基于MODIS的青藏高原湖泊透明度遥感反演

doi:10.18306/dlkxjz.2017.05.007

地理科学进展 ›› 2017, Vol. 36 ›› Issue (5): 597-609.doi: 10.18306/dlkxjz.2017.05.007

基于MODIS的青藏高原湖泊透明度遥感反演

刘翀^1,³(), 朱立平^1,^2,^3,^*(), 王君波^1,², 乔宝晋^1,³, 鞠建廷¹, 黄磊^1,³

1. 中国科学院青藏高原研究所青藏高原地表过程与环境变化实验室,北京 100101
2. 中国科学院青藏高原地球科学卓越创新中心,北京 100101
3. 中国科学院大学,北京100049

收稿日期:2017-04-01 出版日期:2017-05-20 发布日期:2017-05-20
通讯作者: 朱立平
作者简介:
作者简介：刘翀(1992-),男,江西南昌人,硕士研究生,研究方向为湖泊环境遥感应用,E-mail:liuchong@itpcas.ac.cn。
基金资助:
科技部基础性科技工作重点项目(2012FY111400);中国科学院战略性科技先导专项(XDB03030000);中国科学院国际合作重点项目(131C11KYSB20160061)

Remote sensing-based estimation of lake water clarity on the Tibetan Plateau

Chong LIU^1,³(), Liping ZHU^1,^2,^3,^*(), Junbo WANG^1,², Baojin QIAO^1,³, Jianting JU¹, Lei HUANG^1,³

1. Key Laboratory of Tibetan Environment Changes and Land Surface Processes, Institute of Tibetan Plateau Research, CAS, Beijing 100101, China
2. CAS Center for Excellence in Tibetan Plateau Earth System, Beijing 100101, China
3. University of Chinese Academy of Sciences, Beijing 100049, China

Received:2017-04-01 Online:2017-05-20 Published:2017-05-20
Contact: Liping ZHU
Supported by:
中国科学院国际合作重点项目(131C11KYSB20160061) [Foundation：National Basic Research Program of Ministry of Science and Technology (MOST),China, No.2012FY111400;Strategic Priority Research Program of CAS, No.XDB03030000;Key Projects of International Cooperation of CAS, No.131C11KYSB20160061

摘要/Abstract

摘要：

湖泊透明度是湖泊水体性质的一个重要参数,是湖泊浮游生物和进入湖泊的有机和无机颗粒溶解程度的综合反映,对湖泊生态环境研究具有重要的科学及实践意义。遥感影像是获取面积广、时间长的湖泊透明度的重要手段,但由于实测数据缺乏,目前对青藏高原地区湖泊透明度的遥感反演研究相对不足。本文基于青藏高原地区24个湖泊实测透明度SD(Secchi Depth)值和相应的MODIS遥感影像,建立了该地区湖泊水体透明度SD值MODIS遥感反演模型。结果表明：基于MODIS绿色波段B4的单波段幂函数模型在该地区反演效果最好,精度较高(R2=0.91, N=24),并具有较好的稳定性。以当惹雍错为例,选用该模型反演得到湖泊透明度的时间变化序列,发现该湖存在明显的季节波动和较为明显的年际变化。初步分析得出,降水/融水季节的湖泊透明度与湖泊所在流域的降水率具有密切的关系。本文结果表明,利用遥感手段能够有效地开展青藏高原地区湖泊透明度的反演,可为进一步深入研究该地区湖泊透明度及其影响要素奠定基础。

关键词: 青藏高原, 湖泊, 遥感, MODIS, 透明度, SD, 当惹雍错

Abstract:

：Lake water clarity is an important parameter of lake water property, which is an integrated response of lake plankton and organic and inorganic solutions, and has significant scientific and practical implications for lake ecological condition research. Remote sensing is a key method for obtaining lake clarity in wide areas and within long time spans. On the Tibetan Plateau, there are more than 389 lakes with area greater than 10 km², making the Plateau an ideal region for environmental and climate change research. However, study on the estimation of lake water clarity on the Tibetan Plateau by satellite data is insufficient at present due to the paucity of in situ lake water clarity measurement data. In this study, retrieval models of lake water clarity were established based on the in situ water clarity measurements of 24 lakes distributed in different areas on the Tibetan Plateau and the corresponding MODIS imageries. Statistical methods including linear, exponential, power function, and logarithm regressions were used to build relationships between lake water clarity and the reflectance of MODIS bands on the Tibetan Plateau. The results show that power function model with MODIS green band B4 as single independent variable is the best model for estimating lake water clarity (SD value) on the Plateau (R2=0.91, N=24). The stability of the model was also tested based on 10 in situ SD data at different times in a single lake. Based on this model, we analyzed the temporal variation of lake water clarity of a typical lake Tangra Yumco as an example. The result demonstrates clear seasonal and inter-annual variations of lake water clarity for this lake. Preliminary analysis indicates that the variation of water clarity in precipitation-meltwater rich season is correlated with precipitation intensity of the basin. Our work proved that the reflectance of remote sensing imageries is valid for estimating lake water clarity on the Tibetan Plateau. This may promote further investigation of lake water clarity and its influencing factors on the Tibetan Plateau.

Key words: Tibetan Plateau, lake, remote sensing, MODIS, clarity, Secchi Depth (SD), Tangra Yumco

刘翀, 朱立平, 王君波, 乔宝晋, 鞠建廷, 黄磊. 基于MODIS的青藏高原湖泊透明度遥感反演[J]. 地理科学进展, 2017, 36(5): 597-609.

Chong LIU, Liping ZHU, Junbo WANG, Baojin QIAO, Jianting JU, Lei HUANG. Remote sensing-based estimation of lake water clarity on the Tibetan Plateau[J]. PROGRESS IN GEOGRAPHY, 2017, 36(5): 597-609.

图/表 13

图1

表1

文中获取的湖泊透明度SD值及对应遥感影像信息"

序号	湖泊名称	采样坐标		MODIS 影像文件名	SD/m	采样日期	影像日期	日期偏差/d
1	纳木错	90.7456°E	30.7338°N	MOD021KM.A2016323.0500.006.2016333195247	8.0	2016.11.19	2016.11.19	0
2	塔若错	84.1366°E	31.1403°N	MOD021KM.A2014249.0525.006.2014249130649	6.2	2014.9.06	2014.9.6	0
3	班公错	79.8094°E	33.5509°N	MOD021KM.A2012209.0455.006.2014224155957	14.0	2012.7.28	2012.7.29	1
4	结则茶卡	80.8814°E	33.9417°N	MOD021KM.A2012212.0525.006.2014224201213	3.0	2012.7.31	2012.7.30	1
5	阿翁错	81.7586°E	32.7531°N	MOD021KM.A2012216.0500.006.2014225101108	3.0	2012.8.5	2012.8.3	2
6	别若则错	82.9585°E	32.4378°N	MOD021KM.A2012216.0500.006.2014225101108	0.5	2012.8.6	2012.8.3	3
7	达热布错	83.2328°E	32.4829°N	MOD021KM.A2012216.0500.006.2014225101108	3.2	2012.8.6	2012.8.3	3
8	拉果错	84.1647°E	32.0269°N	MOD021KM.A2012223.0510.006.2014224150200	5.0	2012.8.8	2012.8.10	2
9	洞错	84.7651°E	32.1623°N	MOD021KM.A2012223.0510.006.2014224150200	0.8	2012.8.8	2012.8.10	2
10	达瓦错	84.9422°E	31.2233°N	MOD021KM.A2012223.0510.006.2014224150200	1.0	2012.8.11	2012.8.10	1
11	攸布错	84.8241°E	30.7900°N	MOD021KM.A2012223.0510.006.2014224150200	12.5	2012.8.12	2012.8.10	1
12	昂古错	85.4441°E	31.2053°N	MOD021KM.A2012223.0510.006.2014224150200	3.5	2012.8.13	2012.8.10	3
13	张乃错	87.4118°E	31.5508°N	MOD021KM.A2012229.0430.006.2014220065835	3.0	2012.8.17	2012.8.16	1
14	恰规错	88.2445°E	31.8489°N	MYD021KM.A2012232.0640.006.2012232192302	5.0	2012.8.19	2012.8.19	0
15	错鄂	88.7061°E	31.6598°N	MYD021KM.A2012232.0640.006.2012232192302	8.0	2012.8.20	2012.8.19	1
16	巴木错	90.6184°E	31.2639°N	MOD021KM.A2012238.0425.006.2014220060635	3.2	2012.8.21	2012.8.25	4
17	达则错	87.5503°E	31.8538°N	MOD021KM.A2012228.0525.006.2014220103327	6.0	2012.8.18	2012.8.15	3
18	色林错	88.8889°E	31.8190°N	MYD021KM.A2014218.0745.006.2014220180109	3.2	2014.8.7	2014.8.6	1
19	龙木错	80.4734°E	34.6240°N	MOD021KM.A2015253.0610.006.2015253195641	2.5	2015.9.10	2015.9.10	0
20	邦达错	81.5300°E	34.9575°N	MOD021KM.A2015248.0550.006.2015248134032	1.3	2015.9.5	2015.9.5	0
21	阿克赛钦湖	79.7935°E	35.2456°N	MOD021KM.A2015259.0535.006.2015259134615	1.0	2015.9.17	2015.9.17	0
22	多尔索洞措	89.8341°E	33.3490°N	MOD021KM.A2016298.0510.006.2016298133407	7.5	2016.10.24	2016.10.24	0
23	赤布张错	90.2322°E	33.3813°N	MOD021KM.A2016305.0515.006.2016305133931	5.0	2016.10.31	2016.10.31	0
24	多格错仁	88.9916°E	34.5537°N	MOD021KM.A2016311.0435.006.2016311134330	2.0	2016.11.6	2016.11.6	0

