多源再分析降水数据在拉萨河流域应用对比研究

doi:10.18306/dlkxjz.2017.08.012

摘要/Abstract

摘要：

针对资料稀缺地区水文模拟计算难题,开展多源再分析降水数据在拉萨河流域应用对比研究,本文基于HIMS系统构建了拉萨河流域分布式水文模型,以气象站实测数据为参照,对比分析了中国区域地面降水格点日值数据集和中国区域高时空分辨率地面气象要素驱动数据集两套遥感再分析数据集的气象数据在拉萨河流域的径流模拟效果。结果表明：在日和月时间尺度上,气象站实测降水数据的径流模拟精度最好,驱动集降水数据径流模拟结果要好于网格点降水数据。总体上,基于气象站实测降水数据的径流模拟纳西效率系数为0.86(日过程)和0.93(月过程),相关系数均在0.9以上。基于两类再分析数据的降水径流模拟纳西效率系数均在0.7(日过程)和0.8(月过程)以上,相关系数均在0.9左右。对于资料稀缺地区,多源再分析降水数据是重要的可用数据来源。借助于降水—径流模型,探讨多源再分析降水数据对径流模拟精度的影响,是完善多源再分析降水数据产品质量的一个重要环节。

关键词: 分布式水文模型, 多源再分析降水数据, 模拟径流, 对比分析, 拉萨河流域

Abstract:

Hydrological simulation in ungauged basins is a challenging topic in hydrology and water resource fields internationally. With the fast development of remote sensing technology, it is possible to utilize remote sensing derived precipitation data in hydrological fields to accelerate the progress of research in the PUB (predictions in ungauged basins) plan. This study compared the applications of different reanalyzed precipitation data—the grid and forcing precipitation data—in hydrological simulation in the Lhasa River Basin. The study built a distributed hydrological model using the HIMS model for the basin. The process started with inputting the daily precipitation data from the National Meteorological Center, then based on the measured flow in the Lhasa hydrological control station to calibrate and verify the hydrological model. After this, two types of remote sensing reanalyzed precipitation data in HIMS model were imported for runoff simulation, and the results were compared with simulation results of the measured weather station daily precipitation data. Subsequently, the applicability of the two types of remote sensing reanalyzed precipitation data in the Lhasa River Basin was analyzed. On the whole, the Nash-Sutcliffe efficiency coefficient of the runoff simulation based on daily precipitation data is 0.86 (daily process) and 0.93 (monthly process), and the correlation coefficient is above 0.9. The Nash-Sutcliffe efficiency coefficient of the rainfall-runoff simulations based on the two reanalyzed precipitation datasets are both above 0.7 in the daily scale process and over 0.8 in the monthly scale process, and the correlation coefficient are both around 0.9. The results show that the measured weather station daily precipitation data resulted in the best simulation outcomes and both the grid precipitation data and forcing precipitation data generate satisfactory runoff simulation results in the Lhasa River Basin. This indicates that daily precipitation data are useful although the number of rainfall stations in this area is limited. The remote sensing reanalyzed precipitation datasets can be well used in ungauged areas such as the Lhasa River Basin and it may become a reliable source when analyzing the relationship between rainfall and runoff in ungauged basins. Using rainfall-runoff model to examine the impact of multi-sources reanalyzed precipitation datasets on the accuracy of runoff simulation is essential for evaluating the quality of such datasets.

Key words: distributed hydrological model, multi-source reanalyzed precipitation data, runoff simulation, comparitive analysis, Lhasa River Basin

郭禹含, 王中根, 伍玉良. 多源再分析降水数据在拉萨河流域应用对比研究[J]. 地理科学进展, 2017, 36(8): 1033-1039.

Yuhan GUO, Zhonggen WANG, Yuliang WU. Comparison of applications of different reanalyzed precipitation data in the Lhasa River Basin based on HIMS model[J]. PROGRESS IN GEOGRAPHY, 2017, 36(8): 1033-1039.

