基于生态-经济权衡的京津冀城市群土地利用优化配置

doi:10.18306/dlkxjz.2019.01.003

Abstract

Abstract:

In order to achieve harmonious ecological and economic development in urban agglomerations, it is important to explore the trade-offs between environmental protection and economic development, and use this knowledge to optimize land use allocation. This study aimed to simulate land use changes in the Beijing-Tianjin-Hebei urban agglomeration with different goals and under different scenarios in 2025 to identify the optimal land use allocation strategies based on the trade-offs between ecological and economic benefits. In order to meet the land use demands for environment-friendly development in the Beijing-Tianjin-Hebei urban agglomeration, we developed two optimization goals—ecosystem services value maximization and economic value maximization, and four land use scenarios—environmental protection, balanced development, food security, and economic development focus. A CLUE-S model was built to simulate and predict the optimal land use allocation strategy. The results show that the optimal land use allocations with the ecosystem services maximization goal were very different comparing to that with the economic value maximization goal. The ecosystem services value is estimated to be approximately 1442.36 billion Yuan with the ecosystem services maximization goal and under the environmental protection scenarios, more than that with the economic value maximization goal and under the same scenario. Spatially, the increase of ecologically beneficial land-use types, including forest land and grassland, is more often seen in the Bashang Plateau, Yanshan Mountains, and Taihang Mountains. The increase of water areas often occurs in coastal regions in the east. There are significant trade-offs between ecosystem services value maximization and economic value maximization. The results of this trade-off analysis can provide a basis for future ecological projects in the Beijing-Tianjin-Hebei urban agglomeration.

Key words: ecological-economic benefits trade-off, land use allocation, CLUE-S model, Beijing-Tianjin-Hebei urban agglomeration

Bingying MA, Jiao HUANG, Shuangcheng LI. Optimal allocation of land use types in the Beijing-Tianjin-Hebei urban agglomeration based on ecological and economic benefits trade-offs[J].PROGRESS IN GEOGRAPHY, 2019, 38(1): 26-37.

