基于“三类”空间的后备可利用土地资源评价研究——以山西省介休市为例

doi:10.18306/dlkxjz.2021.02.008

地理科学进展 ›› 2021, Vol. 40 ›› Issue (2): 272-282.doi: 10.18306/dlkxjz.2021.02.008

基于“三类”空间的后备可利用土地资源评价研究——以山西省介休市为例

徐小任¹, 王梁¹, 徐勇²^,³^,^*(), 段健⁴

^1. 山东省水土保持与环境保育重点实验室,临沂大学资源环境学院,山东临沂 276005
^2. 中国科学院地理科学与资源研究所,北京 100101
^3. 中国科学院大学,北京 100049
^4. 浙江师范大学地理与环境科学学院,浙江金华 321004

收稿日期:2020-01-06 修回日期:2020-08-14 出版日期:2021-02-28 发布日期:2021-04-28
通讯作者: 徐勇
作者简介:徐小任(1985- ), 女,汉族,山东临沂人,博士,讲师,主要研究方向为土地利用、区域可持续发展。E-mail: xuxiaoren@lyu.edu.cn
基金资助:
山东省自然科学基金项目(ZR2018PD003)

Evaluation of reserve available land resources based on three types of territorial space: A case study of Jiexiu City in Shanxi Province

XU Xiaoren¹, WANG Liang¹, XU Yong²^,³^,^*(), DUAN Jian⁴

^1. Shandong Provincial Key Laboratory of Water and Soil Conservation and Environmental Protection, College of Resources and Environment, Linyi University, Linyi 276005, Shandong, China
^2. Institute of Geographic Sciences and Natural Resources Research, CAS, Beijing 100101, China
^3. University of Chinese Academy of Sciences, Beijing 100049, China
^4. College of Geography and Environmental Sciences, Zhejiang Normal University, Jinhua 321004, Zhejiang, China

Received:2020-01-06 Revised:2020-08-14 Online:2021-02-28 Published:2021-04-28
Contact: XU Yong
Supported by:
National Natural Science Foundation of Shandong, No(ZR2018PD003)

摘要/Abstract

摘要：

针对当前国土空间规划“双评价”中存在的后备适宜建设用地与后备适宜耕地在城镇、农业空间分布上的重叠性问题,论文在对2类用地进行概念内涵辨析的基础上,尝试构建后备可利用土地资源集成评价方法,探讨不同类型后备可利用土地资源用途的地域导向,并选取山西省介休市作为案例区进行实证应用研究。结果表明：介休市后备适宜建设用地面积较大(45.3 km ²),但集中连片趋势不明显。人均后备适宜建设用地面积为0.16亩/人。区域后备适宜耕地面积74.1 km ²,人均后备适宜耕地面积为0.26亩/人。研究区域2类用地具有相似的空间分布格局,即绵山镇、连福镇等地区后备可利用土地资源潜力较大,而城区及周围地区的潜力较小。针对2类用地的重叠性和差异性,介休市城区、各乡镇中心及北部地区的后备可利用土地资源未来可转化建设用地,即未来应被划归城镇空间。连福、绵山、义棠、张兰等乡镇南部地区未来可转化为新增耕地,即应被划归农业空间。

关键词: 后备可利用土地资源, 后备适宜建设用地, 后备适宜耕地, 国土空间规划, “三类”空间;, 介休市

Abstract:

