寒地水稻障碍型冷害指数构建及应用——以辽宁省为例

doi:10.18306/dlkxjz.2017.04.005

Abstract

Abstract:

Temperature and consecutive cold days are commonly used to evaluate rice sterile-type cold damage in Northeast China. In order to realize quantitative evaluation and prediction, it is necessary to construct a comprehensive index of sterile-type cold damage using multiple factors. Based on a temperature suitability model, temperature and consecutive cold days, and considering the effects of three fundamental points temperature on rice's growing process, this study constructed the rice sterile-type cold damage index (RSCDI) by using the data of daily mean temperature and rice growth period in recent 50 years in Liaoning Province. It then analyzed the occurrence tendency of rice sterile-type cold damage, and forecast cold damage in Liaoning Province with RSCDI. The results are as follows: (1) During the 50 years from 1961 to 2010, local light cold damage happened in 20 years, local moderate cold damage occurred in 14 years, local severe cold damage occurred in 10 years, and there was no occurrence of regional and large scale cold damage; (2) The highest frequency of cold damage was in the 1970s. The frequency decreased from 1981 to 2000, and the lowest frequency of cold damage was in the 1990s. But there was an increasing trend after 2001. Cold damage mainly occurred in the western and northeastern parts of Liaoning Province. With climate warming, the frequency decreased to some extent, but the occurrence of rice sterile-type cold damage was uncertain in Liaoning Province; (3) The forecast of rice sterile-type cold damage in Liaoning Province from 2011 to 2014 using RSCDI shows that cold damage will not appear in most areas, but in Jianping County moderate damage may occur in the flowering period in 2012 and 2014.

Key words: rice, sterile-type cold damage, index, variation, Liaoning Province

Ruipeng JI, Wenying YU, Rui FENG, Jinwen WU, Yushu ZHANG. Construction and application of Rice Sterile-type Cold Damage Index in cold area: A case study of Liaoning Province[J].PROGRESS IN GEOGRAPHY, 2017, 36(4): 437-445.

