1986—2017年呼伦湖湖冰物候特征变化

doi:10.18306/dlkxjz.2019.12.009

Abstract

Abstract:

Lake ice phenology is a sensitive indicator of climate change. This study examined lake ice phenology of the Hulun Lake in Inner Mongolia, China based on multi-source remote sensing imageries including MODIS, Landsat, GF-1, and HJ-1 and meteorological data. We used GIS technology to comprehensively analyze the phenological characteristics of ice in the Hulun Lake and its response to regional climate from 1986 to 2017. The results show that: 1) The average freezing time of the Hulun Lake began in late October to early November, and the average time from freezing to complete freezing was 6.4 days. The melting start was usually in early April of the following year, and the ablation period averaged about 32 days. At the beginning of early May, the lake ice completely melted. 2) From 1986 to 2017, the complete freezing period of the Hulun Lake showed a significant shortening trend, with an average shortening of 18.5 days. The complete freezing time showed some delay, with an average delay of 8.4 days. The complete ice melting time advanced, with an average advancement of 11.2 days. 3) The spatial characteristics of freezing and melting of lake ice are different. Freezing starts from the complex shoreline areas of the lake, then rapidly propagate from the east coast to the west coast, but melting starts from the northwest coast of the lake and gradually spread toward the east shore. 4) The characteristics of ice conditions in the Hulun Lake are mainly affected by regional air temperature, wind speed, wind direction, among other factors.

Key words: lake ice, multi-source remote sensing, temporal and spatial changes, phenology, Hulun Lake

WU Qihui, LI Changyou, SUN Biao, SHI Xiaohong, ZHAO Shengnan, HAN Zhiming. Change of ice phenology in the Hulun Lake from 1986 to 2017[J].PROGRESS IN GEOGRAPHY, 2019, 38(12): 1933-1943.

