青海北川河流域径流变化的机理研究——基于模型和统计两种方法

doi:10.18306/dlkxjz.2022.02.010

Abstract

Abstract:

Climate change and land use/cover change (LUCC) are two major drivers that impact streamflow. Deconvolving the impacts of climate change and LUCC on streamflow will benefit local water resources management. In this study, two methods—the Budyko water balance method and the Distributed-Hydrology-Soil-Vegetation Model (DHSVM) coupled with a new reservoir regulation scheme—were used to deconvolve the impacts of climate change and LUCC on the streamflow in the Beichuan River Basin, Qinghai Province, to reduce uncertainty in the results inherited from the individual methods through cross examination. The study found that: 1) Streamflow at the basin outlet decreased at 0.037 m³/s per year in 1967-2019, and the abrupt change occurred in 1969. 2) Both methods agree that the relative impacts of the decadal climate change during the past five decades were in the order of 1990s > 2000s > 1970s > 1980s = 2010s, and LUCC was the dominant driver for streamflow reduction at the outlet for 1970-2019, with 94.58% and 65.68% contributions for the Budyko method and the DHSVM, respectively. 3) The Budyko method specializes in assessing the change of the entire river basin, while the distributed hydrologic modeling can efficiently describe the spatiotemporal heterogeneity of the impacts across the basin. The modeling showed that streamflow changes in the upstream and midstream was dominated by climate change, but downstream flow change was controlled by LUCC. Reservoir regulation exerted important impact on monthly streamflow. The possible reasons of the discrepancies in climate change and LUCC impacts estimated by the two methods were also discussed.

Key words: streamflow, climate change, land use/cover change, Budyko, DHSVM, reservoir regulation, Beichuan River Basin

LIU Zhe, CUO Lan. Investigating the mechanisms of streamflow change in the Beichuan River Basin, Qinghai Province: Based on modeling and statistic analyses[J].PROGRESS IN GEOGRAPHY, 2022, 41(2): 304-315.

