基于精准修复的陕西传统乡村聚落景观基因变异性研究

doi:10.18306/dlkxjz.2020.09.011

地理科学进展 ›› 2020, Vol. 39 ›› Issue (9): 1544-1556.doi: 10.18306/dlkxjz.2020.09.011

基于精准修复的陕西传统乡村聚落景观基因变异性研究

向远林¹(), 曹明明¹^,^*(), 秦进², 吴冲¹

1.西北大学城市与环境学院,西安 710127
2.商洛学院城乡规划与建筑工程学院,陕西商洛 726000

收稿日期:2019-12-02 修回日期:2020-04-03 出版日期:2020-09-28 发布日期:2020-11-28
通讯作者: 曹明明
作者简介:向远林(1987— ),男,博士生,主要从事传统乡村聚落景观基因、乡村聚落保护与规划研究。E-mail: xbdxiangyuanlin@126.com
基金资助:
国家自然科学基金项目(41771539);中国科学院国际合作局对外合作重点项目(131551KYSB20160002);中国科学院战略性先导科技专项(XDA20030301)

Study of traditional rural settlements landscape genetic variability in Shaanxi Province based on accurate-restoration

XIANG Yuanlin¹(), CAO Mingming¹^,^*(), QIN Jin², WU Chong¹

1. College of Urban and Environmental Sciences, Northwest University, Xi'an 710127, China
2. College of Urban, Rural Planning and Architectural Engineering, Shangluo University, Shangluo 726000, Shaanxi, China

Received:2019-12-02 Revised:2020-04-03 Online:2020-09-28 Published:2020-11-28
Contact: CAO Mingming
Supported by:
National Natural Science Foundation of China(41771539);International Partnership Program of Chinese Academy of Sciences(131551KYSB20160002);Strategic Priority Research Program of Chinese Academy of Sciences(XDA20030301)

摘要/Abstract

摘要：

传统乡村聚落景观基因是当前聚落景观的研究热点之一。结合相关研究,论文定义了景观基因信息链,明确了其层次结构,提出了传统乡村聚落景观基因的类生命总体变异机制;在此基础上,结合陕西传统乡村聚落景观特征,进一步构建其景观基因信息链,提出其景观基因总体变异机制及总体变异特征。最后,提出了传统乡村聚落景观基因信息链精准修复的理论框架,并对陕西发生变异的典型聚落进行了精准修复实践,验证了景观基因信息链精准修复的必要性、可操作性。研究旨在为传统乡村聚落保护、活化提供新的、景观基因视角的独特思路与方法。

关键词: 传统乡村聚落, 景观基因信息链, 景观基因变异性, 变异机制, 精准修复, 陕西

Abstract:

Landscape genes of traditional rural settlements are a hotspot of settlements' landscape research. Based on existing research, this study defined the landscape genetic information chain and its hierarchy. The general life-like variation mechanism of landscape genes in traditional rural settlements was also proposed. On these bases, considering the landscape characteristics of traditional rural settlements in Shaanxi Province, the landscape genetic information chains of traditional rural settlements in the province were constructed and the general variation mechanism and characteristics of traditional rural settlements in the province were proposed. A theoretical framework of accurate restoration of the traditional rural settlements' landscape genetic information chain was further put forward. In addition, accurate restoration was applied to the typical settlement with variation in Shaanxi Province as an empirical case. The results verified the necessity and operability of accurate restoration. This research provides some thoughts and methods that are fresh and original for the protection and activation of traditional rural settlements from a landscape genetic perspective.

Key words: traditional rural settlements, landscape genetic information chain, landscape genetic variability, variation mechanism, accurate restoration, Shaanxi Province

向远林, 曹明明, 秦进, 吴冲. 基于精准修复的陕西传统乡村聚落景观基因变异性研究[J]. 地理科学进展, 2020, 39(9): 1544-1556.

