基于MOD13Q1数据的宁夏生长季植被动态监测

doi:10.18306/dlkxjz.2017.06.009

Abstract

Abstract:

In order to ascertain the dynamics of vegetation and its impacting factors in the period of 2000-2014, based on MOD13Q1, the DEM data, and the land use classification map, this study analyzed the characteristics of the spatiotemporal distribution and future trends of the administrative areas of Ningxia Autonomous Region at different altitudes and slopes, as well as with different types of vegetation, using the Sen + Mann-Kendall nonparametric test, the Hurst index, and other methods. Based on the center of gravity migration model and transition matrix, this study analyzed the temporal change of vegetation patterns from 2000 to 2014. The results are as follows: (1) NDVI values were high in the north and the south, but low in the central area, due to its arid condition; NDVI values were significantly positively correlated with elevation and slope. (2) The transition matrix of vegetation coverage shows that the percentage of area of higher vegetation grew from 17.29% in 2000 to 31.55% in 2014, which was mainly developed from lower vegetation coverage in the beginning of the period. (3) The center of gravity migration direction indicates that moderate and higher vegetation cover centers moved: the moderate vegetation cover center migrated toward the northeast by 129.49 km, and the higher vegetation cover center migrated toward the southeast by 89.49 km. (4) The trends of NDVI show that overall, NDVI of Ningxia improved from 2000 to 2014. The area where the values of NDVI significantly increased accounted for 59.63% of the total area, while the slightly improved area accounted for 31.72% of the total. The significantly improved area of woodland and paddy accounted for 71.50% and 70.80% of the total woodland and paddy areas. The significantly improved area of NDVI firstly increased and then decreased with the increase of elevation and slope. The area in the south with increased NDVI was larger than that in the north. (5) The trend of NDVI change indicates that vegetation restoration in Ningxia is sustained—89.24% of the vegetation-covered area continued to show an improving trend, while 5.7% continued to decrease, which was mainly in the Yellow River irrigated district. The areas in southern Ningxia where NDVI presented a positive sustained development was greater than that in the north.

Key words: NDVI, temporal and spatial variation, transition matrix, center of gravity migration, Ningxia, Hurst index

Zhuowen ZHAO, Lianpeng ZHANG, Xing LI, Yongxiang WANG, Shengli WANG. Monitoring vegetation dynamics during the growing season in Ningxia based on MOD13Q1 data[J].PROGRESS IN GEOGRAPHY, 2017, 36(6): 741-752.