Figures/Tables 9

Fig.1

Tab.1

Fig.2

Tab.2

Fig.3

Fig.4

Fig.5

Fig.6

Tab.3

References 53

[1]	Teuling A J, de Badts E A G, Jansen F A, et al. Climate change, reforestation/afforestation, and urbanization impacts on evapotranspiration and streamflow in Europe[J]. Hydrology and Earth System Sciences, 2019, 23(9):3631-3652. doi: 10.5194/hess-23-3631-2019
[2]	Henriques C, Garnett K, Weatherhead E K, et al. The future water environment: Using scenarios to explore the significant water management challenges in England and Wales to 2050[J]. Science of the Total Environment, 2015, 512/513:381-396. doi: 10.1016/j.scitotenv.2014.12.047
[3]	Milly P C D, Betancourt J, Falkenmark M, et al. Stationarity is dead: Whither water management?[J]. Science, 2008, 319:573-574. doi: 10.1126/science.1151915 pmid: 18239110
[4]	Wang D B, Hejazi M. Quantifying the relative contribution of the climate and direct human impacts on mean annual streamflow in the contiguous United States[J]. Water Resources Research, 2011, 47(10): W00J12. doi: 10.1029/2010WR010283. doi: 10.1029/2010WR010283
[5]	Milly P C D, Dunne K A, Vecchia A V. Global pattern of trends in streamflow and water availability in a changing climate[J]. Nature, 2005, 438:347-350. doi: 10.1038/nature04312
[6]	Bosch J M, Hewlett J D. A review of catchment experiments to determine the effect of vegetation changes on water yield and evapotranspiration[J]. Journal of Hydrology, 1982, 55:3-23. doi: 10.1016/0022-1694(82)90117-2
[7]	Brown A E, Zhang L, McMahon T A, et al. A review of paired catchment studies for determining changes in water yield resulting from alterations in vegetation[J]. Journal of Hydrology, 2005, 310(1-4):28-61. doi: 10.1016/j.jhydrol.2004.12.010
[8]	李丽娟, 姜德娟, 李九一, 等. 土地利用/覆被变化的水文效应研究进展[J]. 自然资源学报, 2007, 22(2):211-224.
	[ Li Lijuan, Jiang Dejuan, Li Jiuyi, et al. Advances in hydrological response to land use /land cover change. Journal of Natural Resources, 2007, 22(2):211-224. ]
[9]	Tang Q H, Oki T. Terrestrial water cycle and climate change: Natural and human-induced impacts[M]. New Jersey, USA: John Wiley & Sons, Inc., 2016: 103-134.
[10]	黄艳艳, 赵红莉, 蒋云钟, 等. 雅砻江上游径流及影响因素关系研究[J]. 干旱区地理, 2018, 41(1):127-133.
	[ Huang Yanyan, Zhao Hongli, Jiang Yunzhong, et al. Runoff and its influencing factors in the upper reaches of the Yalong River. Arid Land Geography, 2018, 41(1):127-133. ]
[11]	Gao P, Li P F, Zhao B L, et al. Use of double mass curves in hydrologic benefit evaluations[J]. Hydrological Processes, 2017, 31(26):4639-4646. doi: 10.1002/hyp.v31.26
[12]	Wang F Y, Duan K Q, Fu S Y, et al. Partitioning climate and human contributions to changes in mean annual streamflow based on the Budyko complementary relationship in the Loess Plateau, China[J]. Science of the Total Environment, 2019, 665:579-590. doi: 10.1016/j.scitotenv.2019.01.386
[13]	Dey P, Mishra A. Separating the impacts of climate change and human activities on streamflow: A review of methodologies and critical assumptions[J]. Journal of Hydrology, 2017, 548:278-290. doi: 10.1016/j.jhydrol.2017.03.014
[14]	Wang H N, Chen L H, Yu X X. Distinguishing human and climate influences on streamflow changes in Luan River Basin in China[J]. Catena, 2016, 136:182-188. doi: 10.1016/j.catena.2015.02.013
[15]	Cuo L, Zhang Y X, Gao Y H, et al. The impacts of climate change and land cover/use transition on the hydrology in the upper Yellow River Basin, China[J]. Journal of Hydrology, 2013, 502:37-52. doi: 10.1016/j.jhydrol.2013.08.003
[16]	孙赫, 苏凤阁. 雅鲁藏布江流域多源降水产品评估及其在水文模拟中的应用[J]. 地理科学进展, 2020, 39(7):1126-1139. doi: 10.18306/dlkxjz.2020.07.006
	[ Sun He, Su Fengge. Evaluation of multiple precipitation datasets and their potential utilities in hydrologic modeling over the Yarlung Zangbo River Basin. Progress in Geography, 2020, 39(7):1126-1139. ]
[17]	冯夏清, 章光新, 尹雄锐. 基于SWAT模型的乌裕尔河流域气候变化的水文响应[J]. 地理科学进展, 2010, 29(7):827-832.
	[ Feng Xiaqing, Zhang Guangxin, Yin Xiongrui. Study on the hydrological response to climate change in Wuyur River Basin based on the SWAT model. Progress in Geography, 2010, 29(7):827-832. ]
[18]	Bhatta B, Shrestha S, Shrestha P K, et al. Evaluation and application of a SWAT model to assess the climate change impact on the hydrology of the Himalayan River Basin[J]. Catena, 2019, 181:104082. doi: 10.1016/j.catena.2019.104082. doi: 10.1016/j.catena.2019.104082
[19]	Chang J X, Zhang H X, Wang Y M, et al. Impact of climate change on runoff and uncertainty analysis[J]. Natural Hazards, 2017, 88(2):1113-1131. doi: 10.1007/s11069-017-2909-0
[20]	Liu Z, Cuo L, Li Q J, et al. Impacts of climate change and land use/cover change on streamflow in Beichuan River Basin in Qinghai Province, China[J]. Water, 2020, 12(4):1198. doi: 10.3390/w12041198. doi: 10.3390/w12041198
[21]	Wu J W, Miao C Y, Wang Y M, et al. Contribution analysis of the long-term changes in seasonal runoff on the Loess Plateau, China, using eight Budyko-based methods[J]. Journal of Hydrology, 2017, 545:263-275. doi: 10.1016/j.jhydrol.2016.12.050
[22]	Ehsani N, Vörösmarty C J, Fekete B M, et al. Reservoir operations under climate change: Storage capacity options to mitigate risk[J]. Journal of Hydrology, 2017, 555:435-446. doi: 10.1016/j.jhydrol.2017.09.008
[23]	Gao B, Yang D W, Yang H B. Impact of the Three Gorges Dam on flow regime in the middle and lower Yangtze River[J]. Quaternary International, 2013, 304:43-50. doi: 10.1016/j.quaint.2012.11.023
[24]	Wurbs R. Water rights analysis package (WRAP) modeling system reference manual[M]. Texas, USA: Texas Water Resources Institute, 2012: 11-223.
[25]	Zhao G, Gao H L, Naz B S, et al. Integrating a reservoir regulation scheme into a spatially distributed hydrological model[J]. Advances in Water Resources, 2016, 98:16-31. doi: 10.1016/j.advwatres.2016.10.014
[26]	郭志云, 张宝元. 大通北川河源区自然保护区季节性冻土调查研究初探[J]. 青海农林科技, 2014(1):41-42.
