城市化与PM2.5时空格局演变及其影响因素的研究进展

doi:10.18306/dlkxjz.2018.08.001

摘要/Abstract

摘要：

快速的城市化和经济发展在改善我们物质生活的同时,也因其剧烈人为活动导致了严重的环境污染,尤其是近年来以细颗粒物(PM_2.5)为首要污染物的城市与区域空气污染问题凸显。而传统的研究更注重孤立地开展空气污染或城市化的研究,缺乏对二者相互耦合关系的综合研究。本文以中国近年来广受关注的以PM_2.5为首要污染物的城市空气污染为切入点,系统地分析总结了在城市化与PM_2.5时空格局演变及其影响因素方面的主要研究进展,包括研究框架、主要方法和相关的主要研究成果等。指明该领域的研究已从空间格局分析逐步深入到健康影响、社会经济驱动等相关方向,并已延伸至复合主题的研究。未来,开展更为深入细致的研究,对于拓展城市与景观生态学的理论体系,了解城市化与城市空气质量的影响关系,解析不同城市发展阶段所面临的城市空气质量问题,将具有重要的科学与现实意义。

关键词: 城市空气质量, 大气污染, PM_2.5, 生态城市, 时空格局, 城市化

Abstract:

Urbanization is essentially a geographical concentration of population and industry, and change of landscape patterns. The proportion of the urbanized population in China has increased to more than 50% during the recent decade. The rapid growth in such a short time period has not only led to an improvement of material wealth and a higher standard of living, but also caused severe environmental pollution, particularly the air pollution in many urbanized regions of China. In this research, multi-resolution remote sensing images, meteorological records, environmental monitoring data, and ground survey records were employed at multiple scales to understand the relationship between rapid urbanization and urban air quality, taking PM_2.5 concentration as an indicator of air quality. The key findings are in the following three areas: (1) The spatial-temporal patterns of PM_2.5 concentration in China; (2) The spatial-temporal patterns of the relationship between urban PM_2.5pollution and rural PM_2.5 pollution in China's major cities; and (3) The linkage between urbanization and PM_2.5 concentration at global, regional, city, and local scales. The results of this research also encourage different approaches to urbanization study in order to mitigate the negative impact caused by urban air pollution, both in China and in other rapidly developing mid- and low-income countries.

Key words: urban air quality, atmospheric pollution, PM_2.5, ecological city, spatial temporal pattern, urbanization

韩立建. 城市化与PM_2.5时空格局演变及其影响因素的研究进展[J]. 地理科学进展, 2018, 37(8): 1011-1021.

Lijian HAN. Relationship between urbanization and urban air quality: An insight on fine particulate dynamics in China[J]. PROGRESS IN GEOGRAPHY, 2018, 37(8): 1011-1021.

