基于手机定位数据的深圳市热浪人口暴露度分析

doi:10.18306/dlkxjz.2020.02.005

地理科学进展 ›› 2020, Vol. 39 ›› Issue (2): 231-242.doi: 10.18306/dlkxjz.2020.02.005

基于手机定位数据的深圳市热浪人口暴露度分析

谢铖¹, 黄波^2,^3,^4,^*(), 刘晓倩¹, 周涛¹, 王宇¹

^1. 西南交通大学地球科学与环境工程学院,成都 611756
^2. 香港中文大学地理与资源管理学系,香港 999077
^3. 香港中文大学太空与地球信息科学研究所,香港 999077
^4. 香港中文大学深圳研究院,广东深圳 518057

收稿日期:2019-02-18 修回日期:2019-05-14 出版日期:2020-02-28 发布日期:2020-04-28
作者简介:谢铖(1993— ),男,硕士生,研究方向为城市热环境与地理大数据分析。E-mail:gis2013@163.com
基金资助:
国家科技支撑计划项目(2013BAJ05B04);自然资源部城市国土资源监测与仿真重点实验室开放基金资助课题(KF-2015-01-011)

Population exposure to heatwaves in Shenzhen based on mobile phone location data

XIE Cheng¹, HUANG Bo^2,^3,^4,^*(), LIU Xiaoqian¹, ZHOU Tao¹, WANG Yu¹

^1. Faculty of Geosciences and Environmental Engineering, Southwest Jiaotong University, Chengdu 611756, China
^2. Department of Geography and Resource Management, The Chinese University of Hong Kong, Hong Kong 999077, China
^3. Institute of Space and Earth Information Science, The Chinese University of Hong Kong, Hong Kong 999077, China
^4. Shenzhen Research Institute, The Chinese University of Hong Kong, Shenzhen 518057, Guangdong, China

Received:2019-02-18 Revised:2019-05-14 Online:2020-02-28 Published:2020-04-28
Supported by:
National Key Technology Research and Development Program of the Ministry of Science and Technology of China(2013BAJ05B04);The Project Supported by the Open Fund of Key Laboratory of Urban Land Resources Monitoring and Simulation, MNR(KF-2015-01-011)

摘要/Abstract

摘要：

热浪作为城市化特征灾害之一,严重影响着城市居民的生命健康。目前针对热浪的研究主要聚焦基于静态数据的时空模式、风险管理和脆弱性评价分析方向,对动态人口暴露度的研究尚少。论文基于手机定位数据,首先融合深圳市逐时人口与气温时空分布模型,揭示热浪动态人口暴露度水平;其次,构建基于7类城市兴趣点(point of interest,POI)与不同时段人口分布的地理加权回归模型,初步分析了热浪环境下POI对人群行为模式的影响机制。结果显示：① 相比于基准时段(2018年7月28日12:00~18:00),2018年7月26日至8月1日热浪平均辐射范围在7月29日以8.66倍速增长,至7月30日则以18.93倍速跃至峰值,覆盖区域整体呈现西部高于东部、南部低于北部的特征;② 人口在不同时段均表现为明显的带状聚集分布态势,且人口暴露度与气温和人口的动态演变紧密关联,其暴露度同热浪扩散幅度相似,总体呈2.29倍等比增长,辐射范围包括南山区、福田区、罗湖区等城市商业、工业、住宅中心人口密集区域;③ 同类POI在不同时刻、不同POI在相同时刻对人群减少热浪暴露的移动交互行为具有明显的时空驱动机制差异及选择偏好特征。在持续性城市化背景下,该研究方法可为同类的城市灾害人口暴露度分析提供一定的科学参考。

关键词: 手机定位数据, 热浪, 人口暴露度, POI, 地理加权回归, 深圳市

Abstract:

As one of the characteristic disasters of urbanization, heatwaves seriously affect the life and health of urban residents. Existing research on heatwaves mainly focuses on the spatial and temporal pattern based on static data, risk management, and vulnerability assessment, and studies on dynamic population exposure are relatively few. This study first integrated spatial and temporal distribution models of population and temperature hourly in Shenzhen to reveal the dynamic population exposure to heatwaves based on mobile phone location data. Then a set of geographically weighted regression models in different time were built based on seven types of points of interest (POIs) and population distribution to explore the influencing mechanisms of POIs on crowd behavior patterns during the heatwaves. The results show that: 1) Compared with the baseline (12:00 to 18:00 on 28 July 2018), the average radiation range of the heatwaves increases by 8.66 times on 29 July, and jumped to the peak of 18.93 times on 30 July from 26 July to 1 August 2018. The overall coverage shows that temperature in the west was higher than the east and temperature in the south was lower than the north. 2) Population distribution exhibited an obvious zonal distribution of aggregates in different time periods, and population exposure was closely related to the dynamic evolution of temperature and population. The population exposure was similar to that of heatwaves, showing 2.29 times proportional growth. The coverage included densely populated urban commercial, industrial, and residential centers such as Nanshan District, Futian District, and Luohu District. 3) The same type of POIs at different times and the different types of POIs at the same time showed obvious spatial-temporal differences as driving mechanisms and selection preferences in the interactive mobility behavior of reducing population exposure. Under the background of sustainable urbanization, this research can provide a scientific reference for the analysis of population exposure to similar urban hazards and disasters.

Key words: mobile phone location data, heatwaves, population exposure, POI, geographically weighted regression, Shenzhen

谢铖, 黄波, 刘晓倩, 周涛, 王宇. 基于手机定位数据的深圳市热浪人口暴露度分析[J]. 地理科学进展, 2020, 39(2): 231-242.

XIE Cheng, HUANG Bo, LIU Xiaoqian, ZHOU Tao, WANG Yu. Population exposure to heatwaves in Shenzhen based on mobile phone location data[J]. PROGRESS IN GEOGRAPHY, 2020, 39(2): 231-242.

