资源环境承载能力预警城市化地区专项评价——以京津冀地区为例

doi:10.18306/dlkxjz.2017.003.012

摘要/Abstract

摘要：

资源环境承载能力预警评价中,除基础评价外,还需针对城市化地区存在的特殊问题开展专项评价。但现有相关研究大多较为复杂、难以操作,且较少考虑目前中国城市化地区之间存在的发展水平差异,难以满足实际应用需求。本文根据近年来中国城市化地区资源环境凸显的主要问题,从城市人居环境入手,选取城市黑臭水体和PM2.5超标天数2个要素设计城市水气环境黑灰指数,作为城市化地区专项评价的主要指标;同时考虑到优化开发区域和重点开发区域的主体功能导向差异,以京津冀城市化地区为例开展试评价分析,结果显示：京津冀城市化地区的104个区县中,47个区县为重警,46个中警,仅11个为轻警,整体形势不容乐观。其中,重警区县主要集中在京广高铁沿线,与地区主要交通线路分布及钢铁工业聚集格局一致;轻警区县主要分布在北部的张承地区及东部沿海,工业相对较少,且地理位置有利于污染物迅速扩散。城市化地区专项评价作为基础评价的补充,能更清晰地反映现阶段影响城市人居环境的主要制约因子以及不同发展水平地区间的差异,评价结果可为城市化地区开展国土空间规划、城镇发展战略研究和产业结构调整等提供科学依据。

关键词: 资源环境承载能力, 预警评价, 城市化地区, 城市水气环境黑灰指数, 评价阈值, 京津冀地区

Abstract:

Due to the serious resource and environmental problems in urbanized areas, it is necessary to carry out a specific evaluation on their typical problems in the early-warning of the resource and environmental carrying capacity. However, most of the existing studies are too complicated to operationalize for practical use, and they lack consideration of the differences among development stages. According to the resource and environmental problems highlighted in the urbanized areas in recent years, we adopted an urban black-gray index of water and air environment as the specific indicator to reflect the comfort degree of habitat environment in urbanized areas at the present stage. Meanwhile, the key thresholds of urban black-odor water bodies and PM2.5 pollution days were determined in line with the major functions of the optimized and prioritized zones. Based on the above method, this article presented an empirical analysis on the urbanized area in the Beijing-Tianjin-Hebei region. Trial evaluation shows that, in the Beijing-Tianjin-Hebei urbanized areas, 47 districts or counties were in the severe warning category, 46 were in the moderate warning category, and only 11 were in the mild warning category. The severe-warning districts or counties were mainly concentrated along the Beijing-Guangzhou high-speed railway, and the distribution pattern was consistent with the regional distribution of major traffic lines and steel manufacture aggregation. The mild-warning districts and counties were mainly distributed in the northern Zhangjiakou-Chengde area and the eastern coastal areas, where the industries were relatively few and the geographic location was conducive to the rapid spread of pollutants. In summary, as an indispensable supplement to basic evaluation of resource and environmental carrying capacity for early-warning, the specific evaluation for urbanized areas can reflect the main constraints of these areas more clearly, and determine the early-warning status of different functional zones in different development stages objectively. The evaluation provides a scientific basis for urban spatial planning, urban development strategy research, and industrial structure adjustment in urbanized areas

Key words: resource and environmental carrying capacity, early-warning evaluation, urbanized area, urban black-gray index of water and air environment, evaluation thresholds, Beijing-Tianjin-Hebei region

周道静, 王传胜. 资源环境承载能力预警城市化地区专项评价——以京津冀地区为例[J]. 地理科学进展, 2017, 36(3): 359-366.

Daojing ZHOU, Chuansheng WANG. Specific evaluation of resource and environmental carrying capacity of urbanized areas for early-warning: A case study of the Beijing-Tianjin-Hebei region[J]. PROGRESS IN GEOGRAPHY, 2017, 36(3): 359-366.