表1

表2

表3

其他地区湖泊SD值遥感反演拟合形式总结"

研究地区	反演方法	最优拟合形式	R2	N	传感器	参考文献
美国明尼苏达州、威斯康星州	单波段/波段组合、逐步回归、多元线性回归	ln(SD) = b₀ + b₁(B₂/B₄) + b₂B₁	0.82	311	OLI	Olmanson et al, 2016
中国吉林省中西部	先取相关系数较高的单波段、波段倒数、波段比值,再作多元线性回归	SD=a(B1/B2)+b(B1/B3)+c(B2/B3)+d	0.639	70	HJ-1 CCD	马建行等, 2016
中国吉林省中西部	先取相关系数较高的单波段、波段倒数、波段比值,再作多元线性回归	SD=aB1+bB2+c(B2/B3)+d	0.894	63	MODIS	马建行等, 2016
美国五大湖	单波段多项式	1/SD=aRrs₍₅₅₀₎³+ bRrs₍₅₅₀₎²+cRrs₍₅₅₀₎ +d	0.74	1328	CZCS, SeaWiFS, MODIS	Binding et al, 2015
美国缅因州	单波段、波段比值	SD= a(B1/B3)+bB1+cB7+d	0.70~0.89	24~71	TM	Courville et al, 2014
美国缅因州	单波段、波段比值	SD= aB1+bB3+ c	0.63~0.83	31~117	TM	McCullough et al, 2012
美国明尼苏达州	根据前人经验直接利用蓝、红波段	ln(SD)= aB1+bB3+ c	0.32~0.71	748	MODIS	Knight et al, 2012
中国太湖	直接利用前人经验公式	ln(SD)=a(TM1/TM3)+bTM1+c	0.77	32	ETM+	Zhao et al, 2011
鄱阳湖	取相关性较好的单波段、波段组合,做线性、对数、指数、倒数、开方、多项式回归取最优取相关性较好的单波段、波段组合,做线性、对数、指数、倒数、开方、多项式回归取最优	ln(SD)= aB_blue+bB_red+ c	0.88	71	MODIS	Wu et al, 2008
鄱阳湖		ln(SD)= aB_blue+bB_red+ c	0.83	25	TM	Wu et al, 2008
中国东北部	取单波段、波段比值、平均作一元回归	SD= aB3/B2+b 或SD= aB3/B1+b 或SD= a (B1+B4)/2+b 或SD= a (B3+B2)/2+b 及上述方式变量取对数	0.69~0.98	7~20	TM	Duan et al, 2009
美国明尼苏达州	直接利用前人经验公式	ln(SD)=a(TM1/TM3)+bTM1+c	0.71~0.96	13~278	MSS, TM, ETM+	Olmanson et al, 2008
美国明尼阿波利斯	单波段、波段组合、逐步回归选取关系较强参数,作多元回归	ln(SD)=a(TM1/TM3)+bTM1+c	0.70~0.80	21~53	MSS,TM	Kloiber et al, 2002

