黔桂喀斯特山区年NDVI变化的影响因素研究

doi:10.18306/dlkxjz.2019.11.013

地理科学进展 ›› 2019, Vol. 38 ›› Issue (11): 1783-1792.doi: 10.18306/dlkxjz.2019.11.013

黔桂喀斯特山区年NDVI变化的影响因素研究

刘梁美子^1,², 占车生^1,^*(), 胡实¹, 张琦^1,²

^1. 中国科学院地理科学与资源研究所陆地水循环及地表过程重点实验室,北京 100101
^2. 中国科学院大学,北京 100049

收稿日期:2019-01-07 修回日期:2019-04-25 出版日期:2019-11-28 发布日期:2019-11-28
通讯作者: 占车生
作者简介:刘梁美子(1995— ),女,湖北黄冈人,硕士生,主要研究水文与水资源学。E-mail:liuliangmeizi17@mails.ucas.ac.cn
基金资助:
国家重点基础研究发展计划973计划项目(2015CB452701);国家自然科学基金项目(41571019);国家自然科学基金项目(51779009)

Impact factors of annual NDVI change in karst mountain areas of Guizhou and Guangxi Provinces

LIU Liangmeizi^1,², ZHAN Chesheng^1,^*(), HU Shi¹, ZHANG Qi^1,²

^1. Key Laboratory of Water Cycle and Related Land Surface Processes, Institute of Geographic Sciences and Natural Resources Research, CAS, Beijing 100101, China
^2. University of Chinese Academy of Sciences, Beijing 100049, China

Received:2019-01-07 Revised:2019-04-25 Online:2019-11-28 Published:2019-11-28
Contact: ZHAN Chesheng
Supported by:
National Key Basic Research Program of China (973 Program), No(2015CB452701);National Natural Science Foundation of China, No(41571019);National Natural Science Foundation of China, No(51779009)

摘要/Abstract

摘要：

喀斯特山区是中国典型的生态脆弱区,区内的植被极易发生退化,且退化后难以恢复。论文采用逐步多元回归、相关性分析和残差分析等方法,探讨了黔桂喀斯特山区气候变化特征及其NDVI变化的影响因素。结果表明：2002—2015年研究区气候变化呈现暖湿化趋势,但变化并不显著,年降水量和年均温变化分别介于-15.6~25.6 mm/a和-0.08~0.06 ℃/a之间,年均增速分别为7.9 mm/a和0.000 35 ℃/a。过去14 a内,气候变化是影响NDVI变化的关键因素(贡献率约95%),其中降水对植被NDVI的影响大于气温。残差分析表明,近14 a来黔桂喀斯特山区NDVI残差和NDVI残差趋势的均值分别为0.03和0.0007/a,说明人类活动的正效应呈上升趋势。城市化的进程使得大量耕地、林地被建设用地占用,在毕节、安顺、贵阳以及河池、柳州、百色一带,人类活动对植被NDVI变化呈较明显的负效应,但是在六盘水、黔西南自治州、遵义和来宾,由于一系列生态还林工程的实施,人类活动则表现为正向影响。

关键词: 植被变化, 气候因子, 人类活动, 喀斯特山区

Abstract:

The karst mountain areas are typical ecologically fragile regions in China. The vegetation is highly prone to degradation and is difficult to recover after that. In this study, we explored the change trend of climatic factors and distinguished the impact factors of annual NDVI change in karst mountain areas, by using stepwise regression, correlation analysis, and residual analysis. From 2002 to 2015, a warm and humid trend was found in the study area, but not significant at the P=95% level. The average annual changes of precipitation and temperature are in the range of -15.6-25.6 mm/a and -0.08-0.06 ℃/a, with an increasing rate of 7.9 mm/a and 0.00035 ℃/a respectively at the regional scale. During the study period, climate variability was the dominating factor of NDVI changes, which accounted for 95% of the annual variations, and the impact of precipitation on NDVI was slightly greater than that of temperature. The residual analysis of NDVI showed that the mean values of NDVI residual and its trend were 0.03 and 0.0007/a in the last 14 years, indicating that the positive effects of human activities were present. Human activities such as urbanization caused a large amount of cultivated land and forest to be occupied by construction land, thus had obvious negative effects on NDVI changes in Bijie, Anshun, Guiyang, Hechi, Liuzhou, and Baise. However, due to the implementation of ecological rehabilitation and reforestation projects, human activities had positive effects on NDVI changes in Liupanshui, Qianxinan, Zunyi, and Laibin.