The spatial distribution of reserve available construction land overlaps with that of reserve available cultivated land in the resources and environmental carrying capacity and territorial development suitability evaluations of current territorial spatial planning. On the basis of elaborating the connotation of relevant concept, this study developed an integrated evaluation method of reserve available land resources, discussed the regional tendency of use of these two types of land, and took Jiexiu City in Shanxi Province as an example. The results are as follows: 1) Reserve available construction land in Jiexiu City had an area of 45.3 km ², which was 6.1% of the total land area of the city. Its distribution was scattered. The reserve available construction land could be generally divided into three levels: highly suitable, suitable, and less suitable. The corresponding areas were 3.6 km ², 16.1 km ², and 25.6 km ² respectively. The area of reserve available construction land per capita was 0.16 mu. 2) The area of the reserve available cultivated land was 74.1 km ², which was 10% of the total. The reserve available cultivated land also could be divided into three levels: highly suitable, suitable, and less suitable. The corresponding areas were 21.7 km ², 26.1 km ², and 26.3 km ²respectively. The area of reserve available cultivated land per capita was 0.26 mu. There were similar spatial distributions between these two types of land in the study area. The potential of reserve available land resources in Mianshan and Lianfu towns was large, while the potential of the urban area and its surroundings was small. In view of the overlap and difference of spatial distribution between these two types of land, reserve available land resources in the urban area, town centers, and the northern part of the city could be used as construction land preferentially in the future. They should be classified as urban space. Reserve available land resources in the southern areas of Lianfu, Mianshan, Yitang, and Zhanglan towns could be transformed into new cultivated land. They should be classified as agricultural space.

Key words: reserve available land resources, reserve available construction land, reserve available cultivated land, territorial spatial planning, three types of territorial spaces, Jiexiu City

徐小任, 王梁, 徐勇, 段健. 基于“三类”空间的后备可利用土地资源评价研究——以山西省介休市为例[J]. 地理科学进展, 2021, 40(2): 272-282.

XU Xiaoren, WANG Liang, XU Yong, DUAN Jian. Evaluation of reserve available land resources based on three types of territorial space: A case study of Jiexiu City in Shanxi Province[J]. PROGRESS IN GEOGRAPHY, 2021, 40(2): 272-282.

图/表 9

表1

后备可利用土地资源评价方法"

指标项	计算公式	公式说明
可利用土地资源	$L = L σ + L φ$	L为可利用土地资源面积; $L σ$ 、 $L φ$ 是指地形坡度分别小于15°、15°~25°且满足一定高程条件的可利用土地资源面积
后备适宜建设用地	$L sc = L σ - L fgσ - L waσ - L pzσ - L gdσ$	$L sc$ 为适宜建设用地面积; $L ac$ 为后备适宜建设用地面积; $L fgσ$ 、 $L waσ$ 、 $L pzσ$ 、 $L gdσ$ 、 $L ecσ$ 、 $L cuσ$ 、 $L gaσ$ 、 $L faσ$ 分别为坡度小于15°的可利用土地资源内所含的林地、水域用地、保护区、沙漠戈壁、已有建设用地、耕地、园地、基本农田等用地面积; $α$ 的取值可根据国土部门划定的耕地保护红线的分布格局进行确定
	$L faσ = L cuσ × α, α ∈ [0.9, 1]$
	$L ac = L sc - L ecσ - L faσ - L gaσ$
人均后备适宜建设用地	$L pac = L ac P$	$L pac$ 为人均后备适宜建设用地面积,P为区域人口数量
后备适宜耕地	$L au = L - L fg - L wa - L pz - L gd - L ec - L cu - L ga$	$L au$ 为后备适宜耕地面积; $L fg$ 、 $L wa$ 、 $L pz$ 、 $L gd$ 、 $L ec$ 、 $L cu$ 、 $L ga$ 分别指区域可利用土地资源内所含的林地、水域用地、保护区、沙漠戈壁、已有建设用地、耕地、园地、基本农田等地类面积
人均后备适宜耕地	$L pau = L au P$	$L pau$ 为人均后备适宜耕地面积