XIANG Yuanlin, CAO Mingming, QIN Jin, WU Chong. Study of traditional rural settlements landscape genetic variability in Shaanxi Province based on accurate-restoration[J]. PROGRESS IN GEOGRAPHY, 2020, 39(9): 1544-1556.

图/表 9

表1

图1

图2

图3

表2

图4

表3

陕西传统乡村聚落景观基因总体变异特征"

自然经济区	传统乡村聚落景观基本特征	典型变异聚落	总体变异特征
陕北	窑洞聚落是主体,由于该区域历史上多位于边境,产生了多个军屯聚落;由于封建时代封闭发展的经济,产生了多个延续数代的地主庄园窑洞聚落;革命时期中央的驻扎,又使其产生了多个红色窑洞聚落;窑洞聚落与沟、塬、梁、峁相伴相生,是黄土高原最典型的人文景观	杨家沟村、高杰村、碾畔村、马家湾村等	窑洞聚落大面积闲置、废弃,聚落空心化严重,大量窑洞聚落景观基因信息消失或者破坏,变异类型以景观基因突变和景观结构变异为主,大量窑洞聚落景观基因元、基因链、基因形三层次结构全面破坏
关中	受都城营建思想的影响及为防兵燹、匪患,无险可守的关中平原上形成了大量的防御式古堡;渭北旱塬处于关中盆地向黄土高原过渡地带,呈现出房窑结合的聚落景观特征,地坑院窑洞聚落尤其典型	程家川村、老县城村、双泉村、曹家村等	防御古堡文化和地坑窑文化即将消失,相关景观基因信息流失严重,变异类型以景观基因重组和景观结构变异为主,多个聚落景观基因形、基因链损坏严重
陕南	陕南东部的安康、商洛地区传统乡村聚落受秦、楚文化及湖广移民文化影响,聚落景观亦秦亦楚亦徽,多呈徽派移民聚落景观特征;陕南西部汉中地区则深受巴蜀文化影响,聚落景观多呈秦巴文化融合的特征。陕南传统聚落多选址于山顶、半山腰及沿河沟谷地带,多呈带枝状及团块状发展的形态	双柏村、天宝村、青木川村、前河村等	以徽派天井院民居为代表的移民文化,全面走向现代多层居住小区文化,变异类型以景观结构变异为主,传统乡村聚落景观基因元、基因链、基因形等景观基因信息即将大面积消失

