环渤海地区水污染物排放的时空格局及其驱动因素

doi:10.18306/dlkxjz.2017.02.004

Abstract

Abstract:

A clear understanding of the spatiotemporal patterns and driving forces of water pollutant discharge has a crucial practical significance for regional joint reduction and prevention of water pollution. Based on the cross-section data of water pollutant discharge and socioeconomic parameters in 67 cities at the prefectural level or above, the spatiotemporal patterns and effects of spatial association of water pollution are quantitatively measured in the Bohai Rim region. Meanwhile, the socioeconomic drivers of water pollutant discharge are estimated by using the econometric model, and some suggestions for the reduction and control of regional water pollution are put forward. The results show that: (1) The Haihe River Basin is the largest and the most prominent watershed with regard to the total quantity and increment of water pollutants in the Bohai Rim Region. Its COD and NH₃-N discharges accounted for 38.94% and 39.23% of the regional total discharges, respectively. (2) The spatial pattern of high water pollutant discharge areas has changed greatly, from scattered to continuous distribution since 2005. The Beijing-Tianjin-Hebei region, the Central and Southern Liaoning region, and the Shandong Peninsula region become the superimposed areas of high discharge zone of COD and NH₃-N. (3) Discharges of water pollutants have significant spatial association effects in the Bohai Rim region, and the significance of water pollutant discharge presents a general decreasing trend from the coastal area to inland areas. Moreover, the Beijing-Tianjin-Hebei region has been situated in the hotspots for a long period, and the coverage of hotspot and sub-hotspot areas has expanded continuously from the Beijing-Tianjin-Hebei region to the Haihe River and Huaihe River Basin since 2012. (4) By means of an ordinary least squares (OLS) model estimation, it is demonstrated that there are significant differences in the driving forces of water pollutant discharges. Economic growth rate and fixed asset investment show marked positive correlation with COD discharge, and the level of urbanization and industrialization act as a disincentive to COD discharge. Population size is the primary driving factor of NH₃-N discharge in the Bohai Rim region, and fixed asset investment and foreign direct investment also show marked positive correlation with NH₃-N discharge. There is an appreciable association of high capital investment and high water pollutant discharge in the Bohai Rim region. But high economic development level depresses the discharge of water pollutant, especially in the accumulation zone of high intensity discharge.

Key words: water pollutant discharge, spatiotemporal pattern, spatial association, driving force, Bohai Rim Region

Kan ZHOU, Jie FAN, Hanchu LIU. Spatiotemporal patterns and driving forces of water pollutant discharge in the Bohai Rim Region[J].PROGRESS IN GEOGRAPHY, 2017, 36(2): 171-181.