Figures/Tables 10

Fig.1

Fig.2

Tab.1

Fig.3

Tab.2

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

References 35

[1]	白照广 . 2013. 高分一号卫星的技术特点[J]. 中国航天, ( 8):5-9.
	[ Bai Z G . 2013. Technical characteristics of Gaofen-1 satellite. Chinese Space, ( 8):5-9. ]
[2]	车涛, 李新, 晋锐 . 2009. 利用被动微波遥感低频亮温数据监测青海湖封冻与解冻期[J]. 科学通报, 54(6):787-791.
	[ Che T, Li X, Jin R . 2009. Monitoring the frozen duration of Qinghai Lake using satellite passive microwave remote sensing low frequency data. Chinese Science Bulletin, 54(6):787-791. ]
[3]	勾鹏, 叶庆华, 魏秋方 . 2015. 2000—2013年西藏纳木错湖冰变化及其影响因素[J]. 地理科学进展, 34(10):1241-1249. doi: 10.18306/dlkxjz.2015.10.004
	[ Gou P, Ye Q H, Wei Q F . 2015. Lake ice change at the Namco Lake on the Tibetan Plateau during 2000-2013 and influencing factors. Progress in Geography, 34(10):1241-1249. ] doi: 10.18306/dlkxjz.2015.10.004
[4]	韩知明, 贾克力, 赵胜男 , 等. 2017. 呼伦湖冰封期与非冰封期营养盐与离子分布特征研究[J]. 生态环境学报, 26(7):1201-1209.
	[ Han Z M, Jia K L, Zhao S N , et al. 2017. Distribution characteristics of the nutrients and ion of Hulun Lake in frozen and unfrozen period. Ecology and Environmental Sciences, 26(7):1201-1209. ]
[5]	祁苗苗, 姚晓军, 李晓锋 , 等. 2018. 2000—2016年青海湖湖冰物候特征变化[J]. 地理学报, 73(5):932-944. doi: 10.11821/dlxb201805012
	[ Qi M M, Yao X J, Li X F , et al. 2018. Spatial-temporal characteristics of ice phenology of Qinghai Lake from 2000 to 2016. Acta Geographica Sinica, 73(5):932-944. ] doi: 10.11821/dlxb201805012
[6]	秦大河 . 2012. 中国气候与环境演变: 2012综合卷 [M]. 北京: 气象出版社.
	[ Qin D H. 2012. Climate and environment change in China: 2012 comprehensive volume. Beijing, China: China Meteorological Press. ]
[7]	曲斌, 康世昌, 陈锋 , 等. 2012. 2006—2011年西藏纳木错湖冰状况及其影响因素分析[J]. 气候变化研究进展, 8(5):327-333. doi: 10.3969/j.issn.1673-1719.2012.05.003
	[ Qu B, Kang S C, Chen F , et al. 2012. Lake ice and its effect factors in the Nam Co Basin, Tibetan Plateau. Progressus Inquisitiones de Mutatione Climatis, 8(5):327-333. ] doi: 10.3969/j.issn.1673-1719.2012.05.003
[8]	孙标 . 2010. 基于空间信息技术的呼伦湖水量动态演化研究[D]. 呼和浩特: 内蒙古农业大学.
	[ Sun B . 2010. The dynamic change of water based on spatial information technology for Hulun Lake in Inner Mongolia. Huhhot, China: Inner Mongolia Agricultural University. ]
[9]	陶安琪 . 2014. 被动微波遥感纳木错湖冰变化研究[D]. 南京: 南京大学.
	[ Tao A Q . 2014. Research on the variation of Namco Lake ice by passive microwave remote sensing. Nanjing, China: Nanjing University. ]
[10]	汪敬忠, 吴敬禄, 曾海鳌 , 等. 2015. 内蒙古主要湖泊水资源及其变化分析[J]. 干旱区研究, 32(1):7-14.
	[ Wang J Z, Wu J L, Zeng H A , et al. 2015. Changes of Water resources of the Main Lakes in Inner Mongolia. Arid Zone Research, 32(1):7-14. ]
[11]	王桥, 吴传庆, 厉青 . 2010. 环境一号卫星及其在环境监测中的应用[J]. 遥感学报, 14(1):113-126. doi: 10.11834/jrs.20100109
	[ Wang Q, Wu C Q, Li Q . 2010. Environment satellite 1 and its application in environmental monitoring. Journal of Remote Sensing, 14(1):113-126. ] doi: 10.11834/jrs.20100109
[12]	王苏民 . 1998. 中国湖泊志 [M]. 北京: 科学出版社.
	[ Wang S M. 1998. China lakes record. Beijing, China: Science Press. ]
[13]	王智颖, 吴艳红, 常军 , 等. 2017. 青藏高原湖冰物候的时空变化及其影响因素[J]. 北京工业大学学报, 43(5):701-709.
	[ Wang Z Y, Wu Y H, Chang J , et al. 2017. Temporal and spatial variation of lake ice phenology and its influencing factors in the Tibetan Plateau. Journal of Beijing University of Technology, 43(5):701-709. ]
[14]	魏秋方, 叶庆华 . 2010. 湖冰遥感监测方法综述[J]. 地理科学进展, 29(7):803-810. doi: 10.11820/dlkxjz.2010.07.005
	[ Wei Q F, Ye Q H . 2010. Review of lake ice monitoring by remote sensing. Progress in Geography, 29(7):803-810. ] doi: 10.11820/dlkxjz.2010.07.005
[15]	吴其慧 . 2018. 基于遥感影像的呼伦湖湖冰近30年的变化分析及其影响因素研究[D]. 呼和浩特: 内蒙古农业大学.
	[ Wu Q H . 2018. Study on the variation of Hulun Lake ice in recent 30 years and its influencing factors based on remote sensing image. Huhhot, China: Inner Mongolia Agricultural University. ]
[16]	徐占江 . 1989. 呼伦湖志 [M]. 吉林: 吉林文史出版社.
	[ Xu Z J. 1989. Records of Hulun Lake. Jilin, China: Jilin Literature and History Press. ]
[17]	殷青军, 杨英莲 . 2005. 基于EOS/MODIS数据的青海湖遥感监测[J]. 湖泊科学, 17(4):356-360.
	[ Yin Q J, Yang Y L . 2005. Remote sensing monitoring of Lake Qinghai basedon EOS/MODIS data. Journal of Lake Sciences, 17(4):356-360. ]
[18]	姚晓军, 李龙, 赵军 , 等. 2015. 近10年来可可西里地区主要湖泊冰情时空变化[J]. 地理学报, 70(7):1114-1124. doi: 10.11821/dlxb201507008
	[ Yao X J, Li L, Zhao J , et al. 2015. Spatial-temporal variations of lake ice in the Hoh Xil region from 2000 to 2011. Acta Geographica Sinica, 70(7):1114-1124. ] doi: 10.11821/dlxb201507008
[19]	Benson B J, Magnuson J J, Jensen O P , et al. 2012. Extreme events, trends, and variability in Northern Hemisphere lake-ice phenology (1855-2005)[J]. Climatic Change, 112(2):299-323. doi: 10.1007/s10584-011-0212-8
[20]	Cai Y, Chang Q K, Li X , et al. 2019. Variations of lake ice phenology on the Tibetan Plateau from 2001 to 2017 based on MODIS Data[J]. Journal of Geophysical Research: Atmospheres, 124(2):825-843. doi: 10.1029/2018JD028993
[21]	Cheng A, Ruth P . 2013. An ice-ocean coupled model for the Northern Hemisphere[J]. Geophysical Research Letters, 19(9):901-904. doi: 10.5065/D6TH8KGW pmid: 31633127
[22]	Dibike Y, Prowse T, Bonsal B , et al. 2012. Simulation of North American lake ice cover characteristics under contemporary and future climate conditions[J]. International Journal of Climatology, 32(5):695-709. doi: 10.1002/joc.v32.5
[23]	Duguay C R, Prowse T D, Bonsal B R , et al. 2010. Recent trends in Canadian lake ice cover[J]. Hydrological Processes, 20(4):781-801. doi: 10.1016/j.envpol.2018.05.049 pmid: 29870948
[24]	Hodgkins G A, Ii I C J, Huntington T G . 2002. Historical changes in lake ice-out dates as indicators of climate change in New England, 1850-2000[J]. International Journal of Climatology, 22(15):1819-1827. doi: 10.1002/(ISSN)1097-0088
[25]	Howell S E L, Brown L C, Kang K K , et al. 2009. Variability in ice phenology on Great Bear Lake and Great Slave Lake, Northwest Territories, Canada, from SeaWinds/QuikSCAT: 2000-2006[J]. Remote Sensing of Environment, 113(4):816-834. doi: 10.1016/j.rse.2008.12.007
[26]	Kour R, Patel N, Krishna A P . 2015. Assessment of relationship between snow cover characteristics (SGI and SCI) and snow cover indices (NDSI and S3)[J]. Earth Science Informatics, 8(2):317-326. doi: 10.1007/s12145-015-0216-4
[27]	Kropáček J, Maussion F, Chen F , et al. 2013. Analysis of ice phenology of lakes on the Tibetan Plateau from MODIS data[J]. Cryosphere, 7(1):287-301. doi: 10.5194/tc-7-287-2013
[28]	Latifovic R, Pouliot D . 2007. Analysis of climate change impacts on lake ice phenology in Canada using the historical satellite data record[J]. Remote Sensing of Environment, 106(4):492-507. doi: 10.1016/j.rse.2006.09.015
[29]	Magnuson J J, Robertson D M, Benson B J , et al. 2000. Historical trends in lake and river ice cover in the northern hemisphere[J]. Science, 289:1743-1746. doi: 10.1126/science.289.5485.1743 pmid: 10976066
[30]	Oveisy A, Boegman L, Imberger J . 2014. Three-dimensional simulation of lake and ice dynamics during winter[J]. Journal of Limnology, 73(3):43-57.
[31]	Pachauri R, La M . 2014. IPCC 2014: Climate change 2014: Synjournal report. Contribution of Working Groups I, II and III to the fifth assessment report of the intergovernmental panel on climate change[J]. Journal of Romance Studies, 4(2):85-88. doi: 10.3828/jrs.4.2.85
[32]	Stocker T F, Qin D, Plattner G K , et al. 2014. Climate change 2013: The physical science basis. Contribution of working group I to the fifth assessment report of IPCC the intergovernmental panel on climate change [M]. Cambridge, UK: Cambridge University Press.
[33]	Weber H, Riffler M, Nõges T , et al. 2016. Lake ice phenology from AVHRR data for European lakes: An automated two-step extraction method[J]. Remote Sensing of Environment, 174:329-340. doi: 10.1016/j.rse.2015.12.014
[34]	Weyhenmeyer G A, Meili M, Livingstone D M . 2012. Nonlinear temperature response of lake ice breakup[J]. Geophysical Research Letters, 31(31):157-175.
[35]	Zhang G Q, Xie H J, Yao T D , et al. 2013. Water balance estimates of ten greatest lakes in China using ICESat and Landsat data[J]. Chinese Science Bulletin, 58(31):3815-3829. doi: 10.1007/s11434-013-5818-y

