地理科学进展 ›› 2020, Vol. 39 ›› Issue (1): 24-35.doi: 10.18306/dlkxjz.2020.01.003
董晓宇1, 姚华荣1, 戴君虎2,3,*(), 朱梦瑶2,3
收稿日期:
2019-09-23
修回日期:
2019-12-11
出版日期:
2020-01-28
发布日期:
2020-03-28
通讯作者:
戴君虎
作者简介:
董晓宇(1995— ),女,新疆奇台人,硕士生,主要从事物候学研究。E-mail: dongxy@igsnrr.ac.cn
基金资助:
DONG Xiaoyu1, YAO Huarong1, DAI Junhu2,3,*(), ZHU Mengyao2,3
Received:
2019-09-23
Revised:
2019-12-11
Online:
2020-01-28
Published:
2020-03-28
Contact:
DAI Junhu
Supported by:
摘要:
荒漠草原分布于干旱区和半干旱区,对气候变化的响应极为敏感,但目前学术界对于荒漠草原物候与生产力变化的研究仍较为薄弱。有鉴于此,论文采用2000—2017年MODIS NDVI数据和气象数据,利用通用数量化方法提取内蒙古荒漠草原植被的生长季始期(start of season, SOS)和生长季末期(end of season, EOS);基于Carnegie-Ames-Stanford Approach (CASA)模型估算了植被净初级生产力(NPP),并分析了植被物候和净初级生产力之间的关系。研究结果表明:① 2000—2017年内蒙古荒漠草原SOS呈显著提前趋势(0.88 d/a,P<0.05),EOS不显著提前(0.13 d/a,P>0.05),生长季长度(length of season, LOS)呈显著延长趋势(0.76 d/a)。81.53%像元的SOS与2—4月平均气温呈负相关(8.21%显著相关,P<0.05),60.80%像元的SOS与4月降水量呈负相关关系(6.12%显著相关,P<0.05);65.16%像元的EOS与9月平均气温呈负相关(5.03%显著相关,P<0.05),78.61%像元的EOS 与7—9月降水量呈正相关关系(10.12%显著相关,P<0.05)。② 内蒙古荒漠草原多年平均NPP为104.71 gC/(m 2·a),有自东向西逐渐降低的区域差异;在研究时段内,春、夏季和生长季的NPP均呈不显著增加趋势,秋季NPP有不显著减少趋势;生长季降水量增加有利于生长季NPP的积累。③ 春季NPP与SOS呈不显著负相关,秋季NPP与EOS呈显著正相关。LOS的延长促进了NPP的累积,其中生长季NPP与EOS的推迟关系更为密切。研究结果揭示气候变化对内蒙古荒漠草原植被物候和生产力有显著影响,对区域生态系统管理和生态建设具有重要参考意义。
董晓宇, 姚华荣, 戴君虎, 朱梦瑶. 2000—2017年内蒙古荒漠草原植被物候变化及对净初级生产力的影响[J]. 地理科学进展, 2020, 39(1): 24-35.
DONG Xiaoyu, YAO Huarong, DAI Junhu, ZHU Mengyao. Phenological changes of desert steppe vegetation and its effect on net primary productivity in Inner Mongolia from 2000 to 2017[J]. PROGRESS IN GEOGRAPHY, 2020, 39(1): 24-35.
