中国沿海集装箱港口航运网络空间联系及区域差异

doi:10.18306/dlkxjz.2018.11.006

摘要/Abstract

摘要：

沿海港口是“一带一路”海陆双向通道的交汇点,航运网络则是港口融入海上丝绸之路的载体,其空间联系及一体化水平是港口整体竞争力的重要指标。利用复杂网络模型对2005年与2015年航运网络联系进行定量刻画和空间分析,探讨近10年来中国集装箱港口航运网络的空间联系和区域差异,结果表明：① 中国集装箱港口航运网络具有较高的集聚系数与较小的平均路径长度,整体服从小世界模型。各港口间的网络可达性与中转衔接功能差异性较小,各地的区域性枢纽港较为稳定。② 基于社会网络分析(UCINET)呈现的最强联系航运网络看,三个相对独立的区域性网络演变为全国性的轴—辐空间网络,航运网络的一体化程度显著提升。③ 从区域差异来看,四大区域港口间的联系强度增强,台湾地区各港口的最强联系区域由珠三角变为长三角,其网络可达性及中转衔接功能有所提升,并形成以高雄港为区域性枢纽的区域性网络。整个台湾地区港口与大陆其他区域的联系强度上升79.46%,而香港港虽保持了与深圳港的最强联系,但与大陆港口的整体联系强度却下降了22.99%,从全国性枢纽港弱化为珠三角区域性枢纽港。

关键词: 中国沿海集装箱港口, 复杂网络, 轴—辐结构, 加权网络, 区域差异

Abstract:

Coastal ports are the intersections between the Belt and Road sea and land routes and the shipping network is the carrier for the ports' integration into the Maritime Silk Road, therefore their spatial connection and integration level are important indicators of the overall competitiveness of the ports. Using a complex network model to quantitatively depict and analyze the shipping network connection in 2005 and 2015, this article discusses the spatial and regional differences of container ports of China in the past 10 years. The results show that: (1) The container port shipping network of China had a bigger clustering coefficient and a smaller average path length and the whole network follows the small-world model. Differences between network accessibility and transfer function of the ports are relatively smaller, and regional hub ports are more stable. (2) Based on the strongest connection of shipping network from social network analysis (UCINET), from a national perspective three relatively independent regional networks have evolved into an integrative hub-spoke spatial network. From a regional perspective, although a few ports have the strongest connection with non-local hub ports, four regional ports still form relatively complete networks. (3) From the perspective of regional differences, the vertex strength of the connections among the four regional ports has increased, the network accessibility and transfer function of ports in Taiwan have improved, and their strongest connection area changed from the Pearl River Delta to the Yangtze River Delta. It also forms a regional network with Kaohsiung Port as a regional hub. The vertex strength between all ports in Taiwan and ports in China's mainland has increased by 79.46%. The vertex strength between the Hong Kong Port and all ports in China's mainland has decreased by 22.99%. The Hong Kong Port has declined from the national hub port to the Pearl River Delta regional hub port.

Key words: coastal container ports of China, complex network, hub-spoke, weighted network, regional difference

郭建科, 何瑶, 侯雅洁. 中国沿海集装箱港口航运网络空间联系及区域差异[J]. 地理科学进展, 2018, 37(11): 1499-1509.

Jianke GUO, Yao HE, Yajie HOU. Spatial connection and regional difference of the coastal container port shipping network of China[J]. PROGRESS IN GEOGRAPHY, 2018, 37(11): 1499-1509.

