京津冀地区耕地利用转型时空分异及驱动机制

doi:10.18306/dlkxjz.2020.12.003

Abstract

Abstract:

The transition of cultivated land use represents the change trend of cultivated land use form. Taking 157 counties in the Beijing-Tianjin-Hebei region as cases, this study constructed the index system of cultivated land use form from the dual attributes of dominant form and recessive form. The spatial and temporal characteristics of change of cultivated land use form were analyzed by the methods of cold/hot spot analysis and spatial variation functions. On this basis, the driving mechanism of cultivated land use transition is quantitatively analyzed by the spatial error model (SEM). The results show that: 1) Cultivated land use form index values in the Beijing-Tianjin-Hebei region is high in the southeast and low in the northwest, which is consistent with the terrain distribution pattern in the region. Due to the development of characteristic agriculture on the Bashang Plateau, an independent high-value area was formed. 2) The spatial differentiation of cultivated land use form index in the Beijing-Tianjin-Hebei region shows a trend of gradual reduction. The distribution of significant hot spots and significant cold spots is relatively stable and the area continues to shrink, which indicates that the transition of cultivated land use is relatively steady. Specifically, the dominant morphological value generally increases first and then decreases, while the recessive morphological value increases, demonstrating that the cultivated land in the Beijing-Tianjin-Hebei region is undergoing spatial contraction and functional optimization transitions. 3) Elevation is the main natural environmental factor that affects the spatial characteristics of cultivated land utilization, while the economic and urban development factors such as the proportion of secondary and tertiary industries, average fixed asset investment, and urbanization rate are the leading factors driving the transition of cultivated land in the Beijing-Tianjin-Hebei region from 1990 to 2015. However, there are differences in the dynamic mechanism of cultivated land use transition in different time periods and different county units, and the intensity of each driving factor is also different.

Key words: cultivated land use transition, cultivated land use form, spatial transition, functional transition, Beijing-Tianjin-Hebei region

FU Hui, LIU Yanjun, SUN Hongri, ZHOU Guolei. Spatiotemporal characteristics and dynamic mechanism of cultivated land use transition in the Beijing-Tianjin-Hebei region[J].PROGRESS IN GEOGRAPHY, 2020, 39(12): 1985-1998.