表1
内蒙古荒漠草原区植被物候期与气候因子的偏相关系数"
物候期 | 时间尺度 | 气温 | 降水 | |||||
---|---|---|---|---|---|---|---|---|
r | n/% | n/%(P<0.05) | r | n/% | n/%(P<0.05) | |||
SOS | 4月 | -0.44 | 79.68 | 5.72 | -0.34 | 60.8 | 6.12 | |
3—4月 | -0.38 | 81.27 | 4.56 | -0.23 | 58.37 | 1.97 | ||
2—4月 | -0.47 | 81.53 | 8.21 | -0.28 | 53.45 | 1.55 | ||
EOS | 9月 | -0.14 | 65.16 | 5.03 | 0.05 | 66.13 | 4.88 | |
8—9月 | -0.04 | 61.29 | 3.16 | 0.48 | 81.53 | 8.88 | ||
7—9月 | -0.20 | 61.54 | 3.12 | 0.57 | 78.61 | 10.12 |
[1] | IPCC. Summary for policymakers. Climate change 2013: The physical science basis, contribution of working group i to the fifth assessment report of the intergovernmental panel on climate change [M]. Cambridge, UK: Cambridge University Press, 2013. |
[2] | 《第三次气候变化国家评估报告》编写委员会. 第三次气候变化国家评估报告 [M]. 北京: 科学出版社, 2015. |
[ The Compilation Group of the Third National Assessment Report of Climate Change. Third national assessment report on climate change. Beijing, China: Science Press, 2015. ] | |
[3] | Sparks T H, Menzel A . Observed changes in seasons: An overview[J]. International Journal of Climatology, 2002,22(14):1715-1725. |
[4] | 张湜溪, 戴君虎, 葛全胜 . 植物始花期对气候变化响应的激素调控机理研究进展[J]. 地理科学进展, 2019,38(7):1045-1055. |
[ Zhang Shixi, Dai Junhu, Ge Quansheng . Progress of responses of first flowering date to climate change and the correlations of plant hormone regulation. Progress in Geography, 2019,38(7):1045-1055. ] | |
[5] | Ge Q S, Wang H J, Rutishauser T , et al. Phenological response to climate change in China: A meta-analysis[J]. Global Change Biology, 2015,21(1):265-274. |
[6] | 黄文婕, 葛全胜, 戴君虎 , 等. 贵阳木本植物始花期对温度变化的敏感度[J]. 地理科学进展, 2017,36(8):1015-1024. |
[ Huang Wenjie, Ge Quansheng, Dai Junhu , et al. Sensitivity of first flowering dates to temperature change for typical woody plants in Guiyang City, China. Progress in Geography, 2017,36(8):1015-1024. ] | |
[7] | Piao S L, Fang J Y, Zhou L M , et al. Variations in satellite-derived phenology in China's temperate vegetation[J]. Global Change Biology, 2006,12(4):672-685. |
[8] | 丛楠, 沈妙根 . 1982—2009年基于卫星数据的北半球中高纬地区植被春季物候动态及其与气候的关系[J]. 应用生态学报, 2016,27(9):2737-2746. |
[ Cong Nan, Shen Miaogen . Variation of satellite-based spring vegetation phenology and the relationship with climate in the Northern Hemisphere over 1982 to 2009. Chinese Journal of Applied Ecology, 2016,27(9):2737-2746. ] | |
[9] | 顾润源, 周伟灿, 白美兰 , 等. 气候变化对内蒙古草原典型植物物候的影响[J]. 生态学报, 2012,32(3):767-776. |
[ Gu Runyuan, Zhou Weican, Bai Meilan , et al. Impacts of climate change on phenological phase of herb in the main grassland in Inner Mongolia. Acta Ecologica Sinica, 2012,32(3):767-776. ] | |
[10] | 李夏子, 韩国栋 . 内蒙古东部草原优势牧草生长季对气象因子变化的响应[J]. 生态学杂志, 2013,32(4):987-992. |
[ Li Xiazi, Han Guodong . Response of grass growing season to meteorological change in eastern Inner Mongolia grassland. Chinese Journal of Ecology, 2013,32(4):987-992. ] | |
[11] | Sha Z Y, Zhong J L, Bai Y F , et al. Spatio-temporal patterns of satellite-derived grassland vegetation phenology from 1998 to 2012 in Inner Mongolia, China[J]. Journal of Arid Land, 2016,8(3):462-477. |