Figures/Tables 10

Tab.1

Tab.2

Fig.1

Fig.2

Tab.3

Fig.3

Fig.4

Tab.4

Tab.5

Fig.5

References 32

[1]	陈媛媛, 李坤望. 2010. 开放条件下工业污染物排放强度影响因素分析[J]. 上海财经大学学报, 12(4): 90-97.
	[Chen Y Y, Li K W.2010. The influencing factors of emission intensity of industrial pollutants under open economy[J]. Journal of Shanghai University of Finance and Economics, 12(4): 90-97.]
[2]	陈祖海, 雷朱家华. 2015. 中国环境污染变动的时空特征及其经济驱动因素[J]. 地理研究, 34(11): 2165-2178. doi: 10.11821/dlyj201511015
	[Chen Z H, Leizhu J H.2015. The spatial-temporal characteristics and economic drivers of environmental pollution changes in China[J]. Geographical Research, 34(11): 2165-2178.] doi: 10.11821/dlyj201511015
[3]	程钰, 任建兰, 陈延斌, 等. 2016. 中国环境规制效率空间格局动态演变及其驱动机制[J]. 地理研究, 35(1): 123-136.
	[Cheng Y, Ren J L, Chen Y B, et al.2016. Spatial evolution and driving mechanism of China’s environmental regulation efficiency[J]. Geographical Research, 35(1): 123-136.]
[4]	高爽, 魏也华, 陈雯, 等. 2011. 发达地区制造业集聚和水污染的空间关联: 以无锡市区为例[J]. 地理研究, 30(5): 902-912. doi: 10.11821/yj2011050014
	[Gao S, Wei Y H, Chen W, et al.2011. Study on spatial-correlation between water pollution and industrial agglomeration in the developed region of China: A case study of Wuxi City[J]. Geographical Research, 30(5): 902-912.] doi: 10.11821/yj2011050014
[5]	郭卫华, 周永章, 阚兴龙. 2015. 1990-2012年广东省废水排放特征及其驱动因素: 基于STIRPAT模型和脱钩指数的研究[J]. 灌溉排水学报, 2015, 34(2): 7-10. doi: 10.13522/j.cnki.ggps.2015.02.002
	[Guo W H, Zhou Y Z, Kan X L.2015. Characteristics and driving factors of wastewater emissions in Guangdong Province from 1990 to 2012: A study based on STIRPAT model and decoupling index[J]. Journal of Irrigation and Drainage, 34(2): 7-10.] doi: 10.13522/j.cnki.ggps.2015.02.002
[6]	国家发展改革委. 2015. 环渤海地区合作发展纲要[EB/OL]. 2015-10-12 [2016-08-01]. .
	[National Development and Reform Commission. 2015. Bohai Rim region cooperation development plan[EB/OL]. 2015-10-12 [2016-08-01]. .]
[7]	纪建悦, 于富洋, 方胜民. 2012. 环渤海地区经济与海洋环境的耦合度研究[J]. 海洋环境科学, 31(6): 847-850.
	[Ji J Y, Yu F Y, Fang S M.2012. Study on coupling degree between economy and marine environment in Bohai Sea Rim[J]. Marine Environmental Science, 31(6): 847-850.]
[8]	贾绍凤, 张士锋. 2003. 海河流域水资源安全评价[J]. 地理科学进展, 22(4): 379-387. doi: 10.11820/dlkxjz.2003.04.006
	[Jia S F, Zhang S F.2003. Water resources security appraisement of Haihe Basin[J]. Progress in Geography, 22(4): 379-387.] doi: 10.11820/dlkxjz.2003.04.006
[9]	蒋伟, 赖明勇. 2009. 空间相关与外商直接投资区位决定: 基于中国城市数据的空间计量分析[J]. 财贸研究, 20(6): 1-6, 19.
	[Jiang W, Lai M Y.2009. Spatial dependence and FDI location determinants: Spatial econometrical analysis based on Chinese urban data[J]. Finance and Trade Research, 20(6): 1-6, 19.]
[10]	刘满凤, 谢晗进. 2014. 中国省域经济集聚性与污染集聚性趋同研究[J]. 经济地理, 34(4): 25-32.
	[Liu M F, Xie H J.2014. The convergence research of economy aggregation and pollution aggregation among China’s provinces[J]. Economic Geography, 34(4): 25-32.]
[11]	刘昕, 熊晓波, 贾俊松, 等. 2008. 社会经济因素对中部地区环境压力的影响分析: 以江西省为例[J]. 人口研究, 32(3): 75-78. doi: 10.3969/j.issn.1000-6087.2008.03.010