图/表 6

表1

表2

图1

图2

图3

图4

参考文献 53

[1]	别同, 韩立建, 何亮, 等. 2018. 城市空气污染对周边区域空气质量的影响[J]. 生态学报, 38(12): 4268-4275.
	[Bie T, Han L J J, He L, et al, 2018. Impact of urban air pollution on surrounding areas in Beijing, Tianjin, and Hebei Provinces[J]. Acta Ecologica Sinica, 38(12): 4268-4275.]
[2]	别同, 韩立建, 田淑芳, 等. 2018. 城市化对空气污染人群暴露贡献的定量方法研究[J]. 生态学报, 38(13): 4570-4583.
	[Bie T, Han L J, Tian S F, et al, 2018. Method for quantifying the contribution of urbanization on population exposure to air pollution[J]. Acta Ecologica Sinica, 38(13): 4570-4583.]
[3]	陈利顶, 周伟奇, 韩立建, 等. 2016. 京津冀城市群地区生态安全格局构建与保障对策[J]. 生态学报, 36(22): 7125-7129. doi: 10.5846/stxb201610142085
	[Chen L D, Zhou W Q, Han L J, et al, 2016. Developing key technologies for establishing ecological security patterns at the Beijing-Tianjin-Hebei urban megaregion[J]. Acta Ecologica Sinica, 36(22): 7125-7129.] doi: 10.5846/stxb201610142085
[4]	傅尧, 王琛, 王乐, 等. 2016. 河北省PM2.5污染变化特征及暴露人群健康效应评估研究[J]. 环境科学与管理, 41(12): 187-190. doi: 10.3969/j.issn.1673-1212.2016.12.042
	[Fu Y, Wang C, Wang L, et al, 2016. Variation characteristics of PM2.5 polluion in Hebei Province and health effects evaluation of exposed population[J]. Environmental Science and Management, 41(12): 187-190.] doi: 10.3969/j.issn.1673-1212.2016.12.042
[5]	李辉, 郭家秀, 尹华强. 2013. PM2.5对人体健康的影响研究进展[J]. 四川化工, 16(1): 52-54. doi: 10.3969/j.issn.1672-4887.2013.01.015
	[Li H, Guo J X, Yin H Q, 2013. Research progress of PM2.5 effects on human health[J]. Sichuan Chemical Industry, 16(1): 52-54.] doi: 10.3969/j.issn.1672-4887.2013.01.015
[6]	李沈鑫, 邹斌, 刘兴权, 等. 2017. 2013-2015年中国PM2.5污染状况时空变化[J]. 环境科学研究, 30(5): 678-687.
	[Li S X, Zou B, Liu X Q, et al, 2017. Pollution status and spatial-temporal variations of PM2.5 in China during 2013-2015[J]. Research of Environmental Sciences, 30(5): 678-687.]
[7]	刘帅, 宋国君. 2016. 城市PM2.5健康损害评估研究[J]. 环境科学学报, 36(4): 1468-1476. doi: 10.13671/j.hjkxxb.2015.0686
	[Liu S, Song G J, 2016. Evaluation of PM2.5's adverse human health effect in cities[J]. Acta Scientiae Circumstantiae, 36(4): 1468-1476.] doi: 10.13671/j.hjkxxb.2015.0686
[8]	孙敏, 陈健, 林鑫涛, 等. 2018. 城市景观格局对PM2.5污染的影响[J]. 浙江农林大学学报, 35(1): 135-144.
	[Sun M, Chen J, Lin X T, et al, 2018. Urban landscape patterns and PM2.5 pollution[J]. Journal of Zhejiang A & F University, 35(1): 135-144.]
[9]	王德庆,王宝庆,白志鹏. 2012. PM2.5污染与居民每日死亡率关系的Meta分析[J], 环境与健康杂志, 29(6): 529-532.
	[Wang D Q, Wang B Q, Bai Z P, 2012. Meta-analysis of association between air fine particulate and daily mortality of residents[J]. Journal of Environmental Health, 29(6): 529-532.]
[10]	王桂林, 杨昆, 杨扬. 2017. 京津冀地区不透水表面扩张对PM2.5污染的影响研究[J]. 中国环境科学, 37(7): 2470-2481.
	[Wang G L, Yang K, Yang Y, 2017. The spatio-temporal variation of PM2.5 pollution and the its correlation with the impervious surface expansion[J]. China Environmental Science, 37(7): 2470-2481.]
[11]	王桂芝, 武灵艳, 陈纪波, 等. 2017. 北京市PM2.5污染健康经济效应的CGE分析[J]. 中国环境科学, 37(7): 2779-2785.
	[Wang G Z, Wu L Y, Chen J B, et al.2017. A CGE-based analysis on PM2.5-induced health-related economic effect in Beijing[J]. China Environmental Science, 37(7): 2779-2785.]
[12]	王振波, 方创琳, 许光, 等. 2015. 2014年中国城市PM2.5浓度的时空变化规律[J]. 地理学报, 70(11): 1720-1734. doi: 10.11821/dlxb201511003
	[Wang Z B, Fang C L, Xu G, et al, 2015. Spatial-temporal characteristics of the PM2.5 in China in 2014[J]. Acta Geographica Sinica, 70(11): 1720-1734.] doi: 10.11821/dlxb201511003
[13]	张凡, 苏德奇. 2016. PM2.5对人体健康的影响研究进展[J]. 疾病预防控制通报, 31(4): 88-91.
	[Zhang F, Su D Q, 2016. Research advance of PM2.5 effects on human health[J]. Bulletin of Disease Control and Prevention, 31(4): 88-91.]
[14]	张淑平, 韩立建, 周伟奇, 等. 2016a. 城市规模对大气污染物NO2和PM2.5浓度的影响[J]. 生态学报, 36(16): 7125-7129.
	[Zhang S P, Han L J, Zhou W Q, et al, 2016a. Impact of urban population on concentrations of nitrogen dioxide ( NO2) and fine particles ( PM2.5) in China[J]. Acta Ecologica Sinica, 36(16): 7125-7129.]
[15]	张淑平, 韩立建, 周伟奇, 等. 2016b. 冬季PM2.5的气象影响因素解析[J]. 生态学报, 36(24): 7897-7907. doi: 10.5846/stxb201505020901