Figures/Tables 12

Fig.1

Tab.1

Tab.2

Tab.3

Tab.4

Tab.5

Tab.6

Fig.2

Fig. 3

Tab.9

References 22

[1]	包蕊, 刘峰, 张建平, 等. 2018. 基于多目标线性规划的甲积峪小流域生态系统服务权衡优化[J]. 生态学报, 38(3): 812-828.
	[Bao R, Liu F, Zhang J P, et al.2018. Multi-objective linear programming-based trade-off and optimization of the ecosystem services in Jiajiyu small watershed in the Loess Plateau, China. Acta Ecologica Sinica, 38(3): 812-828. ]
[2]	陈卓, 李秀霞, 徐龙. 2013. 基于经济-生态双重目标的土地结构优化: 以吉林省西部为例[J]. 国土资源科技管理, 30(5): 28-34.
	[Chen Z, Li X X, Xu L.2013. Optimization of land use structure based on dual targets of ecology and economy: A case study of west of Jilin Province. Scientific and Technological Management of Land and Resources, 30(5): 28-34. ]
[3]	方创琳, 周成虎, 顾朝林, 等. 2016. 特大城市群地区城镇化与生态环境交互耦合效应解析的理论框架及技术路径[J]. 地理学报, 71(4): 531-550.
	[Fang C L, Zhou C H, Gu C L, et al.2016. Theoretical analysis of interactive coupled effects between urbanization and eco-environment in mega-urban agglomerations. Acta Geographica Sinica, 71(4): 531-550. ]
[4]	龚建周, 刘彦随, 张灵. 2010. 广州市土地利用结构优化配置及其潜力[J]. 地理学报, 65(11): 1391-1400.
	[Gong J Z, Liu Y S, Zhang L.2010. The optimal allocation of land use and its potential appraisal in Guangzhou City. Acta Geographica Sinica, 65(11): 1391-1400. ]
[5]	郭小燕, 刘学录, 王联国. 2016. 以提高生态系统服务为导向的土地利用优化研究: 以兰州市为例[J]. 生态学报, 36(24): 7992-8001.
	[Guo X Y, Liu X L, Wang L G.2016. Land use optimization in order to improve ecosystem service: A case of Lanzhou City. Acta Ecologica Sinica, 36(24): 7992-8001.]
[6]	李双成, 等. 2014. 生态系统服务地理学 [M]. 北京: 科学出版社: 1-58.
	[Li S C, et al.2014. The geography of ecosystem services . Beijing, China: Science Press: 1-58. ]
[7]	李天猜, 李韦, 冯长春, 等. 2016. 湘江新区土地利用结构多目标规划及决策偏好分析[J]. 地域研究与开发, 35(1): 132-138.
	[Li T C, Li W, Feng C C, et al.2016. Multi-objective land use planning and decision analysis in Xiangjiang new area. Areal Research and Development, 35(1): 132-138. ]
[8]	刘超, 许月卿, 孙丕苓, 等. 2016. 土地利用多功能性研究进展与展望[J]. 地理科学进展, 35(9): 1087-1099.
	[Liu C, Xu Y Q, Sun P L, et al.2016. Progress and prospects of multi-functionality of land use research. Progress in Geography, 35(9): 1087-1099. ]
[9]	刘金龙, 马程, 王阳, 等. 2013. 基于径向基函数网络的京津冀地区生态系统服务脆弱性评估[J]. 北京大学学报(自然科学版), 49(6): 1040-1046.
	[Liu J L, Ma C, Wang Y, et al.2013. Assessing the vulnerability of ecosystem services of Beijing-Tianjin-Hebei area based on radial basis function network. Acta Scientiarum Naturalium Universitatis Pekinensis, 49(6): 1040-1046. ]
[10]	刘静怡, 蔡永立, 於家, 等. 2013. 基于CLUE-S和灰色线性规划的嘉兴北部土地利用优化配置研究[J]. 生态与农村环境学报, 29(4): 529-536.
	[Liu J Y, Cai Y L, Yu J, et al.2013. Optimization of land use arrangement in North Jiaxing based on CLUE-S and grey linear programming models. Journal of Ecology and Rural Environment, 29(4): 529-536. ]
[11]	马程, 李双成, 刘金龙, 等. 2013. 基于SOFM网络的京津冀地区生态系统服务分区[J]. 地理科学进展, 32(9): 1383-1393. doi: 10.11820/dlkxjz.2013.09.008
	[Ma C, Li S C, Liu J L, et al.2013. Regionalization of ecosystem services of Beijing-Tianjin-Hebei area based on SOFM neural network. Progress in Geography, 32(9): 1383-1393. ] doi: 10.11820/dlkxjz.2013.09.008
[12]	王丽艳, 张学儒, 张华, 等. 2010. CLUE-S模型原理与结构及其应用进展[J]. 地理与地理信息科学, 26(3): 73-77.
	[Wang L Y, Zhang X R, Zhang H, et al.2010. Principle and structure of CLUE-S model and its progresses . Geography and Geo-Information Science, 26(3): 73-77. ]
[13]	王月健, 丁武泉, 谢付杰. 2010. 基于线性规划法的轮台县土地利用结构优化[J]. 安徽农业科学, 38(9): 4733-4734.
	[Wang Y J, Ding W Q, Xie F J.2010. Optimization on land use structure in Luntai County based on linear programing method. Journal of Anhui Agricultural Sciences, 38(9): 4733-4734. ]
[14]	谢高地, 张彩霞, 张雷明, 等. 2015. 基于单位面积价值当量因子的生态系统服务价值化方法改进[J]. 自然资源学报, 30(8): 1243-1254. doi: 10.11849/zrzyxb.2015.08.001
	[Xie G D, Zhang C X, Zhang L M, et al.2015. Improvement of the evaluation method for ecosystem service value based on per unit area. Journal of Natural Resources, 30(8): 1243-1254.] doi: 10.11849/zrzyxb.2015.08.001
[15]	许小亮, 李鑫, 肖长江, 等. 2016. 基于CLUE-S模型的不同情景下区域土地利用布局优化[J]. 生态学报, 36(17): 5401-5410.
	[Xu X L, Li X, Xiao C J, et al.2016. Land use layout optimization under different scenarios by using the CLUE-S model. Acta Ecologica Sinica, 36(17): 5401-5410. ]
[16]	叶浩, 濮励杰. 2010. 苏州市土地利用变化对生态系统固碳能力影响研究[J]. 中国土地科学, 24(3): 60-64.
	[Ye H, Pu L J.2010. Study on the impact of land use change on the capability of carbon sequestration of ecosystem in Suzhou City. China Land Science, 24(3): 60-64. ]
[17]	张鸿辉, 曾永年, 谭荣, 等. 2011. 多智能体区域土地利用优化配置模型及其应用[J]. 地理学报, 66(7): 972-984.
	[Zhang H H, Zeng Y N, Tan R, et al.2011. A model for regional land use optimization allocation based on multi-agent system and its application. Acta Geographica Sinica, 66(7): 972-984. ]
[18]	张佳会, 黄全富, 王力. 2001. 最优线性规划法在土地利用总体规划中的应用[J]. 重庆师范大学学报(自然科学版), 18(1): 36-39.
	[Zhang J H, Wang Q F, Wang L.2001. The utilization of the optimum linear plan method in the masterplan of land utilization. Journal of Chongqing Normal University (Natural Science Edition), 18(1): 36-39. ]
[19]	赵阳, 张艺, 涂志华, 等. 2014. 基于生态服务价值的多目标水源地土地利用结构优化[J]. 中国环境科学, 34(1): 232-238.
	[Zhao Y, Zhang Y, Tu Z H, et al.2014. Multi-objective optimization of land use structures for water resources area based on eco-service value. China Environment Science, 34(1): 232-238. ]
[20]	Blumstein M, Thompson J R.2015. Land-use impacts on the quantity and configuration of ecosystem service provisioning in Massachusetts, USA[J]. Journal of Applied Ecology, 52(8): 1009-1019. doi: 10.1111/1365-2664.12444
[21]	Verburg P H, Veldkamp A.2004. Projecting land use transitions at forest fringes in the Philippines at two spatial scales[J]. Land scape Ecology, 19(1): 77-98. doi: 10.1023/B:LAND.0000018370.57457.58
[22]	Verburg P H, Veldkamp A, Dekoning G H J, et al.1999. A spatial explicit allocation procedure for modelling the pattern of land use change based upon actual land use[J]. Ecological Modelling, 116(1): 45-61. doi: 10.1016/S0304-3800(98)00156-2

