1978-2015年喀喇昆仑山克勒青河流域冰川变化的遥感监测

doi:10.18306/dlkxjz.2016.07.009

地理科学进展 ›› 2016, Vol. 35 ›› Issue (7): 878-888.doi: 10.18306/dlkxjz.2016.07.009

1978-2015年喀喇昆仑山克勒青河流域冰川变化的遥感监测

许艾文, 杨太保^*(), 王聪强, 冀琴

兰州大学资源环境学院,冰川与生态地理研究所,兰州 730000

收稿日期:2015-12-01 修回日期:2016-05-01 出版日期:2016-07-20 发布日期:2016-07-20
通讯作者: 杨太保
作者简介:
作者简介：许艾文(1992-),女,湖北十堰人,硕士研究生,研究方向为冰川变化与气候响应,E-mail: xuaw92@163.com。
基金资助:
基金项目：国家自然科学基金项目(41271024); 兰州大学地理学基地科研训练及科研能力提高项目(J1210065)

Variation of glaciers in the Shaksgam River Basin, Karakoram Mountains during 1978-2015

Aiwen XU, Taibao YANG^*(), Congqiang WANG, Qin JI

Institute of Glaciology and Ecogeography, College of Earth and Environmental Science, Lanzhou University, Lanzhou 730000, China

Received:2015-12-01 Revised:2016-05-01 Online:2016-07-20 Published:2016-07-20
Contact: Taibao YANG
Supported by:
Foundation: National Natural Science Foundation of China, No.41271024;Scientific Research Training and Scientific Research Ability Improvement Project of Geography Base of Lanzhou University, No.J1210065

摘要/Abstract

摘要：

本文采用1978、1991、2001和2015年的Landsat MSS、TM、ETM+和OLI遥感影像,通过遥感图像计算机辅助分类和目视解译等方法提取冰川边界,分析喀喇昆仑山克勒青河流域冰川在1978-2015年间的进退变化。结果表明：1978-2015年间研究区冰川面积由1821.70 km2减少至1675.92 km2,减少145.78 km2,占1978年冰川总面积的8.00%;冰川消融率较低,在气候变暖的背景下反而呈现出退缩速率由快变慢的趋势。研究区东南向冰川退缩率明显高于西北向,冰川退缩率随冰川规模的增大而减小。研究区内有27处冰川在1978-2015年间发生过特殊的前进现象,面积与长度显著增加。其中,木斯塔冰川西侧冰川末端在1996-1998年间前进速度为904 m/a,乔戈里冰川东侧冰川末端在2007-2009年间前进速度为446 m/a,5Y654D0097冰川末端在1978-1990年间前进速度为238 m/a,初步判定这三条冰川为跃动冰川。以10 a为滞后期分析研究区周边气象站点资料发现：研究区气温持续升高,降水量以1981年为分界点呈现“先减后增”趋势是冰川退缩速率减慢的原因之一;此外,亚大陆型冰川性质、巨大山势条件和高山冷储作用,也可能是冰川退缩幅度较小的原因。

关键词: 冰川变化, 遥感技术, 跃动冰川, 克勒青河流域

Abstract:

Based on Landsat MSS/TM/ETM+/OLI images of 1978, 1991, 2001, and 2015, glacier boundaries in the Shaksgam River Basin, Karakoram Mountains were extracted using computer aided image classification and visual interpretation methods, and the changes of glaciers in the study area were analyzed. The results show that the total area of glaciers in the study area was reduced from 1821.70 km2 to 1675.92 km2 during 1978-2015, by 145.78 km2, or 8% of the total area of glaciers. Under the background of climate warming, however, the rate of glacier retreating shifted from fast to slow in nearly 40 years. In the study area, the glacier retreat rate on the southeastern aspect was significantly higher than on the northwestern aspect. Glacier retreat rate decreased with the increase of scale of glaciers. There were 27 typical glaciers that clearly progressed during 1978-2015, with areas and lengths significant increased. Among these, the velocity of change for the western side of the Wood stark glacier was 904 m/a during 1996-1998, the velocity of change for the eastern side of the K2 glacier was 446 m/a during 2007-2009, and the velocity of change for the 5Y654D497 glacier was 238 m/a during 1978-1990, respectively. These three glaciers seem to be the surge-type glacier. By analyzing the climate records and glacier variation in the study area, it was concluded that higher temperatures led to the glacier retreat of the study area, but increasing rainfall to some extent inhibited glacier retreat. Topographic condition and the scale of glacier were key factors for glacier changes as well.

