轨道站点周边建成环境对残疾人出行行为的影响研究——以武汉市189个轨道站点为例

doi:10.18306/dlkxjz.2021.07.005

Abstract

Abstract:

Mobility of persons with disabilities is an important aspect of equality of societies. Due to their special physical and socioeconomic conditions, the travel behavior of persons with disabilities has unique characteristics and is more susceptible to the impact of the built environment. Based on the smart card data of Wuhan rail transit, this study explored the spatial and temporal characteristics of rail transit trips of persons with disabilities in Wuhan City, and further explored the spatial heterogeneity of the impact of the built environment around rail transit stations on the passenger flow of persons with disabilities by using the geographically weighted regression (GWR) model. The findings are as follows: 1) 29.7% of the persons with disabilities who travel by subway show the characteristics of commuting, the frequency of travel on working days is higher than that on nonworking days, and they all show the trend of off-peak travel in the mornings and evenings. 2) Traveling is mostly within the short and medium distance of 15-30 minutes, and the range of activities is concentrated in the main city within the Third Ring Road, with the most frequent trips in the same area and few trips across the river. 3) In most research areas, bus stop density, road density, and large park density and opening time all have positive influence on the ridership of persons with disabilities. 4) The daily average ridership of persons with disabilities in transfer stations is significantly higher than that in non-transfer stations. 5) Different from the conclusions of previous studies, the mixed degree of land use and barrier-free facilities have no significant influence on the ridership of persons with disabilities. The result of this research can provide data support for the optimization of the built environment of disability-friendly subway stations and the land use of new stations, and enhance the people-oriented development of urban public services.

Key words: rail transit stations, built environment, persons with disabilities, travel behavior, geographically weighted regression, Wuhan City

WANG Anqi, PENG Jiandong, REN Peng, YANG Hong, DAI Qi. Impact of the built environment of rail transit stations on the travel behavior of persons with disabilities: Taking 189 rail transit stations in Wuhan City as an example[J].PROGRESS IN GEOGRAPHY, 2021, 40(7): 1127-1140.

Figures/Tables 15

Fig.1

Tab.1

Tab.2

Variables of the multinomial regression model

分类	指标	指标计算与解释
土地利用模式	站点距中央商务区距离	—
土地利用模式	土地利用混合度	土地利用混合度熵值： $S = - ∑ i = 1 n p i × lg p i$ S为土地利用混合程度熵值;n为土地利用类型的划分数目;p_i是第i类土地面积所占比例, $∑ i = 1 n p i = 1$
站点可达性	公交站点密度	站点480 m圆形范围内公交站个数与范围总面积之比(个/m²)
	路网密度	站点480 m圆形范围内道路长度与范围总面积之比(m/m²)
	交叉口数量	站点480 m圆形范围内交叉口个数(个)
轨道站点特征	轨道站点开通时间	—
	是否属于换乘站	是记为1;否记为0
	站点出入口个数	—
	无障碍设施及指示系统	包括：是否有坡道;坡道是否可用;无障碍直梯是否可用;盲道是否连续;是否有无障碍指示系统等。是记为1;否记为0
公共服务设施布局	站点范围内医疗机构数量站点周边范围内大型公园数量站点周边范围内文化休闲场所数量站点周边范围内大型购物中心数量站点周边范围内公司企业数量	—