图/表 7

图1

图2

表1

图3

图4

表2

表3

参考文献 25

1	摆万奇, 姚丽娜, 张镱锂, 等. 2014. 近35 a西藏拉萨河流域耕地时空变化趋势[J]. 自然资源学报, 29(4): 623-632.
	[Bai W Q, Yao L N, Zhang Y L, et al.2014. Spatial-temporal dynamics of cultivated land in recent 35 years in the Lhasa River basin of Tibet[J]. Journal of Natural Resources, 29(4): 623-632.]
2	陈利群, 刘昌明, 袁飞. 2006. 大尺度资料稀缺地区水文模拟可行性研究[J]. 资源科学, 28(1): 87-92.
	[Chen L Q, Liu C M, Yuan F.2006. Feasibility study on hydrologic simulation in basins with macro-scale data scarce[J]. Resources Science, 28(1): 87-92.]
3	黄浠, 王中根, 桑燕芳, 等. 2016. 雅鲁藏布江流域不同源降水数据质量对比研究[J]. 地理科学进展, 35(3): 339-348. doi: 10.18306/dlkxjz.2016.03.008
	[Huang X, Wang Z G, Sang Y F, et al.2016. Precision of data in three precipitation datasets of the Yarlung Zangbo River basin[J]. Progress in Geography, 35(3): 339-348.] doi: 10.18306/dlkxjz.2016.03.008
4	黄粤, 陈曦, 包安明, 等. 2009. 干旱区资料稀缺流域日径流过程模拟[J]. 水科学进展, 20(3): 332-336. doi: 10.3321/j.issn:1001-6791.2009.03.004
	[Huang Y, Chen X, Bao A M, et al.2009. Daily flow modeling in arid ungauged basin[J]. Advances in Water Science, 20(3): 332-336.] doi: 10.3321/j.issn:1001-6791.2009.03.004
5	季漩, 罗毅. 2011. 资料稀缺高海拔山区降水量推算方法及在水文模拟中的应用[J]. 灌溉排水学报, 30(6): 103-106.
	[Ji X, Luo Y.2011. A precipitation estimation method and its application in hydrologic simulation in data-scarce high mountain area[J]. Journal of Irrigation and Drainage, 30(6): 103-106.]
6	刘波, 肖子牛. 2011. 多源降水数据在澜沧江—湄公河流域的比较研究[J]. 干旱区地理, 34(6): 958-966.
	[Liu B, Xiao Z N.2011. Comparison of different precipitation datasets in Lancang-Mekong River basin[J]. Arid Land Geography, 34(6): 958-966.]
7	刘昌明, 白鹏, 张丹, 等. 2012. 基于HIMS的稀缺资料地区径流估算[C]//水利部水文局,国际水文计划(IHP)中国国家委员会,国际水文科学协会
8	刘昌明, 王中根, 郑红星, 等. 2008. HIMS系统及其定制模型的开发与应用[J]. 中国科学: 技术科学, 38(3): 350-360.
	[Liu C M, Wang Z G, Zheng H X, et al.2008. HIMS system and development and application of its customized model[J]. Chinese Science (E Series: Science and Technology), 38(3): 350-360.]
9	刘俊峰, 陈仁升, 韩春坛, 等. 2010. 多卫星遥感降水数据精度评价[J]. 水科学进展, 21(3): 343-348.
	[Liu J F, Chen R S, Han C T, et al.2010. Evaluating TRMM multi-satellite precipitation analysis using gauge precipitation and MODIS snow-cover products[J]. Advances in Water Science, 21(3): 343-348.]
10	刘文丰, 徐宗学, 刘浏, 等. 2012. 基于VIC模型的拉萨河流域分布式水文模拟[J]. 北京师范大学学报: 自然科学版, 48(5): 524-529.
	[Liu W F, Xu Z X, Liu L, et al.2012. Distributed hydrological simulation in the Lhasa River basin based on VIC model[J]. Journal of Beijing Normal University: Natural Science, 48(5): 524-529.]
11	刘元波, 傅巧妮, 宋平, 等. 2011. 卫星遥感反演降水研究综述[J]. 地球科学进展, 26(11): 1162-1172. doi: 10.11867/j.issn.1001-8166.2011.11.1162
	[Liu Y B, Fu Q N, Song P, et al.2011. Satellite retrieval of precipitation: An overview[J]. Advances in Earth Science, 26(11): 1162-1172.] doi: 10.11867/j.issn.1001-8166.2011.11.1162
12	林志强, 唐叔乙, 何晓红, 等. 2011. 西藏高原汛期水汽输送特征与降水异常[J]. 气象, 37(8): 984-990.
	[Lin Z Q, Tang S Y, He X H, et al.2011. Features of water vapor transfer in rainy season and their relations to rainfall anomalies over Tibetan Plateau[J]. Meteorological Monthly, 37(8): 984-990.]