	[Liu X, Xiong X B, Jia J S, et al.2008. Shehui jingji yinsu dui zhongbu diqu huanjing yali de yingxiang fenxi: Yi Jiangxisheng weili[J]. Population Research, 32(3): 75-78.] doi: 10.3969/j.issn.1000-6087.2008.03.010
[12]	陆大道. 2015. 中速增长: 中国经济的可持续发展[J]. 地理科学, 35(10): 1207-1219.
	[Lu D D.2015. Moderate-speed growth: Sustainable development of China's economy[J]. Scientia Geographica Sinica, 35(10): 1207-1219.]
[13]	马树才, 李国柱. 2006. 中国经济增长与环境污染关系的Kuznets曲线[J]. 统计研究, 23(8): 37-40. doi: 10.3969/j.issn.1002-4565.2006.08.009
	[Ma S C, Li G Z.2006. The Kuznets Curve of relationship between economic growth and environmental pollution[J]. Statistical Research, 23(8): 37-40.] doi: 10.3969/j.issn.1002-4565.2006.08.009
[14]	牛海鹏, 朱松, 尹训国, 等. 2012. 经济结构、经济发展与污染物排放之间关系的实证研究[J]. 中国软科学, (4): 160-166. doi: 10.3969/j.issn.1002-9753.2012.04.018
	[Niu H P, Zhu S, Yin X G, et al.2012. Empirical study on the relationship among economic structure, economic development and pollutant emission[J]. China Soft Science, (4): 160-166.] doi: 10.3969/j.issn.1002-9753.2012.04.018
[15]	孙才志, 李欣. 2013. 环渤海地区海洋资源、环境阻尼效应测度及空间差异[J]. 经济地理, 33(12): 169-176. doi: 10.3969/j.issn.1000-8462.2013.12.027
	[Sun C Z, Li X.2013. Measurement and spatial analysis of marine resources and environment damping effect in the Bohai Sea Ring area[J]. Economic Geography, 33(12): 169-176.] doi: 10.3969/j.issn.1000-8462.2013.12.027
[16]	唐德才. 2009. 工业化进程、产业结构与环境污染: 基于制造业行业和区域的面板数据模型[J]. 软科学, 23(10): 6-11.
	[Tang D C.2009. Industrialization, industry structure and environment pollution: Based on manufacturing industry and regional panel model[J]. Soft Science, 23(10): 6-11.]
[17]	王强, 刘雅玲, 吴悦颖, 等. 2015. 我国主要污染物排放强度区域特征分析研究[J]. 环境保护科学, 41(3): 57-61. doi: 10.3969/j.issn.1004-6216.2015.03.015
	[Wang Q, Liu Y L, Wu Y Y, et al.2015. Analysis of spatial characteristics of emission intensity of the main pollutants in China[J]. Environmental Protection Science, 41(3): 57-61.] doi: 10.3969/j.issn.1004-6216.2015.03.015
[18]	王书明, 周寒. 2015. 竞争、合作与生态文明建设合作制度的建构: 结合环渤海区域水污染治理的思考[J]. 哈尔滨工业大学学报: 社会科学版, 17(6): 103-108. doi: 10.3969/j.issn.1009-1971.2015.06.019
	[Wang S M, Zhou H.2015. Competition, cooperation and construction of cooperative system of ecological civilization: Study on the problems of water pollution governance around the Bohai Sea Region[J]. Journal of HIT: Social Sciences Edition, 17(6): 103-108.] doi: 10.3969/j.issn.1009-1971.2015.06.019
[19]	吴凯. 1997. 环渤海区域水环境问题及其防治对策[J]. 地理科学, 17(3): 231-236.
	[Wu K.1997. The status quo and the preventing and controlling countermeasures for the water environment problems in the region surrounded by the Bohai Sea[J]. Scientia Geographica Sinica, 17(3): 231-236.]
[20]	夏军. 2002. 华北地区水循环与水资源安全: 问题与挑战[J]. 地理科学进展, 21(6): 517-526. doi: 10.3969/j.issn.1007-6301.2002.06.001
	[Xia J.2002. A perspective on hydrological base of water security problem and its application study in North China[J]. Progress in Geography, 21(6): 517-526.] doi: 10.3969/j.issn.1007-6301.2002.06.001
[21]	项尧尧. 2015. 环境污染对环渤海沿海地区经济的“增长阻力”研究[D]. 青岛: 中国海洋大学.