Key words: glacier change, remote sensing, glacier surging, Shaksgam River Basin

许艾文, 杨太保, 王聪强, 冀琴. 1978-2015年喀喇昆仑山克勒青河流域冰川变化的遥感监测[J]. 地理科学进展, 2016, 35(7): 878-888.

Aiwen XU, Taibao YANG, Congqiang WANG, Qin JI. Variation of glaciers in the Shaksgam River Basin, Karakoram Mountains during 1978-2015[J]. PROGRESS IN GEOGRAPHY, 2016, 35(7): 878-888.

图/表 11

图1

表1

表2

图2

图3

表3

研究区典型冰川变化特征"

序号	冰川名称	经度/°	纬度/°	面积变化/km²				长度变化/km
序号	冰川名称	经度/°	纬度/°	1978-1991年		1991-2001年	2001-2015年	1978-1991年	1991-2001年	2001-2015年
1	5Y654D0068	36.068	76.355	-0.03	0.01	0.59		-0.33	0.21	1.60
2	木斯塔冰川	35.898	76.232	0.12	0.31	0.05		0.75	1.25	-0.32
3	木斯塔冰川	35.900	76.299	0.03	0.17	-0.13		0.22	1.11	-0.03
4	木斯塔冰川	35.907	76.255	-0.03	0.14	0.49		-0.56	0.61	1.37
5	木斯塔冰川	35.918	76.273	0.41	-0.33	0.22		1.28	-0.98	1.25
6	音苏盖提冰川	36.093	76.071	-0.07	0.12	-0.06		0.22	1.15	-0.06
7	音苏盖提冰川	36.036	76.205	0.04	0.07	0.53		0.29	0.68	0.83
8	木斯塔冰川	35.982	76.325	0.10	1.06	-1.14		0.37	2.90	-1.90
9	乔戈里冰川	35.983	76.499	-0.12	-0.31	1.37		-0.50	-0.39	2.25
10	5Y654D0023	36.009	76.391	0.03	0.01	0.15		0.23	0.22	1.33
11	乔戈里冰川	35.967	76.456	0.11	-0.09	0.21		0.58	0.38	1.11
12	5Y654D0064	36.089	76.225	0.00	0.06	0.21		-0.61	0.16	0.95
13	5Y654D0064	36.083	76.229	0.06	-0.05	0.15		0.91	-0.54	1.37
14	音苏盖提冰川	36.083	76.269	-0.04	0.09	0.21		-0.40	0.65	1.40
15	音苏盖提冰川	36.039	76.196	-0.48	-0.12	1.06		1.01	0.83	1.05
16	音苏盖提冰川	36.145	76.093	-0.07	0.28	-0.15		0.44	1.44	0.00
17	音苏盖提冰川	36.128	76.126	0.07	0.34	-0.14		0.39	1.04	-0.46
18	音苏盖提冰川	36.122	76.134	0.06	0.12	-0.06		0.23	1.22	-0.42
19	5Y654D0097	36.191	76.181	1.37	-0.33	-0.44		2.86	-0.03	-0.04
20	5Y654D0096	36.161	76.201	-0.12	-0.46	3.22		0.00	0.12	4.92
21	塔吐鲁沟冰川	36.322	76.388	0.08	0.02	0.41		0.39	0.14	1.79
22	塔吐鲁沟冰川	36.324	76.398	-0.10	-0.18	1.11		-0.08	0.16	1.71
23	蚯蚓冰川	36.068	76.768	0.01	0.05	0.24		-0.09	0.07	1.18
24	沙克斯干冰川	35.746	76.821	0.22	-0.09	0.46		0.55	-0.08	0.58
25	5Y654C0132	35.712	76.941	-0.40	0.47	0.05		-0.72	1.29	-0.02
26	特拉木坎力冰川	35.678	76.989	-0.02	0.10	-0.08		-0.47	0.91	0.19
27	5Y654D0077	36.129	76.313	-0.03	0.35	0.67		-0.18	0.52	0.84