图/表 8

表1

表2

表3

表4

图1

表5

表6

图2

参考文献 33

[1]	樊杰. 2014. 人地系统可持续过程、格局的前沿探索[J]. 地理学报, 69(8): 1060-1068. doi: 10.11821/dlxb201408003
	[Fan J.2014. Frontier approach of the sustainable process and pattern of human-environment system[J]. Acta Geographica Sinica, 69(8): 1060-1068.] doi: 10.11821/dlxb201408003
[2]	樊杰. 2016. 城市地理学进入城市规划领域的学术优势与协同发展[M]//樊杰, 等. 中国人文与经济地理学者的学术探究和社会贡献. 北京: 商务印书馆: 42-87.
	[Fan J.2016. The academic advantages of urban geography and its coordinated development with urban planning[M]//Fan J, et al. How Chinese human geographers influence decision makers & society. Beijing, China: The Commercial Press: 42-87.]
[3]	樊杰, 王亚飞, 汤青, 等. 2015. 全国资源环境承载能力监测预警(2014版)学术思路与总体技术流程[J]. 地理科学, 35(1): 1-10.
	[Fan J, Wang Y F, Tang Q, et al.2015. Academic thought and technical progress of monitoring and early-warning of the national resources and environment carrying capacity (V 2014)[J]. Scientia Geographica Sinica, 35(1): 1-10.]
[4]	方宇翘, 裘祖楠, 张国莹, 等. 1993. 城市河流中黑臭现象的研究[J]. 中国环境科学, 13(4): 256-262.
	[Fang Y Q, Qiu Z N, Zhang G Y, et al.1993. A study on the phenomenon of water blackening and smell in urban river[J]. China Environmental Science, 13(4): 256-262.]
[5]	傅崇辉, 王文军, 汤健, 等. 2014. PM2.5健康风险的空间人口分布研究: 以深圳为例[J]. 中国软科学, (9): 78-91. doi: 10.3969/j.issn.1002-9753.2014.09.008
	[Fu C H, Wang W J, Tang J, et al.2014. Study on demographic spatial distribution of health risks caused by PM2.5: A case from Shenzhen[J]. China Soft Science, (9): 78-91.] doi: 10.3969/j.issn.1002-9753.2014.09.008
[6]	胡鞍钢. 2003. 城市化是今后中国经济发展的主要推动力[J]. 中国人口科学, (6): 5-12. doi: 10.3969/j.issn.1000-7881.2003.06.001
	[Hu A G.2003. Chengshihua shi jinhou Zhongguo jingji fazhan de zhuyao tuidongli[J]. Chinese Journal of Population Science, (6): 5-12.] doi: 10.3969/j.issn.1000-7881.2003.06.001
[7]	李宇军. 2014. 中国城市环境保护面临的挑战及其对策[J]. 云南农业大学学报, 8(5): 104-109. doi: 10.3969/j.issn.1004-390X(s).2014.05.020
	[Li Y J.2014. Urban environmental protection in China: Challenges and countermeasures[J]. Journal of Yunnan Agricultural University, 8(5): 104-109.] doi: 10.3969/j.issn.1004-390X(s).2014.05.020
[8]	刘晓丽, 方创琳. 2008. 城市群资源环境承载力研究进展及展望[J]. 地理科学进展, 27(5): 35-42. doi: 10.11820/dlkxjz.2008.05.005
	[Liu X L, Fang C L.2008. Progress and prospect of study on carrying capacity of resource and environment of city clusters[J]. Progress in Geography, 27(5): 35-42.] doi: 10.11820/dlkxjz.2008.05.005
[9]	陆大道, 樊杰. 2012. 区域可持续发展研究的兴起与作用[J]. 中国科学院院刊, 27(3): 290-300, 319.
	[Lu D D, Fan J.2012. The rise and effects of regional sustainable development studies in China[J]. Bulletin of Chinese Academy of Sciences, 27(3): 290-300, 319.]
[10]	吕斌, 孙莉, 谭文垦. 2008. 中原城市群城市承载力评价研究[J]. 中国人口·资源与环境, 18(5): 53-58. doi: 10.3969/j.issn.1003-2363.2008.03.004
	[Lv B, Sun L, Tan W K.2008. Urban carrying capacity evaluation of Zhongyuan City Agglomeration[J]. China Population, Resources and Environment, 18(5): 53-58.] doi: 10.3969/j.issn.1003-2363.2008.03.004