图/表 8

图1

图2

图3

表1

表2

图4

表3

图5

参考文献 34

[1]	曹有挥. 1999. 集装箱港口体系的演化模式研究: 长江下游集装箱港口体系的实证[J]. 地理科学, 19(6): 485-490.
	[Cao Y H.1999. On the evolution model of the container port system: A case study of the lower Changjiang River container port system[J]. Scientia Geographica Sinica, 19(6): 485-490.]
[2]	曹有挥, 李海建, 陈雯. 2004. 中国集装箱港口体系的空间结构与竞争格局[J]. 地理学报, 59(6): 1020-1027. doi: 10.3321/j.issn:0375-5444.2004.06.026
	[Cao Y H, Li H J, Chen W.2004. The spatial structure and the competition pattern of the container port system of China[J]. Acta Geographica Sinica, 59(6): 1020-1027.] doi: 10.3321/j.issn:0375-5444.2004.06.026
[3]	陈艳华, 韦素琼, 陈松林. 2017. 大陆台资跨界生产网络的空间组织模式及其复杂性研究: 基于大陆台商千大企业数据[J]. 地理科学, 37(10): 1517-1526.
	[Chen Y H, Wei S Q, Chen S L.2017. The spatial organization pattern and its complexity characteristics of cross-border production networks of Taiwan-funded enterprises in mainland China: Based on top 1000 Taiwan-funded enterprises in mainland China[J]. Scientia Geographica Sinica, 37(10): 1517-1526.]
[4]	范斐, 刘承良, 游小珺, 等. 2015. 全球港口间集装箱运输贸易网络的时空分异[J]. 经济地理, 35(6): 109-115. doi: 10.15957/j.cnki.jjdl.2015.06.015
	[Fan F, Liu C L, You X J, et al.2015. The spatial-temporal differentiation and of global trade of container transportation network between ports[J]. Economic Geography, 35(6): 109-115.] doi: 10.15957/j.cnki.jjdl.2015.06.015
[5]	韩增林, 安筱鹏. 2001. 东北集装箱运输网络的建设与优化探讨[J]. 地理科学, 21(4): 308-314. doi: 10.3969/j.issn.1000-0690.2001.04.004
	[Han Z L, An X P.2001. Research on the construction and optimization of container transportation network in Northeast China[J]. Scientia Geographica Sinica, 21(4): 308-314.] doi: 10.3969/j.issn.1000-0690.2001.04.004
[6]	焦敬娟, 王姣娥. 2014. 海航航空网络空间复杂性及演化研究[J]. 地理研究, 33(5): 926-936. doi: 10.11821/dlyj201405011
	[Jiao J J, Wang J E.2014.Spatial structure and evolution of Hainan Airlines network: An analysis of complex network[J]. Geographical Research, 33(5): 926-936.] doi: 10.11821/dlyj201405011
[7]	莫辉辉, 王姣娥. 2012.复杂交通网络[M]. 经济管理出版社..
	[Mo H H, Wang J E.2012.Complex transport network[M]. Beijing, China: Economic Management Press.]
[8]	莫辉辉, 王姣娥, 金凤君. 2008. 交通运输网络的复杂性研究[J]. 地理科学进展, 27(6): 112-120. doi: 10.11820/dlkxjz.2008.06.016
	[Mo H H, Wang J E, Jin F J.2008. Complexity perspectives on transportation network[J]. Progress in Geography, 27(6): 112-120.] doi: 10.11820/dlkxjz.2008.06.016
[9]	潘竟虎, 戴维丽. 2017. 基于网络分析的城市影响区和城市群空间范围识别[J]. 地理科学进展, 36(6): 667-676. doi: 10.18306/dlkxjz.2017.06.002
	[Pan J H, Dai W L.2017. Identification of urban hinterlands and urban agglomerations in China based on network analysis[J]. Progress in Geography, 36(6): 667-676.]. doi: 10.18306/dlkxjz.2017.06.002
[10]	任义科, 宋连成, 佘瑞芳, 等. 2017. 属性和网络结构双重视角下农民工流动规律研究[J]. 地理科学进展, 36(8): 940-951. doi: 10.18306/dlkxjz.2017.08.003
	[Ren Y K, Song L C, She R F, et al.2017. Migrant workers' migration patterns from the dual perspectives of attributes and network structures[J]. Progress in Geography, 36(8): 940-951.] doi: 10.18306/dlkxjz.2017.08.003
[11]	王成金, 金凤君. 2006. 中国海上集装箱运输的组织网络研究[J]. 地理科学, 26(4): 392-401.
	[Wang C J, Jin F J.2006. Organization networks of Chinese marine container transportation[J]. Scientia Geographica Sinica, 26(4): 392-401.]
[12]	王列辉, 洪彦. 2016. 直航背景下海峡两岸集装箱港口体系空间结构: 基于复杂网络的视角[J]. 地理学报, 71(4): 605-620. doi: 10.11821/dlxb201604006
	[Wang L H, Hong Y.2016. Spatial structure of container port systems across the Taiwan straits under the direct shipping policy: A complex network system approach[J]. Acta Geographica Sinica, 71(4): 605-620.] doi: 10.11821/dlxb201604006
[13]	谢燮. 2010. 我国港口空间格局演化的成因及趋势分析[J]. 中国水运, (2): 8-9.
	[Xie X.2010. The causes and trend of evolution of the spatial pattern of Chinese ports[J]. China Water Transport, (2): 8-9.]
[14]	杨静蕾, 罗梅丰, 吴晓璠. 2012. 美国集装箱港口体系演进过程研究[J]. 经济地理, 32(2): 94-100.
	[Yang J L, Luo M F, Wu X P.2012. Research on the evolution process of U.S. container port system[J]. Economic Geography, 32(2): 94-100.]
[15]	张兰霞, 秦勇, 王莉. 2016. 高速铁路加权复杂网络特性分析[J]. 铁道科学与工程学报, 13(2): 201-209.
	[Zhang L X, Qin Y, Wang L.2016. Statistical analysis of weighted complex network in Chinese high-speed railway[J]. Journal of Railway Science and Engineering, 13(2): 201-209.]
[16]	Barke M.1986. Transport and trade: Conceptual frameworks in geography[M]. Edinburgh, UK: Oliver and Boyd.
[17]	Deng W B, Long G, Wei L, Xu C.2009.Worldwide marine transportation network: Efficiency and container throughput[J]. Chinese Physics Letters, 26(11): 118-901.
[18]	Ducruet C, Notteboom T.2012. The Worldwide maritime network of container shipping: Spatial structure and regional dynamics[J]. Global Network, 12(3): 395-423. doi: 10.1111/j.1471-0374.2011.00355.x
[19]	Frémont A, Soppé M.2007. Northern European range: Shipping line concentration andport hierarchy//Wang J, Olivier D, Notteboom T, et al. Ports, cities and global supplychains. Alderschot, England:Ashgate: 105-120.
[20]	Guo J, Wang S, Wang D, et al.2017. Spatial structural pattern and vulnerability of China-Japan-Korea shipping network[J]. Chinese Geographical Science, 27(5): 697-708. doi: 10.1007/s11769-017-0903-9
[21]	Hayuth Y.1981. Containerization and the load center concept[J]. Economic Geography, 57: 160-176. doi: 10.2307/144140
[22]	Hayuth Y.1988. Rationalization and concentration of the U.S. container port system[J]. Professional Geographer, 40(3): 279-288. doi: 10.1111/j.0033-0124.1988.00279.x
[23]	Kaluza P, Kölzsch A, Gastner M T, Blasius B.2010. The complex network of global cargo ship movements[J]. Journal of the Royal Society Interface, 7(48): 1093-1103. doi: 10.1098/rsif.2009.0495 pmid: 2880080
[24]	Le Y, Ieda H.2009. Evolution dynamics of container port systems with a Geo-Economic concentration index: A comparison of Japan, China and Korea[J]. Proceedings of the Eastern Asia Society for Transportation Studies, (1): 46-61.
[25]	Lee S W. Song D W, Ducruet C.2008. A tale of Asia's world ports: the spatial evolution in global hub port cities[J]. Geoforum, 39(1): 372-395. doi: 10.1016/j.geoforum.2007.07.010
[26]	Mayer H M.1978. Current trends in Great Lakes shipping[J]. Geojournal, 2(2): 117-122.
[27]	Monios J, Wilmsmeier G.2013. The role of intermodal transport in port regionalisation[J]. Transport Policy, 30: 161-172. doi: 10.1016/j.tranpol.2013.09.010
[28]	Monios J, Wilmsmeier G.2016, Between path dependency and contingency: New challenges for the geography of port system evolution[J]. Journal of Transport Geography, 51: 247-251. doi: 10.1016/j.jtrangeo.2016.01.008
[29]	Notteboom T E.1997. Concentration and load centre development in the European container port system[J]. Journal of Transport Geography, 5(2): 99-115. doi: 10.1016/S0966-6923(96)00072-5
[30]	Notteboom T E, Rodrigue J-P.2005. Port regionalization: Towards a new phase in port development[J]. Maritime Policy and Management, 32(3): 297-313 doi: 10.1080/03088830500139885
[31]	Rimmer P J.1967. The search for spatial regularities in the development of Australian seaports 1861-1961/2[J]. Geograkiska Annaler, 49: 42-54. doi: 10.1007/978-1-349-15506-4_5
[32]	Taaffe E J, Morrill R L, Gould P R.1963. Transport expansion in underdeveloped countries: A comparative analysis[J]. Geographical Review, 53(4): 503-529. doi: 10.2307/212383
[33]	Van Klink H A.1998. The port network as a new stage in port development: The case of Rotterdam[J]. Environment and Planning A, 30(1): 143-160. doi: 10.1068/a300143
[34]	Wang C, Ducruet C.2012. New port development and global city making: Emergence of the Shanghai-Yangshan multi-layered gateway hub[J]. Journal of Transport Geography,25: 58-69. doi: 10.1016/j.jtrangeo.2012.07.008

