收缩城市建设用地利用效率时空分异及影响机制——以黑龙江省伊春市为例

doi:10.18306/dlkxjz.2021.06.004

Abstract

Abstract:

Construction land is a spatial carrier of urban economic and social activities, and its utilization efficiency is an important basis for regulating the expansion and allocation of construction land. This study took the shrinking city Yichun of Heilongjiang Province as an example, and used data envelopment analysis (DEA) model and Geodetector to analyze the spatiotemporal change and influencing mechanism of spatial differentiation of construction land use efficiency from 1995 to 2015. The research reveals the following points: 1) The overall level of construction land use efficiency in Yichun City is not high, and it generally shows a trend of "rising first and then descending" from 1995 to 2015. From the perspective of temporal change, the regional differences of construction land use efficiency in Yichun were gradually decreasing, and the overall efficiency level developed towards a low-level equilibrium. 2) From the perspective of regional differences and spatial characteristics, the regional differences of construction land use efficiency in Yichun were obvious. Construction land use efficiency showed a decreasing trend from the northern and southern ends to the central part, which generally forms a spatial pattern of "high in the peripheral area and low in the core area". 3) Construction land use efficiency change in Yichun is the result of the joint action of multiple factors. The differences in per capita GDP of secondary and tertiary industries, non-agricultural population density, rationalization of industrial structure, optimization of industrial structure, and non-agriculturalization rate are highly related to the spatial differentiation of construction land use efficiency. However, the influence degree and sensitivity of some factors are slightly different in different periods.

Key words: construction land, utilization efficiency, shrinking cities, influencing mechanism, data envelopment analysis (DEA) model, Geodetector, Yichun City

XU Huixiao, LIU Yanjun. Spatiotemporal differentiation and influencing mechanism of construction land use efficiency of shrinking cities： A case study of Yichun City of Heilongjiang Province[J].PROGRESS IN GEOGRAPHY, 2021, 40(6): 937-947.

Figures/Tables 8

Fig.1

Fig.2

Tab.1

Tab.2

Indicator system of influencing factors of construction land use efficiency in Yichun City

探测因子	指标	指标计算	探测因素
X₁	人均二、三产业GDP	二、三产业产值/非农人口数	经济发展水平
X₂	产业结构高级度	$θ = arccos ∑ i = 1 n (x i x i, 0) ∑ i = 1 n x i 2 12 ∑ i = 1 n x i, 0 2 12 ①$	产业升级水平
X₃	产业结构合理度	$TL = ∑ i = 1 n Y i Y ln Y i L i Y L (i = 1,2, 3) ②$	产业合理程度
X₄	非农人口密度	非农人口数/建设用地面积	人口规模扩张
X₅	非农化率	非农人口数/总人口数	城镇发展水平
X₆	是否设置经济开发区	是(赋值1)、否(赋值0)	政策支持力度