	[ Guo Zhiyun, Zhang Baoyuan. Survey on seasonal frozen soil Heyuan District of Beichuan Nature Reserve. Science and Technology of Qinghai Agriculture and Forestry, 2014(1):41-42. ]
[27]	张建国, 武玉峰. 黑泉水库汇流区的基本特征与生态保护对策[J]. 青海环境, 2002, 12(4):149-151.
	[ Zhang Jianguo, Wu Yufeng. Basic characteristics and ecological protection countermeasures of Heiquan reservoir drainage basin. Journal of Qinghai Environment, 2002, 12(4):149-151. ]
[28]	Li L J, Zhang L, Wang H, et al. Assessing the impact of climate variability and human activities on streamflow from the Wuding River Basin in China[J]. Hydrological Processes, 2007, 21(25):3485-3491. doi: 10.1002/(ISSN)1099-1085
[29]	Liang L Q, Li L J, Liu Q. Temporal variation of reference evapotranspiration during 1961-2005 in the Taoer River Basin of Northeast China[J]. Agricultural and Forest Meteorology, 2010, 150(2):298-306. doi: 10.1016/j.agrformet.2009.11.014
[30]	Zhang X Z, Li P, Li D S. Spatiotemporal variations of precipitation in the southern part of the Heihe River Basin (China), 1984-2014[J]. Water, 2018, 10(4):410. doi: 10.3390/w10040410. doi: 10.3390/w10040410
[31]	Wang X B, He K N, Dong Z. Effects of climate change and human activities on runoff in the Beichuan River Basin in the northeastern Tibetan Plateau, China[J]. Catena, 2019, 176:81-93. doi: 10.1016/j.catena.2019.01.001
[32]	Cuo L, Zhang Y X, Wu Y Q, et al. Desertification affecting the Tibetan Plateau between 1971-2015: Viewed from a climate perspective[J]. Land Degradation & Development, 2020, 31(15):1956-1968. doi: 10.1002/ldr.v31.15
[33]	Ding J, Cuo L, Zhang Y X, et al. Monthly and annual temperature extremes and their changes on the Tibetan Plateau and its surroundings during 1963-2015[J]. Scientific Reports, 2018, 8:11860. doi: 10.1038/s41598-018-30320-0. doi: 10.1038/s41598-018-30320-0 pmid: 30089784
[34]	Budyko M I. Climate and life[M]. London, UK: Academic Press, 1974.
[35]	孟德娟, 莫兴国. 气候变化对不同气候区流域年径流影响的识别[J]. 地理科学进展, 2013, 32(4):587-594. doi: 10.11820/dlkxjz.2013.04.011
	[ Meng Dejuan, Mo Xingguo. Identification of impact of climate change on annual runoff in typical basins of different climate zones. Progress in Geography, 2013, 32(4):587-594. ]
[36]	Milly P C D. Climate, soil water storage, and the average annual water balance[J]. Water Resources Research, 1994, 30(7):2143-2156. doi: 10.1029/94WR00586
[37]	Zhang L, Dawes W R, Walker G R. Response of mean annual evapotranspiration to vegetation changes at catchment scale[J]. Water Resources Research, 2001, 37(3):701-708. doi: 10.1029/2000WR900325
[38]	Porporato A, Daly E, Rodriguez-Iturbe I. Soil water balance and ecosystem response to climate change[J]. The American Naturalist, 2004, 164(5):625-632. pmid: 15540152
[39]	Choudhury B J. Evaluation of an empirical equation for annual evaporation using field observations and results from a biophysical model[J]. Journal of Hydrology, 1999, 216(1/2):99-110. doi: 10.1016/S0022-1694(98)00293-5
[40]	Yang H B, Yang D W, Lei Z D, et al. New analytical derivation of the mean annual water‐energy balance equation[J]. Water Resources Research, 2008, 44(3):W03410. doi: 10.1029/2007WR006135. doi: 10.1029/2007WR006135
[41]	Wigmosta M S, Vail L W, Lettenmaier D P. A distributed hydrology‐vegetation model for complex terrain[J]. Water resources research, 1994, 30(6):1665-1679. doi: 10.1029/94WR00436
[42]	Cuo L, Lettenmaier D P, Alberti M, et al. Effects of a century of land cover and climate change on the hydrology of the Puget Sound Basin[J]. Hydrological Processes, 2009, 23(6):907-933. doi: 10.1002/hyp.v23:6
[43]	Elsner M M, Cuo L, Voisin N, et al. Implications of 21st century climate change for the hydrology of Washington State[J]. Climatic Change, 2010, 102(1/2):225-260. doi: 10.1007/s10584-010-9855-0
[44]	Burges S J, Wigmosta M S, Meena J M. Hydrological effects of land-use change in a zero-order catchment[J]. Journal of Hydrologic Engineering, 1998, 3(2):86-97. doi: 10.1061/(ASCE)1084-0699(1998)3:2(86)
[45]	Cuo L, Beyene T K, Voisin N, et al. Effects of mid-twenty-first century climate and land cover change on the hydrology of the Puget Sound Basin, Washington[J]. Hydrological Processes, 2011, 25(11):1729-1753. doi: 10.1002/hyp.v25.11
[46]	Cuo L, Lettenmaier D P, Mattheussen B V, et al. Hydrologic prediction for urban watersheds with the Distributed Hydrology-Soil-Vegetation Model[J]. Hydrological Processes, 2008, 22(21):4205-4213. doi: 10.1002/hyp.v22:21
[47]	Zhao G, Gao H, Cuo L. Effects of urbanization and climate change on peak flows over the San Antonio River Basin, Texas[J]. Journal of Hydrometeorology, 2016, 17(9):2371-2389. doi: 10.1175/JHM-D-15-0216.1
[48]	Sun N, Yearsley J, Voisin N, et al. A spatially distributed model for the assessment of land use impacts on stream temperature in small urban watersheds[J]. Hydrological Processes, 2015, 29(10):2331-2345. doi: 10.1002/hyp.10363
[49]	Sun N, Yearsley J, Baptiste M, et al. A spatially distributed model for assessment of the effects of changing land use and climate on urban stream quality[J]. Hydrological Processes, 2016, 30(25):4779-4798. doi: 10.1002/hyp.v30.25
[50]	Doten C O, Bowling L C, Lanini J S, et al. A spatially distributed model for the dynamic prediction of sediment erosion and transport in mountainous forested watersheds[J]. Water Resources Research, 2006, 42(4):W04417. doi: 10.1029/2004WR003829. doi: 10.1029/2004WR003829
[51]	Moriasi D N, Arnold J G, Van Liew M W, et al. Model evaluation guidelines for systematic quantification of accuracy in watershed simulations[J]. Transactions of the ASABE, 2007, 50(3):885-900. doi: 10.13031/2013.23153
[52]	Beven K. A manifesto for the equifinality journal[J]. Journal of Hydrology, 2006, 320(1/2):18-36. doi: 10.1016/j.jhydrol.2005.07.007
[53]	徐宗学. 水文模型:回顾与展望[J]. 北京师范大学学报(自然科学版), 2010, 46(3):278-289.
	[ Xu Zongxue. Hydrological models: Past, present and future. Journal of Beijing Normal University (Natural Science), 2010, 46(3):278-289. ]