	[Xiang Y Y.2015. Research on economic “growth drag” caused by environmental pollution in the Bohai coastal areas[D]. Qingdao, China: Ocean University of China.]
[22]	徐林清, 聂楠. 2015. 污染物排放的空间集聚及其影响因素: 基于岭回归模型的分析[J]. 生态经济, 31(5): 160-165. doi: 10.3969/j.issn.1671-4407.2015.05.034
	[Xu L Q, Nie N.2015. Spatial agglomeration and influencing factors of pollutant emissions: The analysis based on ridge regression model[J]. Ecological Economy, 31(5): 160-165.] doi: 10.3969/j.issn.1671-4407.2015.05.034
[23]	徐胜, 王晓惠, 宋维玲, 等. 2011. 环渤海地区经济增长与环境污染关系分析: 基于环境库兹涅茨曲线[J]. 海洋通报, 30(6): 601-606. doi: 10.3969/j.issn.1001-6392.2011.06.001
	[Xu S, Wang X H, Song W L, et al.2011. Analysis of the relationship between economic growth and environmental pollution in Circum-Bohai-Sea Zone: Based on environmental Kuznets Curve[J]. Marine Science Bulletin, 30(6): 601-606.] doi: 10.3969/j.issn.1001-6392.2011.06.001
[24]	赵红, 彭馨. 2013. 对外贸易、相对收入与污染物排放: 基于我国省级单位面板数据的研究[J]. 南京农业大学学报: 社会科学版, 13(1): 103-112.
	[Zhao H, Peng X.2013. Trade, relative income and emissions of the pollutants: A study based on panel data from provincial level units[J]. Journal of Nanjing Agricultural University: Social Sciences Edition, 13(1): 103-1112.]
[25]	赵小风, 黄贤金, 张兴榆, 等. 2009. 区域COD、SO2及TSP排放的空间自相关分析: 以江苏省为例[J]. 环境科学, 30(6): 1580-1587.
	[Zhao X F, Huang X J, Zhang X Y, et al.2009. Application of spatial autocorrelation analysis to the COD, SO2 and TSP emission in Jiangsu Province[J]. Environmental Science, 30(6): 1580-1587.]
[26]	周侃. 2016. 中国环境污染的时空差异与集聚特征[J]. 地理科学, 36(7): 989-997. doi: 10.13249/j.cnki.sgs.2016.07.004
	[Zhou K.2016. Spatial-temporal differences and cluster features of environmental pollution in China[J]. Scientia Geographica Sinica, 36(7): 989-997.] doi: 10.13249/j.cnki.sgs.2016.07.004
[27]	周侃, 樊杰. 2016. 中国环境污染源的区域差异及其社会经济影响因素: 基于339个地级行政单元截面数据的实证分析[J]. 地理学报, 71(11): 1911-1925. doi: 10.11821/dlxb201611004
	[Zhou K, Fan J.2016. Regional disparity of environmental pollution source and its socio-economic influencing factors: Based on the cross-section data of 339 cities at prefecture level or above in China[J]. Acta Geographica Sinica, 71(11): 1911-1925.] doi: 10.11821/dlxb201611004
[28]	朱悦. 2013. 环渤海地区经济增长与环境污染关系[J]. 辽宁工程技术大学学报: 自然科学版, 32(7): 968-977. doi: 10.3969/j.issn.1008-0562.2013.07.022
	[Zhu Y.2013. Relationship between economic growth and environmental pollution in Circum-Bohai-Sea Zone[J]. Journal of Liaoning Technical University: Natural Science, 32(7): 968-977.] doi: 10.3969/j.issn.1008-0562.2013.07.022
[29]	Anselin L.1988. Spatial econometrics: Methods and models[M]. Dordrecht, Netherlands: Kluwer Academic Publishers.
[30]	Ehrlich P R, Holdren J P.1971. Impact of population growth[J]. Science, 171: 1212-1217. doi: 10.1126/science.171.3977.1212 pmid: 5545198
[31]	Grossman G M, Krueger A B.1995. Economic, growth and the environment[J]. The Quarterly Journal of Economics, 110(2): 353-377.
[32]	Hosseini H M, Kaneko S.2013. Can environmental quality spread through institutions[J]. Energy Policy, 56: 312-321. doi: 10.1016/j.enpol.2012.12.067