Key words: vegetation change, climatic factors, human activities, karst mountain areas

刘梁美子, 占车生, 胡实, 张琦. 黔桂喀斯特山区年NDVI变化的影响因素研究[J]. 地理科学进展, 2019, 38(11): 1783-1792.

LIU Liangmeizi, ZHAN Chesheng, HU Shi, ZHANG Qi. Impact factors of annual NDVI change in karst mountain areas of Guizhou and Guangxi Provinces[J]. PROGRESS IN GEOGRAPHY, 2019, 38(11): 1783-1792.

图/表 6

图1

图2

表1

图3

图4

图5

参考文献 10

11	孙艳玲, 延晓冬, 谢德体 . 2007. 基于因子分析方法的中国植被NDVI与气候关系研究[J]. 山地学报, 25(1):54-63.
	Sun Y L, Yan X D, Xie D T . 2007. Study on the relationship between vegetation and climate in China using factor analysis. Journal of Mountain Science, 25(1):54-63. ]
12	谭剑波, 李爱农, 雷光斌 . 2016. 青藏高原东南缘气象要素Anusplin和Cokriging空间插值对比分析[J]. 高原气象, 35(4):875-886. doi: 10.7522/j.issn.1000-0534.2015.00037
	Tan J B, Li A N, Lei G B . 2016. Contrast on Anusplin and Cokriging meteorological spatial interpolation in southeastern margin of Qinghai-Xizang Plateau. Plateau Meteorology, 35(4):875-886. ] doi: 10.7522/j.issn.1000-0534.2015.00037
13	童晓伟, 王克林, 岳跃民 , 等. 2014. 桂西北喀斯特区域植被变化趋势及其对气候和地形的响应[J]. 生态学报, 34(12):3425-3434. doi: <a href='http://dx.doi.org/10.5846/stxb201310162503'>10.5846/stxb201310162503</a>
	Tong X W, Wang K L, Yue Y M , et al. 2014. Trends in vegetation and their responses to climate and topography in northwest Guangxi. Acta Ecologica Sinica, 34(12):3425-3434. ] doi: <a href='http://dx.doi.org/10.5846/stxb201310162503'>10.5846/stxb201310162503</a>
14	王彦颖 . 2016. 中国东北植被时空动态变化及其对气候响应研究[D]. 长春: 东北师范大学.
	Wang Y Y . 2016. Study on temporal and spatial dynamic change of vegetation and its response to climate in Northeast China. Changchun, China: Northeast Normal University. ]
15	杨雪梅, 杨太保, 刘海猛 , 等. 2016. 气候变暖背景下近30a北半球植被变化研究综述[J]. 干旱区研究, 33(2):379-391.
	Yang X M, Yang T B, Liu H M , et al. 2016. Vegetation variation in the North Hemisphere under climate warming in the last 30 years. Arid Zone Research, 33(2):379-391. ]
16	姚永慧 . 2005. 贵州喀斯特景观格局研究[D]. 北京: 中国科学院研究生院.
	Yao Y H . 2005. Analysis of karst landscape pattern in Guizhou Province. Beijing, China: Graduate University of the Chinese Academy of Sciences. ]
17	于飞, 郑小波, 谷晓平 , 等. 2008. 复杂山地环境下气候要素空间插值精度比较研究[J]. 贵州气象, 32(3):3-6.
	Yu F, Zheng X B, Gu X P , et al. 2008. Comparative study on spatial interpolation of climate elements precision in complex mountainous environment. Journal of Guizhou Meteorology, 32(3):3-6. ]
18	张雪梅, 王克林, 岳跃民 , 等. 2017. 生态工程背景下西南喀斯特植被变化主导因素及其空间非平稳性[J]. 生态学报, 37(12):4008-4018. doi: 10.5846/stxb201611192354
	Zhang X M, Wang K L, Yue Y M , et al. 2017. Factors impacting on vegetation dynamics and spatial non-stationary relationships in karst regions of Southwest China. Acta Ecologica Sinica, 37(12):4008-4018. ] doi: 10.5846/stxb201611192354
19	Archer E R M . 2004. Beyond the "climate versus grazing" impasse: Using remote sensing to investigate the effects of grazing system choice on vegetation cover in the eastern Karoo[J]. Journal of Arid Environments, 57:381-408. doi: 10.1016/S0140-1963(03)00107-1