表3

图5

图6

参考文献 43

[1]	汤茂林. 文化景观的内涵及其研究进展[J]. 地理科学进展, 2000,19(1):70-79. doi: 10.11820/dlkxjz.2000.01.011
	[ Tang Maolin. The inventory and progress of cultural landscape study. Progress in Geography, 2000,19(1):70-79. ]
[2]	孙艺惠, 陈田, 王云才. 传统乡村地域文化景观研究进展[J]. 地理科学进展, 2008,27(6):90-96. doi: 10.11820/dlkxjz.2008.06.013
	[ Sun Yihui, Chen Tian, Wang Yuncai. Progress and prospects in research of the traditional rural cultural landscape. Progress in Geography, 2008,27(6):90-96. ]
[3]	刘沛林. 传统村落选址的意象研究[J]. 中国历史地理论丛, 1995(1):119-128.
	[ Liu Peilin. Image study on site selection of traditional villages. Journal of Chinese Historical Geography, 1995(1):119-128. ]
[4]	刘沛林. 中国传统村落意象的构成标志[J]. 衡阳师专学报(社会科学), 1994(4):62-67.
	[ Liu Peilin. The constitutes symbol of Chinese traditional villages image. Journal of Hengyang Normal College (Social Science), 1994(4):62-67. ]
[5]	刘沛林, 董双双. 中国古村落景观的空间意象研究[J]. 地理研究, 1998,17(1):32-39.
	[ Liu Peilin, Dong Shuangshuang. Study of landscape-image of Chinese ancient village. Geographical Research, 1998,17(1):32-39. ]
[6]	刘沛林. 古村落: 独特的人居文化空间[J]. 人文地理, 1998,13(1):34-37.
	[ Liu Peilin. Ancient village: The unique space of human settlement culture. Human Geography, 1998,13(1):34-37. ]
[7]	刘沛林. 论中国历史文化村落的“精神空间”[J]. 北京大学学报(哲学社会科学版), 1996(1):44-48.
	[ Liu Peilin. On "the spiritual space" of China's historical-cultural villages. Journal of Peking University (Philosophy and Social Science), 1996(1):44-48. ]
[8]	刘沛林. 论中国古代的村落规划思想[J]. 自然科学史研究, 1998,17(1):82-90.
	[ Liu Peilin. Research on village planning thoughts of ancient China. Studies in the History of Natural Sciences, 1998,17(1):82-90. ]
[9]	刘沛林. 古村落文化景观的基因表达与景观识别[J]. 衡阳师范学院学报(社会科学), 2003,24(4):1-8.
	[ Liu Peilin. The gene expression and the sight identification of the ancient villages' cultural landscape. Journal of Hengyang Normal University (Social Science), 2003,24(4):1-8. ]
[10]	胡最, 刘沛林, 邓运员, 等. 传统聚落景观基因的识别与提取方法研究[J]. 地理科学, 2015,35(12):1518-1524.
	[ Hu Zui, Liu Peilin, Deng Yunyuan, et al. A novel method for identifying and separating landscape genes from traditional settlements. Scientia Geographica Sinica, 2015,35(12):1518-1524. ]
[11]	胡最, 刘沛林, 申秀英, 等. 传统聚落景观基因信息单元表达机制[J]. 地理与地理信息科学, 2010,26(6):96-101.
	[ Hu Zui, Liu Peilin, Shen Xiuying, et al. Expression mechanism of landscape-gene information unit of traditional settlement. Geography and Geo-information Science, 2010,26(6):96-101. ]
[12]	刘沛林, 刘春腊, 邓运员, 等. 基于景观基因完整性理念的传统聚落保护与开发[J]. 经济地理, 2009,29(10):1731-1736.
	[ Liu Peilin, Liu Chunla, Deng Yunyuan, et al. Study on ancient village's protection and development which based on the concept of landscape-gene's integrity. Economic Geography, 2009,29(10):1731-1736. ]
[13]	刘沛林, 刘春腊, 邓运员, 等. 客家传统聚落景观基因识别及其地学视角的解析[J]. 人文地理, 2009,24(6):40-43.
