基于野外控制试验的不同持续时间干旱对喀斯特溶蚀的影响研究

doi:10.18306/dlkxjz.2021.10.008

Abstract

Abstract:

Karst dissolution is one of the most fundamental processes in the karst area, which is closely related to water and extremely prone to the impact of drought. Previous studies have shown that drought has a significant impact on karst dissolution. However, the magnitude of drought impact is unclear, especially the karst dissolution loss caused by different intensities of drought. The present study used a field control test to quantify the effects of 12 different drought durations on karst dissolution for the forest, shrub grassland, and cropland in central Guizhou Province using the standard carbonate tablets method. We also analyzed the drought influence mechanism of karst dissolution. The results show that drought has caused enormous karst dissolution loss and the loss percentage ranges from 30.61% to 83.33% for the forest area, 38.45% to 88.82% for shrub grassland, and 66.76% to 95.14% for cropland, respectively. According to the loss data of different soil layers, the deeper soil layers have higher karst dissolution loss under the impact of shorter duration drought, while the surface soil layers have lower karst dissolution loss. However, under the influence of more prolonged drought, the karst dissolution loss of surface soil layers is higher than the deeper soil layers. The mechanism of influence of drought indicates that soil moisture was the leading cause of karst dissolution loss, which plays a crucial role in karst dissolution loss caused by drought.

Key words: drought, different durations, karst dissolution, loss, field control test, standard carbonate tablets

LI Kaizhong, XU Zhongchun, LV Xiaoxi, DONG Yingping, WANG Hengsong. Quantifying the effect of drought with different durations on karst dissolution based on field control test[J].PROGRESS IN GEOGRAPHY, 2021, 40(10): 1704-1715.