表3

图2

图3

表4

图4

图5

图6

图7

图8

图9

参考文献 18

[19]	Garibaldi L, Anzani A, Marieni A, et al.2003. Studies on the phytoplankton of the deep subalpine Lake Iseo[J]. Journal of Limnology, 62(2): 177-189. doi: 10.4081/jlimnol.2003.177
[20]	Gitelson A A, Yacobi Y Z, Schalles J F, et al.2000. Remote estimation of phytoplankton density in productive waters[J]. Advances in Limnology, 55: 121-136.
[21]	Holeck K T, Watkins J M, Mills E L, et al.2008. Spatial and long-term temporal assessment of Lake Ontario water clarity, nutrients, chlorophyll a, and zooplankton[J]. Aquatic Ecosystem Health & Management, 11(4): 377-391. doi: 10.1080/14634980802515302
[22]	Kloiber S M, Brezonik P L, Olmanson L G, et al.2002. A procedure for regional lake water clarity assessment using Landsat multispectral data[J]. Remote Sensing of Environment, 82(1): 38-47. doi: 10.1016/S0034-4257(02)00022-6
[23]	Knight J F, Voth M L.2012. Application of MODIS imagery for intra-annual water clarity assessment of Minnesota Lakes[J]. Remote Sensing, 4(7): 2181-2198.
[24]	Lathrop R C, Carpenter S R, Rudstam L G.1996. Water clarity in Lake Mendota since 1900: Responses to differing levels of nutrients and herbivory[J]. Canadian Journal of Fisheries and Aquatic Sciences, 53(10): 2250-2261.
[25]	Liang E Y, Wang Y F, Piao S L, et al.2016. Species interactions slow warming-induced upward shifts of treelines on the Tibetan Plateau[J]. Proceedings of the National Academy of Sciences of the United States of America, 113(16): 4380-4385. doi: 10.1073/pnas.1520582113 pmid: 27044083
[26]	Ma R H, Yang G S, Duan H T, et al.2011. China’s lakes at present: Number, area and spatial distribution[J]. Science China Earth Sciences, 54(2): 283-289. doi: 10.1007/s11430-010-4052-6
[27]	Malthus T J, Hestir E L, Dekker A G, et al.2012. The case for a global inland water quality product[C]//Proceedings of the 2012 IEEE international geoscience and remote sensing symposium (IGARSS). Munich, Germany: IEEE, 5234-5237, doi: 10.1109/IGARSS.2012.6352429.
[28]	Mancino G, Nolè A, Urbano V, et al.2009. Assessing water quality by remote sensing in small lakes: The case study of Monticchio lakes in southern Italy[J]. iForest-Biogeosciences and Forestry, 2(1): 154-161.
[29]	McCullough I M, Loftin C S, Sader S A.2012. Combining lake and watershed characteristics with Landsat TM data for remote estimation of regional lake clarity[J]. Remote Sensing of Environment, 123: 109-115. doi: 10.1016/j.rse.2012.03.006
[30]	Olmanson L G, Bauer M E, Brezonik P L.2008. A 20-year Landsat water clarity census of Minnesota's 10000 lakes[J]. Remote Sensing of Environment, 112(11): 4086-4097. doi: 10.1016/j.rse.2007.12.013
[31]	Olmanson L G, Brezonik P L, Bauer M E, et al.2011. Evaluation of medium to low resolution satellite imagery for regional lake water quality assessments[J]. Water Resources Research, 47(9): W09515. doi: 10.1029/2011WR011005
[32]	Olmanson L G, Brezonik P L, Finlay J C, et al.2016. Comparison of Landsat 8 and Landsat 7 for regional measurements of CDOM and water clarity in lakes[J]. Remote Sensing of Environment, 185: 119-128. doi: 10.1016/j.rse.2016.01.007
[33]	Qiao B J, Wang J B, Huang L, et al.2017. Characteristics and seasonal variations in the hydrochemistry of the Tangra Yumco basin, central Tibetan Plateau, and responses to the Indian Summer Monsoon[J]. Environmental Earth Sciences, 76(4): 162, doi: 10.1007/s12665-017-6479-y. doi: 10.1007/s12665-017-6479-y
[34]	Qin D H, Liu S Y, Li P J.2006. Snow cover distribution, variability, and response to climate change in western China[J]. Journal of Climate, 19(9): 1820-1833.
[1]	勾鹏, 叶庆华, 魏秋方. 2015. 2000-2013年西藏纳木错湖冰变化及其影响因素[J]. 地理科学进展, 34(10): 1241-1249. doi: 10.18306/dlkxjz.2015.10.004