[11]	仇保兴. 2007. 第三次城市化浪潮中的中国范例: 中国快速城市化的特点、问题与对策[J]. 城市规划, 31(6): 9-15. doi: 10.3321/j.issn:1002-1329.2007.06.002
	[Qiu B X.2007. Disanci chengshihua langchao zhong de Zhongguo fanli: Zhongguo kuaisu chengshihua de tedian, wenti yu duice[J]. City Planning Review, 31(6): 9-15.] doi: 10.3321/j.issn:1002-1329.2007.06.002
[12]	夏军, 张永勇, 王中根, 等. 2006. 城市化地区水资源承载力研究[J]. 水利学报, 37(12): 1482-1488. doi: 10.3321/j.issn:0559-9350.2006.12.013
	[Xia J, Zhang Y Y, Wang Z G, et al.2006. Water carrying capacity of urbanized area[J]. Journal of Hydraulic Engineering, 37(12): 1482-1488.] doi: 10.3321/j.issn:0559-9350.2006.12.013
[13]	谢元博, 陈娟, 李巍. 2014. 雾霾重污染期间北京居民对高浓度PM2.5持续暴露的健康风险及其损害价值评估[J]. 环境科学, 35(1): 1-8.
	[Xie Y B, Chen J, Li W.2014. An assessment of PM2.5 related health risks and impaired values of Beijing residents in a consecutive high-level exposure during heavy haze days[J]. Environmental Science, 35(1): 1-8.]
[14]	徐琳瑜, 杨志峰, 李巍. 2005. 城市生态系统承载力理论与评价方法[J]. 生态学报, 25(4): 771-777. doi: 10.3321/j.issn:1000-0933.2005.04.017
	[Xu L Y, Yang Z F, Li W.2005. Theory and evaluation of urban ecosystem carrying capacity[J]. Acta Ecologica Sinica, 25(4): 771-777.] doi: 10.3321/j.issn:1000-0933.2005.04.017
[15]	许学强, 李郇. 2009. 改革开放30年珠江三角洲城镇化的回顾与展望[J]. 经济地理, 29(1): 13-18.
	[Xu X Q, Li X.2009. Review and preview of the urbanization in Pearl River Delta in the past 30 years of reform and opening up[J]. Economic Geography, 29(1): 13-18.]
[16]	杨亮, 吕耀, 郑华玉. 2010. 城市土地承载力研究进展[J]. 地理科学进展, 29(5): 593-600. doi: 10.11820/dlkxjz.2010.05.012
	[Yang L, Lv Y, Zheng H Y.2010. Review on research of urban land carrying capacity[J]. Progress in Geography, 29(5): 593-600.] doi: 10.11820/dlkxjz.2010.05.012
[17]	于玉彬, 黄勇. 2010. 城市河流黑臭原因及机理的研究进展[J]. 环境科技, 23(S2): 111-114. doi: 10.3969/j.issn.1674-4829.2010.z2.037
	[Yu T B, Huang Y.2010. Review of reason and mechanism of black and stink in urban rivers[J]. Environmental Science and Technology, 23(S2): 111-114.] doi: 10.3969/j.issn.1674-4829.2010.z2.037
[18]	周一星, 曹广忠. 1999. 改革开放20年来的中国城市化进程[J]. 城市规划, 23(12): 8-13.
	[Zhou Y X, Cao G Z.1999. The urbanization process in China in the past 20 years[J]. City Planning Review, 23(12): 8-13.]
[19]	Bai X M, Shi P J, Liu Y S.2014. Realizing China's urban dream[J]. Nature, 509: 158-160. doi: 10.1038/509158a
[20]	Chan C K, Yao X H.2008. Air pollution in mega cities in China[J]. Atmospheric Environment, 42(1): 1-42. doi: 10.1016/j.atmosenv.2007.09.003
[21]	Fan J, Wang Y F, Ouyang Z Y, et al.2017. Risk forewarning of regional development sustainability based on a natural resources and environmental carrying index in China[J]. Earth's Future, doi: 10.1002/2016EF000490. doi: 10.1002/2016EF000490
[22]	Fang C L, Liu X L.2010. Comprehensive measurement for carrying capacity of resources and environment of city clusters in central China[J]. Chinese Geographical Science, 20(3): 281-288. doi: 10.1007/s11769-010-0281-z