	耕地	林地	草地	水体	建设用地	未利用地
经济效益系数	10.832	17.148	16.125	31.822	163.139	0
单位面积ESV/(元/m²)	2.183	10.734	6.574	48.398	0	0.354

模拟情景	内涵
生态保护	偏好生态用地(林地、草地、水体)面积的增加,限制生态用地向其他地类转换的数量
统筹兼顾	同时考虑生态保护、粮食安全和经济发展,均衡分配生态用地、耕地和建设用地面积
粮食安全	重点保障基本农田面积,严格控制耕地向其他地类转换的数量,维护粮食安全
经济发展	放宽经济发展限制,适当增加建设用地面积以提高经济效益

优化目标	模拟情景	价值量约束	粮食需求约束	土地利用面积约束
经济目标	生态保护	ESV增加10%	增加0.8%	水域面积不少于总面积的3%,林地面积不少于总面积的30% (2006—2020年北京、天津、河北的土地利用总体规划),草地、建设用地面积不小于现状值
	统筹兼顾	ESV增加5%	增加1%	林地、草地、水域、建设用地面积不低于现状值
	粮食安全	ESV不低于现状值	增加1.6%	林地、草地、水域、建设用地面积不低于现状值,耕地面积不低于受保护基本农田面积
	经济发展	ESV不低于现状值	增加1.3%	林地、草地、水域、建设用地面积不低于现状值
生态目标	生态保护	GDP增加5%	增加0.8%	水域面积不少于总面积的3%,林地面积不少于总面积的30% (2006—2020年北京、天津、河北的土地利用总体规划),草地、建设用地面积不小于现状值
	统筹兼顾	GDP增加6.5%	增加1%	林地、草地、水域、建设用地面积不低于现状值
	粮食安全	GDP增加6.5%	增加1.6%	林地、草地、水域、建设用地面积不低于现状值,耕地面积不低于受保护基本农田面积
	经济发展	GDP增加8%	增加1.3%	林地、草地、水域、建设用地面积不低于现状值