Figures/Tables 11

Fig.1

Fig.2

Tab.1

Tab.2

Fig.3

Fig.4

Tab.3

Tab.4

Fig.5

Tab.5

Fig.6

References 35

[1]	龙花楼. 论土地利用转型与乡村转型发展[J]. 地理科学进展, 2012,31(2):131-138.
	[ Long Hualou. Land use transition and rural transformation development. Progress in Geography, 2012,31(2):131-138. ]
[2]	宋小青, 吴志峰, 欧阳竹. 耕地转型的研究路径探讨[J]. 地理研究, 2014,33(3):403-413.
	[ Song Xiaoqing, Wu Zhifeng, Ouyang Zhu. Route of cultivated land transition research. Geographical Research, 2014,33(3):403-413. ]
[3]	宋小青, 欧阳竹. 耕地多功能内涵及其对耕地保护的启示[J]. 地理科学进展, 2012,31(7):859-868.
	[ Song Xiaoqing, Ouyang Zhu. Connotation of multifunctional cultivated land and its implications for cultivated land protection. Progress in Geography, 2012,31(7):859-868. ]
[4]	刘永强, 龙花楼. 黄淮海平原农区土地利用转型及其动力机制[J]. 地理学报, 2016,71(4):666-679.
	[ Liu Yong-qiang, Long Hualou. Land use transitions and their dynamic mechanism in the Huang-Huai-Hai Plain. Acta Geographica Sinica, 2016,71(4):666-679. ]
[5]	Li H, Wu Y, Huang X, et al. Spatial-temporal evolution and classification of marginalization of cultivated land in the process of urbanization[J]. Habitat International, 2017,61:1-8.
[6]	龙花楼. 论土地利用转型与土地资源管理[J]. 地理研究, 2015,34(9):1607-1618.
	[ Long Hualou. Land use transition and land management. Geographical Research, 2015,34(9):1607-1618. ]
[7]	宋小青, 吴志峰, 欧阳竹. 1949年以来中国耕地功能变化[J]. 地理学报, 2014,69(4):435-447.
	[ Song Xiaoqing, Wu Zhifeng, Ouyang Zhu. Changes of cultivated land function in China since 1949. Acta Geographica Sinica, 2014,69(4):435-447. ]
[8]	张英男, 龙花楼, 戈大专, 等. 黄淮海平原耕地功能演变的时空特征及其驱动机制[J]. 地理学报, 2018,73(3):518-534.
	[ Zhang Yingnan, Long Hualou, Ge Dazhuan, et al. Spatio-temporal characteristics and dynamic mechanism of farmland functions evolution in the Huang-Huai-Hai Plain. Acta Geographica Sinica, 2018,73(3):518-534. ]
[9]	Grainger A. The forest transition: An alternative approach[J]. Area, 1995,27(3):242-251.
[10]	Mather A S. The forest transition[J]. Area, 1992,24(4):367-379.
[11]	李全峰, 胡守庚, 瞿诗进. 1990—2015年长江中游地区耕地利用转型时空特征[J]. 地理研究, 2017,36(8):1489-1502.
	[ Li Quanfeng, Hu Shougeng, Qu Shijin. Spatiotemporal characteristics of cultivated land use transition in the Middle Yangtze River from 1990 to 2015. Geographical Research, 2017,36(8):1489-1502. ]
[12]	宋小青, 李心怡. 区域耕地利用功能转型的理论解释与实证[J]. 地理学报, 2019,74(5):992-1010.
	[ Song Xiaoqing, Li Xinyi. Theoretical explanation and case study of regional cultivated land use function transition. Acta Geographica Sinica, 2019,74(5):992-1010. ]
[13]	Todorova S, Ikova J. Multifunctional agriculture: Social and ecological impacts on the organic farms in Bulgaria[J]. Procedia Economics & Finance, 2014,9(1):310-320.
[14]	杨雪, 谈明洪. 近年来北京市耕地多功能演变及其关联性[J]. 自然资源学报, 2014,29(5):733-743.
	[ Yang Xue, Tan Minghong. Changes and relationships of arable land functions in Beijing in recent years. Journal of Natural Resources, 2014,29(5):733-743. ]
[15]	杨雪, 谈明洪. 北京市耕地功能空间差异及其演变[J]. 地理研究, 2014,33(6):1106-1118.
	[ Yang Xue, Tan Minghong. Spatial differences and evolution of arable land functions in Beijing. Geographical Research, 2014,33(6):1106-1118. ]
[16]	郇红艳, 谭清美, 朱平. 城乡一体化进程中耕地利用变化的驱动因素及区域比较[J]. 农业工程学报, 2013,29(21):201-213.
	[ Huan Hongyan, Tan Qingmei, Zhu Ping. Driving factors of cultivated land use change in city and countryside integration process and region comparisons. Transactions of the CSAE, 2013,29(21):201-213. ]
[17]	张光宏, 崔许锋. 耕地资源非农化驱动机制及其区域差异性[J]. 中国农业科学, 2015,48(8):1632-1640.
	[ Zhang Guanghong, Cui Xufeng. Driving mechanism and regional differentiation of cultivated land non-agricultural-transformation. Scientia Agricultura Sinica, 2015,48(8):1632-1640. ]
[18]	马历, 龙花楼, 张英男, 等. 中国县域农业劳动力变化与农业经济发展的时空耦合及其对乡村振兴的启示[J]. 地理学报, 2018,73(12):2364-2377.
	[ Ma Li, Long Hualong, Zhang Yingnan, et al. Spatio-temporal coupling relationship between agricultural labor changes and agricultural economic development at county level in China and its implications for rural revitalization. Acta Geographica Sinica, 2018,73(12):2364-2377. ]
[19]	曹雪, 金晓斌, 王金朔, 等. 近300年中国耕地数据集重建与耕地变化分析[J]. 地理学报, 2014,69(7):896-906.
	[ Cao Xue, Jin Xiaobin, Wang Jinshuo, et al. Reconstruction and change analysis of cropland data of China in recent 300 years. Acta Geographica Sinica, 2014,69(7):896-906. ]
