基于时空临近重复效应的犯罪热点特征及成因分析——以北京市抢劫案件为例

doi:10.18306/dlkxjz.2020.05.009

Abstract

Abstract:

As a significant spatiotemporal characteristic of crimes, repeat and near repeat pattern has received much interest in criminology research. The purpose of this study was to explore the formation process and features of crime hotspots by using near repeat principle. Robbery cases in six districts of Beijing inner city from 2012 to 2014 were used to examine the extent to which repeats and near repeats spatially intersect robbery hotspots. All the case chains within crime hotspots satisfying repeat and near repeat principle were screened out. From this, by dividing the case characteristics into criminal factors and environmental factors, the characteristics of case chains were analyzed to describe the features and formation of hotspots. The results suggest that there were three main crime hotspots in the six districts of Beijing inner city, namely "a", "b", "c", and most of the cases located within the hotspots were repeats and near repeats. The hotspot "a" was located in Shuangjing and Jinsong, and the hotspot "c" was located in Dahongmen Bridge. The characteristics of the criminal factors of these two hotspots were more consistent than that of the environmental factors, which indicates that the formation of the hotspots were more likely to originate from the repeated crimes committed in the area by criminals. The hotspot "b" was located in Fenzhongsi area by the southeastern third ring road. The characteristics of the environmental factors of this hotspot were more consistent than that of the criminal factors, which indicates that the formation of the hotspot was more likely to originate from different criminals committing crimes in this area. The research findings presented in this article can aid decision making on crime prevention and detection in policing.

Key words: near repeat principle, crime hotspot, Simpson index, case chain, Beijing

GUO Yaqi, CHEN Peng. Formation and feature analyses of crime hotspots using near repeat principle: A case study of robbery in Beijing[J].PROGRESS IN GEOGRAPHY, 2020, 39(5): 804-814.

