地理科学进展 ›› 2019, Vol. 38 ›› Issue (9): 1305-1315.doi: 10.18306/dlkxjz.2019.09.004
收稿日期:
2019-05-15
修回日期:
2019-08-19
出版日期:
2019-09-28
发布日期:
2019-09-25
通讯作者:
刘正佳
作者简介:
姜凯斯(1994— ),女,河北唐山人,硕士生,主要从事土地利用与乡村发展研究。E-mail:15613559335@163.com
基金资助:
JIANG Kaisi1,LIU Zhengjia2,*(),LI Yurui2,WANG Yongsheng2,WANG Yu1
Received:
2019-05-15
Revised:
2019-08-19
Online:
2019-09-28
Published:
2019-09-25
Contact:
LIU Zhengjia
Supported by:
摘要:
深入开展乡村地域土地利用变化和聚落发展规律的研究对于探究乡村地域系统优化、推进城乡融合与乡村可持续发展具有重要意义。论文以延安市碾庄流域为例,基于ENVI和GIS等软件技术,结合Landsat卫星影像、马尔科夫链模型和实地调查,从土地利用转移与交换变化、建筑用地空间转移、社会响应等角度探讨了黄土丘陵沟壑区典型村域土地利用变化特征以及对区域乡村发展转型的影响。研究表明:① 在一系列生态工程措施作用下,碾庄流域生态覆被发生明显改观,主要表现为大量的坡耕地及稀疏生态用地转化为林地,其中,林地面积占比由32.34%(2009年)增加至50.88%(2018年);② 在社会经济发展和延安新城“边缘效应”的影响下,碾庄建设用地呈现向流域的东南和西南方向拓展的趋势,10 a间建设用地面积增加了近75%;③ 在人类活动的主导作用下,黄土丘陵沟壑区的乡村正在朝着生态化和集约化的方向转型发展。研究结果有望为深入理解黄土丘陵沟壑区乡村地域系统结构和优化提供新参考。
姜凯斯,刘正佳,李裕瑞,王永生,王昱. 黄土丘陵沟壑区典型村域土地利用变化及对区域乡村转型发展的启示[J]. 地理科学进展, 2019, 38(9): 1305-1315.
JIANG Kaisi,LIU Zhengjia,LI Yurui,WANG Yongsheng,WANG Yu. Land use change of typical villages in the loess hilly and gully region and implications for regional rural transformation and development[J]. PROGRESS IN GEOGRAPHY, 2019, 38(9): 1305-1315.
Tab.1
Remote sensing imageries used in this study"
传感器类别 | 卫星 | 成像时间 | 分辨率/m | 轨道号 | 云量/% |
---|---|---|---|---|---|
TM | Landsat 5 | 2009-06-14 | 30 | 127/35 | 3 |
TM | Landsat 5 | 2009-06-30 | 30 | 127/35 | 0 |
TM | Landsat 5 | 2009-10-20 | 30 | 127/35 | 0 |
OLI | Landsat 8 | 2014-05-11 | 30 | 127/35 | 2.34 |
OLI | Landsat 8 | 2014-08-15 | 30 | 127/34 | 0.08 |
OLI | Landsat 8 | 2014-10-02 | 30 | 127/34 | 0 |
OLI | Landsat 8 | 2018-05-22 | 30 | 127/35 | 0.99 |
OLI | Landsat 8 | 2018-09-11 | 30 | 127/35 | 9.7 |
OLI | Landsat 8 | 2018-10-29 | 30 | 127/35 | 0.01 |
表2
2009—2018年土地类型面积和占比变化"
土地类型 | 2009年 | 2014年 | 2018年 | |||||
---|---|---|---|---|---|---|---|---|
面积/km2 | 占比/% | 面积/km2 | 占比/% | 面积/km2 | 占比/% | |||
建设用地 | 2.05 | 3.80 | 2.20 | 4.08 | 3.59 | 6.66 | ||
水体 | 0.26 | 0.48 | 0.21 | 0.39 | 0.16 | 0.30 | ||
耕地 | 5.40 | 10.01 | 6.86 | 12.73 | 4.65 | 8.62 | ||
林地 | 17.43 | 32.34 | 24.46 | 45.39 | 27.42 | 50.88 | ||
