中国嵌入“21世纪海上丝绸之路”航运网络的关键节点识别

doi:10.18306/dlkxjz.2018.11.005

Abstract

Abstract:

In May 2017, The Belt and Road Initiative First International Cooperation Forum, which once again highlighted China's efforts and contributions in the construction of the "community of human destiny," was held in Beijing. We have drawn up the strategic conception of building the 21st Century Maritime Silk Road, thus paving the maritime passage of elements flow in Eastern and Western countries, and expanding the new trade route for China to connect the world economy. Based on the relationship of shipping between the Chinese and international ports and social network analysis (SNA), this study mapped the connection network of Chinese and international ports along the 21st Century Maritime Silk Road. The study also used the SNA method to analyze the overall network spatial structure and its core-periphery structure. We considered the network centrality and the actual shipping capability of the Chinese and international port nodes, thus identifying the functional nodes in the shipping network. The main conclusions are as follows. (1) The 21st Century Maritime Silk Road shipping network presents a spatial pattern of the pickaxe shape, and the close connection between the Chinese and Southeast Asian ports is the core of this pattern. Shanghai, Shenzhen, Singapore, and Port Klang constitute the hub and spoke network structure of the port of high efficiency and low consumption. (2) We derived the backbone network and core network through filtering, and identified special nodes and core nodes of international ports with different breadth and intensity. (3) There are two ways for ports to enter the shipping network. One is the hierarchical embedding mode (breadth, depth, intermediary function), such as China and Southeast Asia, and the other is homogeneous embedding mode, such as Africa, south West Asia-Middle East, South Asia, and Europe. (4) We identified five types of Chinese port nodes: potential composite hub port, export-oriented trunk port, inward direct port, intermediary branch port, and marginal feeder port. Then, the development proposals for these five types of ports are put forward, in order to effectively coordinate the port organization pattern and node functions so that ports can complement each other and enhance the value of the 21st Century Maritime Silk Road.

Key words: 21st Century Maritime Silk Road, shipping network, external connection, network pattern, key nodes

Cheng WANG, Maojun WANG, Yi WANG. Identification of Chinese key nodes in the shipping network of the 21st Century Maritime Silk Road[J].PROGRESS IN GEOGRAPHY, 2018, 37(11): 1485-1498.

Figures/Tables 18

Tab.1

Tab.2

Tab.3

Measurement index of 2-mode network of port nodes in China and foreign countries"

指标	表征含义	测算原理	测算方式
度数中心度 (关联广度)	表征港口的实际航线数量,直观反映某港口节点为其腹地提供的外向航运链接的广度和机会大小。	与港口节点i存在直接航运关联的节点j的数量总和。	$k i = ∑ i = 1 n a ij$
关联频次 (关联强度)	港口之间的关联强度。	港口节点i和节点j之间的直接航运关联次数总和。	$Q i = ∑ i = 1 n q ij$
接近中心度 (航运效率)	港口节点由于自身为数不多的直接链接对象拥有更多的直接链接对象,从而获得较高的间接参与网络的机会。	港口节点n_i与同类节点、他类节点的最短路径长度之和。式中,g、h是中、外港口数,中国港口k与外国港口i邻接。	$C C NM n i =$ $1 + ∑ j = 1 g + h min k d (k, j) g + h - 1 - 1$
中间中心度 (中转功能)	某港口位于其他港口城市关系的捷径上,这类港口作为高效中转站,能在竞合过程中打破其他港口城市的共谋而获得额外利好。	如果给定的一对港口节点(n_i, n_j)仅与一个港口节点m_k发生关联(即 $X ij N = 1$ ),则港口节点m_k的中介度增加 $1 X ij N$ 个单位。	$B m k = 12 ∑ 1 X ij N$
核心-边缘结构	综合考量个体港口节点的网络中心性,定量计算各港口节点的核心度,识别网络地位更高的核心关联对,并合理设定阈值划分港口网络中的核心边缘结构。		块模型法