	[Zhang S P, Han L J, Zhou W Q, et al, 2016b. Relationships between fine particulate matter(PM2.5) and meteorological factors in winter at typical Chinese cities[J]. Acta Ecologica Sinica, 36(24): 7897-7907.] doi: 10.5846/stxb201505020901
[16]	周伟奇, 王坤, 虞文娟, 等. 2017. 城市与区域生态关联研究进展[J]. 生态学报, 37(15): 5238-5245.
	[Zhou W Q, Wang K, Yu W J, et al, 2017. Understanding the social and ecological connections between cities and surrounding regions for urban and regional sustainability[J]. Acta Ecologica Sinica, 37(15): 5238-5245.]
[17]	Bai X, Shi P, Liu Y.2014. Realizing China's urban dream[J]. Nature, 509: 158-160. doi: 10.1038/509158a
[18]	Brauer M, Freedman G, Frostad J, et al.2016. Ambient air pollution exposure estimation for the global burden of disease 2013[J]. Environmental Science & Technology, 50, 79-88.
[19]	Chan C, Yao X.2008. Air pollution in mega cities in China[J]. Atmospheric Environment, 42: 1-42. doi: 10.1016/j.atmosenv.2007.09.003
[20]	Fleischer N, Merialdi M, van Donkelaar A, et al.2014. Outdoor air pollution, preterm birth, and low birth weight: Analysis of the World Health Organization Global Survey on Maternal and Perinatal Health[J]. Environmental Health Perspectives, 122: 425-430.
[21]	Ford B, Heald C.2016. Exploring the uncertainty associated with satellite-based estimates of premature mortality due to exposure to fine particulate matter[J]. Atmospheric Chemistry and Physics, 16: 3499-3523.
[22]	Forouzanfar M, Alexander L, Anderson H, et al.2015. Global, regional, and national comparative risk assessment of 79 behavioural, environmental and occupational, and metabolic risks or clusters of risks in 188 countries, 1990-2013: A systematic analysis for the Global Burden of Disease Study 2013[J]. Lancet, 86: 2287-2323.
[23]	Fu J, Jiang D, Lin G, et al.2015. An ecological analysis of PM2.5 concentrations and lung cancer mortality rates in China[J]. BMJ Open, 5: e009452. doi: 10.1136/bmjopen-2015-009452 pmid: 26603253
[24]	Guo Y, Zeng H, Zheng R, et al.2017. The burden of lung cancer mortality attributable to fine particles in China[J]. Science of the Total Environment, 579: 1460-1466. doi: 10.1016/j.scitotenv.2016.11.147 pmid: 27913022
[25]	Han L J, Zhou W Q, Li W F, et al.2014. Impact of urbanization level on urban air quality: A case of fine particles (PM2.5) in Chinese cities[J]. Environmental Pollution, 194: 163-170.
[26]	Han L J, Zhou W Q, Li W F.2015a. City as a major source area of fine particulate (PM2.5) in China[J]. Environmental Pollution, 206: 183-187. doi: 10.1016/j.envpol.2015.06.038 pmid: 26176632
[27]	Han L J, Zhou W Q, Li W F.2015b. Increasing impact of urban fine particles (PM2.5) on areas surrounding Chinese cities[J]. Scientific Reports, 5: 12467. doi: 10.1038/srep12467 pmid: 4518225
[28]	Han L J, Zhou W Q, Li W F.2016. Fine particulate (PM2.5) dynamics during rapid urbanization in Beijing[J]. Scientific Reports, 6: 23604. doi: 10.1038/srep23604 pmid: 27031598
[29]	Han L J, Zhou W Q, Li W F, et al.2017. Global population exposed to fine particulate pollution by population increase and pollution expansion[J]. Air Quality, Atmosphere & Health, 10: 1221-1226.
[30]	Han L J, Zhou W Q, Li W F.2018a. Growing urbanization and the impact on fine particulate matter (PM2.5) dynamic[J]. Sustainability, 10: 1696. doi: 10.3390/su10061696
[31]	Han L J, Zhou W Q, Li W F.2018b. Urbanization strategy and environmental changes: An insight with relationship between population change and fine particulate pollution[J]. Science of the Total Environment, 642: 789-799.
[32]	Han L J, Zhou W Q, Pickett S T, et al.2016. An optimum city size? The scaling relationship for urban population and fine particulate (PM2.5) concentration[J]. Environmental Pollution, 208: 96-101.
[33]	Han L J, Zhou W Q, Pickett S T, et al.2018. Multicontaminant air pollution in Chinese cities[J]. Bulletin of the World Health Organization, 96: 233-242E. doi: 10.2471/BLT.17.195560
[34]	He C, Han L J, Zhang R, 2016. More than 500 million Chinese urban residents (14% of the global urban population) are imperiled by fine particulate hazard[J]. Environmental Pollution, 218: 558-562.
