北京城市代谢预测研究——基于长短期记忆神经网络模型

doi:10.18306/dlkxjz.2019.06.006

Abstract

Abstract:

The underlying causes of aggravating urban environmental pollution, escalating energy consumption, population overcrowding, and other urban environmental problems are imbalances in urban metabolism. In order to accurately predict the trend of urban metabolism changes in Beijing City, the exosomatic metabolic rate of Beijing from 1980 to 2016 was estimated by the indicators of energy consumption and human activity time, and the degree of urban metabolism was characterized. Based on the results, the long short-term memory (LSTM) neural network model was used to predict the exosomatic metabolic rate of various sectors in Beijing from 2017 to 2022. The results show that: 1) the urban metabolic prediction model based on LSTM neural network has high accuracy and can make more accurate prediction on the exosomatic metabolic rate of various sectors in Beijing. 2) From 2017 to 2022, the exosomatic metabolic rate of the primary industry and the overall external energy in Beijing show a downward trend, among which the primary industry reached its peak in 2017, and the exosomatic metabolism rates of the secondary and tertiary industries show an increasing trend. 3) Except for the primary industry, tertiary industry and the overall exosomatic metabolic rate, the temporal perturbation of historical change ranged from small to large. 4) The factors that contribute the most to EMR_T are EMR₂, and the least are EMR₁. This study may provide a theoretical basis and decision-making support for policymakers to optimize urban management plans and enhance urban comprehensive strength.

Key words: long short-term memory neural network, exosomatic metabolic rate, urban metabolism, Beijing

Bingchun LIU, Xin QI, Qingshan WANG. Urban metabolism prediction of Beijing City based on long short-term memory neural network[J].PROGRESS IN GEOGRAPHY, 2019, 38(6): 851-860.

