate Change, 2014, 4(7): 615-619. doi: 10.1038/nclimate2266
[15]	张雅芳, 郭英, 沈彦俊, 等. 华北平原种植结构变化对农业需水的影响[J]. 中国生态农业学报(中英文), 2020, 28(1): 8-16.
	[ Zhang Yafang, Guo Ying, Shen Yanjun, et al. Impact of planting structure changes on agricultural water requirement in North China Plain. Chinese Journal of Eco-Agriculture, 2020, 28(1): 8-16. ]
[16]	周广胜. 气候变化对中国农业生产影响研究展望[J]. 气象与环境科学, 2015, 38(1): 80-94.
	[ Zhou Guang-sheng. Research prospect on impact of climate change on agricultural production in China. Meteorological and Environmental Sciences, 2015, 38(1): 80-94. ]
[17]	周美君, 李飞, 邵佳琪, 等. 气候变化背景下中国玉米生产潜力变化特征[J]. 地理科学进展, 2020, 39(3): 443-453. doi: 10.18306/dlkxjz.2020.03.009
	[ Zhou Meijun, Li Fei, Shao Jiaqi, et al. Change characteristics of maize production potential under the background of climate change in China. Progress in Geography, 2020, 39(3): 443-453. ] doi: 10.18306/dlkxjz.2020.03.009
[18]	Liu F S, Chen Y, Bai N N, et al. Divergent climate feedbacks on winter wheat growing and dormancy periods as affected by sowing date in the North China Plain[J]. Biogeosciences, 2021, 18(7): 2275-2287. doi: 10.5194/bg-18-2275-2021
[19]	阿多, 熊凯, 赵文吉, 等. 1960-2013年华北平原气候变化时空特征及其对太阳活动和大气环境变化的响应[J]. 地理科学, 2016, 36(10): 1555-1564. doi: 10.13249/j.cnki.sgs.2016.10.013
	[ A Duo, Xiong Kai, Zhao Wenji, et al. Temporal trend of climate change and mutation analysis of North China Plain during 1960 to 2013. Scientia Geographica Sinica, 2016, 36(10): 1555-1564. ] doi: 10.13249/j.cnki.sgs.2016.10.013
[20]	史培军, 孙劭, 汪明, 等. 中国气候变化区划(1961-2010年)[J]. 中国科学: 地球科学, 2014, 44(10): 2294-2306.
	[ Shi Peijun, Sun Shao, Wang Ming, et al. Climate change regionalization in China (1961-2010). Scientia Sinica Terrae, 2014, 44(10): 2294-2306. ] doi: 10.1360/zd-2014-44-10-2294
[21]	Lokupitiya E, Denning S, Paustian K, et al. Incorporation of crop phenology in Simple Biosphere Model (SiBcrop) to improve land-atmosphere carbon exchanges from croplands[J]. Biogeosciences, 2009, 6(6): 969-986. doi: 10.5194/bg-6-969-2009
[22]	Liu F S, Chen Y, Xiao D P, et al. Modeling crop growth and land surface energy fluxes in wheat-maize double cropping system in the North China Plain[J]. Theoretical and Applied Climatology, 2020, 142: 959-970. doi: 10.1007/s00704-020-03353-7
[23]	Chen Y, Liu F S, Tao F L, et al. Calibration and validation of SiBcrop Model for simulating LAI and surface heat fluxes of winter wheat in the North China Plain[J]. Journal of Integrative Agriculture, 2020, 19(9): 2206-2215. doi: 10.1016/S2095-3119(20)63178-1
[24]	Farquhar G D, von Caemmerer S, Berry J A. A biochemical model of photosynthetic CO₂ assimilation in leaves of C₃ species[J]. Planta, 1980, 149(1): 78-90. doi: 10.1007/BF00386231 pmid: 24306196
[25]	Collatz G J, Berry J A, Farquhar G D, et al. The relationship between the Rubisco reaction mechanism and models of photosynthesis[J]. Plant Cell and Environment, 1990, 13(3): 219-225. doi: 10.1111/j.1365-3040.1990.tb01306.x
[26]	Song Y, Jain A K, McIsaac G F. Implementation of dynamic crop growth processes into a land surface model: Evaluation of energy, water and carbon fluxes under corn and soybean rotation[J]. Biogeosciences, 2013, 10(12): 8039-8066. doi: 10.5194/bg-10-8039-2013
[27]	Mo X G, Liu S X, Lin Z H. Evaluation of an ecosystem model for a wheat-maize double cropping system over the North China Plain[J]. Environmental Modelling & Software, 2012, 32: 61-73.
[28]	Boisier J P, Pitman A J, et al. Attributing the impacts of land-cover changes in temperate regions on surface temperature and heat fluxes to specific causes: Results from the first LUCID set of simulations[J]. Journal of Geophysical Research: Atmospheres, 2012, 117: D12116. doi: 10.1029/2011JD017106.
[29]	农业百科. 春玉米播种时间是什么时候, 如何确定播种日期[EB/OL]. 2020-11-11 [2021-01-23]. http://www.nongyie.com/zliangshiym/2020/49633.html .
	[ Agricultural encyclopedia. When is the sowing time of spring maize and how to determine the sowing date. 2020-11-11 [2021-01-23]. http://www.nongyie.com/zliangshiym/2020/49633.html . ]
[30]	Ge Q S, Zhang X Z, Zheng J Y. Simulated effects of vegetation increase/decrease on temperature changes from 1982 to 2000 across the Eastern China[J]. International Journal of Climatology, 2014, 34(1): 187-196. doi: 10.1002/joc.3677
[31]	O'Brien P L, Daigh A L M. Tillage practices alter the surface energy balance: A review[J]. Soil and Tillage Research, 2019, 195: 104354. doi: 10.1016/j.still.2019.104354. doi: 10.1016/j.still.2019.104354
[32]	牛萌萌, 方会敏, 荐世春, 等. 黄淮海东部小麦玉米周年全程机械化生产现状[J]. 农业工程, 2020, 10(10): 1-7.
	[ Niu Mengmeng, Fang Huimin, Jian Shichun, et al. Present situation of annual whole process mechanization of wheat and maize in east of Huanghuaihai Plain. Agricultural Engineering, 2020, 10(10): 1-7. ]
[33]	韩鲁佳, 闫巧娟, 刘向阳, 等. 中国农作物秸秆资源及其利用现状[J]. 农业工程学报, 2002, 18(3): 87-91.
	[ Han Lujia, Yan Qiaojuan, Liu Xiangyang, et al. Straw resources and their util ization in China. Transactions of the CSAE, 2002, 18(3): 87-91. ]
[34]	Liu Z J, Wu C Y, Liu Y S, et al. Spring green-up date derived from GIMMS3g and SPOT-VGT NDVI of winter wheat cropland in the North China Plain[J]. ISPRS Journal of Photogrammetry & Remote Sensing, 2017, 130: 81-91.
[35]	Xiao D P, Tao F L, Liu Y J, et al. Observed changes in winter wheat phenology in the North China Plain for 1981-2009 [J]. International Journal of Biometeorology, 2013, 57(2): 275-285. doi: 10.1007/s00484-012-0552-8
[36]	Bohm K, Ingwersen J, Milovac J, et al. Distinguishing between early- and late-covering crops in the land surface model Noah-MP: Impact on simulated surface energy fluxes and temperature[J]. Biogeosciences, 2020, 17(10): 2791-2805. doi: 10.5194/bg-17-2791-2020