Figures/Tables 9

Fig.1

Fig.2

Tab.1

Fig.3

Tab.2

Tab.3

Fig.4

Fig.5

Tab.4

References 38

[1]	任美锷, 刘振中. 岩溶学概论[M]. 北京: 商务印书馆, 1983.
	[ Ren Mei'e, Liu Zhenzhong. Introduction to karst. Beijing, China: The Commercial Press, 1983. ]
[2]	Ford D, Williams P. Karst hydrogeology and geomorphology[M]. Chichester, UK: John Wiley & Sons, 2007.
[3]	袁道先, 蒋勇军, 沈立成, 等. 现代岩溶学[M]. 北京: 科学出版社, 2016.
	[ Yuan Daoxian, Jiang Yongjun, Shen Licheng, et al. Modern karst. Beijing, China: Science Press, 2016. ]
[4]	袁道先. 碳循环与全球岩溶[J]. 第四纪研究, 1993, 13(1):1-6.
	[ Yuan Daoxian. Carbon cycle and global karst. Quaternary Sciences, 1993, 13(1):1-6. ]
[5]	Dreybrodt W. The role of dissolution kinetics in the development of karst aquifers in limestone: A model simulation of karst evolution[J]. The Journal of Geology, 1990, 98(5):639-655. doi: 10.1086/629431
[6]	Goudie A S, Viles H A. Weathering and the global carbon cycle: Geomorphological perspectives[J]. Earth-Science Reviews, 2012, 113(1/2):59-71. doi: 10.1016/j.earscirev.2012.03.005
[7]	Zeng S B, Liu Z H, Kaufmann G. Sensitivity of the global carbonate weathering carbon-sink flux to climate and land-use changes[J]. Nature Communications, 2019, 10:5749. doi: 10.1038/s41467-019-13772-4. doi: 10.1038/s41467-019-13772-4
[8]	李朝君, 王世杰, 白晓永, 等. 全球主要河流流域碳酸盐岩风化碳汇评估[J]. 地理学报, 2019, 74(7):1319-1332. doi: 10.11821/dlxb201907004
	[ Li Chaojun, Wang Shijie, Bai Xiaoyong, et al. Estimation of carbonate rock weathering-related carbon sink in global major river basins. Acta Geographica Sinica, 2019, 74(7):1319-1332. ]
[9]	刘再华. 岩石风化碳汇研究的最新进展和展望[J]. 科学通报, 2012, 57(2/3):95-102.
	[ Liu Zaihua. New progress and prospects in the study of rock-weathering-related carbon sinks. Chinese Science Bulletin, 2012, 57(2/3):95-102. ]
[10]	曹建华, 杨慧, 康志强. 区域碳酸盐岩溶蚀作用碳汇通量估算初探: 以珠江流域为例[J]. 科学通报, 2011, 56(26):2181-2187.
	[ Cao Jianhua, Yang Hui, Kang Zhiqiang. Preliminary regional estimation of carbon sink flux by carbonate rock corrosion: A case study of the Pearl River Basin. Chinese Science Bulletin, 2011, 56(26):2181-2187. ]
[11]	Day M. Carbonate erosion rates in southwestern Wisconsin[J]. Physical Geography, 1984, 5(2):142-149. doi: 10.1080/02723646.1984.10642249
[12]	袁道先, 蔡桂鸿. 岩溶环境学[M]. 重庆: 重庆出版社, 1988.
	[ Yuan Daoxian, Cai Guihong. The science of karst environment. Chongqing, China: Chongqing Publishing Group, 1988. ]
[13]	Krklec K, Domínguez-Villar D, Perica D. Use of rock tablet method to measure rock weathering and landscape denudation[J]. Earth-Science Reviews, 2021, 212:103449. doi: 10.1016/j.earscirev.2020.103449. doi: 10.1016/j.earscirev.2020.103449
[14]	Plan L. Factors controlling carbonate dissolution rates quantified in a field test in the Austrian Alps[J]. Geomorphology, 2005, 68(3/4):201-212. doi: 10.1016/j.geomorph.2004.11.014
[15]	章程, 谢运球, 吕勇, 等. 不同土地利用方式对岩溶作用的影响: 以广西弄拉峰丛洼地岩溶系统为例[J]. 地理学报, 2006, 61(11):1181-1188.
	[ Zhang Cheng, Xie Yunqiu, Lv Yong, et al. Impact of land-use patterns upon Karst processes: Taking Nongla Fengcong depression area in Guangxi as an example. Acta Geographica Sinica, 2006, 61(11):1181-1188. ]
[16]	王冬银, 章程, 谢世友, 等. 亚高山不同植被类型区的雨季岩溶溶蚀速率研究[J]. 地球学报, 2007, 28(5):488-495.
	[ Wang Dongyin, Zhang Cheng, Xie Shiyou, et al. Karst dissolution rates of areas with different vegetation types in the sub-mountain region. Acta Geoscientica Sinica, 2007, 28(5):488-495. ]
[17]	王冬银, 谢世友, 章程. 典型岩溶区不同土地利用方式下雨季、旱季岩溶作用研究[J]. 生态环境学报, 2009, 18(6):2366-2372.
	[ Wang Dongyin, Xie Shiyou, Zhang Cheng. Impact of land-use patterns upon Karst processes in typical karst regions of Jinfo Mountain. Ecology and Environmental Sciences, 2009, 18(6):2366-2372. ]
[18]	章程. 不同土地利用土下溶蚀速率季节差异及其影响因素: 以重庆金佛山为例[J]. 地质论评, 2010, 56(1):136-140.
	[ Zhang Cheng. Seasonal variation of dissolution rate under the soil at different land uses and its influence factors: A case study of Jinfo Mountain, Chongqing. Geological Review, 2010, 56(1):136-140. ]
[19]	李光超, 张春来, 杨慧, 等. 典型岩溶区旱季板栗树下岩溶溶蚀速率的研究[J]. 地球与环境, 2012, 40(4):512-516.
	[ Li Guangchao, Zhang Chunlai, Yang Hui, et al. Study on karst processes under Castanea mollissima trees at dry season in typical karst areas. Earth and Environment, 2012, 40(4):512-516. ]
[20]	刘文, 张强, 贾亚男. 夏季不同土地利用方式下的溶蚀作用研究: 以重庆青木关岩溶槽谷区为例[J]. 中国岩溶, 2012, 31(1):1-6.
	[ Liu Wen, Zhang Qiang, Jia Yanan. Karstification under different land-use patterns in summer: A case study in the Qingmuguan karst valley, Chongqing. Carsologica Sinica, 2012, 31(1):1-6. ]
[21]	Qiu J. China drought highlights future climate threats[J]. Nature, 2010, 465:142-143. doi: 10.1038/465142a
[22]	Dai A G. Increasing drought under global warming in observations and models[J]. Nature Climate Change, 2013, 3(1):52-58. doi: 10.1038/nclimate1633
[23]	Naumann G, Alfieri L, Wyser K, et al. Global changes in drought conditions under different levels of warming[J]. Geophysical Research Letters, 2018, 45(7):3285-3296. doi: 10.1002/grl.v45.7
[24]	Gabrovšek F. On concepts and methods for the estimation of dissolutional denudation rates in karst areas[J]. Geomorphology, 2009, 106(1/2):9-14. doi: 10.1016/j.geomorph.2008.09.008
[25]	刘再华. 岩溶作用及其碳汇强度计算的“入渗-平衡化学法”: 兼论水化学径流法和溶蚀试片法[J]. 中国岩溶, 2011, 30(4):379-382.
	[ Liu Zaihua. "Method of maximum potential dissolution" to calculate the intensity of Karst process and the relevant carbon sink: With discussions on methods of solute load and carbonate-rock-tablet test. Carsologica Sinica, 2011, 30(4):379-382. ]
[26]	王兴山, 张捷, 秦中. 岩石侵蚀速率测算方法研究综述及展望[J]. 地球科学进展, 2013, 28(4):447-454.
	[ Wang Xingshan, Zhang Jie, Qin Zhong. Methods for measuring erosion rate of rock: An overview. Advances in Earth Science, 2013, 28(4):447-454. ]
[27]	Dixon J C, Thorn C E, Darmody R G, et al. Weathering rates of fine pebbles at the soil surface in Kärkevagge, Swedish Lapland[J]. Catena, 2001, 45(4):273-286. doi: 10.1016/S0341-8162(01)00152-7
[28]	Moses C, Robinson D, Barlow J. Methods for measuring rock surface weathering and erosion: A critical review[J]. Earth-Science Reviews, 2014, 135:141-161. doi: 10.1016/j.earscirev.2014.04.006
[29]	袁道先. 中国西南部的岩溶及其与华北岩溶的对比[J]. 第四纪研究, 1992, 12(4):352-361.
	[ Yuan Daoxian. Karst in southwest China and its comparison with Karst in North China. Quaternary Sciences, 1992, 12(4):352-361. ]
[30]	袁道先. 岩溶与全球变化研究[J]. 地球科学进展, 1995, 10(5):471-474.
	[ Yuan Daoxian. Karst and global change. Advances in Earth Science, 1995, 10(5):471-474. ]
[31]	Jiang Z C, Lian Y Q, Qin X Q. Rocky desertification in Southwest China: Impacts, causes, and restoration[J]. Earth-Science Reviews, 2014, 132:1-12. doi: 10.1016/j.earscirev.2014.01.005
[32]	贺晋云, 张明军, 王鹏, 等. 近50年西南地区极端干旱气候变化特征[J]. 地理学报, 2011, 66(9):1179-1190.
	[ He Jinyun, Zhang Mingjun, Wang Peng, et al. Climate characteristics of the extreme drought events in Southwest China during recent 50 years. Acta Geographica Sinica, 2011, 66(9):1179-1190. ]
[33]	Lin W, Wen C, Wen Z, et al. Drought in Southwest China: A review[J]. Atmospheric and Oceanic Science Letters, 2015, 8(6):339-344.
[34]	Han L Y, Zhang Q, Ma P L, et al. The spatial distribution characteristics of a comprehensive drought risk index in southwestern China and underlying causes[J]. Theoretical and Applied Climatology, 2016, 124:517-528. doi: 10.1007/s00704-015-1432-z
[35]	Chen Y, Zhai P. Changing structure of wet periods across southwest China during 1961-2012[J]. Climate Research, 2014, 61(2):123-131. doi: 10.3354/cr01247
[36]	Liu B J, Li Y, Chen J F, et al. Long-term change in precipitation structure over the Karst area of Southwest China[J]. International Journal of Climatology, 2016, 36(6):2417-2434. doi: 10.1002/joc.4501
[37]	Zhang C, Pei J G, Xie Y Q, et al. Impact of land use covers upon karst processes in a typical Fengcong depression system of Nongla, Guangxi, China[J]. Environmental Geology, 2008, 55(8):1621-1626. doi: 10.1007/s00254-007-1111-1
[38]	李涛, 赵东兴, 张美良, 等. 土壤CO₂、土壤水的动态特征及其对岩溶作用的驱动[J]. 热带地理, 2013, 33(5):575-581.
	[ Li Tao, Zhao Dongxing, Zhang Meiliang, et al. Dynamic characteristics of the soil CO₂ and soil water chemistry, and their driving action on karstification. Tropical Geography, 2013, 33(5):575-581. ]