Figures/Tables 8

Fig.1

Tab.1

Fig. 2

Fig.3

Fig.4

Fig.5

Tab.2

Tab.3

References 23

[1]	陈书强, 杨丽敏, 赵海新, 等. 2012. 寒地水稻低温冷害防御技术研究进展[J]. 沈阳农业大学学报, 43(6): 693-698. doi: 10.3969/j.issn.1000-1700.2012.06.008
	[Chen S Q, Yang L M, Zhao H X, et al.2012. Advances in prevention and control technique of low temperature injury of rice in cold region[J]. Journal of Shenyang Agricultural University, 43(6): 693-698.] doi: 10.3969/j.issn.1000-1700.2012.06.008
[2]	丁士晟. 1980. 东北地区夏季低温的气候分析及其对农业生产的影响[J]. 气象学报, 38(3): 234-242. doi: 10.11676/qxxb1980.028
	[Ding S S.1980. The climatic analysis of low temperature in summer over the Northeast China and influence for agricultural product[J]. Acta Meteorologica Sinica, 38(3): 234-242.] doi: 10.11676/qxxb1980.028
[3]	方修琦, 王媛, 朱晓禧. 2005. 气候变暖的适应行为与黑龙江省夏季低温冷害的变化[J]. 地理研究, 24(5): 664-672. doi: 10.3321/j.issn:1000-0585.2005.05.002
	[Fang X Q, Wang Y, Zhu X X.2005. Change of cool summer hazard under an adaptation behavior to the climate warming in Heilongjiang Province, Northeast China[J]. Geographical Research, 24(5): 664-672.] doi: 10.3321/j.issn:1000-0585.2005.05.002
[4]	冯喜媛, 郭春明, 陈长胜, 等. 2013. 基于气象模型分析东北三省近50年水稻孕穗期障碍型低温冷害时空变化特征[J]. 中国农业气象, 34(4): 462-467. doi: 10.3969/j.issn.1000-6362.2013.04.013
	[Feng X Y, Guo C M, Chen C S, et al.2013. Spatial-temporal variation of sterile-type chilling damages at rice booting stage in Northeast China in last 50 years based on meteorological model[J]. Chinese Journal of Agrometeorology, 34(4): 462-467.] doi: 10.3969/j.issn.1000-6362.2013.04.013
[5]	龚强, 汪宏宇, 张运福, 等. 2013. 辽宁省气候变化及其对极端天气气候的影响[J]. 生态学杂志, 32(6): 1525-1531.
	[Gong Q, Wang H Y, Zhang Y F, et al.2013. Climate change and its impacts on extreme climate events in Liaoning Province of Northeast China[J]. Chinese Journal of Ecology, 32(6): 1525-1531.]
[6]	郭建平, 马树庆. 2009. 农作物低温冷害监测预测理论和实践[M]. 北京: 气象出版社, 38-39.
	[Guo J P, Ma S Q.2009. Nongzuowu diwen lenghai jiance yuce lilun he shijian [M]. Beijing: Meteorological Press, 38-39.]
[7]	郭建平, 田志会, 左旭. 2004. 东北地区水稻热量指数预测模型[J]. 自然灾害学报, 13(3): 138-145. doi: 10.3969/j.issn.1004-4574.2004.03.025
	[Guo J P, Tian Z H, Zuo X.2004. Forecasting models of heat index for rice in Northeast China[J]. Journal of Natural Disasters, 13(3): 138-145.] doi: 10.3969/j.issn.1004-4574.2004.03.025
[8]	郝志新, 郑景云, 葛全胜, 等. 2011. 中国南方过去400年的极端冷冬变化[J]. 地理学报, 66(11): 1479-1485. doi: 10.11821/xb201111004
	[Hao Z X, Zheng J Y, Ge Q S, et al.2011. Variations of extreme cold winter events in Southern China in the past 400 years[J]. Acta Geographica Sinica, 66(11): 1479-1485.] doi: 10.11821/xb201111004
[9]	胡春丽, 李辑, 林蓉, 等. 2014. 东北水稻障碍型低温冷害变化特征及其与关键生育期温度的关系[J]. 中国农业气象, 35(3): 323-329. doi: 10.3969/j.issn.1000-6362.2014.03.014
	[Hu C L, Li J, Lin R, et al.2014. Characters of sterile-type chilling damage in rice and its relationship with temperature at key growth stage in Northeast China[J]. Chinese Journal of Agrometeorology, 35(3): 323-329.] doi: 10.3969/j.issn.1000-6362.2014.03.014
[10]	纪瑞鹏, 张玉书, 冯锐, 等. 2007. 辽宁省农业气候资源变化特征分析[J]. 资源科学, 29(2): 74-82. doi: 10.3321/j.issn:1007-7588.2007.02.012
	[Ji R P, Zhang Y S, Feng R, et al.2007. Analyzing the changing characteristics of agricultural climate resources in Liaoning Province[J]. Resources Science, 29(2): 74-82.] doi: 10.3321/j.issn:1007-7588.2007.02.012
[11]	姜丽霞, 季生太, 李帅, 等. 2010. 黑龙江省水稻空壳率与孕穗期低温的关系[J]. 应用生态学报, 21(7): 1725-1730.
	[Jiang L X, Ji S T, Li S, et al.2010. Relationships between rice empty grain rate and low temperature at booting stage in Heilongjiang Province[J]. Chinese Journal of Applied Ecology, 21(7): 1725-1730.]