站点	品种	观测时期	气温/℃	降水/mm	播种期(DOY)	收获期(DOY)	GDD/(℃·d)
宝坻	春玉米	1982—1997	23.6	514.3	133.6	259.8	2952.5
宝坻	夏玉米	1998—2009	24.2	340.7	166.6	272.8	2542.8
黄骅	夏玉米	1981—2009(1997)	25.4	340.6	170.0	259.2	2170.6
密云	春玉米	1981—1998(1988)	23.3	560.6	147.0	247.3	2844.2
密云	夏玉米	1999—2009	24.2	362.5	174.6	269.1	2253.6
南阳	夏玉米	1981—2009	25.8	409.9	160.0	259.0	2520.8
商丘	夏玉米	1981—2009	25.6	408.2	161.1	258.2	2455.6
唐山	春玉米	1981—1993(1986/1987/1989)	24.1	520.8	123.2	239.9	2670.8
唐山	夏玉米	1994—2009	23.1	374.7	174.4	277.4	2455.1
潍坊	春玉米	1984—2005	24.6	393.3	145.5	254.1	2644.4
潍坊	夏玉米	1986、1996、2006—2009	24.7	377.3	160.7	260.0	2422.6
新乡	夏玉米	1981—2009	25.9	341.2	158.7	257.1	2519.7
郑州	夏玉米	1981—2009(1992)	26.0	354.6	158.2	254.1	2464.3
驻马店	夏玉米	1990—2009	26.0	532.1	160.7	258.4	2505.1