[12] | Gong Z, Kawamura K, Ishikawa N , et al. MODIS normalized difference vegetation index (NDVI) and vegetation phenology dynamics in the Inner Mongolia grassland[J]. Solid Earth, 2015,6(4):1185-1194. |
[13] | Myneni R B, Keeling C D, Tucker C J , et al. Increased plant growth in the northern high latitudes from 1981 to 1991[J]. Nature, 1997,386:698-702. |
[14] | Field C B, Behrenfeld M J, Randerson J T , et al. Primary production of the biosphere: Integrating terrestrial and oceanic components[J]. Science, 1998,281:237-240. |
[15] | 焦伟, 陈亚宁, 李稚 . 西北干旱区植被净初级生产力的遥感估算及时空差异原因[J]. 生态学杂志, 2017,36(1):181-189. |
[ Jiao Wei, Chen Yaning, Li Zhi . Remote sensing estimation and the reasons for temporal-spatial differences of vegetation net primary productivity in arid region of Northwest China. Chinese Journal of Ecology, 2017,36(1):181-189. ] | |
[16] | 朴世龙, 方精云, 郭庆华 . 利用CASA模型估算我国植被净第一性生产力[J]. 植物生态学报, 2001,25(5):603-608. |
[ Piao Shilong, Fang Jingyun, Guo Qinghua . Application of CASA model to the estimation of Chinese terrestrial net primary productivity. Acta Phytoecologica Sinica, 2001,25(5):603-608. ] | |
[17] | 穆少杰, 李建龙, 杨红飞 , 等. 内蒙古草地生态系统近10年NPP时空变化及其与气候的关系[J]. 草业学报, 2013,22(3):6-15. |
[ Mu Shaojie, Li Jianlong, Yang Hongfei , et al. Spatio-temporal variation analysis of grassland net primary productivity and its relationship with climate over the past 10 years in Inner Mongolia. Acta Prataculturae Sinica, 2013,22(3):6-15. ] | |
[18] | 朱玉果, 杜灵通, 谢应忠 , 等. 2000—2015年宁夏草地净初级生产力时空特征及其气候响应[J]. 生态学报, 2019,39(2):123-134. |
[ Zhu Yuguo, Du Lingtong, Xie Yingzhong , et al. Spatiotemporal characteristics of grassland net primary production in Ningxia Province from 2000 to 2015 and its response to climate change. Acta Ecologica Sinica, 2019,39(2):123-134. ] | |
[19] | Piao S L, Friedlingstein P, Ciais P , et al. Growing season extension and its impact on terrestrial carbon cycle in the Northern Hemisphere over the past 2 decades[J]. Global Biogeochemical Cycles, 2007,21:1-11. doi: 10.1029/2006GB002888. |
[20] | Richardson A D, Black T A, Ciais P , et al. Influence of spring and autumn phenological transitions on forest ecosystem productivity[J]. Philosophical Transactions of the Royal Society of London, 2010,365:3227-3246. |
[21] | Piao S L, Ciais P, Friedlingstein P , et al. Net carbon dioxide losses of northern ecosystems in response to autumn warming[J]. Nature, 2008,451:49-52. |
[22] | 秦洁, 韩国栋, 乔江 , 等. 内蒙古不同草地类型中羊草地上生物量对放牧强度的响应[J]. 中国草地学报, 2016,38(4):76-82. |
[ Qin Jie, Han Guodong, Qiao Jiang , et al. Response of Leymus chinensis above-ground biomass to grazing intensity in different grasslands of Inner Mongolia. Chinese Journal of Grassland, 2016,38(4):76-82. ] | |
[23] | 刘永信, 郝敦元, 马克健 . 内蒙古草原退化群落恢复演替规律的仿真[J]. 自然资源学报, 2003,18(3):347-352. |
[ Liu Yongxin, Hao Dunyuan, Ma Kejian . The simulation for the restoring succession rule of the degenerated grassland communities in Inner Mongolia. Journal of Natural Resources, 2003,18(3):347-352. ] | |
[24] | 马瑞芳, 李茂松, 马秀枝 . 气候变化对内蒙古草原退化的影响[J]. 内蒙古气象, 2011(2):30-34. |