类型	站点	纬度/(°)	经度/(°)	海拔/m	数据类型	时段	数据来源	备注
气象站	门源(MY)	37.38	101.62	2938	最高气温、最低气温、降水、风速、相对湿度	1960—2019年	青海省气象局	相对湿度(2000—2019年)
	大通(DT)	36.95	101.68	2459	最高气温、最低气温、降水、风速、相对湿度	1960—2019年	青海省气象局
水文站	牛场(NC)	37.25	101.36	3004	降水、流量	2002—2019年	青海省水文水资源勘测局	降水(1976—2019年)
	黑林(HL)	37.08	101.4	2756	降水、流量	1981—2019年	青海省水文水资源勘测局
	峡门(XM)	37.08	101.57	2618	降水、流量	1966—2000年	青海省水文水资源勘测局
	桥头(QT)	36.93	101.69	2442	降水、流量	1960—2019年	青海省水文水资源勘测局

站点		牛场 (率定期)	峡门 (验证期)	黑林 (验证期)
时段		2002—2019年	1966—1975年	1980—1988年
实测流量/(m³/s)		8.05	11.60	2.46
模拟流量/(m³/s)		7.76	12.59	2.58
E_ns	日尺度	0.65	0.56	0.53
	月尺度	0.86	0.79	0.79
RSR	日尺度	0.59	0.67	0.69
	月尺度	0.38	0.45	0.46
E_r/%		-3.61	8.55	4.99

月份	总径流量变化/mm	气候变化影响/%	下垫面变化影响
月份	总径流量变化/mm	气候变化影响/%	土地覆盖变化影响/%	水库调节影响/%	两者影响之和/%
1	3.39	2.29	-10.71	108.42	97.71
2	3.19	2.60	-9.38	106.79	97.40
3	2.91	15.00	-14.04	99.04	85.00
4	1.94	54.67	-43.18	88.51	45.33
5	-7.78	66.33	27.53	6.14	33.67
6	-5.40	-15.03	58.04	56.99	115.03
7	-7.80	-3.32	39.06	64.25	103.32
8	-16.08	50.90	18.25	30.85	49.10
9	-5.28	-64.24	65.29	98.96	164.24
10	-4.96	49.20	41.30	9.50	50.80
11	1.25	-56.56	-68.24	224.80	156.56
12	3.07	-3.76	-16.46	120.22	103.76

Investigating the mechanisms of streamflow change in the Beichuan River Basin, Qinghai Province: Based on modeling and statistic analyses