[20]	Sanchez P A, Leakey R R B. Land use transformation in Africa: Three determinants for balancing food security with natural resource utilization[J]. European Journal of Agronomy, 1997,7(1):15-23.
[21]	张永民, 赵士洞. 近15年科尔沁沙地及其周围地区土地利用变化分析[J]. 自然资源学报, 2003,18(2):174-181, 260.
	[ Zhang Yongmin, Zhao Shidong. Analysis of land use change in Horqin Sandy Land and its surrounding area during the past 15 years. Journal of Natural Resources, 2003,18(2):174-181, 260. ]
[22]	Vereijken P H. Transition to multifunctional land use and agriculture[J]. NJAS: Wageningen Journal of Life Sciences, 2003,50(2):171-179.
[23]	潘佩佩, 杨桂山, 王晓旭, 等. 典型经济快速发展区耕地变化区域分异研究[J]. 长江流域资源与环境, 2017,26(10):1587-1596.
	[ Pan Peipei, Yang Guishan, Wang Xiaoxu, et al. Research on spatial heterogeneity of cropland change in rapid economic development area. Resources and Environment in the Yangtza Basin, 2017,26(10):1587-1596. ]
[24]	Verburg P H, Chen Y, Veldkamp T. Spatial explorations of land use change and grain production in China[J]. Agriculture Ecosystems and Environment, 2000,82(1-3):333-354.
[25]	彭建, 刘志聪, 刘焱序, 等. 京津冀地区县域耕地景观多功能性评价[J]. 生态学报, 2016,36(8):2274-2285.
	[ Peng Jian, Liu Zhicong, Liu Yanxu, et al. Assessment of farmland landscape multifunctionality at county level in Beijing-Tianjin-Hebei area. Acta Ecologica Sinica, 2016,36(8):2274-2285. ]
[26]	吴兆娟, 魏朝富, 丁声源. 丘陵山区地块尺度耕地社会保障功能价值研究[J]. 资源科学, 2013,35(4):773-781.
	[ Wu Zhaojuan, Wei Zhaofu, Ding Shengyuan. Research on the social security function of cultivated land in a hilly-mountainous region. Resources Science, 2013,35(4):773-781. ]
[27]	孙小祥, 杨桂山, 欧维新, 等. 太湖流域耕地变化及其对生态服务功能影响研究[J]. 自然资源学报, 2014,29(10):1675-1685.
	[ Sun Xiaoxiang, Yang Guishan, Ou Weixin, et al. Impacts of cropland change on ecosystem services in the Taihu Lake Basin. Journal of Natural Resources, 2014,29(10):1675-1685. ]
[28]	杜国明, 马敬盼, 春香. 现代化农区耕地利用形态转型研究[J]. 中国农业资源与区划, 2018,39(3):185-192.
	[ Du Guoming, Ma Jingpan, Chun Xiang. Study on the transformation of cultivated land use in modern agricultural region. Chinese Journal of Agricultural Resources and Regional Planning, 2018,39(3):185-192. ]
[29]	吴思, 胡守庚, 熊婷, 等. 长江中游经济带主体功能区土地利用转型模式研究[J]. 资源科学, 2018,40(11):2213-2224.
	[ Wu Si, Hu Shougeng, Xiong Ting, et al. The pattern of land use transition in different major function zones in the middle reaches of Yangtze River Economic Belt. Resources Science, 2018,40(11):2213-2224. ]
[30]	龙花楼, 曲艺, 屠爽爽, 等. 城镇化背景下中国农区土地利用转型及其环境效应研究: 进展与展望[J]. 地球科学进展, 2018,33(5):455-463.
	[ Long Hualou, Qu Yi, Tu Shuanshuang, et al. Land use transitions under urbanization and their environmental effects in the farming areas of China: Research progress and prospect. Advances in Earth Science, 2018,33(5):455-463. ]
[31]	胡雪瑶, 张子龙, 陈兴鹏, 等. 县域经济发展时空差异和影响因素的地理探测: 以甘肃省为例[J]. 地理研究, 2019,38(4):772-783.
	[ Hu Xueyao, Zhang Zilong, Chen Xingpeng, et al. Geographic detection of spatial-temporal difference and its influencing factors on county economic development: A case study of Gansu Province. Geographical Research, 2019,38(4):772-783. ]
[32]	周扬, 李宁, 吴文祥, 等. 1982—2010年中国县域经济发展时空格局演变[J]. 地理科学进展, 2014,33(1):102-113.
	[ Zhou Yang, Li Ning, Wu Wenxiang, et al. Evolution of spatial-temporal pattern of county economic development in China during 1982-2010. Progress in Geography, 2014,33(1):102-113. ]
[33]	刘艳军, 于会胜, 刘德刚, 等. 东北地区建设用地开发强度格局演变的空间分异机制[J]. 地理学报, 2018,73(5):818-831.
	[ Liu Yanjun, Yu Huisheng, Liu Degang, et al. Spatial differentiation mechanisms of the pattern evolution of construction land development intensity in Northeast China. Acta Geographica Sinica, 2018,73(5):818-831. ]
[34]	吴一凡, 刘彦随, 李裕瑞. 中国人口与土地城镇化时空耦合特征及驱动机制[J]. 地理学报, 2018,73(10):1865-1879.
	[ Wu Yifan, Liu Yansui, Li Yurui. Spatio-temporal coupling of demographic-landscape urbanization and its driving forces in China. Acta Geographica Sinica, 2018,73(10):1865-1879. ]
[35]	高金龙, 包菁薇, 刘彦随, 等. 中国县域土地城镇化的区域差异及其影响因素[J]. 地理学报, 2018,73(12):2329-2344.
	[ Gao Jinlong, Bao Jingwei, Liu Yansui, et al. Regional disparity and the influencing factors of land urbanization in China at the county level, 2000-2015. Acta Geographica Sinica, 2018,73(12):2329-2344. ]