图/表 13

图1

表1

表3

图2

表4

图3

图4

图5

图6

表5

图7

图8

参考文献 37

[1]	IPCC. Climate change 2014: Synbook report. Contribution of working groups I, II and III to the fifth asessment report of the Intergovernmental Panel on Climate Change[M]. Geneva, Switzerland, 2014.
[2]	Meehl G A, Tebaldi C . More intense, more frequent, and longer lasting heat waves in the 21st Century[J]. Science, 2004,35:994-997.
[3]	Lin L J, Ge E, Liu X P , et al. Urbanization effects on heat waves in Fujian Province, Southeast China[J]. Atmo- spheric Research, 2018,210:123-132.
[4]	金星星, 祁新华, 陆玉麒 , 等. 福建省高温热浪风险评估与空间分异研究[J]. 地球信息科学学报, 2018,20(12):1820-1829.
	[ Jin Xingxing, Qi Xinhua, Lu Yuqi , et al. Evaluation and spatial differentiation of heat waves risk of Fujian Province. Journal of Geo-information Science, 2018,20(12):1820-1829. ]
[5]	聂羽, 韩振宇, 韩荣青 , 等. 中国夏季热浪持续天数的年际变化及环流异常分析[J]. 气象, 2018,44(2):294-303.
	[ Nie Yu, Han Zhenyu, Han Rongqing , et al. Interannual variation of heat wave frequency persistence over China and the associated atmospheric circulation anomaly. Meteorological Monthly, 2018,44(2):294-303. ]
[6]	Stillman J H . Heat waves, the new normal: Summertime temperature extremes will impact animals, ecosystems, and human communities[J]. Physiology, 2019,34(2):86-100.
[7]	谢盼, 王仰麟, 彭建 , 等. 基于居民健康的城市高温热浪灾害脆弱性评价: 研究进展与框架[J]. 地理科学进展, 2015,34(2):165-174.
	[ Xie Pan, Wang Yanglin, Peng Jian , et al. Health related urban heat wave vulnerability assessment: Research progress and framework. Progress in Geography, 2015,34(2):165-174. ]
[8]	周洋, 祝善友, 华俊玮 , 等. 南京市高温热浪时空分布研究[J]. 地球信息科学学报, 2018,20(11):1613-1621.
	[ Zhou Yang, Zhu Shanyou, Hua Junwei , et al. Spatio-temporal distribution of high temperature heat wave in Nanjing. Journal of Geo-information Science, 2018,20(11):1613-1621. ]
[9]	Founda D, Santamouris M . Synergies between urban heat island and heat waves in Athens (Greece), during an extremely hot summer (2012)[J]. Scientific Reports, 2017,27(1):10973. doi: 10.1038/s41598-017-11407-6.
[10]	Zhao L, Oppenheimer M, Zhu Q , et al. Interactions between urban heat islands and heat waves[J]. Environm- ental Research Letters, 2018,13(3):034003. doi: 10.1088/1748-9326/aa9f73.
[11]	李双双, 延军平, 杨赛霓 , 等. 1960—2016 年秦岭—淮河地区热浪时空变化特征及其影响因素[J]. 地理科学进展, 2018,37(4):504-514.
	[ Li Shuangshuang, Yan Junping, Yang Saini , et al. Spatiotemporal variability of heat waves and influencing factors in the Qinling-Huaihe region, 1960-2016. Progress in Geography, 2018,37(4):504-514. ]
[12]	Savic S, Markovic V, Seceov I , et al. Heat wave risk assessment and mapping in urban areas: Case study for a midsized Central European city, Novi Sad (Serbia)[J]. Natural Hazards, 2018,91(3):891-911.
[13]	Lemonsu A, Viguié V, Daniel M , et al. Vulnerability to heat waves: Impact of urban expansion scenarios on u- rban heat island and heat stress in Paris (France)[J]. Urban Climate, 2015,14(4):586-605.
[14]	谢盼, 王仰麟, 刘焱序 , 等. 基于社会脆弱性的中国高温灾害人群健康风险评价[J]. 地理学报, 2015,70(7):1041-1051.
	[ Xie Pan, Wang Yanglin, Liu Yanxu , et al. Incorporating social vulnerability to assess population health risk due to heat stress in China. Acta Geographica Sinica, 2015,70(7):1041-1051. ]
[15]	税伟, 陈志淳, 邓捷铭 , 等. 耦合适应力的福州市高温脆弱性评估[J]. 地理学报, 2017,72(5):830-849.
	[ Shui Wei, Chen Zhichun, Deng Jieming , et al. Evaluation of urban high temperature vulnerability of coupling adaptability in Fuzhou, China. Acta Geographica Sinica, 2017,72(5):830-849. ]
[16]	Jones B, O'Neill B C, McDaniel L, et al. Future population exposure to US heat extremes[J]. Nature Climate Change, 2015,5(7):652-655.
[17]	黄大鹏, 张蕾, 高歌 . 未来情景下中国高温的人口暴露度变化及影响因素研究[J]. 地理学报, 2016,71(7):1189-1200.
	[ Huang Dapeng, Zhang Lei, Gao Ge . Changes in population exposure to high temperature under a future scenario in China and its influencing factors. Acta Geographica Sinica, 2016,71(7):1189-1200. ]
[18]	张蕾, 黄大鹏, 杨冰韵 . RCP4.5情景下中国人口对高温暴露度预估研究[J]. 地理研究, 2016,35(12):2238-2248.
	[ Zhang Lei, Huang Dapeng, Yang Bingyun . Future population exposure to high temperature in China under RCP4.5 scenario. Acta Geographica Sinica, 2016,35(12):2238-2248. ]
[19]	金星星, 祁新华, 程煜 , 等. 流动人口对高温热浪影响的感知与适应: 以福州市为例[J]. 福建师范大学学报(自然科学版), 2016,32(4):111-117.
	[ Jin Xingxing, Qi Xinhua, Chen Yu , et al. The perception and adaptation of floating population to heat waves: A case study in Fuzhou. Journal of Fujian Normal University (Natural Science Edition), 2016,32(4):111-117. ]
[20]	彭朝琼, 余淑苑, 廖玉学 , 等. 深圳市2014年居民热浪期间适应性行为调查[J]. 中国公共卫生, 2017,33(5):802-805.