表1

表2

图1

图2

表3

图3

表4

图4

图5

参考文献 31

[1]	Deng X Z, Huang J K, Rozelle S , et al. Impact of urbanization on cultivated land changes in China[J]. Land Use Policy, 2015,45:1-7.
[2]	黄金川, 林浩曦, 漆潇潇 . 面向国土空间优化的三生空间研究进展[J]. 地理科学进展, 2017,36(3):378-391.
	[ Huang Jinchuan, Lin Haoxi, Qi Xiaoxiao . A literature review on optimization of spatial development pattern based on ecological-production-living space. Progress in Geography, 2017,36(3):378-391. ]
[3]	陆大道, 樊杰 . 2050: 中国的区域发展 [M]. 北京: 科学出版社, 2009: 12-15.
	[ Lu Dadao, Fan Jie. 2050: China's regional development. Beijing, China: Science Press, 2009: 12-15. ]
[4]	徐小任 . 基于人类拓居模式的土地资源承载力评价方法及应用研究[D]. 北京: 中国科学院大学, 2017.
	[ Xu Xiaoren . Evaluation methods and application research on carrying capacity of land resources based on human exploiting and settling pattern. Beijing, China: University of Chinese Academy of Sciences, 2017. ]
[5]	黄安, 许月卿, 卢龙辉 , 等. “生产—生活—生态”空间识别与优化研究进展[J]. 地理科学进展, 2020,39(3):503-518.
	[ Huang An, Xu Yueqing, Lu Longhui , et al. Research progress of the identification and optimization of production-living-ecological spaces. Progress in Geography, 2020,39(3):503-518. ]
[6]	中共中央办公厅, 国务院办公厅. 中共中央国务院关于坚持农业农村优先发展做好“三农”工作的若干意见 [EB/OL]. 新华网, 2019- 02- 19 [2020-01-03]. http://www.xinhuanet.com/politics/2019-02/19/c_1210063174.htm.
	[General office of the CPC Central Committee, General office of the State Council. Opinions of the CPC Central Committee and the State Council on giving priority to the development of agriculture and rural areas and doing good jobs in the "three rural issues". Xinhuanet, 2019-02-19 [2020-01-03]. http://www.xinhuanet.com/politics/2019-02/19/c_1210063174.htm. ]
[7]	徐勇, 汤青, 樊杰 , 等. 主体功能区划可利用土地资源指标项及其算法[J]. 地理研究, 2010,29(7):1223-1232.
	[ Xu Yong, Tang Qing, Fan Jie , et al. Available land index items and their calculational methods for major function oriented regionalization. Geographical Research, 2010,29(7):1223-1232. ]
[8]	樊杰, 周成虎, 顾行发 , 等. 汶川地震灾后恢复重建: 资源环境承载能力评价 [M]. 北京: 科学出版社, 2009: 3-10.
	[ Fan Jie, Zhou Chenghu, Gu Xingfa , et al. Post-disaster reconstruction planning in Wenchuan: Evaluation of resource and environmental carrying capacity. Beijing, China: Science Press, 2009: 3-10. ]
[9]	樊杰 . 玉树地震灾后恢复重建: 资源环境承载能力评价 [M]. 北京: 科学出版社, 2010: 5-11.
	[ Fan Jie. Post-disaster reconstruction planning in Yushu: Evaluation of resource and environmental carrying capacity. Beijing, China: Science Press, 2010: 5-11. ]
[10]	国务院. 国民经济和社会发展第十一个五年规划纲要 [EB/OL]. 国务院公报, 2006- 03- 14 [2020-01-03]. http://www.gov.cn/gongbao/content/2006/content_268766.htm.
	[The State Council. Outline of the 11th five-year plan for national economic and social development. State Council Bulletin, 2006-03-14 [2020-01-03].http://www.gov.cn/gongbao/content/2006/content_268766.htm. ]
[11]	国务院. 国民经济和社会发展第十二个五年规划纲要 [EB/OL]. 人大公报, 2011- 08- 16 [2020-01-03]. http://www.npc.gov.cn/wxzl/gongbao/2011-08/16/content_1665636.htm.