干旱持续时间/月	自然溶蚀/(mg/cm²)			干旱溶蚀/(mg/cm²)			数量损失/(mg/cm²)			损失比重/%
干旱持续时间/月	林地	灌草地	耕地	林地	灌草地	耕地	林地	灌草地	耕地	林地	灌草地	耕地
1	0.1199	0.1649	0.3436	0.0772	0.1015	0.1142	0.0427	0.0634	0.2294	35.61	38.45	66.76
2	0.2052	0.3782	0.5903	0.1279	0.1464	0.1372	0.0773	0.2318	0.4531	37.67	61.29	76.76
3	0.2410	0.3413	0.7022	0.1499	0.0830	0.1303	0.0911	0.2583	0.5719	37.80	75.68	81.44
4	0.2410	0.3874	0.8509	0.1269	0.0599	0.1199	0.1141	0.3275	0.7310	47.34	84.54	85.91
5	0.2525	0.4600	1.0769	0.1752	0.1049	0.1015	0.0773	0.3551	0.9754	30.61	77.20	90.57
6	0.4451	0.5096	1.5416	0.1442	0.1718	0.1269	0.3009	0.3378	1.4147	67.60	66.29	91.77
7	0.5327	0.5534	1.9912	0.0888	0.1199	0.0968	0.4439	0.4335	1.8944	83.33	78.33	95.14
8	0.6053	0.6042	2.2357	0.1072	0.1292	0.1361	0.4981	0.4750	2.0996	82.29	78.62	93.91
9	0.7541	0.6192	2.5251	0.1638	0.0692	0.1269	0.5903	0.5500	2.3982	78.28	88.82	94.97
10	0.8694	0.8417	3.1154	0.1591	0.1245	0.1995	0.7103	0.7172	2.9159	81.70	85.21	93.60
11	0.9351	1.1657	3.4671	0.1868	0.1418	0.1937	0.7483	1.0239	3.2734	80.02	87.84	94.41
12	0.9639	1.2475	3.9202	0.2271	0.1441	0.2156	0.7368	1.1034	3.7046	76.44	88.45	94.50