[23]	Huang S L, Chen C S.1990. A system model to analyse environmental carrying capacity for managing urban growth of the Taipei Metropolitan Region[J]. Journal of Environmental Management, 31(1): 47-60. doi: 10.1016/S0301-4797(05)80014-3
[24]	Li X M.2012. Study on urban environmental carrying capacity based on an inexact fuzzy multiobjective programming model[J]. Advanced Materials Research, 518-523: 1226-1232. doi: 10.4028/www.scientific.net/AMR.518-523.1226
[25]	Liu H M.2012. Comprehensive carrying capacity of the urban agglomeration in the Yangtze River Delta, China[J]. Habitat International, 36(4): 462-470. doi: 10.1016/j.habitatint.2012.05.003
[26]	Liu R Z, Borthwick A G L.2011. Measurement and assessment of carrying capacity of the environment in Ningbo, China[J]. Journal of Environmental Management, 92(8): 2047-2053. doi: 10.1016/j.jenvman.2011.03.033 pmid: 21507560
[27]	Meier R L.1978. Urban carrying capacity and steady state considerations in planning for the Mekong valley region[J]. Urban Ecology, 3(1): 1-27. doi: 10.1016/0304-4009(78)90028-1
[28]	Oh K, Jeong Y, Lee D, et al.2005. Determining development density using the Urban Carrying Capacity Assessment System[J]. Landscape and Urban Planning, 73(1): 1-15. doi: 10.1016/j.landurbplan.2004.06.002
[29]	Tehrani N A, Makhdoum M F.2013. Implementing a spatial model of Urban Carrying Capacity Load Number (UCCLN) to monitor the environmental loads of urban ecosystems: Case study: Tehran metropolis[J]. Ecological Indicators, 32: 197-211. doi: 10.1016/j.ecolind.2013.03.022
[30]	Wei Y G, Huang C, Lam P T I, et al.2015. Using urban-carrying capacity as a benchmark for sustainable urban development: An empirical study of Beijing[J]. Sustainability, 7(3): 3244-3268. doi: 10.3390/su7033244
[31]	Widodo B, Lupyanto R, Sulistiono B, et al.2015. Analysis of environmental carrying capacity for the development of sustainable settlement in Yogyakarta urban area[J]. Procedia Environmental Sciences, 28: 519-527. doi: 10.1016/j.proenv.2015.07.062
[32]	World Health Organization.2006. Air quality guidelines: Global update 2005: Particulate matter, ozone, nitrogen dioxide, and sulfur dioxide[M]. Copenhagen, Denmark: World Health Organization.
[33]	Zheng D F, Zhang Y, Zang Z, et al.2015. Empirical research on carrying capacity of human settlement system in Dalian City, Liaoning Province, China[J]. Chinese Geographical Science, 25(2): 237-249. doi: 10.1007/s11769-014-0732-z

特征指标	轻度黑臭	重度黑臭
透明度/cm	25~10^*	<10^*
溶解氧/(mg/L)	0.2~2.0	<0.2
氧化还原电位/mV	-200~50	<-200
氨氮/(mg/L)	8.0~15	>15

功能区	黑臭水体分布密度/(m/km²)			重度黑臭占比/%
功能区	低度	中度	高度	低度	中度	高度
优化开发区域(旅游城市)	<100	100~500	≥500	<25	25~50	≥50
重点开发区域(其他城市)	<300	300~800	≥800	<33	33~66	≥66

分布密度	低度	中度	高度
低度	较轻	一般	一般
中度	较轻	一般	严重
高度	一般	严重	严重

功能区	低或无风险	中风险	高风险	极高风险
优化开发区域(旅游城市)	<60	60~120	120~210	≥210
其中：核心城市主城区^*	<30	30~90	90~180	≥180
重点开发区域(其他城市)	<120	120~180	180~240	≥240
其中：核心城市主城区^*	<60	60~120	120~180	≥210