	[ Peng Chaoqiong, Yu Shuyuan, Liao Yuxue , et al. Adaptive behaviors during heat waves among residents of Shenzhen City, 2014. Chinese Journal of Public Health, 2017,33(5):802-805.]
[21]	Ma W J, Zeng W L, Zhou M G , et al. The short-term effect of heat waves on mortality and its modifiers in China: An analysis from 66 communities[J]. Environment International, 2015,75:103-109.
[22]	Arbuthnott K G, Hajat S . The health effects of hotter summers and heat waves in the population of the Unit- ed Kingdom: A review of the evidence[J]. Environmental Health, 2017,16(S1):119. doi: 10.1186/s12940-017-0322-5.
[23]	IPCC. Climate change 2014: Impacts, adaptation, and vulnerability. Part A: Global and sectoral aspects. Contribution of working group II to the fifth assessment report of the Intergovernmental Panel on Climate Change [M]. Cambridge,UK and New York, USA: Cambridge University Press, 2014.
[24]	陈倩, 丁明军, 杨续超 , 等. 长江三角洲地区高温热浪人群健康风险评价[J]. 地球信息科学学报, 2017,19(11):1475-1484.
	[ Chen Qian, Ding Mingjun, Yang Xuchao , et al. Spatially explicit assessment of heat health risks using multi-source data: A case study of the Yangtze River Delta Region, China. Journal of Geo-information Science, 2017,19(11):1475-1484. ]
[25]	同丽嘎, 李雪铭, 斯琴 , 等. 高温热浪暴露风险评价: 以内蒙古包头市为例[J]. 干旱区地理, 2017,40(2):284-292.
	[ Tong Liga, Li Xueming, Si Qin , et al. Risk assessment of population exposure to heat wave: A case of Baotou City, Inner Mongolia, China. Arid Land Geography, 2017,40(2):284-292. ]
[26]	陈丽娜, 吴升, 陈洁 , 等. 基于手机定位数据的城市人口分布近实时预测[J]. 地球信息科学学报, 2018,20(4):523-531.
	[ Chen Lina, Wu Sheng, Chen Jie , et al. The near-real-time prediction of urban population distributions based on mobile phone location data. Journal of Geo-information Science, 2018,20(4):523-531. ]
[27]	田俊荣, 刘泰山, 白之羽, 等. 鹏城展翅再高飞(壮阔东方潮, 奋进新时代: 庆祝改革开放40年) [N/OL]. 人民日报, 2018- 05- 21(1). .
	[ Tian Junrong, Liu Taishan, Bai Zhiyu , et al. Pengcheng spread wings and flew high again (Expanding the oriental tide, striving for the new era: Celebrating 40 years of reform and opening-up). People's Daily, 2018- 05- 21(1). .]
[28]	俞文政, 刘海涛 . 近35年深圳市气候变化与城市化发展的关联性[J]. 华南师范大学学报(自然科学版), 2018,50(1):85-91.
	[ Yu Wenzheng, Liu Haitao . Correlation between urbanization and climate change of Shenzhen in nearly 35 years. Journal of South China Normal University (Natural Science Edition), 2018,50(1):85-91. ]
[29]	百度地图, 中国城市规划设计研究院. 2018年Q3中国城市活力研究报告 [R/OL]. 百度地图慧眼. . 2018-11-08.
	[ Baidu Map, China Academy of Urban Planning & Design. China urban vitality research report, 2018Q3. Baidu Map Huiyan. . 2018-11-08.]
[30]	百度地图, 中国城市规划设计研究院. 2018年第四季度&年度中国城市活力研究报告 [R/OL]. 百度地图慧眼. . 2019-01-25.
	[ Baidu Map, China Academy of Urban Planning & Design. China urban vitality research report, 2018. Baidu Map Huiyan. . 2019-01-25.]
[31]	林珲, 张鸿生, 林殷怡 , 等. 基于城市不透水面-人口关联的粤港澳大湾区人口密度时空分异规律与特征[J]. 地理科学进展, 2018,37(12):1644-1652.
	[ Lin Hui, Zhang Hongsheng, Lin Yinyi , et al. Spatio-temporal changes of gridded urban population in the Guangdong-Hong Kong-Macao Greater Bay Area based on impervious surface-population correlation. Progress in Geography, 2018,37(12):1644-1652. ]
[32]	中国气象局. 高温科普五: 什么是高温热浪 [R]. 北京: 中国气象报社, 2011.
	[ China Meteorological Administration. High temperature science five: What is high temperature heat wave. Beijing, China: China Meteorological News, 2011. ]
[33]	Cai J X, Huang B, Song Y M . Using multi-source geospatial big data to identify the structure of polycentric cities[J]. Remote Sensing of Environment, 2017,202:210-221.
[34]	Chen B, Song Y M, Jiang T T , et al. Real-time estimation of population exposure to PM_2.5 using mobile and station-based big data[J]. International Journal of Enviromental Research and Public Health, 2018,15(4):573. doi: 10.3390/ijerph15040573.
[35]	杨喜平, 方志祥, 赵志远 , 等. 城市人群聚集消散时空模式探索分析: 以深圳市为例[J]. 地球信息科学学报, 2016,18(4):486-492.
	[ Yang Xiping, Fang Zhixiang, Zhao Zhiyuan , et al. Exploring urban human spatio-temporal convergence-dispersion patterns: A case study of Shenzhen City. Journal of Geo-information Science, 2016,18(4):486-492. ]
[36]	张子民, 周英, 李琦 , 等. 城市局域动态人口估算方法与模拟应用[J]. 地球信息科学学报, 2010,12(4):503-509.
	[ Zhang Zimin, Zhou Ying, Li Qi , et al. An estimation method of dynamic population within an urban local area. Journal of Geo-information Science, 2010,12(4):503-509. ]
[37]	吴健生, 李博, 黄秀兰 . 小城市居民出行行为时空动态及驱动机制研究[J]. 地球信息科学学报, 2017,19(2):176-184.
	[ Wu Jiansheng, Li Bo, Huang Xiulan . Spatio-temporal dynamics and driving mechanisms of resident trip in small cities. Journal of Geo-information Science, 2017,19(2):176-184. ]