Tab.3

Tab.4

Fig.1

Fig.2

Fig.3

Fig.4

Tab.5

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

Fig.10

Fig.11

Fig.12

Tab.6

References 29

[1]	曹琳霞, 陆玉麒, 马颖忆. 2016. 基于烟羽模型的江苏港口腹地范围划分[J]. 地域研究与开发, 35(5): 41-46.
	[Cao L X, Lu Y Q, Ma Y Y.2016. Research on Jiangsu ports hinterland segmentation based on the plume model[J]. Areal Research and Development, 35(5): 41-46.]
[2]	陈文巧, 栾贵勤, 欧东旭. 2013. 聚类分析上海在国内港口城市中的功能定位[J]. 资源开发与市场, 29(10): 1049-1051. doi: 10.3969/j.issn.1005-8141.2013.10.011
	[Chen W Q, Luan G Q, Ou D X.2013. Using cluster analysis to position of Shanghai in domestic port cities[J]. Resource Development & Market, 29(10): 1049-1051.] doi: 10.3969/j.issn.1005-8141.2013.10.011
[3]	程佳佳, 王成金. 2015. 珠江三角洲集装箱港口体系演化及动力机制[J]. 地理学报, 70(8): 1256-1270. doi: 10.11821/dlxb201508006
	[Cheng J J, Wang C J.2015. Evolution and dynamic mechanism of container port system in the Pearl River Delta[J]. Acta Geographica Sinica, 70(8): 1256-1270.] doi: 10.11821/dlxb201508006
[4]	董晓菲, 韩增林. 2016. 东北沿海港口群腹地空间格局及驱动机理[J]. 经济地理, 36(5): 33-39. doi: 10.15957/j.cnki.jjdl.2016.05.005
	[Dong X F, Han Z L.2016. The Northeast coastal ports group of hinterland space structure and drive mechanism analysis[J]. Economic Geography, 36(5): 33-39.] doi: 10.15957/j.cnki.jjdl.2016.05.005
[5]	范斐, 刘承良, 游小珺, 等. 2015. 全球港口间集装箱运输贸易网络的时空分异[J]. 经济地理, 35(6): 109-115. doi: 10.15957/j.cnki.jjdl.2015.06.015
	[Fan F, Liu C L, You X J, et al.2015. The spatial-temporal differentiation and of global trade of container transportation network between ports[J]. Economic Geography, 35(6):109-115.] doi: 10.15957/j.cnki.jjdl.2015.06.015
[6]	付邵武. 2016. 21世纪海上丝绸之路建设与我国沿海港口发展[J]. 智富时代, 33(1): 18-19.
	[Fu S W.2016. 21 Shiji Haishang Sichou Zhilu jianshe yu woguo yanhai gangkou fazhan[J]. The Future Time, 33(1): 18-19.]
[7]	国家发展和改革委员会, 外交部, 商务部. 2015. 推动共建丝绸之路经济带和 21 世纪海上丝绸之路的愿景与行动[EB/OL]. .
	[The National Development and Reform Commission, Ministry of Foreign Affairs, Ministry of Commerce of the People's Republic of China. 2015. Vision and actions on jointly building Silk Road Economic Belt and 21st-century Maritime Silk Road[EB/OL]. 2015-04-01 [2018-09-13]. .]
[8]	何丹, 高鹏. 2016. 长江中游港口腹地演变及港口-腹地经济协调发展研究[J]. 地理科学, 36(12): 1811-1821.
	[He D, Gao P.2016. Hinterland evolution of ports in midstream of the Yangtze River and coordination development of port-hinterland economy[J]. Scientia Geographica Sinica, 36(12): 1811-1821.]
[9]	蹇令香, 李东兵, 赵诗晨. 2016. 我国沿海港口复杂网络演化特征[J]. 经济地理, 36(12): 96-103. doi: 10.15957/j.cnki.jjdl.2016.12.014
	[Jian L X, Li D B, Zhao S C.2016. China's coastal port complex network evolution[J]. Economic Geography, 36(12): 96-103.] doi: 10.15957/j.cnki.jjdl.2016.12.014
[10]	姜晓丽, 张平宇. 2013. 基于Huff模型的辽宁沿海港口腹地演变分析[J]. 地理科学, 33(3): 282-290.
	[Jiang X L, Zhang P Y.2013. The hinterland evolution of Liaoning coastal ports based on the huff model[J]. Scientia Geographica Sinica, 33(3): 282-290.]
[11]	李善同, 侯永志. 2003. 中国(大陆)区域社会经济发展特征分析[J]. 中国发展评论: 中文版, (2): 27-39.
	[Li S T, Hou Y Z.2003. Zhongguo (dalu) quyu shehui jingji fazhan tezheng fenxi[J]. China Development Review: Chinese Version, (2): 27-39.]
[12]	李振福, 汤晓雯. 2014. 港口腹地划分的腹地烟羽模型研究[J]. 地理科学, 34(10): 1169-1175. doi: 10.3969/j.issn.1002-4972.2011.02.016
	[Li Z F, Tang X W.2014. The hinterland plume model of port hinterland segmentation[J]. Scientia Geographica Sinica, 34(10): 1169-1175.] doi: 10.3969/j.issn.1002-4972.2011.02.016
[13]	刘卫东. 2015. “一带一路”战略的科学内涵与科学问题[J]. 地理科学进展, 34(5): 538-544. doi: 10.11820/dlkxjz.2015.05.001