	[The State Council. Outline of the 12th five-year plan for national economic and social development. The National People's Congress Communique, 2011-08-16 [2020-01-03]. http://www.npc.gov.cn/wxzl/gongbao/2011-08/16/content_1665636.htm. ]
[12]	中共中央办公厅. 中共中央关于全面深化改革若干重大问题的决定 [EB/OL]. 新华网, 2013- 11- 15 [2020-01-03]. http://www.xinhuanet.com/politics/2013-11/15/c_118164294.htm.
	[General Office of the CPC Central Committee. Decision of the CPC Central Committee on some major issues concerning comprehensively deepening the reform. Xinhuanet, 2013-11-15 [2020-01-03].http://www.xinhuanet.com/politics/2013-11/15/c_118164294.htm. ]
[13]	中共中央办公厅. 中共中央关于制定国民经济和社会发展第十三个五年规划的建议 [EB/OL]. 新华网, 2015- 11- 03 [2020-01-03]. http://www.xinhuanet.com/politics/2015-11/03/c_1117027676.htm.
	[General Office of the CPC Central Committee. Proposal of CPC Central Committee on formulating the 13th five-year plan for national economic and social development. Xinhuanet, 2015-11-03 [2020-01-03].http://www.xinhuanet.com/politics/2015-11/03/c_1117027676.htm. ]
[14]	中共中央办公厅, 国务院办公厅. 省级空间规划试点方案 [EB/OL]. 新华网, 2017- 01- 09 [2020-01-03]. http://www.xinhuanet.com/politics/2017-01/09/c_1120275320.htm.
	[General Office of the CPC Central Committee, General office of the State Council. Pilot scheme of provincial spatial planning. Xinhuanet, 2017-01-09 [2020-01-03]. http://www.xinhuanet.com/politics/2017-01/09/c_1120275320.htm. ]
[15]	中共中央办公厅, 国务院办公厅. 中共中央, 国务院关于建立国土空间规划体系并监督实施的若干意见 [EB/OL]. 新华网, 2019- 05- 23 [2020-01-03]. http://www.xinhuanet.com/politics/2019-05/23/c_1124534206.htm.
	[General Office of the CPC Central Committee, General office of the State Council. Opinions of the CPC Central Committee and the State Council on the establishment of territorial spatial planning system and supervising its implementation. Xinhuanet, 2019-05-23 [2020-01-03]. http://www.xinhuanet.com/politics/2019-05/23/c_1124534206.htm. ]
[16]	徐勇, 赵燊, 段健 . 国土空间规划的土地利用分类方案研究[J]. 地理研究, 2019,38(10):2388-2401.
	[ Xu Yong, Zhao Shen, Duan Jian . Studies on the land use classification scheme for territory spatial planning. Geographical Research, 2019,38(10):2388-2401. ]
[17]	张凤荣, 郭力娜, 关小克 , 等. 生态安全观下耕地后备资源评价指标体系探讨[J]. 中国土地科学, 2009,23(9):4-8, 14.
	[ Zhang Fengrong, Guo Lina, Guan Xiaoke , et al. Study on the evaluation indicators of the arable land from the view of ecological security. China Land Science, 2009,23(9):4-8, 14. ]
[18]	易玲, 张增祥, 汪潇 , 等. 近30年中国主要耕地后备资源的时空变化[J]. 农业工程学报, 2013,29(6):1-12.
	[ Yi Ling, Zhang Zengxiang, Wang Xiao , et al. Spatial-temporal change of major reserve resources of cultivated land in China in recent 30 years. Transactions of the CSAE, 2013,29(6):1-12. ]
[19]	安祥生, 徐勇, 汤青 . 山西省适垦耕地及其空间分异特征[J]. 中国土地科学, 2010,24(1):37-42, 49.
	[ An Xiangsheng, Xu Yong, Tang Qing . Cultivable farmland in Shanxi Province and its spatial differentiation characteristics. China Land Science, 2010,24(1):37-42, 49. ]
[20]	李晓东, 塔西甫拉提·特依拜, 范卓斌, 等. 基于适宜性和安全性评价的干旱区绿洲后备耕地资源开发: 以渭干河—库车河三角洲为例[J]. 地理研究, 2016,35(1):163-172.