[35]	Huang R, Zhang Y, Bozzetti C, et al.2014. High secondary aerosol contribution to particulate pollution during haze events in China[J]. Nature, 514: 218-222. doi: 10.1038/nature13774 pmid: 25231863
[36]	Hyslop N.2009. Impaired visibility: The air pollution people see[J]. Atmospheric Environment, 43: 182-195. doi: 10.1016/j.atmosenv.2008.09.067
[37]	Larkin A, van Donkelaar A, Geddes J, et al.2016. Relationships between changes in urban characteristics and air quality in East Asia from 2000 to 2010[J]. Environmental Science & Technology, 50: 9142-9149.
[38]	Li G, Fang C, Wang S, et al.2016. The effect of economic growth, urbanization, and industrialization on fine particulate matter (PM2.5) concentrations in China[J]. Environmental Science & Technology, 50: 11452-11459.
[39]	Lim S, Vos T, Flaxman A, et al.2012. A comparative risk assessment of burden of disease and injury attributable to 67 risk factors and risk factor clusters in 21 regions, 1990-2010: A systematic analysis for the Global Burden of Disease Study 2010[J]. Lancet, 380: 2224-2260.
[40]	Lin C, Li Y, Lau A, et al.2016. Estimation of long-term population exposure to PM2.5 for dense urban areas using 1-km MODIS data[J]. Remote Sensing of Environment, 179: 13-22.
[41]	Lin G, Fu J, Jiang D, et al.2014. Spatio-temporal variation of PM2.5 concentrations and their relationship with geographic and socioeconomic factors in China[J]. International Journal of Environmental Research and Public Health, 11: 173-186.
[42]	Lin G, Fu J, Jiang D, et al.2015. Spatial variation of the relationship between PM2.5 concentrations and meteorological parameters in China[J]. Biomed Research International, 25: 259-265.
[43]	Liu M, Huang Y, Ma Z, et al.2016. Spatial and temporal trends in the mortality burden of air pollution in China: 2004-2012[J]. Environmental International, 98: 75-81. doi: 10.1016/j.envint.2016.10.003 pmid: 5479577
[44]	Lu X, Lin C, Li Y, et al.2017. Assessment of health burden caused by particulate matter in southern China using high-resolution satellite observation[J]. Environmental International, 98: 160-170.
[45]	Luo J, Du P, Samat A, et al.2017. Spatiotemporal pattern of PM2.5 concentrations in mainland China and analysis of its influencing factors using geographically weighted regression[J]. Scientific Reports, 7: 40607.
[46]	Ma Z, Hu X, Sayer A, et al.2016. Satellite-based spatiotemporal trends in PM2.5 concentrations: China, 2004-2013[J]. Environmental Health Perspectives, 124: 184-192. doi: 10.1289/ehp.1409481 pmid: 26220256
[47]	McNeill J R.2000. Something new under the sun: An environmental history of the twentieth-century world[B]. W. W. Norton & Company, Inc. New York, N.Y. 10110, U.S.
[48]	Peng J, Chen S, Lu H, et al.2016. Spatiotemporal patterns of remotely sensed PM2.5 concentration in China from 1999 to 2011[J]. Remote Sensing of Environment, 174: 109-121. doi: 10.1016/j.rse.2015.12.008
[49]	Pope III C, Dockey D.2012. Health effects of the fine particle air pollution: Lines that connect[J]. Journal of the Air Waste Management Association, 56: 709-742.
[50]	van Donkelaar A, Martin R, Brauer M, et al.2015. Use of satellite observations for long-term exposure assessment of global concentrations of fine particulate matter[J]. Environmental Health Perspectives, 123: 135-143.
[51]	Wang Z, Liu Y, Hu M, et al.2013. Acute health impact of airborne particles estimated from satellite remote sensing[J]. Environmental International, 51: 150-159. doi: 10.1016/j.envint.2012.10.011 pmid: 23220016
[52]	Xie R, Sabel C, Lu X, et al.2016. Long-term trend and spatial pattern of PM2.5 induced premature mortality in China[J]. Environmental International, 97: 180-186. doi: 10.1016/j.envint.2016.09.003 pmid: 27614532
[53]	Zhu Y, Loannidis J, Li H, et al.2011. Understanding and harnessing the health effect of rapid urbanization in China[J]. Environmental Science & Technology, 45: 5099-5140. doi: 10.1021/es2004254 pmid: 21542627