干旱持续时间/月	林地溶蚀损失			灌草地溶蚀损失			耕地溶蚀损失
干旱持续时间/月	-5 cm	-25 cm	-45 cm	-5 cm	-25 cm	-45 cm	-5 cm	-25 cm	-45 cm
1	0.0069	0.0553	0.0657	0.0450	0.0657	0.0796	0.2836	0.1937	0.2110
2	0.0173	0.0761	0.1384	0.1937	0.2110	0.2906	0.4358	0.4012	0.5223
3	0.0450	0.1280	0.1003	0.2767	0.2145	0.2836	0.5327	0.6607	0.5223
4	0.0380	0.0934	0.2110	0.3079	0.3597	0.3148	0.6468	0.6849	0.8613
5	0.0519	0.0208	0.1591	0.2283	0.4116	0.4255	0.8751	0.9651	1.0861
6	0.1557	0.3874	0.3597	0.3874	0.2940	0.3321	1.4459	1.3559	1.4424
7	0.4531	0.3736	0.5050	0.4566	0.3563	0.4877	1.5808	1.9094	2.1930
8	0.3978	0.5361	0.5604	0.5119	0.3978	0.5154	1.8333	2.0927	2.3729
9	0.5119	0.5569	0.7022	0.6399	0.4635	0.5465	1.8298	2.0927	3.2722
10	0.6883	0.7437	0.6987	0.7817	0.6607	0.7091	2.4697	2.4732	3.8049
11	0.7299	0.5431	0.9720	1.3974	0.8648	0.8094	3.2722	2.8191	3.7288
12	0.7091	0.4946	1.0066	1.3801	1.1207	0.8094	3.7738	3.0854	4.2546

干旱持续时间/月	林地溶蚀损失			灌草地溶蚀损失			耕地溶蚀损失
干旱持续时间/月	-5 cm	-25 cm	-45 cm	-5 cm	-25 cm	-45 cm	-5 cm	-25 cm	-45 cm
1	9.09	42.11	43.18	28.89	45.24	41.07	66.13	65.12	69.32
2	9.62	44.00	52.63	56.00	56.48	70.00	72.83	77.85	79.47
3	29.55	44.05	35.80	78.43	66.67	81.19	79.79	84.51	79.47
4	21.15	39.71	68.54	84.76	83.87	85.05	84.62	85.34	87.37
5	23.08	10.34	47.92	68.04	83.22	77.36	91.01	90.58	90.23
6	55.56	74.67	67.10	70.44	63.91	64.00	94.78	90.95	89.68
7	82.91	75.00	91.25	81.48	70.07	82.46	96.82	95.83	93.37
8	82.14	89.08	76.78	87.57	70.55	77.60	96.54	93.36	92.45
9	81.32	72.85	80.88	96.35	84.81	84.49	96.01	94.53	94.69
10	84.68	80.52	80.16	85.61	84.89	85.06	95.58	93.96	92.13
11	80.84	73.02	83.88	91.40	86.81	83.27	95.75	94.77	93.01
12	77.65	66.51	81.51	92.15	88.77	82.39	96.04	94.49	93.18

土地类型	喀斯特溶蚀损失			土壤水分		土壤pH
土地类型	土壤水分	土壤pH	土壤有机质	土壤pH	土壤有机质	土壤有机质
林地	-0.628^*	0.413	-0.513	-0.570^*	0.307	-0.330
灌草地	-0.455	0.467	-0.627^*	-0.573^*	-0.038	-0.055
耕地	-0.605^*	0.699^**	-0.781^**	-0.907^**	0.769^**	-0.805^**