Tab.2

Tab.3

Fig.3

Tab.4

Fig.4

References 34

[1]	吴康, 李耀川. 收缩情境下城市土地利用及其生态系统服务的研究进展[J]. 自然资源学报, 2019,34(5):1121-1134.
	[ Wu Kang, Li Yaochuan. Research progress of urban land use and its ecosystem services in the context of urban shrinkage. Journal of Natural Resources, 2019,34(5):1121-1134. ]
[2]	龙瀛, 吴康, 王江浩. 中国收缩城市及其研究框架[J]. 现代城市研究, 2015(9):14-19.
	[ Long Ying, Wu Kang, Wang Jianghao. Shrinking cities in China. Modern Urban Research, 2015(9):14-19. ]
[3]	龙瀛, 吴康. 中国城市化的几个现实问题: 空间扩张、人口收缩、低密度人类活动与城市范围界定[J]. 城市规划学刊, 2016(2):72-77.
	[ Long Ying, Wu Kang. Several emerging issues of China's urbanization: Spatial expansion, population shrinkage, low-density human activities and city boundary delimitation. Urban Planning Forum, 2016(2):72-77. ]
[4]	陈逸, 陈志刚, 周艳, 等. 江苏省地级市建设用地利用效率的区域差异与优化配置[J]. 经济地理, 2017,37(6):171-176, 205.
	[ Chen Yi, Chen Zhigang, Zhou Yan, et al. Built land use efficiency and optimal allocation in Jiangsu Province. Economic Geography, 2017,37(6):171-176, 205. ]
[5]	杨海泉, 胡毅, 王秋香. 2001—2012年中国三大城市群土地利用效率评价研究[J]. 地理科学, 2015,35(9):1095-1100. doi: 10.13249/j.cnki.sgs.2015.09.1095
	[ Yang Haiquan, Hu Yi, Wang Qiuxiang. Evaluation of land use efficiency in three major urban agglomerations of China in 2001-2012. Scientia Geographica Sinica, 2015,35(9):1095-1100. ]
[6]	赵鹏军, 曾良恩, 路海艳, 等. 中国区域城市建设用地经济效率及影响因素空间计量分析[J]. 城市发展研究, 2019,26(7):37-49.
	[ Zhao Pengjun, Zeng Liang'en, Lu Haiyan, et al. Measurement and spatial econometrics analysis of provincial economic efficiency of urban construction land in China: 2008-2017. Urban Development Studies, 2019,26(7):37-49. ]
[7]	金贵, 邓祥征, 赵晓东, 等. 2005—2014年长江经济带城市土地利用效率时空格局特征[J]. 地理学报, 2018,73(7):1242-1252. doi: 10.11821/dlxb201807005
	[ Jin Gui, Deng Xiangzheng, Zhao Xiao-dong, et al. Spatio-temporal patterns of urban land use efficiency in the Yangtze River Economic Zone during 2005-2014. Acta Geographica Sinica, 2018,73(7):1242-1252. ]
[8]	杨东峰, 龙瀛, 杨文诗, 等. 人口流失与空间扩张: 中国快速城市化进程中的城市收缩悖论[J]. 现代城市研究, 2015(9):20-25.
	[ Yang Dongfeng, Long Ying, Yang Wenshi, et al. Losing population with expanding space: Paradox of urban shrinkage in China. Modern Urban Research, 2015(9):20-25. ]
[9]	Hollander J B. Moving toward a shrinking cities metric: Analyzing land use changes associated with depopulation in Flint, Michigan[J]. Cityscape, 2010,12(1):133-151.
[10]	Németh J, Langhorst J. Rethinking urban transformation: Temporary uses for vacant land[J]. Cities, 2014,40:143-150. doi: 10.1016/j.cities.2013.04.007
[11]	Yamada C, Terada T, Tanaka T, et al. Directions for vacant lot management in the outer suburbs of the Tokyo metropolitan region[J]. Urban and Regional Planning Review, 2016,3:66-84. doi: 10.14398/urpr.3.66
[12]	Han J, Hayashi Y, Cao X, et al. Application of an integrated system dynamics and cellular automata model for urban growth assessment: A case study of Shanghai, China[J]. Landscape and Urban Planning, 2009,91(3):133-141. doi: 10.1016/j.landurbplan.2008.12.002
[13]	Lauf S, Haase D, Seppelt R, et al. Simulating demography and housing demand in an urban region under scenarios of growth and shrinkage[J]. Environment and Planning B: Planning and Design, 2012,39(2):229-246. doi: 10.1068/b36046t
[14]	Oh K, Jeong Y, Lee D, et al. Determining development density using the urban carrying capacity assessment system[J]. Landscape and Urban Planning, 2005,73(1):1-15. doi: 10.1016/j.landurbplan.2004.06.002
[15]	Taleai M, Sharifi A, Sliuzas R, et al. Evaluating the compatibility of multi-functional and intensive urban land uses[J]. International Journal of Applied Earth Observation and Geoinformation, 2007,9(4):375-391. doi: 10.1016/j.jag.2006.12.002
[16]	Zitti M, Ferrara C, Perini L, et al. Long-term urban growth and land use efficiency in Southern Europe: Implications for sustainable land management[J]. Sustainability, 2015,7(3):3359-3385. doi: 10.3390/su7033359
[17]	Li X G, Zhang Q. AHP-based resources and environment efficiency evaluation index system construction about the west side of Taiwan Straits[J]. Annals of Operations Research, 2015,228(1):97-111. doi: 10.1007/s10479-012-1072-y
[18]	龙拥军, 杨庆媛, 陈琳琳, 等. 省域土地利用效率空间差异分析: 以重庆市为例[J]. 改革与战略, 2011,27(8):114-116, 167.