[ Ma Ruifang, Li Maosong, Ma Xiuzhi . Summarization on the impact of climate change on the degradation of Inner Mongolia grassland. Meteorology Journal of Inner Mongolia, 2011(2):30-34. ] | |
[25] | 中国科学院内蒙古宁夏综合考察队. 内蒙古植被 [M]. 北京: 科学出版社, 1985. |
[ Inner Mongolia and Ningxia Scientific Expedition Group, Chinese Academic of Sciences. Vegetation of Inner Mongolia. Beijing, China: Science Press, 1985. ] | |
[26] | 中国科学院中国植被图编辑委员会. 中华人民共和国植被图(1:1000000) [M]. 北京: 地质出版社, 2007. |
[ The Editorial Committee of Vegetation Map of China, Chinese Academy of Sciences. Vegetation Map of the People's Republic of China (1: 1000000). Beijing, China: Geological Publishing House, 2007. ] | |
[27] | 冉有华, 李新, 卢玲 . 中国地区土地覆盖综合数据集 [DB/OL]. 寒区旱区科学数据中心, 2010. doi: 10.3972/westdc.007.2013.db. |
[ Ran Youhua, Li Xin, Lu Ling . Land cover products of China. Cold and Arid Regions Science Data Center at Lanzhou, 2010. doi: 10.3972/westdc.007.2013.db.] | |
[28] | Liu R G, Liu Y . Generation of new cloud masks from MODIS land surface reflectance products[J]. Remote Sensing of Environment, 2013,133:21-37. |
[29] | Yang K . China meteorological forcing data (1979-2018) [DB]. Big Data System for Pan-Third Pole, 2018. |
[30] | 刘建文, 周玉科 . 站点尺度的青藏高原时序NDVI重构方法比较与应用[J]. 地理科学进展, 2018,37(3):427-437. |
[ Liu Jianwen, Zhou Yuke . Comparison and application of NDVI time-series reconstruction methods at site scale on Tibetan Plateau. Progress in Geography, 2018,37(3):427-437. ] | |
[31] | Jonsson P, Eklundh L . Seasonality extraction by function fitting to time-series of satellite sensor data[J]. IEEE Transactions on Geoscience & Remote Sensing, 2002,40(8):1824-1832. |
[32] | Wang S Y, Zhang B, Yang Q C , et al. Responses of net primary productivity to phenological dynamics in the Tibetan Plateau, China[J]. Agricultural & Forest Meteorology, 2017,232:235-246. |
[33] | 孔冬冬, 张强, 黄文琳 , 等. 1982-2013年青藏高原植被物候变化及气象因素影响[J]. 地理学报, 2017,72(1):39-52. |
[ Kong Dongdong, Zhang Qiang, Huang Wenlin , et al. Vegetation phenology change in Tibetan Plateau from 1982 to 2013 and its related meteorological factors. Acta Geographica Sinica, 2017,72(1):39-52. ] | |
[34] | Potter C S, Randerson J T, Field C B , et al. Terrestrial ecosystem production: A process model based on global satellite and surface data[J]. Global Biogeochemical Cycles, 1993,7(4):811-841. |
[35] | 包刚, 辛晓平, 包玉海 , 等. 内蒙古草原植被最大光能利用率取值优化研究[J]. 光谱学与光谱分析, 2016,36(10):3280-3286. |
[ Bao Gang, Xin Xiaopin, Bao Yuhai , et al. Optimization of maximum light use efficiency in Inner Mongolian steppe. Spectroscopy and Spectral Analysis, 2016,36(10):3280-3286. ] | |
[36] | 朱文泉, 潘耀忠, 龙中华 , 等. 基于GIS和RS的区域陆地植被NPP估算: 以中国内蒙古为例[J]. 遥感学报, 2005,9(3):300-307. |
[ Zhu Wenquan, Pan Yaozhong, Long Zhonghua , et al. Estimating net primary productivity of terrestrial vegetation based on GIS and RS: A case study in Inner Mongolia, China. Journal of Remote Sensing, 2005,9(3):300-307. ] | |
[37] | 包妮沙, 吴立新, 叶宝莹 , 等. 国产高分遥感数据估算草地NPP[J]. 东北大学学报(自然科学版), 2016,37(10):1450-1454. |
[ Bao Nisha, Wu Lixin, Ye Baoying , et al. Estimating net primary productivity using Chinese GF-1 remote sensing data for regional grassland. Journal of Northeastern University (Natural Science), 2016,37(10):1450-1454. ] | |