Figures/Tables 10

Fig.1

Fig.2

Fig.3

Fig.4

Tab.1

Tab.2

Tab.3

Tab.4

Tab.5

Fig.5

References 40

[1]	李恒. 2019. 人口集中、城市群对经济增长作用的实证分析: 以中国十大城市群为例[J]. 河南大学学报(社会科学版), 59(1): 43-52.
	[Li H.2019. Empirical analysis of the effects of population concentration and urban agglomeration on economic growth. Journal of Henan University (Social Science), 59(1): 43-52. ]
[2]	李旋旗, 花利忠. 2012. 基于系统动力学的城市住区形态变迁对城市代谢效率的影响[J]. 生态学报, 32(10): 2965-2974. doi: 10.5846/stxb201104250542
	[Li X Q, Hua L Z.2012. Landscape aesthetic assessment based on experiential paradigm assessment technology. Acta Ecologica Sinica, 32(10): 2965-2974. ] doi: 10.5846/stxb201104250542
[3]	刘晔, 耿涌, 赵恒心. 2011. 基于MSIASM方法的中国省级行政区体外能代谢分析[J]. 生态学报, 31(11): 3133-3142.
	[Liu Y, Geng Y, Zhao H X, 2011. Societal metabolism for chinese provinces based on multi-scale integrated analysis of societal metabolism (MSIASM). Acta Ecologica Sinica, 31(11): 43-52. ]
[4]	宋涛, 蔡建明, 倪攀, 等. 2013a. 城市新陈代谢研究综述及展望[J]. 地理科学进展, 32(11): 1650-1661.
	[Song T, Cai J M, Ni P, et al.2013. Review and prospects of urban metabolism research. Progress in Geography, 32(11): 1650-1661. ]
[5]	宋涛, 蔡建明, 倪攀, 等. 2013b. 基于能值和DEA的中国城市新陈代谢效率分析[J]. 资源科学, 35(11): 2166-2173.
	[Song T, Cai J M, Pan N, et al.2013. Chinese urban metabolic efficiencies based on emergy and DEA. Resources Science, 35(11): 2166-2173. ]
[6]	王天送. 2008. 社会代谢多尺度综合评估(MSIASM)的基本理论与实践[J]. 地球科学进展, 27(1): 63-70.
	[Wang T.2008. The rationale of multiple-scale integrated assessment of societal metabolism. Advances in Earth Science, 27(1): 63-70. ]
[7]	王劲峰,徐成东. 2017. 地理探测器: 原理与展望[J]. 地理学报, 72(1): 116-134.
	[Wang J, Xu C.2017. Geodetector: Principle and prospective. Acta Geographica Sinica, 72(1): 116-134. ]
[8]	文琦,施琳娜,马彩虹, 等. 2018. 黄土高原村域多维贫困空间异质性研究: 以宁夏彭阳县为例[J]. 地理学报, 73(10): 1850-1864.
	[Wen Q, Shi L, Ma C, et al.2018. Spatial heterogeneity of multidimensional poverty at the village level: Loess Plateau. Acta Geographica Sinica, 73(10): 1850-1864. ]
[9]	湛东升,张文忠,余建辉, 等. 2015. 基于地理探测器的北京市居民宜居满意度影响机理[J]. 地理科学进展, 34(8): 966-975. doi: 10.18306/dlkxjz.2015.08.004
	[Zhan D, Zhang W, Yu J, et al.2015. Analysis of influencing mechanism of residents' livability satisfaction in Beijing using geographical detector. Progress in Geography, 34(8): 966-975. ] doi: 10.18306/dlkxjz.2015.08.004
[10]	Abdel-Nasser M, Mahmoud K.2017. Accurate photovoltaic power forecasting models using deep LSTM-RNN[J]. Neural Computing & Applications, 10: 1-14.
[11]	Elliot T, Rugani B, Almenar J B, et al.2018. A proposal to integrate system dynamics and carbon metabolism for urban planning[J]. Procedia CIRP, 69: 78-82. doi: 10.1016/j.procir.2017.10.003
[12]	Geng Y, Liu Y, Liu D, et al.2011. Regional societal and ecosystem metabolism analysis in China: A multi-scale integrated analysis of societal metabolism (MSIASM) approach[J]. Energy, 36(8): 4799-4808. doi: 10.1016/j.energy.2011.05.014
[13]	Giampietro M, Mayumi K.1997. A dynamic model of socioeconomic systems based on hierarchy theory and its application to sustainability[J]. Structural Change & Economic Dynamics, 8(4): 453-469.
[14]	Giampietro M, Mayumi K.2000. Multiple-scale integrated assessment of societal metabolism: Introducing the approach[J]. Population & Environment, 22(2): 109-153.
[15]	Giampietro M, Mayumi K, Munda G.2006. Integrated assessment and energy analysis: Quality assurance in multi-criteria analysis of sustainability[J]. Energy, 31(1): 59-86. doi: 10.1016/j.energy.2005.03.005
[16]	Greff K, Srivastava R K, Koutník J, et al.2017. LSTM: A search space odyssey[J]. IEEE Transactions on Neural Networks & Learning Systems, 28(10): 2222-2232.
[17]	Hadiye A S, Giampietro M, Aleu A L, et al.2009. Applications of the MuSIASEM approach to study changes in the metabolic pattern of Catalonia [R/OL]. Reports on Environmental Sciences. 2009-07-27 [2019-03-15]. .
[18]	Han W, Geng Y, Lu Y, et al.2018. Urban metabolism of megacities: A comparative analysis of Shanghai, Tokyo, London and Paris to inform low carbon and sustainable development pathways[J]. Energy, 155(15): 887-898. doi: 10.1016/j.energy.2018.05.073
[19]	Jiang Q, Tang C, Chen C, et al.2018. Stock price forecast based on LSTM neural network[C]// Xu J, Cooke F, Gen M, et al. Proceedings of the twelfth international conference on management science and engineering management. ICMSEM 2018. Cham: Springer: 393-408.
[20]	Kumar J, Goomer R, Singh A K.2018. Long short term memory recurrent neural network (LSTM-RNN) based workload forecasting model for cloud datacenters[J]. Procedia Computer Science, 125: 676-682. doi: 10.1016/j.procs.2017.12.087