灌木丛 | 7.81 | 14.49 | 7.76 | 14.41 | 6.34 | 11.76 | ||
草地 | 20.96 | 38.89 | 12.35 | 22.91 | 11.74 | 21.78 |
表3
2009—2014年土地利用转移矩阵"
地类 | 2014年 | 总计 | 转出 | ||||||
---|---|---|---|---|---|---|---|---|---|
建设用地 | 水体 | 耕地 | 林地 | 灌木丛 | 草地 | ||||
2009年 | 建设用地 | 0.63 | 0.02 | 0.56 | 0.05 | 0.01 | 0.77 | 2.04 | 1.41 |
水体 | 0.04 | 0.09 | 0.08 | 0.01 | 0 | 0.03 | 0.26 | 0.17 | |
耕地 | 0.44 | 0.05 | 2.26 | 0.70 | 0.03 | 1.92 | 5.39 | 3.14 | |
林地 | 0.46 | 0.03 | 1.21 | 8.38 | 5.28 | 2.04 | 17.41 | 9.04 | |
灌木丛 | 0.06 | 0.02 | 0.17 | 5.12 | 2.14 | 0.30 | 7.80 | 5.66 | |
草地 | 0.55 | 0.01 | 2.58 | 10.20 | 0.31 | 7.28 | 20.93 | 13.64 | |
总计 | 2.20 | 0.21 | 6.86 | 24.46 | 7.76 | 12.35 | - | - | |
转入 | 1.56 | 0.13 | 4.61 | 16.08 | 5.62 | 5.06 | - | - |
表4
2014—2018年土地利用转移矩阵"
地类 | 2018年 | 总计 | 转出 | ||||||
---|---|---|---|---|---|---|---|---|---|
建设用地 | 水体 | 耕地 | 林地 | 灌木丛 | 草地 | ||||
2014年 | 建设用地 | 1.65 | 0.01 | 0.32 | 0.03 | 0.01 | 0.18 | 2.20 | 0.54 |
水体 | 0.06 | 0.12 | 0.03 | 0 | 0 | 0 | 0.21 | 0.09 | |
耕地 | 0.88 | 0.02 | 2.09 | 1.11 | 0.39 | 2.38 | 6.87 | 4.77 | |
林地 | 0.22 | 0 | 0.42 | 19.64 | 1.55 | 2.62 | 24.45 | 4.81 | |
灌木丛 | 0.04 | 0 | 0.06 | 3.58 | 4.01 | 0.07 | 7.76 | 3.75 | |
草地 | 0.75 | 0.01 | 1.72 | 3.02 | 0.38 | 6.46 | 12.34 | 5.88 | |
总计 | 3.59 | 0.16 | 4.64 | 27.39 | 6.33 | 11.72 | - | - | |
转入 | 1.94 | 0.04 | 2.56 | 7.74 | 2.32 | 5.25 | - | - |
[1] | 段增强, 张凤荣, 孔祥斌 . 2005. 土地利用变化信息挖掘方法及其应用[J]. 农业工程学报, 21(12):60-66. |
[ Duan Z Q, Zhang F R, Kong X B . 2005. Method for information mining of land-use change and its application. Transactions of CSAE, 21(12):60-66. ] | |
[2] | 杜志雄, 张兴华 . 2006. 世界农村发展与城乡关系演变趋势及政策分析[J]. 调研世界, ( 7):7-8. |
[ Du Z X, Zhang X H . 2006. Trend and policy analysis of world rural development and urban-rural relation. The World of Survey and Research, ( 7):7-8. ] | |
[3] | 蔺小虎, 姚顽强, 邱春霞 . 2015. 黄土丘陵沟壑区退耕驱动下土地利用变化: 以陕西省安塞县纸坊沟流域为例[J]. 山地学报, 33(6):759-769. |
[ Lin X H, Yao W Q, Qiu C X . 2015. Land use change driven by farmland in loess hilly-gully region: A case study of Zhifanggou gully basin. Mountain Research, 33(6):759-769. ] | |
[4] |
刘可, 杜灵通, 侯静 , 等. 2018. 近30年中国陆地生态系统NDVI时空变化特征[J]. 生态学报, 38(6):1885-1896.