	政策	技术	公众认知	治理周期	环境教育
中国	立法、低效产业和能源结构转型、强力行政管控	限行、限购、管控排放规模、缺乏有效的技术措施;新能源汽车	初级水平,无有效的维权认知和渠道	未知 (2013-)	环境教育严重弱于应试科目,且体系不完善
日本	立法、高效的产业和能源结构转型	大幅度的技术进步和改良;混合动力汽车	对污染企业的大规模集体诉讼,捍卫权力,保护赖以生存的环境	10年 (1970-1980)	完备的环境教育体系;高效科普策略

研究主题	主要相关SCI文章（基于遥感反演PM_2.5浓度数据）		中文论文案例
格局分析	时空格局分析	Han et al, 2014; Lin et al, 2014; Han et al, 2015a, 2015b; Ma et al, 2016; Peng et al, 2016; Luo et al, 2017.	王振波等, 2015. 李沈鑫等, 2017; 别同, 韩立建, 何亮等, 2018
格局分析	空间相互作用分析	Han et al, 2014, 2015b.	王振波等, 2015. 李沈鑫等, 2017; 别同, 韩立建, 何亮等, 2018
健康影响	健康风险评估	Lim et al, 2012; Wang et al, 2013; Fleischer et al, 2014; Fu et al, 2015; Brauer et al, 2016; Ford et al, 2016; Liu et al, 2016; Xie et al, 2016; Guo et al, 2017; Lu et al, 2017.	王德庆等, 2012; 李辉等, 2013; 傅尧等, 2016; 张凡等, 2016; 刘帅等, 2016.
健康影响	人群污染暴露	Han et al, 2015a; van Donkelaar et al, 2015; He et al, 2016; Lin et al, 2016; Peng et al, 2016.	王德庆等, 2012; 李辉等, 2013; 傅尧等, 2016; 张凡等, 2016; 刘帅等, 2016.
社会经济影响	城市化与PM_2.5	Han et al, 2014; Han et al, 2015b; Han et al, 2016; Larkin et al, 2016; Li et al, 2016; Han et al, 2018a, 2018b.	张淑平等, 2016a; 王桂林等, 2017; 王桂芝等, 2017.
社会经济影响	其他因素	Lin et al, 2014; Li et al, 2016; Luo et al, 2017.	张淑平等, 2016a; 王桂林等, 2017; 王桂芝等, 2017.
气象要素影响		Lin et al, 2015.	张淑平等, 2016b.
复合主题	城市化对人群暴露的贡献	Han et al, 2017.	孙敏等, 2018; 别同, 韩立建, 田淑芳等, 2018.
复合主题	复合空气污染及其与城市化的关系	Han, Zhou, Pickett et al, 2018.	无
