PROGRESS IN GEOGRAPHY ›› 2019, Vol. 38 ›› Issue (12): 1957-1967.doi: 10.18306/dlkxjz.2019.12.011
• Articles • Previous Articles Next Articles
DUAN Yaming1, LIU Yong2,*(), LIU Xiuhua3, HE Dong3
Received:
2018-12-12
Revised:
2019-06-26
Online:
2019-12-28
Published:
2019-12-28
Contact:
LIU Yong
E-mail:liuyong80@cqu.edu.cn
Supported by:
DUAN Yaming, LIU Yong, LIU Xiuhua, HE Dong. Measuring polycentric urban structure using Easygo big data: A case study of Chongqing metropolitan area[J].PROGRESS IN GEOGRAPHY, 2019, 38(12): 1957-1967.
Tab.1
Heat value peak statistics of the study area"
编号 | 热力均值 | 位置 | ||
---|---|---|---|---|
休息日 | 工作日 | 整周 | ||
A | 2529 | 2453 | 2510 | 回兴地铁站—宝桐路 |
B | 3967 | 3359 | 3663 | 重庆大学—沙坪坝地铁站 |
C | 4392 | 4156 | 4274 | 建新北路—观音桥地铁站 |
D | 2376 | 2576 | 2476 | 世纪环岛—中山三路 |
E | 3569 | 3940 | 3755 | 临江门地铁站—解放碑 |
F | 2587 | 2861 | 2724 | 石桥铺地铁站 |
G | 3056 | 3006 | 3031 | 石油路地铁站—大坪地铁站 |
H | 4185 | 3969 | 4077 | 南坪地铁站—工贸地铁站 |
I | 3144 | 2811 | 2977 | 石坪桥正街—杨家坪地铁站 |
Tab.2
Average heat value statistics of important urban clusters"
名称 | 休息日 | 工作日 | 整周 | |||||
---|---|---|---|---|---|---|---|---|
热力值 | 排序 | 热力值 | 排序 | 热力值 | 排序 | |||
渝中 | 2101 | 2 | 2193 | 1 | 2147 | 1 | ||
南坪 | 2155 | 1 | 2033 | 2 | 2094 | 2 | ||
观音桥 | 2010 | 4 | 1921 | 3 | 1965 | 3 | ||
沙坪坝 | 2050 | 3 | 1875 | 4 | 1962 | 4 | ||
大杨石 | 1955 | 5 | 1865 | 5 | 1910 | 5 | ||
北碚 | 1795 | 6 | 1791 | 6 | 1793 | 6 | ||
西永 | 1683 | 7 | 1745 | 7 | 1714 | 7 | ||
空港 | 1683 | 7 | 1510 | 8 | 1597 | 8 | ||
大渡口 | 1619 | 9 | 1416 | 9 | 1517 | 9 | ||
茶园 | 1568 | 10 | 1353 | 10 | 1461 | 10 | ||
李家沱 | 1548 | 11 | 1317 | 11 | 1433 | 11 |
Tab.3
Areal statistics of each type of areas in the urban clusters"
组团 | 高集聚区面积/km2 | 中集聚区面积/km2 | 整体占比/% | 排序 | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
热力 | POI | 热力 | POI | 热力 | POI | 均值 | 热力 | POI | 均值 | ||||
渝中 | 5.87 | 6.42 | 3.87 | 3.27 | 99.23 | 98.70 | 98.97 | 1 | 1 | 1 | |||
大杨石 | 13.67 | 12.09 | 20.96 | 19.62 | 90.96 | 83.31 | 87.14 | 2 | 2 | 2 | |||
观音桥 | 15.74 | 12.55 | 33.57 | 31.03 | 86.03 | 76.04 | 81.04 | 3 | 3 | 3 | |||
南坪 | 8.91 | 5.58 | 23.17 | 20.04 | 70.74 | 56.49 | 63.62 | 4 | 4 | 4 | |||
沙坪坝 | 7.40 | 4.95 | 24.58 | 18.08 | 64.85 | 46.70 | 55.78 | 5 | 5 | 5 | |||
人和 | 3.16 | 0.96 | 32.39 | 22.12 | 48.54 | 31.51 | 40.03 | 6 | 6 | 6 | |||
李家沱 | 2.13 | 1.52 | 31.28 | 14.18 | 47.26 | 22.21 | 34.74 | 7 | 8 | 7 | |||
大渡口 | 1.78 | 1.71 | 30.68 | 16.54 | 40.70 | 22.89 | 31.80 | 8 | 7 | 8 | |||