	[ Liu Peilin, Liu Chunla, Deng Yunyuan, et al. Study on the identification of Hakka traditional village's landscape genes and analysis in the perspective of geography. Human Geography, 2009,24(6):40-43. ]
[14]	刘沛林. 中国传统聚落景观基因图谱的构建与应用研究[D]. 北京: 北京大学, 2011.
	[ Liu Peilin. On construction and utilization of Chinese traditional settlements landscape's genetic map. Beijing, China: Peking University, 2011. ]
[15]	胡最, 刘沛林, 曹帅强. 湖南省传统聚落景观基因的空间特征[J]. 地理学报, 2013,68(2):219-231. doi: 10.11821/xb201302007
	[ Hu Zui, Liu Peilin, Cao Shuaiqiang. Spatial pattern of landscape genes in traditional settlements of Hunan Province. Acta Geographica Sinica, 2013,68(2):219-231. ]
[16]	胡最, 刘沛林. 中国传统聚落景观基因组图谱特征[J]. 地理学报, 2015,70(10):1592-1605. doi: 10.11821/dlxb201510005
	[ Hu Zui, Liu Peilin. The conceptual model and characterizations of landscape genome maps of traditional settlements in China. Acta Geographica Sinica, 2015,70(10):1592-1605. ]
[17]	刘沛林, 刘春腊, 李伯华, 等. 中国少数民族传统聚落景观特征及其基因分析[J]. 地理科学, 2010,30(6):810-817.
	[ Liu Peilin, Liu Chunla, Li Bohua, et al. Characteristic and genes -analysis of traditional settlements' landscapes in Chinese minority areas. Scientia Geographica Sinica, 2010,30(6):810-817. ]
[18]	胡最, 郑文武, 刘沛林, 等. 湖南省传统聚落景观基因组图谱的空间形态与结构特征[J]. 地理学报, 2018,73(2):317-332. doi: 10.11821/dlxb201802008
	[ Hu Zui, Zheng Wenwu, Liu Peilin, et al. The forms and structures of traditional landscape genome maps: A case study of Hunan Province. Acta Geographica Sinica, 2018,73(2):317-332. ]
[19]	申秀英, 刘沛林, 邓运员. 景观“基因图谱”视角的聚落文化景观区系研究[J]. 人文地理, 2006,21(4):109-112.
	[ Shen Xiuying, Liu Peilin, Deng Yunyuan. Seeking the landscape's genes atlas: One kind of new angle of view about settlement's cultural landscape districts research. Human Geography, 2006,21(4):109-112. ]
[20]	申秀英, 刘沛林, 邓运员, 等. 景观基因图谱: 聚落文化景观区系研究的一种新视角[J]. 辽宁大学学报(哲学社会科学版), 2006,34(3):143-148.
	[ Shen Xiuying, Liu Peilin, Deng Yunyuan, et al. Landscape gene atlas: A new angle to study the zoning of settlement culture landscape. Journal of Liaoning University (Philosophy and Social Sciences), 2006,34(3):143-148. ]
[21]	刘沛林, 刘春腊, 邓运员, 等. 中国传统聚落景观区划及景观基因识别要素研究[J]. 地理学报, 2010,65(12):1496-1506. doi: 10.11821/xb201012006
	[ Liu Peilin, Liu Chunla, Deng Yunyuan, et al. Landscape division of traditional settlement and effect elements of landscape gene in China. Acta Geographica Sinica, 2010,65(12):1496-1506. ]
[22]	胡最, 刘春腊, 邓运员, 等. 传统聚落景观基因及其研究进展[J]. 地理科学进展, 2012,31(12):1620-1627. doi: 10.11820/dlkxjz.2012.12.007
	[ Hu Zui, Liu Chunla, Deng Yunyuan, et al. Research progress on traditional settlements landscape's gene. Progress in Geography, 2012,31(12):1620-1627. ]
[23]	王兴中, 李胜超, 李亮, 等. 地域文化基因再现及人本观转基因空间控制理念[J]. 人文地理, 2014,29(6):1-9.
	[ Wang Xingzhong, Li Shengchao, Li Liang, et al. Regional cultural gene repetitions and the conception of humanism transgenosis space control. Human Geography, 2014,29(6):1-9. ]