doi: 10.5846/stxb201701150122 |
[ Liu K, Du L T, Hou J , et al. 2018. Spatiotemporal variations of NDVI in terrestrial ecosystems in China from 1982-2012. Acta Ecologica Sinica, 38(6):1885-1896. ]
doi: 10.5846/stxb201701150122 |
|
[5] | 刘瑞, 朱道林 . 2010. 基于转移矩阵的土地利用变化信息挖掘方法探讨[J]. 资源科学, 32(8):1544-1550. |
[ Liu R, Zhu D L . 2010. Methods for detecting land use changes based on the land use transition matrix. Resources Science, 32(8):1544-1550. ] | |
[6] | 刘彦随 . 2018. 中国新时代城乡融合与乡村振兴[J]. 地理学报, 73(4):637-650. |
[ Liu Y S . 2018. Research on the urban-rural integration and rural revitalization in the new era in China. Acta Geographica Sinica, 73(4):637-650. ] | |
[7] | 刘彦随 . 2019. 新时代乡村振兴地理学研究[J]. 地理研究, 38(3):461-466. |
[ Liu Y S . 2019. Research on the geography of rural revitalization in the new era. Geographical Research, 38(3):461-466. ] | |
[8] | 李裕瑞, 李怡, 范朋灿 , 等. 2019. 黄土丘陵沟壑区沟道土地整治对乡村人地系统的影响[J]. 农业工程学报, 35(5):241-250. |
[ Li Y R, Li Y, Fan P C , et al. 2019. Impacts of land consolidation on rural human-environment system in typical watershed of loess hilly and gully region. Transactions of CSAE, 35(5):241-250. ] | |
[9] |
龙花楼 . 2012. 论土地利用转型与乡村转型发展[J]. 地理科学进展, 31(2):131-138.
doi: 10.11821/xb201204012 |
[ Long H L . 2012. Land use transition and rural transformation development. Progress in Geography, 31(2):131-138. ]
doi: 10.11821/xb201204012 |
|
[10] | 龙花楼 . 2013. 论土地整治与乡村空间重构[J]. 地理学报, 68(8):1019-1028. |
[ Long H L . 2013. Land consolidation and rural spatial restructuring. Acta Geographica Sinica, 68(8):1019-1028. ] | |
[11] | 龙花楼, 李秀彬 . 2005. 长江沿线样带农村宅基地转型[J]. 地理学报, 60(2):179-188. |
[ Long H L, Li X B . 2005. Rural housing land transition in transect of the Yangtse River. Acta Geographica Sinica, 60(2):179-188. ] | |
[12] | 龙花楼, 屠爽爽 . 2018. 乡村重构的理论认知[J]. 地理科学进展, 37(5):581-590. |
[ Long H L, Tu S S . 2018. Theoretical thinking of rural restructuring. Progress in Geography, 37(5):581-590. ] | |
[13] | 乔伟峰, 盛业华, 方斌 , 等. 2013. 基于转移矩阵的高度城市化区域土地利用演变信息挖掘: 以江苏省苏州市为例[J]. 地理研究, 32(8):1497-1507. |
[ Qiao W F, Sheng Y H, Fang B , et al. 2013. Land use change information mining in highly urbanized area based on transfer matrix: A case study of Suzhou, Jiangsu Province. Geographical Research, 32(8):1497-1507. ] | |
[14] | 宋伟, 陈百明, 张英 . 2013. 中国村庄宅基地空心化评价及其影响因素[J]. 地理研究, 32(1):20-28. |
[ Song W, Chen B M, Zhang Y . 2013. Typical survey and analysis on influencing factors of village-hollowing of rural housing land in China. Geographical Research, 32(1):20-28. ] | |
[15] | 汤国安, 赵牡丹 . 2000. 基于GIS的乡村聚落空间分布规律研究: 以陕北榆林地区为例[J]. 经济地理, 20(5):1-4. |
[ Tang G A, Zhao M D . 2000. A gis based research on the distribution of rural Settlements: Taking Yulin area as an example. Economic Geography, 20(5):1-4. ] | |
[16] | 汪小钦, 刘亚迪, 周伟东 , 等. 2016. 基于TAVI的长汀县植被覆盖度时空变化研究[J]. 农业机械学报, 47(1):289-298. |
[ Wang X Q, Liu Y D, Zhou W D , et al. 2016. Research on temporal and spatial variation of fractional vegetation cover in Changting County based on TAVI. Transactions of the CSAM, 47(1):289-298. ] | |
[17] | 王继夏, 孙虎, 王祖正 . 2007. 延安碾庄沟流域梯田与坝地土壤水分对比分析[J]. 干旱地区农业研究, 25(1):88-93. |
[ Wang J X, Sun H, Wang Z Z . 2007. Comparison of soil moisture characteristics of terraced field and dammed land in Nianzhuanggou watershed of Yan' an. Agricultural Research in the Arid Areas, 25(1):88-93. ] | |