	[Gou P, Ye Q H, Wei Q F.2015. Lake ice change at the Nam Co Lake on the Tibetan Plateau during 2000-2013 and influencing factors[J]. Progress in Geography, 34(10): 1241-1249.] doi: 10.18306/dlkxjz.2015.10.004
[35]	Rose K C, Greb S R, Diebel M, et al.2017. Annual precipitation regulates spatial and temporal drivers of lake water clarity[J]. Ecological Applications, 27(2): 632-643. doi: 10.1002/eap.1471 pmid: 27859882
[36]	Shen M G, Piao S L, Chen X Q, et al.2016. Strong impacts of daily minimum temperature on the green-up date and summer greenness of the Tibetan Plateau[J]. Global Change Biology, 22(9): 3057-3066. doi: 10.1111/gcb.13301 pmid: 27103613
[2]	何杰, 阳坤. 2011. 中国区域高时空分辨率地面气象要素驱动数据集[Z]. 兰州: 寒区旱区科学数据中心, doi: 10.3972/westdc.002.2014.db.
	[He J, Yang K.2011. China meteorological forcing dataset[Z]. Lanzhou, China: Cold and Arid Regions Science Data Center at Lanzhou, doi: 10.3972/westdc.002.2014.db.]
[37]	Song C Q, Huang B, Ke L H.2013. Modeling and analysis of lake water storage changes on the Tibetan Plateau using multi-mission satellite data[J]. Remote Sensing of Environment, 135: 25-35. doi: 10.1016/j.rse.2013.03.013
[38]	Wu G F, De Leeuw J, Skidmore A K, et al.2008. Comparison of MODIS and Landsat TM5 images for mapping tempo-spatial dynamics of Secchi disk depths in Poyang Lake national nature reserve, China[J]. International Journal of Remote Sensing, 29(8): 2183-2198. doi: 10.1080/01431160701422254
[3]	鲁安新, 姚檀栋, 王丽红, 等. 2005. 青藏高原典型冰川和湖泊变化遥感研究[J]. 冰川冻土, 27(6): 783-792. doi: 10.3969/j.issn.1000-0240.2005.06.001
	[Lu A X, Yao T D, Wang L H, et al.2005. Study on the fluctuations of typical glaciers and lakes in the Tibetan Plateau using remote sensing[J]. Journal of Glaciology and Geocryology, 27(6): 783-792.] doi: 10.3969/j.issn.1000-0240.2005.06.001
[39]	Yang J P, Ding Y J, Chen R S, et al.2003. Causes of glacier change in the source regions of the Yangtze and Yellow Rivers on the Tibetan Plateau[J]. Journal of Glaciology, 49(167): 539-546. doi: 10.3189/172756503781830449
[40]	Yang R M, Zhu L P, Wang J B, et al.2017. Spatiotemporal variations in volume of closed lakes on the Tibetan Plateau and their climatic responses from 1976 to 2013[J]. Climatic Change, 140(3-4): 621-633, doi: 10.1007/s10584-016-1877-9. doi: 10.1007/s10584-016-1877-9
[4]	马建行, 宋开山, 邵田田, 等. 2016. 基于HJ-CCD和MODIS的吉林省中西部湖泊透明度反演对比[J]. 湖泊科学, 28(3): 661-668. doi: 10.18307/2016.0323
	[Ma J H, Song K S, Shao T T, et al.2016. Comparison of water transparency retrieving of lakes in the mid-east part of Jilin Province based on HJ-CCD and MODIS imagery[J]. Journal of Lake Sciences, 28(3): 661-668.] doi: 10.18307/2016.0323
[41]	Yao X J, Li L, Zhao J, et al.2016. Spatial-temporal variations of lake ice phenology in the Hoh Xil region from 2000 to 2011[J]. Journal of Geographical Sciences, 26(1): 70-82. doi: 10.1007/s11442-016-1255-6
[42]	Zhang G Q, Xie H J, Yao T D, et al.2013. Water balance estimates of ten greatest lakes in China using ICESat and Landsat data[J]. Chinese Science Bulletin, 58(31): 3815-3829. doi: 10.1007/s11434-013-5818-y
[5]	马荣华, 唐军武, 段洪涛, 等. 2009. 湖泊水色遥感研究进展[J]. 湖泊科学, 21(2): 143-158. doi: 10.18307/2009.0201
	[Ma R H, Tang J W, Duan H T, et al.2009. Progress in lake water color remote sensing[J]. Journal of Lake Sciences, 21(2): 143-158.] doi: 10.18307/2009.0201
[6]	潘继征, 熊飞, 李文朝, 等. 2008. 云南抚仙湖透明度的时空变化及影响因子分析[J]. 湖泊科学, 20(5): 681-686. doi: 10.3321/j.issn:1003-5427.2008.05.019
	[Pan J Z, Xiong F, Li W C, et al.2008. Spatial-temporal dynamic changes of the water transparency and their influencing factors in Lake Fuxian, Yunnan Province[J]. Journal of Lake Sciences, 20(5): 681-686.] doi: 10.3321/j.issn:1003-5427.2008.05.019