[12]	姜丽霞, 李帅, 申双和, 等. 2010. 近46 a黑龙江水稻障碍型冷害及其与气候生产力的关系[J]. 大气科学学报 , 33(3): 315-320. doi: 10.3969/j.issn.1674-7097.2010.03.007
	[Jiang L X, Li S, Shen S H, et al.2010. Sterile-type cool injury on rice and its relationship with climate productivity in Heilongjiang Province from 1961 to 2006[J]. Transactions of Atmospheric Sciences, 33(3): 315-320.] doi: 10.3969/j.issn.1674-7097.2010.03.007
[13]	姜丽霞, 李帅, 闫平, 等. 2009. 黑龙江水稻孕穗期障碍型冷害及其对产量的影响[J]. 中国农业气象, 30(3): 463-468. doi: 10.3969/j.issn.1000-6362.2009.03.035
	[Jiang L X, Li S, Yan P, et al.2009. Sterile type cool injury of rice during booting stage and its impacts on rice yield in Heilongjiang Province[J]. Chinese Journal of Agrometeorology, 30(3): 463-468.] doi: 10.3969/j.issn.1000-6362.2009.03.035
[14]	刘晓菲, 张朝, 帅嘉冰, 等. 2012. 黑龙江省冷害对水稻产量的影响[J]. 地理学报, 67(9): 1223-1232. doi: 10.11821/xb201209007
	[Liu X F, Zhang Z, Shuai J B, et al.2012. Effect of chilling injury on rice yield in Heilongjiang Province[J]. Acta Geographica Sinica, 67(9): 1223-1232.] doi: 10.11821/xb201209007
[15]	马树庆, 王琪, 王春乙, 等. 2011. 东北地区水稻冷害气候风险度和经济脆弱度及其分区研究[J]. 地理研究, 30(5): 931-938. doi: 10.11821/yj2011050017
	[Ma S Q, Wang Q, Wang C Y, et al.2011. Climate risk and economy vulnerability of rice chilling damage and division in Northeast China[J]. Geographical Research, 30(5): 931-938.] doi: 10.11821/yj2011050017
[16]	曲辉辉, 姜丽霞, 朱海霞, 等. 2011. 孕穗期低温对黑龙江省主栽水稻品种空壳率的影响[J]. 生态学杂志, 30(3): 489-493.
	[Qu H H, Jiang L X, Zhu H X, et al.2011. Effects of low temperature at booting stage on the percentage of unfilled grains of major rice varieties in Heilongjiang Province[J]. Chinese Journal of Ecology, 30(3): 489-493.]
[17]	阮仁超, 陈惠查, 游俊梅, 等. 2007. 籼型杂交水稻低温障碍型耐冷性研究[J]. 西南农业学报, 20(6): 1157-1161. doi: 10.3969/j.issn.1001-4829.2007.06.003
	[Ruan R C, Chen H C, You J M, et al.2007. Characteristics of cold tolerance in Indica hybrid rice varieties with low temperature obstruction[J]. Southwest China Journal of Agricultural Sciences, 20(6): 1157-1161.] doi: 10.3969/j.issn.1001-4829.2007.06.003
[18]	王品, 魏星, 张朝, 等. 2014. 气候变暖背景下水稻低温冷害和高温热害的研究进展[J]. 资源科学, 36(11): 2316-2326.
	[Wang P, Wei X, Zhang Z, et al.2014. A review of cold injury and heat damage to rice growth under global warming[J]. Resources Science, 36(11):2316-2326.]
[19]	王艳华, 任传友, 刘刚, 等. 2013. 东北地区不同季节持续低温指数时空变化特征及其对区域温暖化的响应[J]. 资源科学, 35(5): 1016-1023.
	[Wang Y H, Ren C Y, Liu G, et al.2013. The consecutive cold day index and its response to regional warming in Northeastern China[J]. Resources Science, 35(5): 1016-1023.]
[20]	袭祝香, 马树庆, 纪玲玲. 2014. 东北地区水稻延迟型冷害时空特征及其与气候变暖的关系[J]. 地理研究, 33(7): 1373-1382. doi: 10.11821/dlyj201407016
	[Xi Z X, Ma S Q, Ji L L.2014. Spatial-temporal characteristics of prolong-type rice chilling damage and its relationship with climate change in Northeast China[J]. Geographical Research, 33(7): 1373-1382.] doi: 10.11821/dlyj201407016
[21]	张帅, 陶福禄. 2012. 水稻发育期模型研究进展[J]. 地理科学进展, 31(11): 1485-1491. doi: 10.11820/dlkxjz.2012.11.009
	[Zhang S, Tao F L.2012. Review of research on rice phenology models[J]. Progress in Geography, 31(11): 1485-1491.] doi: 10.11820/dlkxjz.2012.11.009
[22]	中国气象局. 2013. QX/T 182-2013 水稻冷害评估技术规范[S]. 北京: 气象出版社.
	[China Meteorological Administration. 2013. QX/T 182-2013 technical specifications for evaluation of rice cool damage[S]. Beijing: China Meteorological Press.]
[23]	Shimono H.2011. Earlier rice phenology as a result of climate change can increase the risk of cold damage during reproductive growth in northern Japan[J]. Agriculture, Ecosystems & Environment, 144(1): 201-207.