指标项	地区	化学需氧量		氨氮
指标项	地区	2005年	2012年	2005年	2012年
排放总量/×10⁴t	环渤海地区	302.15	635.30	36.98	54.23
排放总量/×10⁴t	全国平均	1364.92	2372.81	145.45	249.73
单位排放量/×10⁴t	环渤海地区	4.51	9.48	0.55	0.81
单位排放量/×10⁴t	全国平均	4.03	7.00		0.74

流域	化学需氧量/×10⁴t			氨氮/×10⁴t
流域	2005年	2012年	贡献率/%	2005年	2012年	贡献率/%
海河	130.79	247.39	35.00	14.05	21.27	41.87
辽河	68.07	152.83	25.44	9.76	12.24	14.41
淮河	43.21	112.94	20.93	4.96	11.07	35.47
黄河	50.72	87.78	11.12	6.87	8.14	7.39
松花江	5.50	21.08	4.68	0.70	0.97	1.53
内陆河	3.87	13.28	2.82	0.64	0.53	-0.66
环渤海地区	302.15	635.30	—	36.98	54.23	—

指标项	年份	Moran’s I	方差	Z(I)	P值
化学需氧量	2005	0.149037	0.005675	2.179537	0.029292
化学需氧量	2012	0.167632	0.005992	2.361349	0.018209
氨氮	2005	0.111121	0.005730	1.668120	0.095292
氨氮	2012	0.199535	0.005872	2.801669	0.005084

变量	总体模型				热区模型
变量	系数	标准误差	t	Sig.	系数	标准误差	t	Sig.
constant	11.6640	2.6526	4.3972	0.0000	16.2826	2.7216	5.9826	0.0000
lnTP	0.1984	0.2156	0.9203	0.3611	-0.0996	0.1885	-0.5283	0.6029
lnUR	-0.9504^***	0.3536	-2.6874	0.0093	-1.4097^***	0.3813	-3.6973	0.0013
lnPGDP	-0.1331	0.1978	-0.6728	0.5037	-0.2982^*	0.1775	-1.6804	0.1077
lnGRGDP	0.8730^*	0.4792	1.8216	0.0736	0.1837	0.4687	0.3919	0.6991
lnIS	-0.7999^**	0.3599	-2.2226	0.0301	-0.4772	0.3979	-1.1995	0.2437
lnFDI	-0.0240	0.0429	-0.5587	0.5785	0.1178	0.0721	1.6332	0.1173
lnFAI	0.6986^***	0.2247	3.1085	0.0029	0.6658^***	0.2206	3.0180	0.0065
P值	0.0000				0.0000
F值	26.7017				11.3521
调整后R²	0.7316				0.7213
D.W值	1.9225				2.0711

变量	总体模型				热区模型
变量	系数	标准误差	t	Sig.	系数	标准误差	t	Sig.
constant	4.7835	1.5686	3.0496	0.0034	6.2443	1.9030	3.2813	0.0026
lnTP	0.5822^***	0.1275	4.5674	0.0000	0.5072^***	0.1367	3.7105	0.0008
lnUR	-0.0943	0.2091	-0.4510	0.6537	-0.0566	0.2615	-0.2163	0.8303
lnPGDP	-0.2502^**	0.1170	-2.1390	0.0366	-0.4285^***	0.1313	-3.2643	0.0027
lnGRGDP	0.4116	0.2834	1.4523	0.1517	0.1617	0.3595	0.4496	0.6562
lnIS	0.0426	0.2128	0.2000	0.8422	0.3048	0.2800	1.0886	0.2850
lnFDI	0.0488^*	0.0254	1.9206	0.0596	0.0820^*	0.0455	1.8014	0.0817
lnFAI	0.2851^**	0.1329	2.1456	0.0360	0.2892^*	0.1458	1.9834	0.0565
P值	0.0000				0.0000
F值	76.7771				39.1698
调整后R²	0.8893				0.8784
D.W值	2.3247				2.1168