	[Liu W D.2015. Scientific understanding of the Belt and Road Initiative of China and related research themes[J]. Progress in Geography, 34(5):538-544.] doi: 10.11820/dlkxjz.2015.05.001
[14]	阮红伟, 李晓静, 赖秀云. 2016. “一带一路”沿线15个沿海港口城市竞争力比较研究[J]. 东方论坛, 30(5): 77-84.
	[Ruan H W, Li X J, Lai X Y.2016. An analysis on competitiveness of fifteen port cities along "Belt and Road Initiative" areas[J]. Eastern Forum, 30(5): 77-84.]
[15]	孙世达, 姜巍, 高卫东. 2016. 中国港口时空格局演变及影响因素分析[J]. 世界地理研究, 25(2): 62-71.
	[Sun S D, Jiang W, Gao W D.2016. Spatio-temporal pattern evolution and factorial analysis on ports in China[J]. World Regional Studies, 25(2): 62-71.]
[16]	王成金. 2012.集装箱港口网络形成演化与发展机制[M]. 北京:科学出版社.
	[Wang C J.2012.The evolution and development mechanisms of container ports network[M]. Beijing, China: Science Press.]
[17]	王列辉, 洪彦. 2016. 直航背景下海峡两岸集装箱港口体系空间结构:基于复杂网络的视角[J]. 地理学报, 71(4): 605-620. doi: 10.11821/dlxb201604006
	[Wang L H, Hong Y.2016. Spatial structure of container port systems across the Taiwan Straits under the direct shipping policy: A complex network system approach[J]. Acta Geographica Sinica, 71(4): 605-620.] doi: 10.11821/dlxb201604006
[18]	王列辉, 朱艳. 2017. 基于“21世纪海上丝绸之路”的中国国际航运网络演化[J]. 地理学报. 72(12): 1-16.
	[Wang L H, Zhu Y.2017. The evolution of China's international maritime network based on the "21st Century Maritime Silk Road"[J]. Acta Geographica Sinica. 72(12): 1-16.]
[19]	王绍卜. 2016. 我国沿海集装箱港口体系的空间结构及演化[J]. 经济地理, 36(8): 93-98.
	[Wang S B.2016. The spatial structure and evolution of China's coastal container port system[J]. Economic Geography, 36(8): 93-98.]
[20]	张梦天, 王成金, 王成龙. 2016. 中国港口铁矿石运输的空间格局及演化[J]. 经济地理, 36(8): 99-105. doi: 10.15957/j.cnki.jjdl.2016.08.014
	[Zhang M T, Wang C J, Wang C L.2016. Distribution characteristics and evolution of port’s iron ore transport in China[J]. Economic Geography, 36(8): 99-105.] doi: 10.15957/j.cnki.jjdl.2016.08.014
[21]	邹嘉龄, 刘卫东. 2016. 2001-2013年中国与“一带一路”沿线国家贸易网络分析[J]. 地理科学, 36(11): 1629-1636. doi: 10.13249/j.cnki.sgs.2016.11.004
	[Zou J L, Liu W D.2016. Trade network of China and countries along "Belt and Road Initiative" areas from 2001 to 2013[J]. Scientia Geographica Sinica, 36(11):1629-1636.] doi: 10.13249/j.cnki.sgs.2016.11.004
[22]	Bird J H.1971. Seaports and Seaport Terminals[M]. London: Hutchinson University Library.
[23]	Castells M.1989. The informational city: Information technology, economic restructuring, and the urban-regional process[M]. Oxford, UK: Basil Blackwell.
[24]	Hayuth Y.1988. Rationalization and concentration of the U. S. container port system[J]. The Professional Geographer, 40(3): 279-288. doi: 10.1111/j.0033-0124.1988.00279.x
[25]	Jacobs W, Ducruet C, De Langen P.2010. Integrating world cities into production networks: The case of port cities[J]. Global Networks, 10(1): 92-113. doi: 10.1111/j.1471-0374.2010.00276.x
[26]	Komadina P, Cisic D, Hlaca B.2006. Globalization in maritime transport industry[J]. Nase More, 53(5/6): 183.
[27]	Pflieger G, Rozenblat C.2010. Urban networks and network theory: The city as the connector of multiple networks[J]. Urban Studies, 47(13): 2723-2735. doi: 10.1177/0042098010377368
[28]	Taaffe E J, Morrill R L, Gould P R.1963. Transport expansion in underdeveloped countries: A comparative analysis[J]. Geographical Review, 53(4): 503-529. doi: 10.2307/212383
[29]	Wang J J, Ng K Y, Olivier D.2004. Port governance in China: A review of policies in an era of internationalizing port management practices[J]. Transport Policy, 11(3): 237-250. doi: 10.1016/j.tranpol.2003.11.003