[18] | 王林林, 路春燕 . 2015. 陕北黄土丘陵沟壑区聚落分布及形成机制研究: 以延安市安塞县为例[J]. 农业现代化研究, 36(5):883-889. |
[ Wang L L, Lu C Y . 2015. Distribution and formation mechanism of settlements in hilly and gully regions of Loess Plateau in North Shaanxi: A case study in Ansai County. Research of Agricultural Modernization, 36(5):883-889. ] | |
[19] | 文琦 . 2009. 中国农村转型发展研究的进展与趋势[J]. 中国人口·资源与环境, 19(1):20-24. |
[ Wen Q . 2009. Recent progress of research in rural transformation development and its trends in China. China Population,Resources and Environment, 19(1):20-24. ] | |
[20] | 吴文恒, 牛叔文, 郭晓东 , 等. 2008. 黄淮海平原中部地区村庄格局演变实证分析[J]. 地理研究, 27(5):1017-1025. |
[ Wu W H, Niu S W, Guo X D , et al. 2008. The empirical analysis of the village pattern evolution in the central part of Huang-Huai-Hai Plain. Geographical Research, 27(5):1017-1025. ] | |
[21] |
杨忍, 刘彦随, 龙花楼 , 等. 2015. 中国乡村转型重构研究进展与展望: 逻辑主线与内容框架[J]. 地理科学进展, 34(8):1019-1030.
doi: 10.18306/dlkxjz.2015.08.009 |
[ Yang R, Liu Y S, Long H L , et al. 2015. Research progress and prospect of rural transformation and reconstruction in China: Paradigms and main content. Progress in Geography, 34(8):1019-1030. ]
doi: 10.18306/dlkxjz.2015.08.009 |
|
[22] | 郑小玉, 刘彦随 . 2018. 新时期中国“乡村病”的科学内涵、形成机制及调控策略[J]. 人文地理, 33(2):100-106. |
[ Zheng X Y, Liu Y S . 2018. Connotation, formation mechanism and regulation strategies of rural disease in the new epoch in China. Human Geography, 33(2):100-106. ] | |
[23] | 朱会义, 李秀彬 . 2003. 关于区域土地利用变化指数模型方法的讨论[J]. 地理学报, 58(5):643-650. |
[ Zhu H Y, Li X B . 2003. Discussion on the index method of regional land use change. Acta Geographica Sinica, 58(5):643-650. ] | |
[24] | Fan L L, Liang S F, Chen H , et al. 2018. Spatio-temporal analysis of the geographical centroids for three major crops in China from 1949 to 2014[J]. Journal of Geographical Sciences, 28(11):1672-1684. |
[25] | Hossen H, Ibrahim M G, Mahmod W E , et al. 2018. Forecasting future changes in Manzala Lake surface area by considering variations in land use and land cover using remote sensing approach[J]. Arabian Journal of Geosciences, 11(5):93. |
[26] | Liu Y S, Fang F, Li Y H . 2014. Key issues of land use in China and implications for policy making[J]. Land Use Policy, 40:6-12. |
[27] | Liu Y S, Li J T, Yang Y Y . 2018. Strategic adjustment of land use policy under the economic transformation[J]. Land Use Policy, 74:5-14. |
[28] | Liu Y S, Yang R, Long H L , et al. 2014. Implications of land-use change in rural China: A case study of Yucheng, Shandong Province[J]. Land Use Policy, 40:111-118. |
[29] | Liu Y S . 2018. Introduction to land use and rural sustainability in China[J]. Land Use Policy, 74:1-4. |
[30] | Long H L, Liu Y S, Li X B , et al. 2010. Building new countryside in China: A geographical perspective[J]. Land Use Policy, 27:457-470. |
[31] | Tucker C, Pinzon J, Brown M , et al. 2005. An extended AVHRR 8-km NDVI dataset compatible with MODIS and SPOT vegetation NDVI data[J]. International Journal of Remote Sensing, 26(20):4485-4498. |
[32] | Watts D, Ilbery B, Maye D , et al. 2009. Implementing pillar II of the common agricultural policy in England: Geographies of the rural enterprise scheme and processing and marketing grant[J]. Land Use Policy, 26:683-694. |