	[ Li Xiaodong, Tashpolat Tiyip, Fan Zhuobin , et al. The reserve cultivated land resources in arid oasis based on suitability assessment and development security: Taking the delta oasis of Weigan and Kuqa Rivers as an example. Geographical Research, 2016,35(1):163-172. ]
[21]	任君临, 方斌, 许实 . 长江中下游地区耕地后备资源空间分布及影响因素研究[J]. 中国土地科学, 2016,30(5):71-79.
	[ Ren Junlin, Fang Bin, Xu Shi . Study on spatial distribution and impact factors of reserved cultivated land resources in the Middle and Lower Reaches of Yangtze River. China Land Science, 2016,30(5):71-79. ]
[22]	金贵, 王占岐, 胡学东 , 等. 基于模糊证据权模型的青藏高原区土地适宜性评价[J]. 农业工程学报, 2013,29(18):241-250.
	[ Jin Gui, Wang Zhanqi, Hu Xuedong , et al. Land suitability evaluation in Qinghai-Tibet Plateau based on fuzzy weight of evidence model. Transactions of the CSAE, 2013,29(18):241-250. ]
[23]	Reshmidevi T V, Eldho T I, Jana R . A GIS-integrated fuzzy rule-based inference system for land suitability evaluation in agricultural watersheds[J]. Agricultural Systems, 2009,101(1-2):101-109.
[24]	Yu J, Chen Y, Wu J P , et al. Cellular automata-based spatial multi-criteria land suitability simulation for irrigated agriculture[J]. International Journal of Geographical Information Science, 2011,25(1):131-148.
[25]	Feizizadeh B, Blaschke T . Land suitability analysis for Tabriz County, Iran: A multi-criteria evaluation approach using GIS[J]. Journal of Environmental Planning and Management, 2013,56(1):1-23.
[26]	Xu Y, Tang Q, Fan J , et al. Assessing construction land potential and its spatial pattern in China[J]. Landscape and Urban Planning, 2011,103(2):207-216.
[27]	汤青, 徐勇, 董晓辉 , 等. 芦山地震灾后重建地区土地资源安全评价[J]. 地理学报, 2015,70(4):650-663.
	[ Tang Qing, Xu Yong, Dong Xiaohui , et al. Appraisal of land resources security in the post-earthquake reconstruction area of Lushan earthquake. Acta Geographica Sinica, 2015,70(4):650-663. ]
[28]	党丽娟, 徐勇, 汤青 , 等. 广西西江沿岸后备适宜建设用地潜力及空间分布[J]. 自然资源学报, 2014,29(3):387-397.
	[ Dang Lijuan, Xu Yong, Tang Qing , et al. Potential and spatial distribution of suitable construction land along the Xijiang Riverside in Guangxi. Journal of Natural Resources, 2014,29(3):387-397. ]
[29]	徐小任, 徐勇 . 长江经济带后备适宜建设用地潜力[J]. 长江流域资源与环境, 2016,25(12):1789-1796.
	[ Xu Xiaoren, Xu Yong . Potential of available construction land in the Yangtze River Economic Belt. Resources and Environment in the Yangtze Basin, 2016,25(12):1789-1796. ]
[30]	王亚飞, 樊杰, 周侃 . 基于”双评价”集成的国土空间地域功能优化分区[J]. 地理研究, 2019,38(10):2415-2429.
	[ Wang Yafei, Fan Jie, Zhou Kan . Territorial function optimization regionalization based on the integration of 'Double Evaluation'. Geographical Research, 2019,38(10):2415-2429. ]
[31]	徐勇, 杨波, 刘国彬 , 等. 黄土高原作物产量及水土流失地形分异模拟[J]. 地理学报, 2008,63(11):1218-1226.
	[ Xu Yong, Yang Bo, Liu Guobin , et al. Topographic differentiation simulation of crop yield and soil and water loss on the Loess Plateau. Acta Geographica Sinica, 2008,63(11):1218-1226. ]