北碚 | 4.01 | 1.70 | 12.19 | 10.92 | 26.02 | 20.28 | 23.15 | 9 | 9 | 9 | |||
空港 | 3.26 | 3.76 | 16.94 | 10.11 | 22.68 | 15.58 | 19.13 | 10 | 10 | 10 | |||
西永 | 5.79 | 0 | 35.33 | 13.20 | 19.85 | 6.37 | 13.11 | 11 | 12 | 11 | |||
茶园 | 0.25 | 0 | 8.75 | 2.10 | 15.55 | 3.63 | 9.59 | 12 | 14 | 12 | |||
礼嘉 | 0 | 0 | 7.27 | 3.30 | 10.17 | 4.61 | 7.39 | 13 | 13 | 13 | |||
西彭 | 0 | 0 | 3.23 | 3.34 | 6.17 | 6.38 | 6.28 | 16 | 11 | 14 | |||
悦来 | 0.23 | 0 | 4.19 | 1.86 | 6.95 | 2.93 | 4.94 | 14 | 15 | 15 | |||
蔡家 | 0 | 0 | 3.14 | 0 | 6.26 | 0 | 3.13 | 15 | 17 | 16 | |||
界石 | 0 | 0 | 1.45 | 0.79 | 3.95 | 2.15 | 3.05 | 19 | 16 | 17 | |||
鱼嘴 | 0 | 0 | 3.36 | 0 | 4.12 | 0 | 2.06 | 17 | 18 | 18 | |||
唐家沱 | 0 | 0 | 1.98 | 0 | 3.99 | 0 | 2.00 | 18 | 19 | 19 | |||
龙兴 | 0.14 | 0 | 1.88 | 0 | 2.02 | 0 | 1.01 | 20 | 20 | 20 | |||
水土 | 0 | 0 | 0.51 | 0 | 1.00 | 0 | 0.50 | 21 | 21 | 21 |
[1] | 丁亮, 钮心毅, 宋小冬 . 2017. 上海中心城区商业中心空间特征研究[J]. 城市规划学刊, ( 1):63-70. |
[ Ding L, Niu X Y, Song X D . 2017. A study on spatial characteristics of commercial centers in the Shanghai central city. Urban Planning Forum, ( 1):63-70. ] | |
[2] | 段亚明, 刘勇, 刘秀华 , 等. 2018. 基于POI大数据的重庆主城区多中心识别[J]. 自然资源学报, 33(5):788-800. |
[ Duan Y M, Liu Y, Liu X H , et al. 2018. Identification of polycentric urban structure of Central Chongqing using points of interest big data. Journal of Natural Resources, 33(5):788-800. ] | |
[3] | 黄光宇 . 2005. 山地城市空间结构的生态学思考[J]. 城市规划, ( 1):57-63. |
[ Huang G Y . 2005. Ecological thinking over spatial structure of Hilly City. City Planning Review, ( 1):57-63. ] | |
[4] | 黄洁, 王姣娥, 靳海涛 , 等. 2018. 北京市地铁客流的时空分布格局及特征: 基于智能交通卡数据[J]. 地理科学进展, 37(3):397-406. |
[ Huang J, Wang J E, Jin H T , et al. 2018. Investigating spatiotemporal patterns of passenger flows in the Beijing metro system from smart card data. Progress in Geography, 37(3):397-406. ] | |
[5] | 李峰清, 赵民, 吴梦笛 , 等. 2017. 论大城市“多中心”空间结构的“空间绩效”机理: 基于厦门LBS画像数据和常规普查数据的研究[J]. 城市规划学刊, ( 5):21-32. |
[ Li F Q, Zhao M, Wu M D , et al. 2017. Polycentric Mage-City and its mechanism of spatial performance: Findings from Xiamen based on LBS and census data. Urban Planning Forum, ( 5):21-32. ] | |
[6] | 廖和平, 彭征, 洪惠坤 , 等. 2007. 重庆市直辖以来的城市空间扩展与机制[J]. 地理研究, 26(6):1137-1146. |
[ Liao H P, Peng Z, Hong H K , et al. 2007. Research on dynamic mechanism and model of urban spatial expansion since the establishment of Chongqing Municipality. Geographical Research, 26(6):1137-1146. ] | |
[7] | 申犁帆, 张纯, 李赫 , 等. 2019. 城市轨道交通通勤与职住平衡状况的关系研究: 基于大数据方法的北京实证分析[J]. 地理科学进展, 38(6):791-806. |