[38] | Tao Z X, Wang H J, Liu Y C , et al. Phenological response of different vegetation types to temperature and precipitation variations in northern China during 1982-2012[J]. International Journal of Remote Sensing, 2017,38(11):3236-3252. |
[39] | 韩芳 . 气候变化对内蒙古荒漠草原生态系统的影响[D]. 呼和浩特: 内蒙古大学, 2013. |
[ Han Fang . Impact of climate change on desert steppe ecosystem in Inner Mongolia. Huhhot, China: Inner Mongolia University, 2013. ] | |
[40] | 韩国栋 . 降水量和气温对小针茅(Stipa klemenzii Roshev.)草原植物群落初级生产力的影响[J]. 内蒙古大学学报(自然版), 2002,33(1):83-88. |
[ Han Guodong . Influence of precipitation and air temperature on primary productivity of Stipa klemenzii plant community, NeiMongol. Acta Scientiarum Naturalium Universitatis Neimongol, 2002,33(1):83-88. ] | |
[41] | 范德芹, 赵学胜, 郑周涛 . 内蒙古羊草草原物候及其对气候变化的响应[J]. 地理与地理信息科学, 2016,32(6):81-86. |
[ Fan Deqin, Zhao Xuesheng, Zheng Zhoutao . Phenology of Leymus Chinensis steppe in Inner Mongolia and its response to climate changes. Geography and Geo-Information Science, 2016,32(6):81-86. ] | |
[42] | 李夏子, 郭春燕, 韩国栋 . 气候变化对内蒙古荒漠化草原优势植物物候的影响[J]. 生态环境学报, 2013,22(1):50-57. |
[ Li Xiazi, Guo Chunyan, Han Guodong . Impacts of climate change on phenological phases of dominant grass species in the desert steppe in Inner Mongolia. Ecology and Environmental Sciences, 2013,22(1):50-57. ] | |
[43] | 韩芳, 刘朋涛, 牛建明 , 等. 50a来内蒙古荒漠草原气候干燥度的空间分布及其演变特征[J]. 干旱区研究, 2013,30(3):449-456. |
[ Han Fang, Liu Pengtao, Niu Jianming , et al. Spatial distribution and evolution of climatic aridity in desert steppe in Inner Mongolia in recent 50 years. Arid Zone Research, 2013,30(3):449-456. ] | |
[44] | 潘萌甜, 梁俊红, 李佳 , 等. 内蒙古温带草原NPP时空变化特征分析[J]. 西北林学院学报, 2018,33(1):233-240. |
[ Pan Mengtian, Liang Junhong, Li Jia , et al. Temporal and spatial pattern of temperate steppe NPP in Inner Mongolia. Journal of Northwest Forestry University, 2018,33(1):233-240. ] | |
[45] | Richardson A D, Anderson R S, Arain M A , et al. Terrestrial biosphere models need better representation of vegetation phenology: Results from the North American carbon program site synjournal[J]. Global Change Biology, 2012,18(2):566-584. |
[46] | Wu C Y, Chen J M, Gonsamo A , et al. Interannual variability of net carbon exchange is related to the lag between the end-dates of net carbon uptake and photosynjournal: Evidence from long records at two contrasting forest stands[J]. Agricultural and Forest Meteorology, 2012,164:29-38. |
[47] | 张煦庭 . 中国温带地区草地植被动态时空特征及其对气候变化的响应[D]. 北京: 中国农业大学, 2018. |
[ Zhang Xuting . Spatial-temporal variation of grassland vegetation dynamics and its response to climate change in China's temperate zone. Beijing, China: China Agricultural University, 2018. ] | |
[48] | 郭灵辉, 郝成元, 吴绍洪 , 等. 21世纪上半叶内蒙古草地植被净初级生产力变化趋势[J]. 应用生态学报, 2016,27(3):803-814. |
[ Guo Linghui, Hao Chengyuan, Wu Shaohong , et al. Projected changes in vegetation net primary productivity of grassland in Inner Mongolia, China during 2011-2050. Chinese Journal of Applied Ecology, 2016,27(3):803-814. ] |