决策层	目标层及权重	指标层	指标计算	指标权重	指标释义
耕地利用形态指数	显性形态 0.4997	人均耕地面积	耕地面积/总人口(hm²/人)	0.38	耕地数量水平
		人均粮食播种面积	粮食播种面积/总人口(hm²/人)	0.25	粮食安全状况
		耕地斑块占景观面积指数(PLAND)	利用景观分析软件Fragstats计算	0.23	耕地空间结构
		耕地斑块聚集度指数(AI)	利用景观分析软件Fragstats计算	0.14	耕地集聚程度
	隐性形态 0.5003	粮食单产	粮食产量/粮食播种面积(kg/hm²)	0.14	耕地质量水平
		单位耕地面积化肥用量	农用化肥施用量/耕地面积(t/hm²)	0.39	耕地投入强度
		农业人均产值	农业总产值/农业人口(元/人)	0.34	耕地经济产出
		单位耕地供养人数	农业人口/耕地面积(人/hm²)	0.13	耕地供养功能

准则层	指标层	指标计算或来源	指标释义
自然环境因素	高程	根据DEM计算高程值	地形地貌基础
	年降水量	根据气象站点数据计算地区平均值	区域降水条件
	距主要河流距离	根据水系分布计算欧氏距离	区域水文环境
经济发展因素	人均GDP	GDP总量/总人口	经济发展水平
	农民人均纯收入	来自统计年鉴数据	农民收入水平
	二三产业占比	二三产业产值/GDP总量	产业结构水平
城镇建设因素	地均固定资产投资	固定资产投资总额/区域土地面积	资产投入力度
	城镇化率	城镇人口/总人口	城镇发展程度
	人口密度	总人口/区域土地面积	人口承载能力
	城市行政等级	县、县级市、地级市区、省会城市和直辖市分别赋值1、2、3、4、5	城镇建设水平