Figures/Tables 10

Fig.1

Fig.2

Fig.3

Fig.4

Tab.1

Tab.2

Tab.3

Tab.4

Tab.5

Tab.6

References 36

[1]	Eck J E, Chainey S P, Cameron J G , et al. Mapping crime: Understanding hot spots [M]. Washington D C, USA: National Institute of Justice, 2005.
[2]	徐嘉祥, 陈鹏, 陈建国 . 基于环境犯罪学理论的入室盗窃时空分布研究: 以北京市主城区案件的分析为例 [J]. 人文地理, 2018,33(1):43-50.
	[ Xu Jiaxiang, Chen Peng, Chen Jianguo . Research on spatial-temporal distributions of burglary based on the environmental criminology: Based on the analysis of crime in Beijing. Human Geography, 2018,33(1):43-50. ]
[3]	Messner S F, Anselin L, Baller R D , et al. The spatial patterning of county homicide rates: An application of exploratory spatial data analysis [J]. Journal of Quantitative Criminology, 1999,15(4):423-450.
[4]	Ceccato V N, Oberwittler D . Comparing spatial patterns of robbery: Evidence from a Western and an Eastern European city [J]. Cities, 2008,25(4):185-196.
[5]	冯健, 黄琳珊, 董颖 , 等. 城市犯罪时空特征与机制: 以北京城八区财产类犯罪为例 [J]. 地理学报, 2012,67(12):1645-1656.
	[ Feng Jian, Huang Linshan, Dong Ying , et al. Research on the spatial-temporal characteristics and mechanism of urban crime: A case study of property crime in Beijing. Acta Geographica Sinica, 2012,67(12):1645-1656. ]
[6]	朱艳丽, 靖常峰, 伏家云 , 等. 时空立方体的抢劫案件时空特征挖掘与分析 [J]. 测绘科学, 2019,44(9):132-138, 145.
	[ Zhu Yanli, Jing Changfeng, Fu Jiayun , et al. Analysis of space-time pattern of robbery crime based on space-time cube. Science of Surveying and Mapping, 2019,44(9):132-138, 145. ]
[7]	Neumayer E . Inequality and violent crime: Evidence from data on robbery and violent theft [J]. Journal of Peace Research, 2005,42(1):101-112.
[8]	Wing M G, Tynon J . Crime mapping and spatial analysis in national forests [J]. Journal of Forestry, 2006,104(6):293-298.
[9]	毛媛媛, 戴慎志 . 犯罪空间分布与环境特征: 以上海市为例 [J]. 城市规划学刊, 2006(3):85-93.
	[ Mao Yuanyuan, Dai Shenzhi . Research on spatial and environmental characters of crimes: Case study of Shanghai. Urban Planning Forum, 2006(3):85-93. ]
[10]	柳林, 张春霞, 冯嘉欣 , 等. ZG市诈骗犯罪的时空分布与影响因素 [J]. 地理学报, 2017,72(2):315-328.
	[ Liu Lin, Zhang Chunxia, Feng Jiaxin , et al. Analysis of spatial-temporal feature of burglary cases in Changchun city. Acta Geographica Sinica, 2017,72(2):315-328. ]
[11]	Townsley M, Homel R, Chaseling J . Infectious burglaries. A test of the near repeat hypojournal [J]. British Journal of Criminology, 2003,43(3):615-633.
[12]	Ratcliffe J H, Rengert G F . Near-repeat patterns in Philadelphia shootings [J]. Security Journal, 2008,21(1-2):58-76.
[13]	Block S, Fujita S . Patterns of near repeat temporary and permanent motor vehicle thefts [J]. Crime Prevention & Community Safety, 2013,15(2):151-167.
[14]	Bowers K J, Johnson S D . Who commits near repeats? A test of the boost explanation [J]. Western Criminology Review, 2004,5(3):12-24.
[15]	Bernasco W . Them again? Same-offender involvement in repeat and near repeat burglaries [J]. European Journal of Criminology, 2008,5(4):411-431.
[16]	Reiss A . Indicators of crime and criminal justice: Quantitative studies [M]. Washington D C, USA: US Department of Justice, Bureau of Justice Statistics, 1980.
[17]	Nelson J F . Multiple victimization in American cities: A statistical analysis of rare events [J]. American Journal of Sociology, 1980,85(4):870-891. doi: 10.1086/227092
[18]	Spelman W . Once bitten, then what? Cross-sectional and time-course explanations of repeat victimization [J]. The British Journal of Criminology, 1995,35(3):366-383.
[19]	Morgan F . Repeat burglary in a Perth suburb: Indicator of short-term or long-term risk? [J]. Crime Prevention Studies, 2000,12:83-118.
[20]	Sidebottom A . Repeat burglary victimization in Malawi and the influence of housing type and area-level affluence [J]. Security Journal, 2012,25(3):265-281.
[21]	Chainey S P, da Silva B F A . Examining the extent of repeat and near repeat victimisation of domestic burglaries in Belo Horizonte, Brazil [J]. Crime Science, 2016,5(1):1-10. doi: 10.1186/s40163-016-0049-6
[22]	Haberman C P, Ratcliffe J H . The predictive policing challenges of near repeat armed street robberies [J]. Policing: A Journal of Policy and Practice, 2012,6(2):151-166.
[23]	Chainey S P, Curtis-Ham S J, Evans R M, et al. Examining the extent to which repeat and near repeat patterns can prevent crime [J]. Policing: An International Journal, 2018,41(5):608-622.
[24]	Wu L, Xu X, Ye X , et al. Repeat and near-repeat burglaries and offender involvement in a large Chinese city [J]. Cartography and Geographic Information Science, 2015,42(2):178-189.
[25]	徐冲, 柳林, 周素红 . DP半岛街头抢劫案件的临近重复发生模式 [J]. 地理研究, 2015,34(2):384-394.
	[ Xu Chong, Liu Lin, Zhou Suhong . Patterns of near-repeat street robbery in DP Peninsula. Geographical Research, 2015,34(2):384-394. ]
[26]	Tompson L. Street robbery [EB/OL]. JDiBrief Series, 2012 [ 2019- 10- 02]. http://www.ucl.ac.uk/jdibrief/crime/street-robbery.
[27]	陈鹏, 李欣, 胡啸峰 , 等. 北京市长安街沿线的扒窃案件高发区分析及防控对策 [J]. 地理科学进展, 2015,34(10):1250-1258.
	[ Chen Peng, Li Xin, Hu Xiaofeng , et al. Clustering pattern analysis and prevention strategies to pickpocketing offence along the Chang'an Street in Beijing. Progress in Geography, 2015,34(10):1250-1258. ]
[28]	李存华, 孙志挥, 陈耿 , 等. 核密度估计及其在聚类算法构造中的应用 [J]. 计算机研究与发展, 2004,41(10):1712-1719.
	[ Li Cunhua, Sun Zhihui, Chen Geng , et al. Kernel density estimation and its application to clustering algorithm construction. Journal of Computer Research and Development, 2004,41(10):1712-1719. ]
[29]	禹文豪, 艾廷华 . 核密度估计法支持下的网络空间POI点可视化与分析 [J]. 测绘学报, 2015,44(1):82-90.
	[ Yu Wenhao, Ai Tinghua . The visualization and analysis of POI features under network space supported by kernel density estimation. Acta Geodaetica et Cartographica Sinica, 2015,44(1):82-90. ]
[30]	Davies T, Johnson S D . Examining the relationship between road structure and burglary risk via quantitative network analysis [J]. Journal of Quantitative Criminology, 2014,31(3):481-507.
[31]	Sampson R J, Groves W B . Community structure and crime: Testing social-disorganization theory [J]. American Journal of Sociology, 1989,94(4):774-802.
[32]	Tseloni A, Pease K . Repeat personal victimization. "Boosts" or "flags"? [J]. British Journal of Criminology, 2003,43(1):196-212.
[33]	Johnson S D . Repeat burglary victimisation: A tale of two theories [J]. Journal of Experimental Criminology, 2008,4(3):215-240.
[34]	Wells W, Wu L, Ye X . Patterns of near-repeat gun assaults in Houston [J]. Journal of Research in Crime and Delinquency, 2012,49(2):186-212.
[35]	韩宁, 陈巍 . 基于聚类分析的串并案研究 [J]. 中国人民公安大学学报(自然科学版), 2012,18(1):53-58.
	[ Han Ning, Chen Wei . Research on bunching and merging cases based on cluster analysis. Journal of People' s Public Security University of China (Science and Technology), 2012,18(1):53-58. ]
[36]	Turchan B, Grubb J A, Pizarro J M , et al. Arson in an urban setting: A multi-event near repeat chain analysis in Flint, Michigan [J]. Security Journal, 2019,32(3):179-197.