表3

图4

表4

图5

图6

图7

参考文献 33

1	段建平, 王丽丽, 任贾文, 等. 2009. 近百年来中国冰川变化及其对气候变化的敏感性研究进展[J]. 地理科学进展, 28(2): 231-237. doi: 10.11820/dlkxjz.2009.02.010
	[Duan J P, Wang L L, Ren J W, et al.2009. Progress in glacier variations in China and its sensitivity to climatic change during the past century[J]. Progress in Geography, 28(2): 231-237.] doi: 10.11820/dlkxjz.2009.02.010
2	冯童. 2015. 喀喇昆仑山乔戈里峰南北坡冰川变化对比研究[D]. 北京: 中国科学院大学.
	Feng T. 2015. A comparison study of glacier changes on the North and South slope of Mt. K2 area, Karakoram[D]. Beijing, China: University of Chinese Academy of Sciences.
3	郭万钦, 刘时银, 许君利, 等. 2012. 木孜塔格西北坡鱼鳞川冰川跃动遥感监测[J]. 冰川冻土, 34(4): 765-774.
	[Guo W Q, Liu S Y, Xu J L, et al.2012. Monitoring recent surging of the Yulinchuan Glacier on north slopes of Muztag range by remote sensing[J]. Journal of Glaciology and Geocryology, 34(4): 765-774.]
4	何毅, 杨太保. 2014. 博格达峰地区气候变化特征及其对冰川变化的影响[J]. 地理科学进展, 33(10): 1387-1396. doi: 10.11820/dlkxjz.2014.10.010
	[He Y, Yang T B.2014. Climate variation and glacier response in the Bogda region, Tianshan Mountains[J]. Progress in Geography, 33(10): 1387-1396.] doi: 10.11820/dlkxjz.2014.10.010
5	冀琴, 杨太保, 李霞. 2014. 念青唐古拉山东段八盖乡地区近40年冰川与气候变化研究[J]. 水土保持研究, 21(4): 306-310.
	[Ji Q, Yang T B, Li X.2014. Study on relationship between glacier retreat and climate change in the eastern Nyainqentanglha in the past 40 years[J]. Research of Soil and Water Conservation, 21(4): 306-310.]
6	蒋宗立, 刘时银, 许君利, 等. 2011. 应用SAR特征匹配方法估计音苏盖提冰川表面流速[J]. 冰川冻土, 33(3): 512-518.
	[Jiang Z L, Liu S Y, Xu J L, et al.2011. Using feature-tracking of ALOS PALSAR images to acquire the Yengisogat Glacier surface velocities[J]. Journal of Glaciology and Geocryology, 33(3): 512-518.]
7	晋锐, 车涛, 李新, 等. 2004. 基于遥感和GIS的西藏朋曲流域冰川变化研究[J]. 冰川冻土, 26(3): 261-266. doi: 10.3969/j.issn.1000-0240.2004.03.004
	[Jin R, Che T, Li X, et al.2004. Glacier variation in the Pumqu Basin derived from remote sensing data and GIS technique[J]. Journal of Glaciology and Geocryology, 26(3): 261-266.] doi: 10.3969/j.issn.1000-0240.2004.03.004
8	康建成, 何元庆. 1990. 喀喇昆仑山克勒青河上游地区冰川的初步研究[J]. 冰川冻土, 12(4): 319-325. doi: 10.1007/BF02919155
	[Kang J C, He Y Q.1990. The preliminary studies on the existing glaciers located in the upper region of Shaksgam River, Karakoram Mountains[J]. Journal of Glaciology and Geocryology, 12(4): 319-325.] doi: 10.1007/BF02919155
9	康建成, 何元庆. 1991. 喀喇昆仑山克勒青河谷冰川冰岩界面特征的初步研究[J]. 冰川冻土, 13(4): 331-336.
	[Kang J C, He Y Q.1991. Characteristic at boundary face of ice-bedrock on the upper region of Shaksgam Valley, Karakoram[J]. Journal of Glaciology and Geocryology, 13(4): 331-336.]
10	李成秀, 杨太保, 田洪阵. 2013. 1990-2011年西昆仑峰区冰川变化的遥感监测[J]. 地理科学进展, 32(4): 548-559. doi: 10.11820/dlkxjz.2013.04.007
	[Li C X, Yang T B, Tian H Z.2013. Variation of West Kunlun Mountains Glacier during 1990-2011[J]. Progress in Geography, 32(4): 548-559.] doi: 10.11820/dlkxjz.2013.04.007