航线	承运人	起始港	目的港	挂靠港
东南亚航线	APL	厦门	巴林	厦门,巴林,厦门,深圳,香港,新加坡-杰贝阿里-迪拜-沙迦-达曼港-富查伊拉-科威特-卡拉奇-巴林
非洲航线	APL	宁波	蒙巴萨	宁波-上海-香港-深圳-新加坡-哥伦布-萨尔斯-蒙巴萨
地中海航线	COSCO	上海	伊泽米尔	上海-宁波-厦门-高雄-香港-新加坡-苏伊士坦-伊斯坦布尔-海达帕萨-伊泽米尔
欧洲航线	OOCL	福州	新加坡	福州-高雄-深圳-香港-新加坡-苏伊士-阿姆斯特丹-汉堡-安特汉普顿-卡利亚里-苏伊士-杰贝阿里-新加坡
……	……	……	……	……

出发港	目的港	航次	港口	大连	广州	海口	宁波	青岛	厦门	上海	……
三亚港区	坤甸	5	阿什杜德	2	5	0	46	28	1	64
广州港区	安科纳	5	安科纳	18	14	0	61	55	13	102
深圳港区	阿什杜德	4	巴生港	520	409	4	1406	1045	729	2694
天津港区	吉布提	6	布鲁特	23	7	0	30	48	7	38
厦门港区	吉达	18	宾土卢	4	141	0	12	9	13	70
青岛港区	安科纳	8	槟城	40	30	1	52	44	27	358
烟台港区	杜蒂戈林	2	达累斯萨拉姆	11	18	0	21	14	4	108
上海港区	贝鲁特	1	海法	14	7	0	56	43	13	54
……	……	……	……	……	……	……	……	……	……	……	……

关联强度过滤阈值	核心—边缘		分派分析
关联强度过滤阈值	初始拟合优度	最终拟合优度	初始拟合优度	最终拟合优度
均值~78	0.696	0.904	0.274	0.414
前10%~166	0.509	0.853	0.272	0.332
标准差~255	0.396	0.807	0.199	0.298

类型	港口	对外关联频次/次	比重/%
复合型枢纽港(3)	上海、深圳、宁波	31993	58.15
外向干线港(2)	青岛、天津	10393	18.89
内向直挂港(2)	广州、大连	4936	8.97
中介支线港(3)	厦门、福州、烟台	7131	12.96
边缘喂给港(5)	湛江、汕头、海口、泉州、三亚	566	1.03