遥感卫星	传感器	轨道号	空间分辨率/m	回归周期/d	过境时间	波段数	使用景数
Landsat	TM/ETM+/OLI	124/26	30	16		7~11	91
TERRA/AQUA	MODIS	h25v04	250	1	10:30 am, 1:30 pm	2	33
GF-1	WFV	4/72	16	2	10:30 am	4	6
HJ-1A/B	CCD	9/52	30	4	10:30 am ±30 min	4	45

时间	初冰日	完全冻结日	开始消融日	完全消融日	湖冰完全封冻期/d	湖冰存在期/d	湖冰冻结期/d	湖冰消融期/d
1986/1987年	297	301	108(+2)	140(+2)	173	209	5	32
1992/1993年	304(-1)	307	102(-1)	127(+1)	162	190	4	26
1997/1998年	300(-1)	311(-1)	95(-1)	122	150	188	11	28
2002/2003年	299(+1)	312(+1)	92	136	147	203	12	45
2005/2006年	303	308(+1)	94(+1)	132	152	195	6	39
2008/2009年	305	311	97	129	153	191	7	33
2010/2011年	287	309	99(-1)	127	156	206	23	29
2011/2012年	308	316(-1)	96	132	147	190	9	36
2012/2013年	303	307	99(+2)	137(+1)	159	201	5	38
2013/2014年	310(-1)	318	95	124	143	180	9	30
2014/2015年	308	309(+1)	98	125	155	183	2	28
2015/2016年	307	310	96	123	153	183	4	28
2016/2017年	300(+1)	303	94(+1)	120(-2)	158	187	3	29
平均	302.3	309.4	97.3	128.8	154.5	192.8	6.4	32.2
阶段平均变幅/d	+0.3	+0.2	-1.2	-1.7	-0.9	-2.3	-0.1	-0.5