[43]	Zhang G Q, Yao T D, Xie H J, et al.2014a. Estimating surface temperature changes of lakes in the Tibetan Plateau using MODIS LST data[J]. Journal of Geophysical Research: Atmospheres, 119(14): 8552-8567. doi: 10.1002/2014JD021615
[44]	Zhang G Q, Yao T D, Xie H J, et al.2014b. Lakes’ state and abundance across the tibetan plateau[J]. Chinese Science Bulletin, 59(24): 3010-3021. doi: 10.1007/s11434-014-0258-x
[45]	Zhao D H, Cai Y, Jiang H, et al.2011. Estimation of water clarity in Taihu Lake and surrounding rivers using Landsat imagery[J]. Advances in Water Resources, 34(2): 165-173. doi: 10.1016/j.advwatres.2010.08.010
[46]	Zhu L P, Xie M P, Wu Y H, et al.2010. Quantitative analysis of lake area variations and the influence factors from 1971 to 2004 in the Nam Co basin of the Tibetan Plateau[J]. Chinese Science Bulletin, 55(13): 1294-1303. doi: 10.1007/s11434-010-0015-8
[7]	王君波, 彭萍, 马庆峰, 等. 2010. 西藏当惹雍错和扎日南木错现代湖泊基本特征[J]. 湖泊科学, 22(4): 629-632. doi: 10.18307/2010.0422
	[Wang J B, Peng P, Ma Q F, et al.2010. Modern limnological features of Tangra Yumco and Zhari Namco, Tibetan Plateau[J]. Journal of Lake Sciences, 22(4): 629-632.] doi: 10.18307/2010.0422
[8]	姚檀栋. 2014. “第三极环境(TPE)”国际计划: 应对区域未来环境生态重大挑战问题的国际计划[J]. 地理科学进展, 33(7): 884-892.
	[Yao T D.2014. TPE international program: A program for coping with major future environmental challenges of The Third Pole region[J]. Progress in Geography, 33(7): 884-892.]
[9]	张晓晶, 李畅游, 贾克力, 等. 2009. 乌梁素海水体透明度分布及影响因子相关分析[J]. 湖泊科学, 21(6): 879-884. doi: 10.18307/2009.0619
	[Zhang X J, Li C Y, Jia K L, et al.2009. Spatial-temporal changes in water transparency and its impact factors in Lake Wuliangsuhai[J]. Journal of Lake Sciences, 21(6): 879-884.] doi: 10.18307/2009.0619
[10]	张运林, 秦伯强, 陈伟民, 等. 2003. 太湖水体透明度的分析、变化及相关分析[J]. 海洋湖沼通报, (2): 30-36. doi: 10.3969/j.issn.1003-6482.2003.02.005
	[Zhang Y L, Qin B Q, Chen W M, et al.2003. Distribution, seasonal variation and correlation analysis of the transparency in Taihu Lake[J]. Transactions of Oceanology and Limnology, (2): 30-36.] doi: 10.3969/j.issn.1003-6482.2003.02.005
[11]	中国科学院青藏高原综合科学考察队. 1984. 西藏河流与湖泊[M]. 北京: 科学出版社.
	[The Qinghai-Tibet Plateau Comprehencive Scientific Expedition of Chinese Academy of Sciences. 1984. Xizang heliu yu hupo[M]. Beijing, China: Science Press.]
[12]	Barbiero R P, Tuchman M L.2004. Long-term dreissenid impacts on water clarity in Lake Erie[J]. Journal of Great Lakes Research, 30(4): 557-565. doi: 10.1016/S0380-1330(04)70371-8
[13]	Binding C E, Greenberg T A, Watson S B, et al.2015. Long term water clarity changes in North America's Great Lakes from multi-sensor satellite observations[J]. Limnology and Oceanography, 60(6): 1976-1995. doi: 10.1002/lno.10146
[14]	Courville B C, Jensen J L R, Dixon R W, et al.2014. A landsat-based evaluation of lake water clarity in Maine lakes[J]. Physical Geography, 35(4): 355-368. doi: 10.1080/02723646.2014.909716
[15]	Delgadillo-Hinojosa F, Gaxiola-Castro G, Segovia-Zavala J A, et al.1997. The effect of vertical mixing on primary production in a bay of the gulf of California[J]. Estuarine, Coastal and Shelf Science, 45(1): 135-148. doi: 10.1006/ecss.1996.0167
[16]	Duan H T, Ma R H, Zhang Y Z, et al.2009. Remote-sensing assessment of regional inland lake water clarity in northeast China[J]. Limnology, 10(2): 135-141. doi: 10.1007/s10201-009-0263-y
[17]	Fee E J, Hecky R E, Kasian S E M, et al.1996. Effects of lake size, water clarity, and climatic variability on mixing depths in Canadian Shield lakes[J]. Limnology and Oceanography, 41(5): 912-920. doi: 10.4319/lo.1996.41.5.0912
[18]	Fukushima T, Matsushita B, Oyama Y, et al.2016. Semi-analytical prediction of Secchi depth using remote-sensing reflectance for lakes with a wide range of turbidity[J]. Hydrobiologia, 780(1): 5-20. doi: 10.1007/s10750-015-2584-7