Tab.2

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Tab.3

Tab.4

Tab.5

Tab.6

Fig.9

References 41

[1]	Bombom L S, Abdullahi I. Travel patterns and challenges of physically disabled persons in Nigeria[J]. GeoJournal, 2016, 81(4):519-533. doi: 10.1007/s10708-015-9629-3
[2]	Krahn G L. WHO world report on disability: A review[J]. Disability and Health Journal, 2011, 4(3):141-142. doi: 10.1016/j.dhjo.2011.05.001
[3]	Ewing R, Cervero R. Travel and the built environment[J]. Journal of the American Planning Association, 2010, 76(3):265-294. doi: 10.1080/01944361003766766
[4]	Wu L L, Wang W, Jing P, et al. Travel mode choice and their impacts on environment: A literature review based on bibliometric and content analysis, 2000-2018[J]. Journal of Cleaner Production, 2020, 249:119391. doi: 10.1016/j.jclepro.2019.119391. doi: 10.1016/j.jclepro.2019.119391
[5]	冯建喜, 杨振山. 南京市城市老年人出行行为的影响因素[J]. 地理科学进展, 2015, 34(12):1598-1608. doi: 10.18306/dlkxjz.2015.12.008
	[ Feng Jianxi, Yang Zhenshan. Factors influencing travel behavior of urban elderly people in Nanjing. Progress in Geography, 2015, 34(12):1598-1608. ]
[6]	Ermagun A, Hajivosough S, Samimi A, et al. A joint model for trip purpose and escorting patterns of the disabled[J]. Travel Behaviour and Society, 2016, 3:51-58. doi: 10.1016/j.tbs.2015.08.002
[7]	Alzouby A M, Nusair A A, Taha L M. GIS based multi criteria decision analysis for analyzing accessibility of the disabled in the greater Irbid municipality area, Irbid, Jordan[J]. Alexandria Engineering Journal, 2019, 58(2):689-698. doi: 10.1016/j.aej.2019.05.015
[8]	Lucas K, Bates J, Moore J, et al. Modelling the relationship between travel behaviours and social disadvantage[J]. Transportation Research Part A: Policy and Practice, 2016, 85:157-173. doi: 10.1016/j.tra.2016.01.008
[9]	Soltani S H K, Sham M, Awang M, et al. Accessibility for disabled in public transportation terminal[J]. Procedia: Social and Behavioral Sciences, 2012, 35:89-96. doi: 10.1016/j.sbspro.2012.02.066
[10]	Ding C, Cao X Y. How does the built environment at residential and work locations affect car ownership? An application of cross-classified multilevel model[J]. Journal of Transport Geography, 2019, 75:37-45. doi: 10.1016/j.jtrangeo.2019.01.012
[11]	申犁帆, 王烨, 张纯, 等. 轨道站点合理步行可达范围建成环境与轨道通勤的关系研究: 以北京市44个轨道站点为例[J]. 地理学报, 2018, 73(12):2423-2439. doi: 10.11821/dlxb201812011
	[ Shen Lifan, Wang Ye, Zhang Chun, et al. Relationship between built environment of rational pedestrian catchment areas and URT commuting ridership: Evidence from 44 URT stations in Beijing. Acta Geographica Sinica, 2018, 73(12):2423-2439. ]
[12]	塔娜, 柴彦威, 关美宝. 建成环境对北京市郊区居民工作日汽车出行的影响[J]. 地理学报, 2015, 70(10):1675-1685. doi: 10.11821/dlxb201510011
	[ Ta Na, Chai Yanwei, Kwan Mei-po. The relationship between the built environment and car travel distance on weekdays in Beijing. Acta Geographica Sinica, 2015, 70(10):1675-1685. ]
[13]	Schreuer N, Plaut P, Golan L, et al. The relations between walkable neighbourhoods and active participation in daily activities of people with disabilities[J]. Journal of Transport & Health, 2019, 15:100630. doi: 10.1016/j.jth.2019.100630.
[14]	鲁斐栋, 谭少华. 城市住区适宜步行的物质空间形态要素研究: 基于重庆市南岸区16个住区的实证[J]. 规划师, 2019, 35(7):69-76.
	[ Lu Feidong, Tan Shaohua. Urban form characteristics for walkable neighborhood: A case study of 16 neighborhoods in Nan'an District, Chongqing. Planners, 2019, 35(7):69-76. ]
[15]	Lamour Q, Morelli A M, Marins K R D C. Improving walkability in a TOD context: Spatial strategies that enhance walking in the Belém neighbourhood, in São Paulo, Brazil[J]. Case Studies on Transport Policy, 2019, 7(2):280-292. doi: 10.1016/j.cstp.2019.03.005
[16]	Jiang Y, Gu P Q, Chen Y L, et al. Influence of land use and street characteristics on car ownership and use: Evidence from Jinan, China[J]. Transportation Research Part D: Transport and Environment, 2017, 52:518-534. doi: 10.1016/j.trd.2016.08.030
[17]	Park K, Ewing R, Scheer B C, et al. The impacts of built environment characteristics of rail station areas on household travel behavior[J]. Cities, 2018, 74:277-283. doi: 10.1016/j.cities.2017.12.015
[18]	Ding C, Cao X Y, Liu C. How does the station-area built environment influence metrorail ridership? Using gradient boosting decision trees to identify non-linear thresholds[J]. Journal of Transport Geography, 2019, 77:70-78. doi: 10.1016/j.jtrangeo.2019.04.011
[19]	黄洁, 王姣娥, 靳海涛, 等. 北京市地铁客流的时空分布格局及特征: 基于智能交通卡数据[J]. 地理科学进展, 2018, 37(3):397-406. doi: 10.18306/dlkxjz.2018.03.010
	[ Huang Jie, Wang Jiao'e, Jin Haitao, et al. Investigating spatiotemporal patterns of passenger flows in the Beijing metro system from smart card data. Progress in Geography, 2018, 37(3):397-406. ]
[20]	潘海啸, 张超. 大型超市购物出行与TOD规划策略: 以上海近郊轨道交通站点地区为例[J]. 城市发展研究, 2018, 25(4):54-61.