指标	参数	1990年	2000年	2010年	2015年
变程	a	628800	718500	577500	255600
块金值	C₀	0.00001	0.00051	0.00013	0.00046
基台值	C₀+C	0.00523	0.00680	0.00682	0.00639
块金系数	C₀/(C₀+C)	0.998	0.925	0.981	0.928
拟合模型		指数	指数	指数	指数
决定系数	R²	0.993	0.986	0.993	0.966

年份	全方位		南—北(0°)		东北—西南(45°)		东—西(90°)		东南—西北(135°)
年份	D	R²	D	R²	D	R²	D	R²	D	R²
1990	1.567	0.940	1.530	0.988	1.614	0.975	1.526	0.880	1.506	0.674
2000	1.700	0.981	1.680	0.851	1.603	0.926	1.771	0.776	1.640	0.730
2010	1.630	0.971	1.580	0.985	1.639	0.968	1.689	0.910	1.599	0.614
2015	1.767	0.905	1.721	0.920	1.778	0.914	1.735	0.945	1.790	0.498

影响因子	1990年			2000年			2010年			2015年
影响因子	OLS	SLM	SEM	OLS	SLM	SEM	OLS	SLM	SEM	OLS	SLM	SEM
高程	-0.182^***	-0.056^***	-0.119^***	-0.094^***	-0.016	-0.100^***	-0.143^***	-0.038^***	-0.140^***	-0.144^***	-0.084^***	-0.151^***
年降水量	-0.192^***	-0.086^***	-0.152^***	0.0003	-0.012	-0.075	-0.038^**	-0.017^*	-0.064^*	-0.169^***	-0.111^***	-0.168^***
距主要河流距离	-0.051^***	-0.028^**	-0.035^*	-0.044^*	-0.032^**	-0.052^**	-0.039^**	-0.022^*	-0.024	-0.084^***	-0.060^***	-0.064^**
人均GDP	0.078^**	0.105^***	0.107^***	0.043	0.047	0.080^**	-0.149	0.005	0.043	0.105	0.156^*	0.169^*
农民人均纯收入	-0.0543^*	0.002	0.025	0.009	0.016	0.010	0.019	0.047	0.006	0.099^***	0.099^***	0.090^***
二三产业占比	-0.010	-0.028^**	-0.027^**	-0.094^***	-0.080^***	-0.065^***	-0.092^***	-0.078^***	-0.044^***	-0.131^***	-0.117^***	-0.103^***
地均固定资产投资	-0.019	-0.069^**	-0.084^***	-0.275^**	-0.282^***	-0.326^***	0.122	-0.063	-0.114^*	-0.081	-0.133	-0.149
城镇化率	-0.051^**	-0.046^***	-0.048^***	-0.041	-0.041^*	-0.057^**	-0.020	-0.023	-0.051^***	-0.074^**	-0.069^**	-0.776^**
人口密度	-0.089^*	-0.051	-0.028	0.160	0.181^***	0.218^***	-0.182	-0.0167	0.035	0.082	0.131^*	0.147^**
城市行政等级	0.010	0.008	0.003	-0.023	0.0003	0.006	-0.036	-0.013	0.007	-0.076^**	-0.072^**	-0.068^**
W-Y		0.764^***			0.779^***			0.796^***			0.422^***
Lambda			0.835^***			0.838^***			0.872^***			0.472^***
R²	0.436	0.739	0.773	0.358	0.713	0.731	0.548	0.808	0.820	0.510	0.577	0.584
LogL	276.7	319.9	327.5	242.1	292.6	294.7	265.8	319.8	320.3	241.5	250.1	250.6
AIC	-531.4	-615.9	-633.0	-462.2	-561.2	-567.4	-509.7	-615.5	-618.6	-461.1	-476.1	-479.1
SC	-497.8	-579.2	-599.4	-428.6	-524.6	-533.7	-476.1	-578.9	-594.9	-427.5	-439.4	-445.6

Spatiotemporal characteristics and dynamic mechanism of cultivated land use transition in the Beijing-Tianjin-Hebei region