13	蔺学东, 张镱锂, 姚治君, 等. 2007. 拉萨河流域近50年来径流变化趋势分析[J]. 地理科学进展, 26(3): 58-67.
	[Lin X D, Zhang Y L, Yao Z J, et al.2007. Trend analysis of the runoff variation in Lhasa River Basin in Tibetan Plateau during the last 50 years[J]. Progress in Geography, 26(3): 58-67.]
14	陆志翔, 蔡晓慧, 邹松兵, 等. 2012. SWAT模型在伊犁河上游缺资料区的应用[J]. 干旱区地理, 35(3): 399-407.
	[Lu Z X, Cai X H, Zou S B, et al.2012. Application of SWAT model in the upstream of Ili River basin with scarce data[J]. Arid Land Geography, 35(3): 399-407.]
15	罗吉忠, 张新华, 肖玉成, 等. 2013. 基于SWAT模型的缺资料流域径流模拟研究[J]. 西南民族大学学报: 自然科学版, 39(1): 80-86. doi: 10.3969/j.issn.1003-4271.2013.01.18
	[Luo J Z, Zhang X H, Xiao Y C, et al.2013. Runoff simulation in data-scarce basins based on SWAT hydrological model[J]. Journal of Southeast University for Nationalities: Natural Science Edition, 39(1): 80-86.] doi: 10.3969/j.issn.1003-4271.2013.01.18
16	芮孝芳. 1997. 流域水文模型研究中的若干问题[J]. 水科学进展, 8(1): 94-98.
	[Rui X F.1997. Some problems in research of watershed hydrology model[J]. Advances in Water Science, 8(1): 94-98.]
17	徐宗学. 2010. 水文模型: 回顾与展望[J]. 北京师范大学学报: 自然科学版, 46(3): 278-289.
	[Xu Z X.2010. Hydrological models: Past, present, future[J]. Journal of Beijing Normal University: Natural Science, 46(3): 278-289.]
18	杨旭, 刘志武, 李波. 2016. 多源降水数据在长江上游流域比较研究[J]. 长江流域资源与环境, 25(1): 131-139.
	[Yang X, Liu Z W, Li B.2016. Comparative study on various rainfall data in upper reaches in Yangtze River[J]. Resources and Environment in the Yangtze Basin, 25(1): 131-139.]
19	赵煜飞, 朱江. 2015. 近50年中国降水格点日值数据集精度及评估[J]. 高原气象, 34(1): 50-58.
	[Zhao Y F, Zhu J.2015. Assessing quality of grid daily precipitation datasets in china in recent 50 years[J]. Plateau Meteorology, 34(1): 50-58.]
20	Bartier P M, Keller C P.1996. Multivariate interpolation to incorporate thematic surface data using inverse distance weighting (IDW)[J]. Computers & Geosciences, 22(7): 795-799. doi: 10.1016/0098-3004(96)00021-0
21	Bastola S, Misra V.2014. Evaluation of dynamically downscaled reanalysis precipitation data for hydrological application[J]. Hydrological Processes, 28(4): 1989-2002. doi: 10.1002/hyp.9734
22	Hrachowitz M, Savenije H H G, Blöschl G, et al.2013. A decade of Predictions in Ungauged Basins (PUB): A review[J]. Hydrological Sciences Journal, 58(6): 1198-1255. doi: 10.1080/02626667.2013.803183
23	Janowiak J E, Gruber A, Kondragunta C R, et al.1998. A comparison of the NCEP-NCAR reanalysis precipitation and the GPCP rain gauge-satellite combined dataset with observational error considerations[J]. Journal of Climate, 11(11): 2960-2979.
24	Sivapalan M.2003. Prediction in ungauged basins: A grand challenge for theoretical hydrology[J]. Hydrological Processes, 17(15): 3163-3170. doi: 10.1002/hyp.5155
25	Sivapalan M, Takeuchi K, Franks S W, et al.2003. IAHS decade on Predictions in Ungauged Basins (PUB), 2003 - 2012: Shaping an exciting future for the hydrological sciences[J]. Hydrological Sciences Journal, 48(6): 857-880. doi: 10.1623/hysj.48.6.857.51421