[21]	Li Y, Wang X, Tian X, et al.2018. Understanding the mechanism of urban material metabolism with ecological network analysis: An experimental study of Wuxi, China[J]. Ecological Modelling, 367: 58-67 doi: 10.1016/j.ecolmodel.2017.09.007
[22]	Lu Y, Geng Y, Qian Y, et al.2016. Changes of human time and land use pattern in one mega city's urban metabolism: A multi-scale integrated analysis of Shanghai[J]. Journal of Cleaner Production, 133(1): 391-401. doi: 10.1016/j.jclepro.2016.05.174
[23]	Ma X, Tao Z, Wang Y, et al.2015. Long short-term memory neural network for traffic speed prediction using remote microwave sensor data[J]. Transportation Research Part C, 54: 187-197 doi: 10.1016/j.trc.2015.03.014
[24]	Martín J R, Eisenmenger N, Schandl H.2008. Different trajectories of exosomatic energy metabolism for Brazil, Chile and Venezuela: Using the MSIASM approach [R]. Working Papers. Barcelona, Spain: Department of Applied Economics, Universitat Autonoma of Barcelona.
[25]	Mayumi K.1991. Temporary emancipation from land: From the industrial revolution to the present time[J]. Ecological Economics, 4(1): 35-56. doi: 10.1016/0921-8009(91)90004-X
[26]	Munro D A, Holdgate M W.1991. Caring for the earth: A strategy for sustainable living[M]. IUCN, UNEP, WWF: 14-15.
[27]	Pincetl S, Bunje P, Holmes T.2012. An expanded urban metabolism method: Toward a systems approach for assessing urban energy processes and causes[J]. Landscape & Urban Planning, 107(3): 193-202.
[28]	Qi W, Deng X, Chu X, et al.2017. Emergy analysis on urban metabolism by counties in Beijing[J]. Physics & Chemistry of the Earth Parts A/B/C, 101: 157-165.
[29]	Ramos-Martin J, Giampietro M, Mayumi K.2007. On China's exosomatic energy metabolism: An application of multi-scale integrated analysis of societal metabolism (MSIASM)[J]. Ecological Economics, 63(1): 174-191. doi: 10.1016/j.ecolecon.2006.10.020
[30]	Scheidel A. 2013. From MuSIASEM theory to practice: Report and reflections from field research in Kampot province, Cambodia [R/OL]. Reports on Environmental Sciences. Institute of Environmental Science and Technology (ICTA). Barcelona, Spain: Autonomous University of Barcelona (UAB). .
[31]	Silva-Macher J C.2016. A metabolic profile of peru: An application of multi-scale integrated analysis of societal and ecosystem metabolism (MuSIASEM) to the mining sector's exosomatic energy flows[J]. Journal of Industrial Ecology, 20(5): 1072-1082. doi: 10.1111/jiec.12337
[32]	Song T, Cai J M, Chahine T, et al.2014. Modeling urban metabolism of Beijing City, China: With a coupled system dynamics: Emergy model[J]. Stochastic Environmental Research & Risk Assessment, 28(6): 1511-1524.
[33]	Tejedor-Flores N, Vicente-Galindo P, Galindo-Villardón P.2017. Sustainability multivariate analysis of the energy consumption of ecuador using MuSIASEM and BIPLOT approach[J]. Sustainability, 9(6): 984. doi: 10.3390/su9060984
[34]	Vafa-Arani H, Jahani S, Dashti H, et al.2014. A system dynamics modeling for urban air pollution: A case study of Tehran, Iran[J]. Transportation Research Part D Transport & Environment, 31(31): 21-36.
[35]	Wang X, Wu S, Li S.2017. Urban metabolism of three cities in Jing-Jin-Ji urban agglomeration, China: Using the MuSIASEM Approach[J]. Sustainability, 9(8): 1481-1502. doi: 10.3390/su9081481
[36]	Yuan X, Chen C, Lei X, et al.2018. Monthly runoff forecasting based on LSTM-ALO model[J]. Stochastic Environmental Research & Risk Assessment, 32(8): 1-14.
[37]	Yan Z, Li Y, Zheng H.2017. Ecological network analysis of energy metabolism in the Beijing-Tianjin-Hebei (Jing-Jin-Ji) urban agglomeration[J]. Ecological Modelling, 351: 51-62. doi: 10.1016/j.ecolmodel.2017.02.015
[38]	Yan Z, Zheng H, Yang Z, et al.2016. Urban energy flow processes in the Beijing-Tianjin-Hebei (Jing-Jin-Ji) urban agglomeration: Combining multi-regional input-output tables with ecological network analysis[J]. Journal of Cleaner Production, 114: 243-256. doi: 10.1016/j.jclepro.2015.06.093
[39]	Zhai M, Huang G, Liu L, et al.2018. Dynamic input-output analysis for energy metabolism system in the Province of Guangdong, China[J]. Journal of Cleaner Production, 196: 747-762. doi: 10.1016/j.jclepro.2018.06.084
[40]	Zhang J, Zhang Y.2011. Ecological network analysis of an urban energy metabolic system[J]. Stochastic Environmental Research & Risk Assessment, 25(5): 685-695.