模拟情景	参数		模拟时段
模拟情景	播种期	GDD/(℃·d)	模拟时段
春玉米	DOY≥136	2730	1980—2010年
夏玉米	DOY≥162	2730	1980—2010年
潜在玉米	DOY≥136	3036	1980—2010年

站点	春玉米(DOY)		夏玉米(DOY)		潜在玉米(DOY)
站点	播种期	收获期	播种期	收获期	播种期	收获期
宝坻	144	268	169	280	144	318
黄骅	144	265	170	280	144	315
密云	145	271	169	280	145	321
南阳	144	260	170	280	144	304
商丘	144	259	170	280	144	306
唐山	145	269	169	280	145	319
潍坊	145	267	170	280	145	317
新乡	144	256	169	280	144	305
郑州	144	261	170	280	144	311
驻马店	144	262	170	280	144	310

覆盖物	可见光波段	近红外波段
绿叶	0.08	0.30
作物土壤	0.11	0.314
裸露土壤	0.33	0.35

情景差异	参数	时期1	时期2	时期3	时期4	时期5	总体
春-夏	LAI/(m²·m^-2)	0.05	1.18	-1.27	-2.91	0.00	-0.59
	T_c/℃	0.49	-0.36	0.18	0.35	0.01	0.13
	R_n/(W·m^-2)	15.54	6.94	-5.56	-23.90	-0.07	-1.41
	LH/(W·m^-2)	6.07	9.10	-4.88	-13.22	0.41	-0.50
	SH/(W·m^-2)	7.76	-0.48	-1.78	-11.40	-0.17	-1.21
潜-春	LAI/(m²·m^-2)	0.06	0.98	1.74	2.43	1.47	1.34
	T_c/℃	-0.06	-0.17	-0.27	-0.21	0.09	-0.12
	R_n/(W·m^-2)	1.21	2.44	6.32	22.77	14.00	9.35
	LH/(W·m^-2)	1.27	3.10	4.83	11.16	3.75	4.82
	SH/(W·m^-2)	0.23	-0.11	2.12	11.28	9.49	4.60
潜-夏	LAI/(m²·m^-2)	0.11	2.16	0.46	-0.48	1.47	0.74
	T_c/℃	0.43	-0.53	-0.09	0.14	0.11	0.01
	R_n/(W·m^-2)	16.75	9.38	0.76	-1.13	13.93	7.94
	LH/(W·m^-2)	7.35	12.20	-0.06	-2.06	4.17	4.32
	SH/(W·m^-2)	7.99	-0.58	0.34	-0.12	9.32	3.39