	[ Long Yongjun, Yang Qingyuan, Chen Linlin, et al. Analysis of the spatial differences in efficiency of provincial land use: Case study of Chongqing. Reformation & Strategy, 2011,27(8):114-116, 167. ]
[19]	李郇, 徐现祥, 陈浩辉. 20世纪90年代中国城市效率的时空变化[J]. 地理学报, 2005,60(4):615-625.
	[ Li Xun, Xu Xianxiang, Chen Haohui. Temporal and spatial changes of urban efficiency in the 1990s. Acta Geographica Sinica, 2005,60(4):615-625. ]
[20]	Crooks A, Castle C, Batty M. Key challenges in agent-based modelling for geo-spatial simulation[J]. Computers Environment and Urban Systems, 2008,32(6):417-430. doi: 10.1016/j.compenvurbsys.2008.09.004
[21]	Berry M W, Hazen B C, MacIntyre R L, et al. Lucas: A system for modeling land-use change[J]. IEEE Computational Science & Engineering, 1996,3(1):24-35.
[22]	Bovet J, Reese M, Köck W. Taming expansive land use dynamics: Sustainable land use regulation and urban sprawl in a comparative perspective[J]. Land Use Policy, 2018,77:837-845. doi: 10.1016/j.landusepol.2017.03.024
[23]	李佳佳, 罗能生. 城镇化进程对城市土地利用效率影响的双门槛效应分析[J]. 经济地理, 2015,35(7):156-162.
	[ Li Jiajia, Luo Nengsheng. The double threshold effects of the urbanization process on urban land use efficiency. Economic Geography, 2015,35(7):156-162. ]
[24]	崔学刚, 方创琳, 张蔷. 山东半岛城市群高速交通优势度与土地利用效率的空间关系[J]. 地理学报, 2018,73(6):1149-1161. doi: 10.11821/dlxb201806012
	[ Cui Xuegang, Fang Chuanglin, Zhang Qiang. Spatial relationship between high-speed transport superiority degree and land-use efficiency in Shandong Peninsula urban agglomeration. Acta Geographica Sinica, 2018,73(6):1149-1161. ]
[25]	戚伟, 刘盛和, 金凤君. 东北三省人口流失的测算及演化格局研究[J]. 地理科学, 2017,37(12):1795-1804. doi: 10.13249/j.cnki.sgs.2017.12.002
	[ Qi Wei, Liu Shenghe, Jin Fengjun. Calculation and spatial evolution of population loss in Northeast China. Scientia Geographica Sinica, 2017,37(12):1795-1804. ]
[26]	Haase D, Haase A, Kabisch N, et al. Actors and factors in land-use simulation: The challenge of urban shrinkage[J]. Environmental Modelling & Software, 2012,35:92-103.
[27]	刘艳军, 于会胜, 刘德刚, 等. 东北地区建设用地开发强度格局演变的空间分异机制[J]. 地理学报, 2018,73(5):818-831. doi: 10.11821/dlxb201805003
	[ Liu Yanjun, Yu Huisheng, Liu Degang, et al. Spatial differentiation mechanisms of the pattern evolution of construction land development intensity in Northeast China. Acta Geographica Sinica, 2018,73(5):818-831. ]
[28]	王良健, 李辉, 石川. 中国城市土地利用效率及其溢出效应与影响因素[J]. 地理学报, 2015,70(11):1788-1799. doi: 10.11821/dlxb201511008
	[ Wang Liangjian, Li Hui, Shi Chuan. Urban land-use efficiency, spatial spillover, and determinants in China. Acta Geographica Sinica, 2015,70(11):1788-1799. ]
[29]	张英浩, 陈江龙, 高金龙, 等. 经济转型视角下长三角城市土地利用效率影响机制[J]. 自然资源学报, 2019,34(6):1157-1170.
	[ Zhang Yinghao, Chen Jianglong, Gao Jinlong, et al. The impact mechanism of urban land use efficiency in the Yangtze River Delta from the perspective of economic transition. Journal of Natural Resources, 2019,34(6):1157-1170. ]
[30]	王劲峰, 徐成东. 地理探测器: 原理与展望[J]. 地理学报, 2017,72(1):116-134. doi: 10.11821/dlxb201701010
	[ Wang Jinfeng, Xu Chengdong. Geodetector: Principle and prospective. Acta Geographica Sinica, 2017,72(1):116-134. ]
[31]	田俊峰, 刘艳军, 付占辉, 等. 哈大巨型城市带要素集聚分异与空间极化格局[J]. 人文地理, 2017,32(3):117-123.
	[ Tian Junfeng, Liu Yanjun, Fu Zhanhui, et al. The differentiation of agglomeration degree and pattern of spatial polarization of the internal elements in the Ha-Da giant urban belt. Human Geography, 2017,32(3):117-123. ]
[32]	湛东升, 张文忠, 余建辉, 等. 基于地理探测器的北京市居民宜居满意度影响机理[J]. 地理科学进展, 2015,34(8):966-975. doi: 10.18306/dlkxjz.2015.08.004
	[ Zhan Dongsheng, Zhang Wenzhong, Yu Jianhui, et al. Analysis of influencing mechanism of residents' livability satisfaction in Beijing using geographical detector. Progress in Geography, 2015,34(8):966-975. ]
[33]	关伟, 许淑婷. 辽宁省能源效率与产业结构的空间特征及耦合关系[J]. 地理学报, 2014,69(4):520-530. doi: 10.11821/dlxb201404008
	[ Guan Wei, Xu Shuting. Spatial patterns and coupling relations between energy efficiency and industrial structure in Liao-ning Province. Acta Geographica Sinica, 2014,69(4):520-530. ]
[34]	何好俊, 彭冲. 城市产业结构与土地利用效率的时空演变及交互影响[J]. 地理研究, 2017,36(7):1271-1282. doi: 10.11821/dlyj201707007
	[ He Haojun, Peng Chong. The spatial-temporal evolution and the interactive effect between urban industrial structure transformation and land use efficiency. Geographical Research, 2017,36(7):1271-1282. ]