11	李治国, 姚檀栋, 叶庆华, 等. 2011. 1980-2007年喜马拉雅东段洛扎地区冰川变化遥感监测[J]. 地理研究, 30(5): 939-952.
	[Li Z G, Yao T D, Ye Q H, et al.2011. Monitoring glacial variations based on remote sensing in the Luozha region, eastern Himalayas, 1980-2007[J]. Geographical Research, 30(5): 939-952.]
12	刘时银, 丁永建, 王宁练, 等. 1998. 天山乌鲁木齐河源1号冰川物质平衡对气候变化的敏感性研究[J]. 冰川冻土, 20(1): 9-13.
	[Liu S Y, Ding Y J, Wang N L, et al.1998. Mass balance sensitivity to climate change of the glacier No.1 at the Urumqi River Head, Tianshan Mts[J]. Journal of Glaciology and Geocryology, 20(1): 9-13.]
13	牛竞飞, 刘景时, 王迪, 等. 2011. 2009年喀喇昆仑山叶尔羌河冰川阻塞湖及冰川跃动监测[J]. 山地学报, 29(3): 276-282. doi: 10.3969/j.issn.1008-2786.2011.03.003
	[Niu J F, Liu J S, Wang D, et al.2011. Monitoring on ice-dammed lake and related surging glaciers in Yarkant River, Karakorum in 2009[J]. Journal of Mountain Science, 29(3): 276-282.] doi: 10.3969/j.issn.1008-2786.2011.03.003
14	蒲健辰, 姚檀栋, 王宁练, 等. 2004. 近百年来青藏高原冰川的进退变化[J]. 冰川冻土, 26(5): 517-522. doi: 10.1007/BF02873097
	[Pu J C, Yao T D, Wang N L, et al.2004. Fluctuations of the glaciers on the Qinghai-Tibetan Plateau during the past century[J]. Journal of Glaciology and Geocryology, 26(5): 517-522.] doi: 10.1007/BF02873097
15	上官冬辉, 刘时银, 丁永建, 等. 2004. 中国喀喇昆仑山、慕士塔格—公格尔山典型冰川变化监测结果[J]. 冰川冻土, 26(3): 374-375.
	[Shangguan D H, Liu S Y, Ding Y J, et al.2004. Monitoring results of glacier changes in China Karakorum and Muztag Ata-Konggur Mountains by remote sensing[J]. Journal of Glaciolgy and Geocryology, 26(3): 374-375.]
16	上官冬辉, 刘时银, 丁永建, 等. 2005. 喀喇昆仑山克勒青河谷近年来发现有跃动冰川[J]. 冰川冻土, 27(5): 641-644.
	[Shangguan D H, Liu S Y, Ding Y J, et al.2005. Surging glacier found in Shaksgam River, Karakorum Mountains[J]. Journal of Glaciology and Geocryology, 27(5): 641-644.]
17	王高峰, 张廷斌, 张建平, 等. 2010. 遥感影像的冰川信息提取方法对比[J]. 地理空间信息, 8(3): 43-46. doi: 10.3969/j.issn.1672-4623.2010.03.015
	[Wang G F, Zhang T B, Zhang J P, et al.2010. Comparative study of glaciers information extraction method based on remote sensing image[J]. Geospatial Information, 8(3): 43-46.] doi: 10.3969/j.issn.1672-4623.2010.03.015
18	王宁练, 张祥松. 1992. 近百年来山地冰川波动与气候变化[J]. 冰川冻土, 14(3): 242-250.
	[Wang N L, Zhang X S.1992. Mountain glacier fluctuations and climatic change during the last 100 years[J]. Journal of Glaciology and Geocryology, 14(3): 242-250.]
19	彦立利, 王建. 2013. 基于遥感的冰川信息提取方法研究进展[J]. 冰川冻土, 35(1): 110-118. doi: 10.7522/j.issn.1000-0240.2013.0013
	[Yan L L, Wang J.2013. Study of extracting glacier information from remote sensing[J]. Journal of Glaciology and Geocryology, 35(1): 110-118.] doi: 10.7522/j.issn.1000-0240.2013.0013
20	张文敬. 1983. 南迦巴瓦峰的跃动冰川[J]. 冰川冻土, 5(4): 75-76.
	[Zhang W J.1983. A surging glacier in the Nanjiabawa Peak area, Himalayas[J]. Journal of Glaciology and Geocryology, 5(4): 75-76.]
21	张祥松, 米德生. 1982. 喀喇昆仑山现代冰川的研究[J]. 冰川冻土, 4(3): 15-28.
	[Zhang X S, Mi D S.1982. Study of the present glaciers in the Karakoram[J]. Journal of Glaciology and Geocryology, 4(3): 15-28.]