Figures/Tables 10

Fig.1

Tab 1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

References 23

[1]	安佑志, 刘朝顺, 施润和, 等. 2012. 基于MODIS时序数据的长江三角洲地区植被覆盖时空变化分析[J]. 生态环境报, 21(12): 1923-1927.
	[An Y Z, Liu C S, Shi R H, et al.2012. Spatio-temporal analysis of the veg-etation changes based on MODIS time-series data in the Yangtze River Delta region[J]. Ecology and Envi-ronmental Sciences, 21(12): 1923-1927.]
[2]	杜加强, 贾尔恒·阿哈提, 赵晨曦, 等. 2016. 三江源区近30年植被生长动态变化特征分析[J]. 草业学报, 25(1): 1-12. doi: 10.11686/cyxb2015111
	[Du J Q, Jiaerheng A H T, Zhao C X, et al.2016. Analysis of vegetation dynamics using GIMMS NDVI3g in the Three-Rivers Headwater region from 1982 to 2012[J]. Acta Prataculturae Sinica, 25(1): 1-12.] doi: 10.11686/cyxb2015111
[3]	杜灵通, 宋乃平, 王磊, 等. 2015. 近30a气候变暖对宁夏植被的影响[J]. 自然资源学报, 30(12): 2095-2106.
	[Du L T, Song N P, Wang L, et al.2015. Impact of global warming on vegetation activity in Ningxia Province from 1982 to 2013[J]. Journal of Natural Resources, 30(12): 2095-2106.]
[4]	杜灵通, 田庆久. 2012. 宁夏植被覆盖动态变化及与气候因子的关系[J]. 中国沙漠, 32(5): 1479-1485.
	[Du L T, Tian Q J.2012. Vegetation coverage variations in Ningxia during 1999-2009 and its relationships with climatic factors[J]. Journal of Desert Research, 32(5): 1479-1485.]
[5]	段翰晨, 王涛, 薛娴, 等. 2012. 科尔沁沙地沙漠化时空演变及其景观格局: 以内蒙古自治区奈曼旗为例[J]. 地理学报, 67(7): 917-928.
	[Duan H C, Wang T, Xue X, et al.2012. Spatial-temporal evolution of aeolian desertification and landscape pattern in Horqin Sandy Land: A case study of Naiman Banner in Inner Mon-golia[J]. Acta Geographica Sinica, 67(7): 917-928.]
[6]	候静, 杜灵通, 马菁, 等. 2015. 基于RS与像元二分模型的近20a宁夏植被覆盖研究[J]. 水土保持通报, 35(5): 127-132.
	[Hou J, Du L T, Ma J, et al.2015. A study on vegetation coverage in Ningxia Hui Autonomous region during past 20 years based on remote sensing and dimidiate pixel model[J]. Bulletin of Soil and Water Conservation, 35(5): 127-132.]
[7]	黄玉霞. 2010. 宁夏平罗县盐渍土变化趋势及土壤生产潜力的研究[D]. 杨凌: 西北农林科技大学.
	[Huang Y X.2010. Study on trend of soil salinization and soil productive poentialty in Pingluo Country, Ningxia[D]. Yangling, China: Northwest A&F University.]
[8]	李菲, 张明军, 李小飞, 等. 2013. 1962-2011年来宁夏不同等级降水的变化特征[J]. 生态学杂志, 32(8): 2154-2162.
	[Li F, Zhang M J, Li X F, et al.2013. Variation characteristics of different-level precipitation in Ningxia of Southwest China in 1962-2011[J]. Chinese Journal of Ecology, 32(8): 2154-2162.]
[9]	李建春. 2014. 银川市耕地变化与基本农田空间布局优化研究[D]. 北京: 中国农业大学.
	[Li J C.2014. Evolution of arable land and optimization of spatial distribution of basic farmland in Yinchuan[D]. Beijing, China: China Agricultural University.]
[10]	李欣, 王连喜, 李琪, 等. 2011. 宁夏近25年植被指数变化及其与气候的关系[J]. 干旱区资源与环境, 25(9): 161-166.
	[Li X, Wang L X, Li Q, et al.2011. NDVI change and its relationship with climate in Ningxia in the last 25 years[J]. Journal of Arid Land Resources and Environment, 25(9): 161-166.]
[11]	凌侠. 2007. 宁夏河东沙地荒漠化态势评价研究: 以盐池县为例[D]. 北京: 北京林业大学.
	[Ling X.2007. Study of the desertification situation evaluation in Hedong Sandy Land of Ningxia Hui Autonomous region: Taking Yanchi County as example[D]. Beijing, China: Beijing Forestry University.]
[12]	刘亚龙, 王庆, 毕景芝, 等. 2010. 基于Mann-Kendall方法的胶东半岛海岸带归一化植被指数趋势分析[J]. 海洋学报, 32(3): 79-87.
	[Liu Y L, Wang Q, Bi J Z, et al.2010. The analysis of NDVI trends in the coastal zone based on Mann-Kendall test: A case in the Jiaodong Peninsula[J]. Acta Oceanologica Sinica, 32(3): 79-87.]
[13]	陆媛媛, 刘超, 曾克峰, 等. 2016. 宁夏城市化与生态环境耦合协调关系[J]. 中国沙漠, 36(4): 1198-1206. doi: 10.7522/j.issn.1000-694X.2015.00096
	[Lu Y Y, Liu C, Zeng K F, et al.2016. Coupling relationship between urbanization and eco-environment in Ningxia, China[J]. Journal of Desert Research, 36(4): 1198-1206.] doi: 10.7522/j.issn.1000-694X.2015.00096
[14]	孙兆军. 2011. 银川平原盐碱荒地改良模式研究[D]. 北京: 北京林业大学.
	[Sun Z J.2011. Amelioration models for saline-alkali wasterland in Yinchuan Plain[D]. Beijing, China: Beijing Forestry University.]
[15]	汤旭光, 李恒鹏, 聂小飞, 等. 2015. 应用MODIS数据监测千岛湖流域植被覆盖动态(2001-2013年)[J]. 湖泊科学, 27(3): 511-518.
	[Tang X G, Li H P, Nie X F, et al.2015. Vegetation dynamical status in the Lake Qiandao drainage basin using time-series MODIS data (2001-2013)[J]. Journal of Lake Sciences, 27(3): 511-518.]
[16]	王情, 刘雪华, 吕宝磊. 2013. 基于SPOT-VGT数据的流域植被覆盖动态变化及空间格局特征: 以淮河流域为例[J]. 地理科学进展, 32(2): 270-277. doi: 10.3724/SP.J.1033.2013.00270
	[Wang Q, Liu X H, Lv B L.2013. Dynamic changes and spatial pat-terns of vegetation cover in a river basin based on SPOT-VGT data: A case study in the Huaihe River Basin[J]. Progress in Geography, 32(2): 270-277.] doi: 10.3724/SP.J.1033.2013.00270
[17]	温晓金, 刘焱序, 杨新军. 2015. 恢复力视角下生态型城市植被恢复空间分异及其影响因素: 以陕南商洛市为例[J]. 生态学报, 35(13): 4377-4389. doi: 10.5846/stxb201406101203
	[Wen X J, Liu Y X, Yang X J.2015. A resilience-based analysis on the spatial heterogeneity of vegetation restoration and its affecting factors in the construction of eco-cities: A case study of Shangluo, Shaanxi[J]. Acta Ecologica Sinica, 35(13): 4377-4389.] doi: 10.5846/stxb201406101203
[18]	武正丽, 贾文雄, 赵珍, 等. 2015. 2000-2012年祁连山植被覆盖变化及其与气候因子的相关性[J]. 干旱区地理, 38(6): 1241-1252.
	[Wu Z L, Jia W X, Zhao Z, et al.2015. Spatial-temporal variations of vegetation and its correlation with climatic factors in Qilian Mountains from 2000 to 2012[J]. Arid Land Geography, 38(6): 1241-1252.]
[19]	薛忠歧. 2006. 银川平原植被生态变化规律及其影响因素的遥感研究[D]. 北京: 中国地质大学(北京).
	[Xue Z Q.2006. Research on ecological variation of vegetation and the influencing factors in Yinchuan Plain based on remote sensing data[D]. Beijing China: China University of Geosciences (Beijing).]
[20]	袁丽华, 蒋卫国, 申文明, 等. 2013. 2000-2010年黄河流域植被覆盖的时空变化[J]. 生态学报, 33(24): 7798-7806. doi: 10.5846/stxb201305281212
	[Yuan L H, Jiang W G, Shen W M, et al.2013. The spatio-temporal variations of vegetation cover in the Yellow River Basin from 2000 to 2010[J]. Acta Ecologica Sinica, 33(24): 7798-7806.] doi: 10.5846/stxb201305281212
[21]	赵卓文, 张连蓬, 王胜利. 2016. 宁夏不同植被类型归一化指数与气象因子分析[J]. 测绘科学, 41(7): 98-103.
	[Zhao Z W, Zhang L P, Wang S L.2016. Correlation between NDVI and meteorological factors of different vegetation types in Ningxia[J]. Science of Surveying and Mapping, 41(7): 98-103.]
[22]	Pettorelli N, Vik J O, Mysterud A, et al.2005. Using the satellite-derived NDVI to assess ecological responses to environmental change[J]. Trends in Ecology & Evolution, 20(9): 503-510. doi: 10.1016/j.tree.2005.05.011 pmid: 16701427
[23]	Wardlow B D, Egbert S L.2008. Large-area crop mapping using time-series MODIS 250 m NDVI data: An assessment for the U.S. Central Great Plains[J]. Remote Sensing of Environment, 112(3): 1096-1116. doi: 10.1016/j.rse.2007.07.019