编号	发布时间	取消时间	预警类型	发布区域是否覆盖全境陆地
1	2018-07-11T05:20	2018-07-12T18:00	高温	是
2	2018-07-16T17:00	2018-07-18T06:10	台风	否
3	2018-07-17T12:25	2018-07-17T20:00	高温	是
4	2018-07-21T07:45	2018-07-22T15:55	高温	是
5	2018-07-22T17:00	2018-07-24T11:00	台风	是
6	2018-07-28T11:45	2018-08-03T17:45	高温	是
7	2018-08-06T09:05	2018-08-09T19:30	高温	是
8	2018-08-09T17:00	2018-08-15T17:00	台风	是
9	2018-08-25T09:00	2018-08-26T15:30	高温	是
10	2018-09-11T11:00	2018-09-13T06:30	台风	否
11	2018-09-14T12:30	2018-09-17T14:10	台风	是
12	2018-09-14T09:10	2018-09-15T20:00	高温	是

解释变量	相关性		多重共线性
解释变量	相关系数	相关性强弱	膨胀系数(VIF)	共线性强弱
交通设施	0.710	强	8.49	较强
购物场所	0.780	强	6.66	无
科教文化	0.702	强	7.35	无
餐饮	0.810	极强	19.87	较强
商务住宅	0.781	强	5.70	无
医疗保健	0.772	强	13.22	较强
生活服务	0.801	极强	32.65	较强
风景名胜	0.268	弱	1.32	无
酒店住宿	0.578	较强	2.24	无
金融服务	0.585	较强	3.49	无
公司企业	0.746	强	3.52	无

日期	12:00	13:00	14:00	15:00	16:00	17:00	18:00
2018-07-26	0	0	2.94	0	0	0	0
2018-07-27	0	0	0	0	0	0	0
2018-07-28	0	0	1.00	10.88	4.10	14.70	0.45
2018-07-29	0	0	52.62	86.52	86.52	74.14	1.00
2018-07-30	83.42	100	99.76	100	91.90	91.95	53.70
2018-07-31	0	0	2.72	0	0	0	0
2018-08-01	0	0	0	0	0	0	0

日期	12:00	13:00	14:00	15:00	16:00	17:00	18:00
2018-07-26	0	0	1.47	0	0	0	0
2018-07-27	0	0	0	0	0	0	0
2018-07-28	0	0	1.54	15.00	5.61	20.31	1.47
2018-07-29	0	0	45.12	93.26	93.17	70.69	1.16
2018-07-30	77.43	100.00	99.80	100.00	97.72	97.55	64.33
2018-07-31	0	0	2.43	0	0	0	0
2018-08-01	0	0	0	0	0	0	0