波段名称	波段宽度/nm	信噪比/NE△t	空间分辨率
B8	405~420	880	1 km
B9	438~448	838	1 km
B3	459~479	243	500 m合成为1 km
B10	483~493	802	1 km
B11	526~536	754	1 km
B12	546~556	750	1 km
B4	545~565	228	500 m合成为1 km
B1	620~670	128	500 m合成为1 km
B13	662~672	910	1 km
B14	673~683	1087	1 km
B15	743~753	586	1 km
B2	841~876	201	250 m合成为1 km
B16	862~877	516	1 km

自变量类型	因变量	最优拟合自变量	最优拟合方法	最优拟合结果	R2	N
波段比值	SD	x=B8/B11	线性	SD= 8.8254x - 4.9669	0.65	24
			指数	SD= 0.3635e^2.0575^x	0.59	24
			对数	SD= 10.027ln(x) + 4.1792	0.63	24
			幂	SD = 3.0486x^2.5065	0.65	24
			多项式	SD= 0.4808x² + 7.6165x - 4.2702	0.65	24
波段比值	ln(SD)	x=B8/B4	线性	ln(SD) = 1.5093x - 0.5485	0.60	24
			多项式	y = -0.9299x² + 4.0536x - 2.0735	0.68	24
			对数	ln(SD) = 1.9501ln(x) + 1.04	0.68	24
			幂	变量含负值,无法拟合
			指数	变量含负值,无法拟合
主成分	ln(SD)	主成分PC₁、PC₂、PC₃、PC₄ (PC₁-PC₄累计贡献率>99%)	主成分回归	ln(SD)=-1.5PC₁+0.95PC₂+10.79PC₃-21.55PC₄	0.88	24
红绿蓝比值与单波段	ln(SD)	x₁=B1/B3、x₂=B3	二元回归	ln(SD)=1.211767x₁-13.1984x₂+1.149798	0.90	24
红绿蓝加减	SD	x=B12+B4	幂	SD=0.2187x^-1.536	0.91	24