[ Shen L F, Zhang C, Li H , et al. 2019. Relationship between urban rail transit commuting and jobs-housing balance: An empirical analysis from Beijing based on big data methods. Progress in Geography, 38(6):791-806. ] | |
[8] | 谭欣, 黄大全, 赵星烁 , 等. 2016. 基于百度热力图的职住平衡度量研究[J]. 北京师范大学学报(自然科学版), 52(5):622-627. |
[ Tan X, Huang D Q, Zhao X S , et al. 2016. Job housing balance based on Baidu thermodynamic diagram. Journal of Beijing Normal University (Natural Science), 52(5):622-627. ] | |
[9] | 吴一洲, 赖世刚, 吴次芳 . 2016. 多中心城市的概念内涵与空间特征解析[J]. 城市规划, 40(6):23-31. |
[ Wu Y Z, Lai S G, Wu C F . 2016. Research on polycentricity: Concept, connotation, and spatial feature. City Planning Review, 40(6):23-31. ] | |
[10] | 吴志强, 叶锺楠 . 2016. 基于百度地图热力图的城市空间结构研究: 以上海中心城区为例[J]. 城市规划, 40(4):33-40. |
[ Wu Z Q, Ye Z N . 2016. Research on urban spatial structure based on Baidu Heat Map: A case study on the central city of Shanghai. City Planning Review, 40(4):33-40. ] | |
[11] | 易峥 . 2004. 重庆组团式城市结构的演变和发展[J]. 规划师, 20(9):33-36. |
[ Yi Z . 2004. The evolvement and development of the clusters urban structure of Chongqing. Planners, 20(9):33-36. ] | |
[12] | 于涛方, 吴唯佳 . 2016. 单中心还是多中心:北京城市就业次中心研究[J]. 城市规划学刊, ( 3):21-29. |
[ Yu T F, Wu W J . 2016. Monocentric or Polycentric? A study on urban employment sub-centers in Beijing. Urban Planning Forum, ( 3):21-29. ] | |
[13] | 张亮, 岳文泽, 刘勇 . 2017. 多中心城市空间结构的多维识别研究: 以杭州为例[J]. 经济地理, 37(6):67-75. |
[ Zhang L, Yue W Z, Liu Y . 2017. Multidimensional analysis of the polycentric urban spatial structure: A case of Hangzhou. Economic Geography, 37(6):67-75. ] | |
[14] | 钟炜菁, 王德, 谢栋灿 , 等. 2017. 上海市人口分布与空间活动的动态特征研究: 基于手机信令数据的探索[J]. 地理研究, 36(5):972-984. |
[ Zhong W J, Wang D, Xie D C , et al. 2017. Dynamic characteristics of Shanghai's population distribution using cell phone signaling data. Geographical Research, 36(5):972-984. ] | |
[15] |
Anas A, Arnott R, Small K A . 1998. Urban spatial structure[J]. Journal of Economic Literature, 36(3):1426-1464.
doi: 10.13227/j.hjkx.201901233 pmid: 31854845 |
[16] | Cai J, Huang B, Song Y . 2017. Using multi-source geospatial big data to identify the structure of polycentric cities[J]. Remote Sensing of Environment, 202:210-221. |
[17] |
Chen Y, Liu X, Li X , et al. 2017. Delineating urban functional areas with building-level social media data: A dynamic time warping (DTW) distance based k-medoids method[J]. Landscape & Urban Planning, 160:48-60.