[24]	翟洲燕, 李同昇, 常芳, 等. 陕西传统村落文化遗产景观基因识别[J]. 地理科学进展, 2017,36(9):1067-1080. doi: 10.18306/dlkxjz.2017.09.003
	[ Zhai Zhouyan, Li Tongsheng, Chang Fang, et al. Genes identification of cultural heritage landscape of Shaanxi traditional villages. Progress in Geography, 2017,36(9):1067-1080. ]
[25]	翟洲燕, 常芳, 李同昇, 等. 陕西省传统村落文化遗产景观基因组图谱研究[J]. 地理与地理信息科学, 2018,34(3):87-94.
	[ Zhai Zhouyan, Chang Fang, Li Tongsheng, et al. Research on the cultural heritage landscape genome maps of traditional villages in Shaanxi Province. Geography and Geo-Information Science, 2018,34(3):87-94. ]
[26]	周烨伟. 甘南藏区传统聚落景观基因图谱研究[D]. 兰州: 兰州理工大学, 2018.
	[ Zhou Yewei. Study on gene atlas of traditional settlement landscape in Gannan Tibetan area. Lanzhou, China: Lanzhou University of Technology, 2018. ]
[27]	秦为径. 凉山彝族地区乡土景观基因及其保护与传承研究[D]. 绵阳: 西南科技大学, 2018.
	[ Qin Weijing. Study on the vernacular landscape genetic elements and the conservation and heritage of Liangshan Yi area. Mianyang, China: Southwest University of Science and Technology, 2018. ]
[28]	惠怡安. 陕北黄土丘陵沟壑区农村聚落发展及其优化研究[D]. 西安: 西北大学, 2010.
	[ Hui Yi'an. Optimization analysis on development of rural settlement in the region of loess hilly and gully in northern area of Shaanxi Province. Xi'an, China: Northwest University, 2010. ]
[29]	祁剑青. 陕西传统民居地理研究[D]. 西安: 陕西师范大学, 2017.
	[ Qi Jianqing. Study on the geography of traditional residence in Shaanxi Province. Xi'an, China: Shaanxi Normal University, 2017. ]
[30]	李红波, 张小林, 吴江国, 等. 苏南地区乡村聚落空间格局及其驱动机制[J]. 地理科学, 2014,34(4):438-446.
	[ Li Hongbo, Zhang Xiaolin, Wu Jiangguo, et al. Spatial pattern and its driving mechanism of rural settlements in southern Jiangsu. Scientia Geographica Sinica, 2014,34(4):438-446. ]
[31]	李伯华, 曾灿, 窦银娣, 等. 基于“三生”空间的传统村落人居环境演变及驱动机制: 以湖南江永县兰溪村为例[J]. 地理科学进展, 2018,37(5):677-687. doi: 10.18306/dlkxjz.2018.05.011
	[ Li Bohua, Zeng Can, Dou Yindi, et al. Change of human settlement environment and driving mechanism in traditional villages based on living-production-ecological space: A case study of Lanxi Village, Jiangyong County, Hunan Province. Progress in Geography, 2018,37(5):677-687. ]
[32]	周明茗, 王成. 乡村生产空间系统要素构成及运行机制研究[J]. 地理科学进展, 2019,38(11):1655-1664. doi: 10.18306/dlkxjz.2019.11.001
	[ Zhou Mingming, Wang Cheng. Elements and operation mechanisms of rural production spatial system. Progress in Geography, 2019,38(11):1655-1664. ]
[33]	于海洋, 罗天. 目标修复体空间中的数量及数量关系在精准美学修复中的应用[J]. 华西口腔医学杂志, 2016,34(3):223-228. doi: 10.7518/hxkq.2016.03.002
	[ Yu Haiyang, Luo Tian. Application of target restoration space quantity and quantitative relation in precise esthetic prosthodontics. West China Journal of Stomatology, 2016,34(3):223-228. ]
[34]	曹明明, 邱海军, 向远林, 等. 陕西地理[M]. 北京: 北京师范大学出版社, 2018: 9-20.