	[ Pan Haixiao, Zhang Chao. Shopping mall travel and transit: Oriented development in suburban area. Urban Development Studies, 2018, 25(4):54-61. ]
[21]	Cervero R, Kockelman K. Travel demand and the 3Ds: Density, diversity, and design[J]. Transportation Research Part D: Transport and Environment, 1997, 2(3):199-219. doi: 10.1016/S1361-9209(97)00009-6
[22]	Jun M J, Choi K, Jeong J E, et al. Land use characteristics of subway catchment areas and their influence on subway ridership in Seoul[J]. Journal of Transport Geography, 2015, 48:30-40. doi: 10.1016/j.jtrangeo.2015.08.002
[23]	Yang Y, Xu Y Q, Rodriguez D A, et al. Active travel, public transportation use, and daily transport among older adults: The association of built environment[J]. Journal of Transport & Health, 2018, 9:288-298.
[24]	Chen F A, Wu J R, Chen X H, et al. Vehicle kilometers traveled reduction impacts of transit-oriented development: Evidence from Shanghai City[J]. Transportation Research Part D: Transport and Environment, 2017, 55:227-245. doi: 10.1016/j.trd.2017.07.006
[25]	Chen E H, Ye Z R, Wang C, et al. Discovering the spatio-temporal impacts of built environment on metro ridership using smart card data[J]. Cities, 2019, 95:102359. doi: 10.1016/j.cities.2019.05.028. doi: 10.1016/j.cities.2019.05.028
[26]	赵鹏军, 李南慧, 李圣晓. TOD建成环境特征对居民活动与出行影响: 以北京为例[J]. 城市发展研究, 2016, 23(6):45-51.
	[ Zhao Pengjun, Li Nanhui, Li Shengxiao. The impacts of the built environment on residents' acitivities and travel behavior in TOD areas: A case study of Beijing. Urban Development Studies. 2016, 23(6):45-51. ]
[27]	Zhao J B, Deng W, Song Y, et al. Analysis of metro ridership at station level and station-to-station level in Nanjing: An approach based on direct demand models[J]. Transportation, 2014, 41(1):133-155. doi: 10.1007/s11116-013-9492-3
[28]	Sung H, Choi K, Lee S, et al. Exploring the impacts of land use by service coverage and station-level accessibility on rail transit ridership[J]. Journal of Transport Geography, 2014, 36:134-140. doi: 10.1016/j.jtrangeo.2014.03.013
[29]	Gutiérrez J, Cardozo O D, García-Palomares J C. Transit ridership forecasting at station level: An approach based on distance-decay weighted regression[J]. Journal of Transport Geography, 2011, 19(6):1081-1092. doi: 10.1016/j.jtrangeo.2011.05.004
[30]	石天戈, 张小雷, 杜宏茹, 等. 乌鲁木齐市居民出行行为的空间特征和碳排放分析[J]. 地理科学进展, 2013, 32(6):897-905. doi: 10.11820/dlkxjz.2013.06.006
	[ Shi Tiange, Zhang Xiaolei, Du Hongru, et al. Spatial characteristics of residents' outings and carbon emissions in Urumqi City. Progress in Geography, 2013, 32(6):897-905. ]
[31]	韩会然, 焦华富, 王荣荣, 等. 城市居民购物消费行为研究进展与展望[J]. 地理科学进展, 2011, 30(8):1006-1013.
	[ Han Huiran, Jiao Huafu, Wang Rongrong, et al. Progress and prospects of the research on shopping behavior of urban residents. Progress in Geography, 2011, 30(8):1006-1013. ]
[32]	Schmöcker J D, Quddus M A, Noland R B, et al. Mode choice of older and disabled people: A case study of shopping trips in London[J]. Journal of Transport Geography, 2008, 16(4):257-267. doi: 10.1016/j.jtrangeo.2007.07.002
[33]	Var T, Yeşiltaş M, Yaylı A, et al. A study on the travel patterns of physically disabled people[J]. Asia Pacific Journal of Tourism Research, 2011, 16(6):599-618. doi: 10.1080/10941665.2011.610143
[34]	Bearse P, Gurmu S, Rapaport C, et al. Paratransit demand of disabled people[J]. Transportation Research Part B: Methodological, 2004, 38(9):809-831. doi: 10.1016/j.trb.2003.10.004
[35]	Taylor Z, Józefowicz I. Intra-urban daily mobility of disabled people for recreational and leisure purposes[J]. Journal of Transport Geography, 2012, 24:155-172. doi: 10.1016/j.jtrangeo.2011.12.008
[36]	Nakamura F, Ooie K. A study on mobility improvement for intellectually disabled student commuters[J]. IATSS Research, 2017, 41(2):74-81. doi: 10.1016/j.iatssr.2017.07.002
[37]	Prasertsubpakij D, Nitivattananon V. Evaluating accessibility to bangkok metro systems using multi-dimensional criteria across user groups[J]. IATSS Research, 2012, 36(1):56-65. doi: 10.1016/j.iatssr.2012.02.003
[38]	刘泉. 轨道交通TOD地区的步行尺度[J]. 城市规划, 2019, 43(3):88-95.
	[ Liu Quan. Walking scale of TOD area along rail transit line. City Planning Review, 2019, 43(3):88-95. ]
[39]	张宁, 戴洁, 张晓军. 基于多项Logit模型的轨道交通站点步行接驳范围[J]. 城市轨道交通研究, 2012, 15(5):46-49.
	[ Zhang Ning, Dai Jie, Zhang Xiaojun. Walking affect area of rail transit station based on multinomial logit model. Urban Mass Transit, 2012, 15(5):46-49. ]
[40]	曹新宇. 社区建成环境和交通行为研究回顾与展望: 以美国为鉴[J]. 国际城市规划, 2015, 30(4):46-52.
	[ Cao Xinyu. Examining the relationship between neighborhood built environment and travel behavior: A review from the USA perspective. Urban Planning International, 2015, 30(4):46-52. ]
[41]	Sohn K, Shim H. Factors generating boardings at metro stations in the seoul metropolitan area[J]. Cities, 2010, 27(5):358-368. doi: 10.1016/j.cities.2010.05.001