排序	2005年			2015年
排序	介数中心性	邻近中心性	度中心性	介数中心性	邻近中心性	度中心性
1	上海	上海	上海	上海	上海	上海
2	深圳	深圳	深圳	深圳	深圳	宁波
3	天津	香港	香港	广州	宁波	深圳
4	青岛	青岛	宁波	天津	香港	香港
5	烟台	宁波	青岛	厦门	青岛	厦门
6	广州	天津	天津	香港	高雄	青岛
7	香港	大连	大连	大连	厦门	高雄
8	大连	厦门	厦门	高雄	天津	天津
9	厦门	广州	广州	青岛	大连	大连
10	基隆	高雄	高雄	宁波	广州	广州

类别	2005年		2015年
类别	港口	数量	港口	数量
第一类	香港、青岛、上海、宁波、深圳	5	上海、宁波、深圳	3
第二类	高雄、大连、天津、厦门、广州	5	大连、天津、青岛、厦门、广州、香港、高雄	7
第三类	基隆、台中、日照、连云港、南通等	28	台中、台北、福州、烟台、连云港等	37

年份		港口个数	介数中心性	邻近中心性	度中心性
2005	环渤海	11	0.0320	3.9080	2.8082
	长三角	11	0.0225	3.9114	2.9998
	珠三角	5	0.0620	4.2296	5.9336
	台湾地区	3	0.0092	4.4518	1.9114
2015	环渤海	11	0.0144	3.1980	0.9841
	长三角	14	0.0261	3.0574	1.2734
	珠三角	10	0.0358	3.0821	1.3626
	台湾地区	5	0.0104	4.2186	1.3856