乡镇名称	适宜建设用地		已有建设用地/km²	基本农田/km²	后备适宜建设用地
乡镇名称	面积/km²	占乡镇土地面积比重/%	已有建设用地/km²	基本农田/km²	面积/km²	占适宜建设用地比重/%	占乡镇土地面积比重/%
城关乡	21.0	89.9	14.8	5.9	0.2	1.0	0.9
洪山镇	16.4	60.9	3.4	8.3	3.9	23.8	14.5
连福镇	49.6	54.7	10.3	28.5	8.9	17.9	9.8
龙凤镇	32.7	57.7	6.4	19.8	4.7	14.4	8.3
绵山林场	0	0	0	0	0	0	0
绵山镇	68.2	65.7	13.4	40.1	10.9	16.0	10.5
三佳乡	17.3	90.2	6.0	10.7	0.3	1.7	1.6
宋古乡	34.1	86.0	9.8	23.0	0.2	0.6	0.5
义安镇	73.3	85.3	21.2	49.7	0.8	1.1	0.9
义棠镇	38.9	50.3	8.9	20.6	8.6	22.0	11.1
张兰镇	75.7	75.9	13.8	50.6	6.8	9.0	6.8
介休市	427.2	57.6	108.0	257.2	45.3	10.6	6.1

乡镇名称	后备适宜建设用地面积/km²	适宜类后备适宜建设用地		较适宜类后备适宜建设用地		条件适宜类后备适宜建设用地		人均后备适宜建设用地面积/(亩/人)
乡镇名称	后备适宜建设用地面积/km²	面积/km²	比重/%	面积/km²	比重/%	面积/km²	比重/%	人均后备适宜建设用地面积/(亩/人)
城关乡	0.2	0.02	10.0	0.1	50.0	0.08	40.0	0.002
洪山镇	3.9	0.3	7.7	1.4	35.9	2.2	56.4	0.53
连福镇	8.9	0.5	5.6	2.5	28.1	5.9	66.3	0.44
龙凤镇	4.7	0.3	6.4	1.7	36.2	2.7	57.4	0.53
绵山林场	0	0	0	0	0	0	0	0
绵山镇	10.9	1.0	9.2	4.3	39.4	5.6	51.4	0.53
三佳乡	0.3	0.04	13.3	0.18	60.0	0.08	26.7	0.02
宋古乡	0.2	0.04	20.0	0.12	60.0	0.04	20.0	0.01
义安镇	0.8	0.2	25.0	0.5	62.5	0.1	12.5	0.02
义棠镇	8.6	0.6	7.0	2.9	33.7	5.1	59.3	0.39
张兰镇	6.8	0.6	8.8	2.4	35.3	3.8	55.9	0.22
合计	45.3	3.6	7.9	16.1	35.5	25.6	56.6	0.16

乡镇名称	后备适宜耕地面积/km²	适宜类后备适宜耕地		较适宜类后备适宜耕地		条件适宜类后备适宜耕地		人均后备适宜耕地面积/(亩/人)
乡镇名称	后备适宜耕地面积/km²	面积/km²	比重/%	面积/km²	比重/%	面积/km²	比重/%	人均后备适宜耕地面积/(亩/人)
城关乡	0.3	0.18	60.0	0.1	33.3	0.02	6.7	0.003
洪山镇	5.9	1.7	28.8	2.2	37.3	2.0	33.9	0.81
连福镇	16.9	3.2	18.9	6.0	35.5	7.7	45.6	0.82
龙凤镇	7.8	2.1	26.9	2.7	34.6	3.0	38.5	0.86
绵山林场	0	0	0	0	0	0	0	0
绵山镇	15.1	5.5	36.4	5.7	37.7	3.9	25.8	0.74
三佳乡	0.6	0.47	78.3	0.1	16.7	0.03	5.0	0.05
宋古乡	1.0	0.74	74.0	0.24	24.0	0.02	2.0	0.05
义安镇	1.2	1.0	83.3	0.2	15.8	0.01	0.8	0.03
义棠镇	14.1	3.6	25.5	5.1	36.2	5.4	38.3	0.65
张兰镇	11.2	3.2	28.6	3.8	33.9	4.2	37.5	0.37
合计	74.1	21.7	29.3	26.1	35.3	26.3	35.4	0.26