卡号	刷卡时间	刷卡线路	刷卡站点	刷卡类型	卡类型
80271104xxxxxxxx	2019-03-11T06:20:51	4	454	28	1104
80271104xxxxxxxx	2019-03-11T06:46:22	4	444	29	1104

模型	换乘站	下四分位数	中位数	上四分位数	Z	P值
工作日模型	是	164.000	291.000	448.000	-4.094	<0.001
工作日模型	否	47.500	118.000	196.000
休息日模型	是	151.500	255.000	376.000	-3.837	<0.001
休息日模型	否	47.750	119.500	203.250

变量	非标准化系数		标准系数	t	P值
变量	β	标准误差	标准系数	t	P值
截距	-87.32324	37.96795		-2.29992	0.02263
公交站点密度	1.20421	0.47318	0.16052	2.54493	0.01179
路网密度	23188.39684	5353.62303	0.27061	4.33135	0.00002
站点开通时间	0.01086	0.00498	0.11617	2.18081	0.03052
大型公园密度	1.87413	1.01713	0.09156	1.84257	0.06707

变量	非标准化系数		标准系数	t	P值
变量	β	标准误差	标准系数	t	P值
截距	-83.93798	40.66735		-2.06401	0.04048
公交站点密度	1.25756	0.50682	0.16398	2.48126	0.01403
路网密度	22990.70125	5734.24782	0.26246	4.00937	0.00009
站点开通时间	0.01027	0.00533	0.10743	1.92484	0.05586
大型公园密度	2.89895	1.08944	0.13854	2.66095	0.00851

日期	模型	残差平方和	决定系数	调整后的决定系数	AICc
工作日	OLS	2238546.4676	0.5748	0.5608	2323.7201
工作日	GWR	1245400.9563	0.7634	0.6785	2298.0343
休息日	OLS	2540259.0715	0.5383	0.5230	2347.6171
休息日	GWR	1419906.6779	0.7419	0.6493	2322.8186