因子	耕地	林地	草地	水域	建设用地	未利用地
高程DEM	-0.001296	0.002152	0.000839	-0.001049	-0.001346	0.001033
人均GDP	-0.000090	-0.000084	-0.000101	0.000040	0.000123	-0.000150
人口密度	-0.000235	-0.001394	-0.000837	-0.000940	0.000493	-0.004780
年均降水量	-0.006083	0.014311	0.001584	0.002384	-0.000694
坡度	-0.100137	0.064939	0.030768	-0.047361	-0.047361	-0.285026
土壤有机碳含量	0.007466	-0.007323	0.011634			-0.032228
常数	4.465737	-10.705531	-3.152 222	-4.098 485	-1.402 509	-3.639565
ROC检验值	0.811	0.892	0.770	0.770	0.825	0.859

土地利用类型	耕地	林地	草地	水域	建设用地	未利用地
耕地	1	1	1	1	1	1
林地	1	1	1	1	1	1
草地	1	1	1	1	1	1
水域	1	1	1	1	1	1
建设用地	1	1	1	1	1	1
未利用地	1	1	1	1	1	1

Optimal allocation of land use types in the Beijing-Tianjin-Hebei urban agglomeration based on ecological and economic benefits trade-offs

RichHTML

PDF (PC)

Like

Knowledge

Cited

Abstract

Cite this article

share this article

Figures/Tables 12

References 22

Related Articles 15

Metrics

Comments

Recommended 0

优化目标	情景	耕地	林地	草地	水体	建设用地	未利用地
经济目标	生态保护	757.84	642.11	336.52	64.21	332.42	7.27
	统筹兼顾	773.01	558.11	336.52	60.82	404.64	7.27
	粮食安全	820.18	491.57	336.52	60.82	424.01	7.27
	经济发展	796.28	496.43	336.52	60.82	443.05	7.27
生态目标	生态保护	757.84	697.55	336.52	64.21	276.98	7.27
	统筹兼顾	773.01	677.64	336.52	60.82	285.11	7.27
	粮食安全	820.18	628.43	336.52	60.82	287.15	7.27
	经济发展	796.28	646.23	336.52	60.82	293.24	7.27

优化目标	情景	耕地	林地	草地	水体	建设用地	未利用地
经济目标	生态保护	758.34	642.16	336.77	63.31	332.54	7.25
	统筹兼顾	773.32	558.44	336.92	59.96	404.47	7.26
	粮食安全	820.21	491.91	336.93	59.92	424.15	7.25
	经济发展	796.73	496.62	336.68	60.01	443.10	7.23
生态目标	生态保护	758.20	697.76	336.72	63.29	277.13	7.27
	统筹兼顾	773.25	678.61	336.09	59.79	285.36	7.27
	粮食安全	819.12	629.56	336.83	60.05	287.55	7.26
	经济发展	796.16	646.62	337.01	59.86	293.44	7.28

目标	情景	生态系统服务价值	经济价值
2015年现状		12224.82	69358.80
经济目标	生态保护	13828.38	80921.12
	统筹兼顾	12801.30	91278.20
	粮食安全	12187.65	93854.73
	经济发展	12189.66	96771.49
生态目标	生态保护	14423.58	72832.03
	统筹兼顾	14077.34	73887.77
	粮食安全	13668.41	73921.01
	经济发展	13793.41	74922.60