时段	类型	较低植被覆盖/%	低植被覆盖/%	中度植被覆盖/%	高植被覆盖/%	较高植被覆盖/%	合计/%
2000-2005	较低植被覆盖	26.30	9.49	0.35	0.13	0.08	36.36
	低植被覆盖	5.23	16.71	6.65	1.99	0.14	30.72
	中度植被覆盖	0.05	0.37	4.03	8.18	1.24	13.87
	高植被覆盖	0.01	0.06	0.24	2.22	4.11	6.63
	较高植被覆盖	0.02	0.09	0.11	0.47	11.72	12.42
	合计	31.61	26.72	11.38	12.99	17.29	100.00
2005-2010	较低植被覆盖	6.53	22.80	1.98	0.23	0.07	31.61
	低植被覆盖	0.12	9.32	15.57	1.54	0.18	26.72
	中度植被覆盖	0.03	0.15	3.16	6.84	1.21	11.38
	高植被覆盖	0.01	0.05	0.25	4.43	8.24	12.99
	较高植被覆盖	0.00	0.04	0.14	0.53	16.57	17.29
	合计	6.69	32.37	21.10	13.57	26.27	100.00
2010-2014	较低植被覆盖	2.57	3.91	0.18	0.02	0.00	6.69
	低植被覆盖	1.33	22.19	8.47	0.30	0.09	32.37
	中度植被覆盖	0.03	4.16	12.41	4.06	0.43	21.10
	高植被覆盖	0.01	0.13	1.18	5.93	6.33	13.57
	较高植被覆盖	0.01	0.09	0.23	1.23	24.70	26.27
	合计	3.96	30.48	22.48	11.54	31.55	100.00