22	Barrand N E, Murray T.2006. Multivariate controls on the incidence of glacier surging in the Karakoram Himalaya[J]. Arctic, Antarctic, and Alpine Research, 38(4): 489-498. doi: 10.1657/1523-0430(2006)38[489:MCOTIO]2.0.CO;2
23	Bolch T, Kamp U.2006. Glacier mapping in high mountains using DEMs, Landsat and ASTER data[J]. Grazer Schriften der Geographie und Raumforschung, 41: 37-48.
24	Bolch T, Kulkarni A, Kääb A, et al.2012. The state and fate of Himalayan glaciers[J]. Science, 336: 310-314. doi: 10.1126/science.1215828 pmid: 22517852
25	Copland L, Pope S, Bishop M P, et al.2009. Glacier velocities across the central Karakoram[J]. Annals of Glaciology, 50(52): 41-49. doi: 10.3189/172756409789624229
26	Copland L, Sylvestre T, Bishop M P, et al.2011. Expanded and recently increased glacier surging in the Karakoram[J]. Arctic, Antarctic, and Alpine Research, 43(4): 503-516. doi: 10.1657/1938-4246-43.4.503
27	Eisen O, Harrison W D, Raymond C F.2001. The surges of Variegated Glacier, Alaska, U.S.A., and their connection to climate and mass balance[J]. Journal of Glaciology, 47(158): 351-358.
28	Gardelle J, Berthier E, Arnaud Y.2012. Slight mass gain of Karakoram glaciers in the early twenty-first century[J]. Nature Geoscience, 5(5): 322-325. doi: 10.1038/ngeo1450
29	Hewitt K.2011. Glacier change, concentration, and elevation effects in the Karakoram Himalaya, Upper Indus Basin[J]. Mountain Research and Development, 31(3): 188-200. doi: 10.1659/MRD-JOURNAL-D-11-00020.1
30	Iturrizaga L.2012. Hummocky debris landforms in the Chapursan Valley (Karakoram range, Pakistan): A glacio-geomorphological investigatio[J]. Geomorphology, 169(10): 1-16. doi: 10.1016/j.geomorph.2011.10.023
31	Jin R, Li X, Che T, et al.2005. Glacier area changes in the Pumqu River Basin, Tibetan Plateau, between the 1970s and 2001[J]. Journal of Glaciology, 51: 607-610. doi: 10.3189/172756505781829061
32	Kamb B, Raymond C F, Harrison W D, et al.1985. Glacier surge mechanism: 1982-1983 surge of Variegated Glacier, Alaska[J]. Science, 227: 469-479. doi: 10.1126/science.227.4686.469 pmid: 17733459
33	Yao T D, Thompson L, Wang W, et al.2012. Different glacier status with atmospheric circulations in Tibetan Plateau and surroundings[J]. Nature Climate Change, 2(9): 663-667. doi: 10.1038/nclimate1580

获取日期	轨道号	传感器	云量/%	分辨率/m	影像说明
1977-08-20	160/34	MSS	0	80	解译影像
1978-07-18	159/35	MSS	5	80	解译影像
1978-07-19	160/35	MSS	13	80	解译影像
1990-08-07	149/34	TM	0	30	解译影像
1991-07-02	148/35	TM	26	30	解译影像
1993-07-07	148/35	TM	1	30	参考影像
2001-07-21	148/35	ETM+	6	30	解译影像
2001-09-30	149/34	ETM+	1	30	解译影像
2002-08-09	148/35	ETM+	20	30	参考影像
2013-07-30	148/35	OLI	5	30	参考影像
2014-08-18	148/35	OLI	17	30	解译影像
2015-08-28	149/34	OLI	12	30	解译影像

年份	面积/ km2	绝对变化/km2	年均变化/(km2/a)	相对变化率/%	年均变化率/(%/a)
1978	1821.70
1991	1753.47	-68.23	-5.24	-3.75	-0.29
2001	1712.96	-40.51	-4.05	-2.31	-0.23
2015	1675.92	-37.04	-2.65	-2.16	-0.15