	[ Cao Mingming, Qiu Haijun, Xiang Yuanlin, et al. Shaanxi geography. Beijing, China: Beijing Normal University Press, 2018: 9-20. ]
[35]	陕西省城乡规划设计研究院. 陕西古村落(一): 记忆与乡愁 [M]. 北京: 中国建筑工业出版社, 2015: 188-202.
	[ Shaanxi Provincial Institute of Urban and Rural Planning and Design. Shaanxi ancient villages (I): Memory and nostalgia. Beijing, China: China Architecture and Building Press, 2015: 188-202. ]
[36]	陕西省城乡规划设计研究院. 陕西古村落(二): 记忆与乡愁 [M]. 北京: 中国建筑工业出版社, 2015: 2-53.
	[ Shaanxi Provincial Institute of Urban and Rural Planning and Design. Shaanxi ancient villages (Ⅱ): Memory and nostalgia. Beijing, China: China Architecture and Building Press, 2015: 2-53. ]
[37]	深尾叶子, 井口淳子, 栗原伸治. 黄土高原的村庄: 声音·空间·社会 [M]. 林琦, 译. 北京: 民族出版社, 2007: 21-27.
	[ Fukao Yoko, Iguchi Junko, Kurihara Shinji. Village life in China's Loess Plateau: Sound, space and society. Translated by Lin Qi. Beijing, China: The Ethnic Publishing House, 2007: 21-27. ]
[38]	刘沛林, 刘春腊, 邓运员, 等. 我国古城镇景观基因“胞—链—形”的图示表达与区域差异研究[J]. 人文地理, 2011,26(1):94-99.
	[ Liu Peilin, Liu Chunla, Deng Yunyuan, et al. A study on icon-expression of China's ancient-city landscape genes "cell-chain-shape" and regional differences. Human Geography, 2011,26(1):94-99. ]
[39]	刘沛林. “景观信息链”理论及其在文化旅游地规划中的运用[J]. 经济地理, 2008,28(6):1035-1039.
	[ Liu Peilin. "Landscape information chain" theory and its utilization in planning of cultural tour destinations. Economic Geography, 2008,28(6):1035-1039. ]
[40]	杨晓俊, 方传珊, 王益益. 传统村落景观基因信息链与自动识别模型构建: 以陕西省为例[J]. 地理研究, 2019,38(6):1378-1388. doi: 10.11821/dlyj020181136
	[ Yang Xiaojun, Fang Chuanshan, Wang Yiyi. Construction of gene information chain and automatic identification model of traditional village landscape: Taking Shaanxi Province as an example. Geographical Research, 2019,38(6):1378-1388. ]
[41]	叶广芩. 老县城[M]. 西安: 西安出版社, 2010: 60-88.
	[ Ye Guangqin. The old county. Xi'an, China: Xi'an Press, 2010: 60-88. ]
[42]	赵元歌. 周至县老县城村环境风貌保护与提升研究[D]. 西安: 西安建筑科技大学, 2018.
	[ Zhao Yuange. Research on the environmental features protection and promotion of Laoxiancheng village in Zhouzhi. Xi'an, China: Xi'an University of Architecture and Technology, 2018. ]
[43]	李盛君. 多自然保护区格局下历史村庄保护利用策略研究[D]. 西安: 西安建筑科技大学, 2016.
	[ Li Shengjun. The study of the protection and usage of historical village, under the pattern of multiple nature reserves. Xi'an, China: Xi'an University of Architecture and Technology, 2016. ]

刘沛林等(借鉴生物学概念)^[38]		王兴中等(基于文化生态学)^[23]		本文(综合)
结构层次	定义	结构层次	定义	结构层次	定义
基因胞	景观基因基本单元	基因元	景观基因的最小单位	基因元	传统聚落历史文化景观的基本信息单元(不可再分的信息单元)
基因链	景观连接通道(交通)	基因链	若干基因元的排列组合模式(线性)	基因链	传统聚落历史文化景观的主要信息单元,包括景观的链接通道、主体结构、主要景观节点等(基因元经二次及以上的排列组合形成的景观信息)
基因形	景观整体形态(城墙)	基因形	若干基因链的排列组合模式(面状)	基因形	传统聚落历史文化景观的总体形态和整体格局等抽象信息

类别/结构	基因形	基因链	基因元
景观基因类 (文本描述表达)	建筑特征:关中民居、徽派民居、窑洞聚落等	传统民居特征:天井四合院、关中窄院、窑洞四合院等	屋顶:四水归堂、单坡屋顶、平窑洞顶等
景观基因组图谱类 (图示表达)	蒲城陶池村总体形态图谱	蒲城陶池村空间序列图谱	蒲城陶池村典型院落图谱