空间间隔/m	时间间隔/d
空间间隔/m	(0, 7]	(8, 14]	(15, 21]	(22, 28]	(29, 35]	(36, 42]	(43, 49]	>49
同一地点 (1, 1000] (1001, 2000] (2001, 3000] (3001, 4000] (4001, 5000] >5000	182 59 42 70 106 98 10723	46 23 39 89 81 121 11182	43 32 42 50 63 87 11291	33 11 45 59 73 95 11114	42 19 33 58 98 104 11011	32 19 53 62 79 90 11184	36 33 59 59 69 78 10852	2351 989 2691 3918 5349 6260 772976

空间间隔/m	时间间隔/d
空间间隔/m	(0, 7]	(8, 14]	(15, 21]	(22, 28]	(29, 35]	(36, 42]	(43, 49]	>49
同一地点 (1, 1000] (1001, 2000] (2001, 3000] (3001, 4000] (4001, 5000] >5000	5.11^ 3.87^ 1.09 1.24^* 1.40^** 1.10 0.98	1.25 1.47^* 0.98 1.54^* 1.03 1.32^** 0.99	1.17 2.00^** 1.06 0.86 0.80 0.95 1.00	0.92 0.70 1.14 1.03 0.94 1.04 1.00	1.17 1.23 0.84 1.02 1.27^* 1.15 1.00	0.87 1.21 1.33^* 1.08 1.01 0.99 1.00	1.02 2.19^** 1.54^* 1.05 0.91 0.88 1.00	0.94 0.92 0.99 0.99 0.99 0.99 1.00^*

统计项	链中案件数量
统计项	2	3	4	5	6	7	8	9	10	11
时间重复案件链数量/条时空临近重复案件链数量/条案件链数量总计/条在所有案件链中占比/%	62 52 114 60.6	8 14 22 11.7	6 12 18 9.6	1 16 17 9.0	0 16 16 8.5	0 0 0 0	0 0 0 0	0 0 0 0	0 0 0 0	1 0 1 0.5

案件因素类型	案件特征类型	案件特征子类
犯罪人因素	发案时间	凌晨/早晨/上午/中午/下午/晚上
犯罪人因素	作案手段	踢打/言语胁迫/扼颈/持锐器/仗势胁迫/露械胁迫/强拿硬要/持钝器/搜身
环境因素	发案处所	宾馆/高层楼房/商业区/居民小区/网吧/普通楼房/楼群/贸易市场/一般公路/乡村公路/广场/结合部/出租屋/树林/商店/建筑工地/平房/街巷
	发案部位	客房/电梯间/路旁/楼道/胡同/卧室/河边/地下室/街心公园/门前/出租房屋/工地料场/楼口/路口/车厢
	被抢物品类型	卡/电子产品/钱/包/首饰/日用品/证件/车/钥匙/衣物

热点编号	统计指标	犯罪人因素		环境因素
热点编号	统计指标	发案时间	作案手段	发案处所	发案部位	被抢物品类型
“a”	最大值最小值平均值标准差	1.000 0 0.648 0.431	1.000 0 0.444 0.435	1.000 0 0.074 0.244	0.167 0 0.019 0.054	1.000 0 0.148 0.317
“b”	最大值最小值平均值标准差	1.000 0 0.287 0.196	0.600 0 0.146 0.136	0.600 0 0.085 0.089	1.000 0 0.347 0.192	1.000 0 0.447 0.269
“c”	最大值最小值平均值标准差	1.000 0 0.800 0.443	1.000 0 0.333 0.365	0.333 0 0.067 0.139	0 0 0 0	1.000 0 0.200 0.400