年份	第一产业		第二产业		第三产业		生活部门			总体
年份	EMR₁/(MJ/h)	增速/%	EMR₂/(MJ/h)	增速/%	EMR₃/(MJ/h)	增速/%	EMR₄/(MJ/h)	增速/%		EMR_T/(MJ/h)	增速/%
2017	22.36	1.09	143.31	1.3	52.04	2.08	2.89		2.62	10.29	-4.94
2018	22.11	-1.1	145.26	1.36	52.8	1.46	2.99		3.16	10	-2.77
2019	22.08	-0.15	147.23	1.36	53.63	1.57	3.09		3.37	9.55	-4.5
2020	21.95	-0.61	149.23	1.36	54.47	1.56	3.21		4.02	9.16	-4.13
2021	21.86	-0.41	151.26	1.36	55.33	1.57	3.35		4.26	8.69	-5.08
2022	21.75	-0.51	153.32	1.36	56.2	1.59	3.51		4.94	8.21	-5.47

代谢率	情景分类	2018年	2019年	2020年	2021年	2022年
EMR_T	历史情景	10.00	9.55	9.16	8.69	8.21
	低增长率	9.10	8.76	8.22	7.74	7.18
	高增长率	10.90	10.33	10.07	9.61	9.23
EMR₁	历史情景	22.11	22.08	21.95	21.86	21.75
	低增长率	20.29	20.43	20.14	20.05	19.86
	高增长率	23.88	23.71	23.72	23.65	23.61
EMR₂	历史情景	145.26	147.23	149.23	151.26	153.32
	低增长率	131.48	133.26	135.06	136.89	138.74
	高增长率	159.05	161.22	163.43	165.67	167.94
EMR₃	历史情景	52.80	53.63	54.47	55.33	56.20
	低增长率	48.20	48.98	49.72	50.49	51.27
	高增长率	57.38	58.30	59.28	60.29	61.34
EMR₄	历史情景	2.99	3.09	3.21	3.35	3.51
	低增长率	2.73	2.86	2.91	3.02	3.12
	高增长率	3.26	3.33	3.54	3.71	3.97

代谢率	情景分类	2018年	2019年	2020年	2021年	2022年	代数平均值
EMR_T	低增长率	-9.02	-8.27	-10.22	-10.90	-12.57	-10.19
EMR_T	高增长率	9.02	8.14	9.95	10.56	12.31	10.00
EMR₁	低增长率	-8.27	-7.48	-8.22	-8.25	-8.69	-8.18
EMR₁	高增长率	8.01	7.36	8.09	8.19	8.58	8.05
EMR₂	低增长率	-9.49	-9.49	-9.50	-9.50	-9.51	-9.50
EMR₂	高增长率	9.50	9.50	9.51	9.52	9.53	9.51
EMR₃	低增长率	-8.72	-8.68	-8.71	-8.74	-8.78	-8.73
EMR₃	高增长率	8.67	8.71	8.84	8.98	9.14	8.87
EMR₄	低增长率	-8.70	-7.20	-9.45	-9.65	-11.29	-9.26
EMR₄	高增长率	9.20	7.85	10.27	10.82	13.09	10.25

代谢率	EMR₁	EMR₂	EMR₃	EMR₄
EMR₁	0.7977
EMR₂	0.9559	0.8948
EMR₃	0.9531	0.9607	0.8209
EMR₄	0.9202	0.9862	0.9397	0.8464

模型	EMR_T	EMR₁	EMR₂	EMR₃	EMR₄
KPCA-SVR	0.0616	0.1636	0.1048	0.4116	0.2650
KPCA-REG	0.0484	0.1879	0.1321	0.3079	6.0582
KPCA-LAS	0.0883	0.2021	0.1321	0.3081	0.4219
KPCA-GBR	0.0864	0.1133	0.2592	0.4692	0.3193
LSMT	0.0470	0.0476	0.0779	0.0208	0.0585