指标层	指标名称	指标计算	指标说明
投入指标	人均建设用地面积	建设用地面积/非农人口数	土地投入
	地均城镇固定资产投资	城镇固定资产投资额/建设用地面积	资本投入
	地均二、三产业从业人员	二、三产业从业人数/建设用地面积	劳动力投入
产出指标	地均二、三产业GDP	二、三产业GDP/建设用地面积	经济产出

市辖区	1995年	2005年	2015年	均值
伊春区	0.514	0.370	0.472	0.452
南岔区	0.786	1	0.638	0.808
友好区	0.720	0.588	0.337	0.548
西林区	1	0.613	1	0.871
翠峦区	0.462	1	0.478	0.647
新青区	1	1	1	1
美溪区	0.543	1	0.462	0.668
金山屯区	0.287	0.976	0.712	0.658
五营区	0.738	0.978	0.601	0.772
乌马河区	0.582	0.724	0.315	0.540
汤旺河区	1	1	0.750	0.917
带岭区	0.589	0.440	0.735	0.588
乌伊岭区	0.560	0.967	0.405	0.644
红星区	0.790	0.456	0.509	0.585
上甘岭区	0.755	0.424	0.954	0.711
平均值	0.688	0.769	0.625	0.694

排序	1995年		2005年		2015年
排序	影响因素	P_D_,_H	影响因素	P_D_,_H	影响因素	P_D_,_H
1	人均二、三产业GDP	0.657	产业结构合理度	0.540	人均二、三产业GDP	0.436
2	非农人口密度	0.321	产业结构高级度	0.409	非农人口密度	0.390
3	产业结构合理度	0.269	非农人口密度	0.304	产业结构合理度	0.380
4	产业结构高级度	0.250	人均二、三产业GDP	0.275	非农化率	0.348
5	非农化率	0.097	非农化率	0.224	产业结构高级度	0.315
6	是否设置经济开发区	0	是否设置经济开发区	0.003	是否设置经济开发区	0.003