doi: 10.1002/cam4.2794 pmid: 31876990 |
[18] | Cheng H, Shaw D . 2018. Polycentric development practice in master planning: The case of China[J]. International Planning Studies, ( 3):1-17. |
[19] |
De Goei B, Burger M J, Van Oort F G , et al. 2010. Functional polycentrism and urban network development in the Greater South East, United Kingdom: Evidence from commuting patterns, 1981-2001[J]. Regional Studies, 44(9):1149-1170.
doi: 10.1080/00343400903365102 |
[20] |
Gordon P, Richardson H W . 2015. Employment decentralization in US metropolitan areas: Is Los Angeles an outlier or the norm?[J]. Environment and Planning A, 28(10):1727-1743.
doi: 10.1111/bjhp.12401 pmid: 31876984 |
[21] |
Green N . 2007. Functional polycentricity: A formal definition in terms of social network analysis[J]. Urban Studies, 44(11):2077-2103.
doi: 10.1080/00420980701518941 |
[22] |
Harris C D, Ullman E L . 1945. The nature of cities[J]. Annals of the American Academy of Political & Social Science, 242(1):7-17.
doi: 10.2190/NS.24.3.c pmid: 25261022 |
[23] | Huang D, Liu Z, Zhao X , et al. 2017. Emerging polycentric megacity in China: An examination of employment subcenters and their influence on population distribution in Beijing[J]. Cities, 69:36-45. |
[24] |
Kloosterman R C, Musterd S . 2001. The polycentric urban region: Towards a research agenda[J]. Urban Studies, 38(4):623-633.
doi: 10.1080/00420980120035259 |
[25] |
Li J, Long Y, Dang A . 2018. Live-work-play centers of Chinese cities: Identification and temporal evolution with emerging data[J]. Computers Environment & Urban Systems, 71:58-66.
doi: 10.3791/60425 pmid: 31840663 |
[26] |
Liu X, Wang M . 2016. How polycentric is urban China and why? A case study of 318 cities[J]. Landscape & Urban Planning, 151:10-20.
doi: 10.1002/cam4.2794 pmid: 31876990 |
[27] |
Liu Y, Fan P, Yue W , et al. 2018. Impacts of land finance on urban sprawl in China: The case of Chongqing[J]. Land Use Policy, 72:420-432.
doi: 10.1016/j.landusepol.2018.01.004 |
[28] |
Liu Y, Yue W, Fan P , et al. 2017. Assessing the urban environmental quality of mountainous cities: A case study in Chongqing, China[J]. Ecological Indicators, 81:132-145.
doi: 10.1016/j.ecolind.2017.05.048 |
[29] |
Liu Z, Liu S . 2018. Polycentric Development and the role of urban polycentric planning in China's mega cities: An examination of Beijing's metropolitan area[J]. Sustainability, 10(5):1588. doi: 10.3390/su10051588.
doi: 10.3390/su10051588 |
[30] |
Small K A, Song S . 1994. Population and employment densities: Structure and change[J]. Journal of Urban Economics, 36(3):292-313.
doi: 10.1006/juec.1994.1037 pmid: 12290251 |
[31] | Timberlake M . 2008. The polycentric metropolis: Learning from mega-city regions in Europe[J]. Journal of the American Planning Association, 74(3):384-385. |
[32] | Wen H, Tao Y . 2015. Polycentric urban structure and housing price in the transitional China: Evidence from Hangzhou[J]. Habitat International, 46:138-146. |
[33] |
Yang L, Wang Y, Bai Q , et al. 2018. Urban form and travel patterns by commuters: Comparative case study of Wuhan and Xi'an, China[J]. Journal of Urban Planning & Development, 144(1):05017014. doi: 10.1061/(ASCE)UP.1943-5444.0000417.
doi: 10.1002/jgc4.1204 pmid: 31876018 |
[34] |
Yue W, Liu Y, Fan P . 2010. Polycentric urban development: The case of Hangzhou[J]. Environment & Planning A, 42(3):563-577.
doi: 10.1002/etc.4657 pmid: 31877573 |
|