生长发育时期	苗期	营养生长期	营养、生殖并进期	开花灌浆期	灌浆成熟期
T₁	9.0	12.5	15.0	15.0	10.5
T₂	28.0	32.0	33.0	33.0	30.0
T₀	21.0	25.0	27.8	26.3	19.3

日期	S(t)	SD	RSCDI	日期	S(t)	SD	RSCDI	日期	S(t)	RSCDI	日期	S(t)	SD	RSCDI
2011/8/1	0.91	0	1	2012/8/1	0.39	1	1	2013/8/1	0.99	1	2014/8/1	1.00	0	1
2011/8/2	0.78	0	1	2012/8/2	0.38	2	1	2013/8/2	0.98	1	2014/8/2	1.00	0	1
2011/8/3	0.83	0	1	2012/8/3	0.73	0	1	2013/8/3	0.98	1	2014/8/3	0.98	0	1
2011/8/4	0.90	0	1	2012/8/4	0.61	0	1	2013/8/4	1.00	1	2014/8/4	0.47	1	1
2011/8/5	0.93	0	1	2012/8/5	0.70	0	1	2013/8/5	0.98	1	2014/8/5	0.59	0	1
2011/8/6	0.83	0	1	2012/8/6	0.82	0	1	2013/8/6	1.00	1	2014/8/6	0.68	0	1
2011/8/7	0.87	0	1	2012/8/7	0.94	0	1	2013/8/7	0.98	1	2014/8/7	0.59	0	1
2011/8/8	0.86	0	1	2012/8/8	0.85	0	1	2013/8/8	0.95	1	2014/8/8	0.75	0	1
2011/8/9	0.97	0	1	2012/8/9	0.80	0	1	2013/8/9	0.89	1	2014/8/9	0.87	0	1
2011/8/10	0.80	0	1	2012/8/10	0.93	0	1	2013/8/10	0.94	1	2014/8/10	0.82	0	1
2011/8/11	0.95	0	1	2012/8/11	0.75	0	1	2013/8/11	1.00	1	2014/8/11	0.72	0	1
2011/8/12	0.95	0	1	2012/8/12	0.23	1	1	2013/8/12	0.91	1	2014/8/12	0.49	1	1
2011/8/13	0.90	0	1	2012/8/13	0.30	2	1	2013/8/13	0.94	1	2014/8/13	0.20	2	1
2011/8/14	0.76	0	1	2012/8/14	0.34	3	0.53	2013/8/14	0.99	1	2014/8/14	0.40	3	0.67
2011/8/15	0.27	1	1	2012/8/15	0.60	0	1	2013/8/15	1.00	1	2014/8/15	0.48	4	0.73
2011/8/16	0.68	0	1	2012/8/16	0.67	0	1	2013/8/16	0.98	1	2014/8/16	0.59	0	1
2011/8/17	0.65	0	1	2012/8/17	0.85	0	1	2013/8/17	0.99	1	2014/8/17	0.50	1	1
2011/8/18	0.56	0	1	2012/8/18	0.85	0	1	2013/8/18	0.70	1	2014/8/18	0.27	2	1
2011/8/19	0.56	0	1	2012/8/19	0.69	0	1	2013/8/19	0.59	1	2014/8/19	0.67	0	1
2011/8/20	0.78	0	1	2012/8/20	0.69	0	1	2013/8/20	0.58	1	2014/8/20	0.89	0	1