20	Evans J, Geerken R . 2004. Discrimination between climate and human induced dryland degradation[J]. Journal of Arid Environments, 57(4):535-554. doi: 10.1016/S0140-1963(03)00121-6
21	Herrmann S M, Anyamba A, Tucker C J . 2017. Recent trends in vegetation dynamics in the African Sahel and their relationship to climate[J]. Global Environmental Change, 15(4):394-404. doi: 10.1016/j.gloenvcha.2005.08.004
22	Hou W J, Gao J B, Wu S H , et al. 2015. Interannual variations in growing-season NDVI and its correlation with climate variables in the southwestern karst region of China[J]. Remote Sensing, 7(9):11105-11124. doi: 10.3390/rs70911105
23	Hutchinson M F, Xu T B . 2013. Anusplin version 4.4 user guide [M/OL]. 2013- 08- 23[2018-11-13]. .
24	Ichii K, Kawabata A, Yamaguchi Y . 2002. Global correlation analysis for NDVI and climatic variables and NDVI trends: 1982-1990[J]. International Journal of Remote Sensing, 23(18):3873-3878. doi: 10.1080/01431160110119416
25	IPCC. 2013. Climate change 2013: The physical science basis, contribution of working group I to the fifth assessment report of the intergovernmental panel on climate change [M]. Cambridge, United Kingdom and New York, USA: Cambridge University Press.
26	Liu R, Xiao L L, Liu Z , et al. 2018. Quantifying the relative impacts of climate and human activities on vegetation changes at the regional scale[J]. Ecological Indicators, 93:91-99. doi: 10.1016/j.ecolind.2018.04.047
27	Liu Y X, Wang Y L, Du Y Y , et al. 2016. The application of polynomial analyses to detect global vegetation dynamics during 1982-2012[J]. International Journal of Remote Sensing, 37(7):1568-1584. doi: 10.1080/01431161.2016.1142688
28	Philippon N, Mougin E, Jarlan L , et al. 2005. Analysis of the linkages between rainfall and land surface conditions in the West African monsoon through CMAP, ERS-WSC, and NOAA-AVHRR data[J]. Journal of Geophysical Research Atmospheres, 110(D24):1064-1067.
29	Tian Y C, Bai X Y, Wang S J , et al. 2017. Spatial-temporal changes of vegetation cover in Guizhou Province, Southern China[J]. Chinese Geographical Science, 27(1):25-38. doi: 10.1007/s11769-017-0844-3
30	Tong X W, Wang K L, Yue Y M , et al. 2017. Quantifying the effectiveness of ecological restoration projects on long-term vegetation dynamics in the karst regions of Southwest China[J]. International Journal of Applied Earth Observation and Geoinformation, 54:105-113. doi: 10.1016/j.jag.2016.09.013
31	Wang J, Wang K L, Zhang M Y , et al. 2015. Impacts of climate change and human activities on vegetation cover in hilly Southern China[J]. Ecological Engineering, 81:451-461. doi: 10.1016/j.ecoleng.2015.04.022
32	Yin G, Hu Z Y, Chen X , et al. 2016. Vegetation dynamics and its response to climate change in Central Asia[J]. Journal of Arid Land, 8(3):375-388. doi: 10.1007/s40333-016-0043-6
33	Zhang Y, Zhang C B, Wang Z Q , et al. 2016. Vegetation dynamics and its driving forces from climate change and human activities in the Three-River Source region, China from 1982 to 2012[J]. Science of the Total Environment, 563- 564:210-220. doi: 10.1016/j.scitotenv.2016.03.223 pmid: 27135584