流域编号	土壤蓄水容量W_mm	产流参数		壤中流系数L_a	地下水补给系数R_c	实际蒸散发系数ε	基流系数K_b	汇流参数
流域编号	土壤蓄水容量W_mm	R		壤中流系数L_a	地下水补给系数R_c	实际蒸散发系数ε	r	C1	C2
1	356.0	9.00	0.10	0.23	0.01	0.10	0.01	0.06	0.05
2	50.0	0.48	0.19	0.97	0.03	1.56	0.05	0.90	0.90
3	50.0	0.22	0.99	0.57	0.09	0.15	0.02	0.05	0.06
4	50.0	5.31	0.10	0.14	0.01	0.16	0.03	0.05	0.25
5	73.0	8.65	0.16	0.20	0.01	0.86	0.02	0.05	0.05
6	50.0	3.00	0.99	0.10	0.01	0.10	0.01	0.05	0.05
7	50.0	2.88	0.10	0.19	0.02	0.96	0.01	0.06	0.05
8	1000.0	3.60	0.63	0.15	0.09	0.10	0.02	0.09	0.28
9	50.0	2.62	0.36	0.51	0.01	0.15	0.01	0.07	0.16
10	96.0	11.25	0.10	0.10	0.13	0.10	0.01	0.05	0.05
11	93.5	0.30	0.10	0.33	0.02	0.38	0.01	0.07	0.17
12	50.0	0.22	0.10	0.10	0.01	0.14	0.01	0.13	0.07
13	50.0	4.83	0.70	0.10	0.03	0.35	0.06	0.06	0.05
14	50.0	0.68	0.10	0.10	0.14	0.10	0.01	0.09	0.09
15	50.0	4.34	0.99	0.15	1.00	0.13	0.01	0.05	0.05
16	113.0	0.37	0.19	0.42	0.01	0.10	0.01	0.05	0.90

计算时期	NSE			RE			WE/%
计算时期	日尺度		月尺度		日尺度	月尺度	日尺度	月尺度
率定期(1973-2002)	0.86	0.93		0.93	0.97		-6.86	-6.91
验证期(2003-2008)	0.83	0.90		0.92	0.95		-11.57	-7.85

日尺度	率定期(1973-2002)			验证期(2003-2008)			月尺度	率定期(1973-2002)				验证期(2003-2008)
日尺度	NSE		RE	WE/%		NSE	RE	WE/%	NSE	RE	WE/%	NSE	RE	WE/%
气象站降水数据	0.86	0.93	-6.86	0.83	0.92	-11.57	气象站降水数据	0.93	0.97	-6.91		0.90	0.95	-7.85
网格点降水数据	0.74	0.89	16.33	0.80	0.89	8.23	网格点降水数据	0.81	0.93	16.32		0.88	0.94	8.16
驱动集降水数据	0.79	0.90	6.36	0.78	0.88	-2.66	驱动集降水数据	0.87	0.94	6.38		0.86	0.93	-2.66