1	杜加强, 贾尔恒·阿哈提, 赵晨曦 , 等. 2016. 三江源区近30年植被生长动态变化特征分析[J]. 草业学报, 25(1):1-12. doi: 10.11686/cyxb2015111
	Du J Q, Ahati J, Zhao C X , et al. 2016. Analysis of vegetation dynamics using GIMMS NDVI3g in the Three-Rivers Headwater region from 1982 to 2012. Acta Prataculturae Sinica, 25(1):1-12. ] doi: 10.11686/cyxb2015111
2	郭敏杰 . 2014. 基于NDVI的黄土高原地区植被覆盖度对气候变化响应及定量分析[D]. 北京: 中国科学院大学.
	Guo M J . 2014. Responses of vegetation coverage to climate change on the Loess Plateau based on AVHRR/NDVI and its quantitative analysis. Beijing, China: University of Chinese Academy of Sciences. ]
3	侯美亭, 赵海燕, 王筝 , 等. 2013. 基于卫星遥感的植被NDVI对气候变化响应的研究进展[J]. 气候与环境研究, 18(3):353-364.
	Hou M T, Zhao H Y, Wang Z , et al. 2013. Vegetation responses to climate change by using the satellite-derived normalized difference vegetation index: A review. Climatic and Environmental Research, 18(3):353-364. ]
4	李昊, 蔡运龙, 陈睿山 , 等. 2011. 基于植被遥感的西南喀斯特退耕还林工程效果评价: 以贵州省毕节地区为例[J]. 生态学报, 31(12):3255-3264.
	Li H, Cai Y L, Chen R S , et al. 2011. Effect assessment of the Project of Grain for Green in the karst region in Southwestern China: A case study of Bijie prefecture. Acta Ecologica Sinica, 31(12):3255-3264. ]
5	李辉霞, 刘国华, 傅伯杰 . 2011. 基于NDVI 的三江源地区植被生长对气候变化和人类活动的响应研究[J]. 生态学报, 31(19):5495-5504.
	Li H X, Liu G H, Fu B J . 2011. Response of vegetation to climate change and human activity based on NDVI in the Three-River Headwaters region. Acta Ecologica Sinica, 31(19):5495-5504. ]
6	刘梁美子, 占车生, 胡实 , 等. 2018. 黔桂喀斯特山区植被变化及其地形效应分析[J]. 地理研究, 37(12):2433-2446.
	Liu L M Z, Zhan C S, Hu S , et al. 2018. Analysis of the vegetation changes and its topographic effects in the karst mountainous area of Guizhou and Guangxi. Geographical Research, 37(12):2433-2446. ]
7	刘志红 , Li Lingtao, McVicar R, 等. 2008. 专用气候数据空间插值软件ANUSPLIN及其应用[J]. 气象, 34(2):92-100.
	Liu Z H, Li L T, McVicar R , et al. 2008. Introduction of the professional interpolation software for meteorology data: ANUSPLINN. Meteorological Monthly, 34(2):92-100. ]
8	蒙吉军, 王钧 . 2007. 20世纪80年代以来西南喀斯特地区植被变化对气候变化的响应[J]. 地理研究, 26(5):857-865.
	Meng J J, Wang J . 2007. The response of vegetation dynamics to climate change in the southwestern karst region of China since the early 1980s. Geographical Research, 26(5):857-865. ]
9	马明国, 王建, 王雪梅 . 2006. 基于遥感的植被年际变化及其与气候关系研究进展[J]. 遥感学报, 10(3):421-431. doi: 10.11834/jrs.20060363
	Ma M G, Wang J, Wang X M . 2006. Advance in the inter-annual variability of vegetation and its relation to climate based on remote sensing. Journal of Remote Sensing, 10(3):421-431. ] doi: 10.11834/jrs.20060363
10	孙建国, 王涛, 颜长珍 . 2012. 气候变化和人类活动在榆林市荒漠化过程中的相对作用[J]. 中国沙漠, 32(3):625-630.
	Sun J G, Wang T, Yan C Z . 2012. The relative roles of climate change and human activities in desertification process: A case study in Yulin, Shaanxi Province, China. Journal of Desert Research, 32(3):625-630. ]

模型	变量	系数大小	系数显著性水平	R²	标准估计的误差
1	P (降水)	-0.599	<0.01	0.359	0.84
1	常数项	2.852×10^-11	<0.05	0.359	0.84
2	P (降水)	-0.953	<0.01	0.611	0.67
	T (温度)	0.615	<0.01
	常数项	4.54×10^-11	<0.05
