城市交通效率的多目标评价方法研究——以北京市城六区为例

doi:10.18306/dlkxjz.2016.01.013

摘要/Abstract

摘要：

高速城镇化和机动化阶段,面临与日剧增的环境压力,城市交通的多目标发展成为交通可持续发展的关键。在提升居民出行满意度的同时,降低交通碳排放是目前及未来城市交通可持续发展关注的核心目标,是城市交通效率的主要内涵。由此,本文从交通出行便捷与交通碳减排双目标综合评估的角度,提出基于中观尺度的城市交通出行满意度和交通碳排放的定量测算方法;并利用数据包络分析(Data Envelopment Analysis, DEA)法探讨城市交通综合效率评价方法。对北京市城六区的实证结果显示,在三环以内地区,城市交通综合效率较高,五环以外大部分地区较差。交通综合效率较高的地区集中分布于：①西三环至西四环万寿路街道的公主坟-五棵松地区。②北三环和平里街道安贞桥附近地区。③东北三环的三里屯地区。而综合效率较差的地区大多位于城市外围,例如西北六环周边,西南五环至西南六环部分地区,以及东五环外常营地区等,交通碳排放较高是这些地区交通效率较差的主要原因。此外,交通效率的空间差异与地理空间环境的差异性呈现高度的相关。例如,交通效率较差的地区大多是高档别墅区集聚的地区,以及城市五环周边公共交通不完善的部分居住区。通勤中机动化比例较高和通勤距离较长是碳排放强度较高的主要原因。

关键词: 交通效率, 多目标综合评价, 数据包络分析, 交通碳排放, 交通满意度

Abstract:

With rapid urbanization, huge populations concentrate in cities, greatly increasing the environmental pressure of urban systems. Improving convenience of travel and at the same time reducing its negative effects on the environment, such as mitigating carbon emissions, is the key objective of present and future sustainable urban transportation development and important indicators of urban transportation efficiency. This research adopted a multi-objective evaluation method to evaluate transportation efficiency, including quantitative models for estimating carbon emission and convenience of travel and integrated methods of carbon emission and transport convenience. The six central urban districts in Beijing were chosen as our study area to test the evaluation method and explore mechanisms of transportation efficiency. The results show that transportation efficiency in Beijing differs between the central city and the outside areas. The efficiency is lower outside the 5th ring road, and higher inside the 3rd ring road. Especially, there are several centers of high and low transportation efficiency areas. The high efficiency centers are located in (1) the Gongzhufen-Wukesong area around the west 3rd and 4th ring roads; (2) the Anzhen Bridge area near the north 3rd ring road; and (3) the Sanlitun area near the east 3rd ring road. The low efficiency centers are located in the suburban areas, such as along the northwest 6th ring road, some areas between the 5th and 6th ring road in the southwest, and the Changying area outside the 5th ring road in the east. Besides, the spatial differences of transportation efficiency in Beijing have a close relationship with the geographic context. High carbon emission is the main cause of low transportation efficiency; this is particularly true in the areas where luxury-villas are located, and where public transportation service provision is insufficient. High proportion of car usage and long commuting distance are the main causes of high carbon emission. In the future, the construction of public transportation, especially the optimization of the subway system development, will improve the spatial distribution of transportation efficiency.

Key words: transportation efficiency, multi-objective evaluation, DEA, traffic carbon emission, travel convenience

季珏, 高晓路, 刘星辰. 城市交通效率的多目标评价方法研究——以北京市城六区为例[J]. 地理科学进展, 2016, 35(1): 118-125.

Jue JI, Xiaolu GAO, Xingchen LIU. Multi-objective evaluation of urban transportation efficiency:Take Beijing as an example[J]. PROGRESS IN GEOGRAPHY, 2016, 35(1): 118-125.

图/表 9

图1

表1

表2

表3

图2

表4

图3

图4

表5

参考文献 17

1	白鹤松. 2008. 基于多目标线性规划的决策模型研究[J]. 哈尔滨理工大学学报, 13(6): 57-59. doi: 10.3969/j.issn.1007-2683.2008.06.016
	[Bai H S.2008. Study on the decision-making model based on the multiple objective linear programming[J]. Journal of Harbin University of Science and Technology, 13(6): 57-59.] doi: 10.3969/j.issn.1007-2683.2008.06.016
2	曹小曙, 黄晓燕, 董哲. 2013. 基于GIS的公共交通可达性与居民出行特征[J]. 华南师范大学学报: 自然科学版, 45(5): 98-105. doi: 10.6054/j.jscnun.2013.07.022
	[Cao X S, Huang X Y, Dong Z.2013. Transit accessibility and characteristics of residents' transportation based on GIS[J]. Journal of South China Normal University: Natural Science Edition, 45(5): 98-105.] doi: 10.6054/j.jscnun.2013.07.022
3	柴彦威, 肖作鹏, 刘志林. 2011. 基于空间行为约束的北京市居民家庭日常出行碳排放的比较分析[J]. 地理科学, 31(7): 843-849.
	[Chai Y W, Xiao Z P, Liu Z L.2011. Comparative analysis on CO2 emission per household in daily travel based on spatial behavior constraints[J]. Scientia Geographica Sinica, 31(7): 843-849.]
4	方国华, 黄显峰. 2011. 多目标决策理论、方法及其应用[M]. 北京: 科学出版社.
	[Fang G H, Huang X F. 2011. Duo mubiao juece lilun, fangfa, jiqi yingyong[M]. Beijing, China: Science Press.]
5	高晓路, 季珏, 张文忠. 2009. 北京市交通出行环境的空间评价[J]. 地理科学, 29(6): 817-824.
	[Gao X L, Ji J, Zhang W Z.2009. Micro-evaluation of traffic environment of Beijing[J]. Scientia Geographica Sinica, 29(6): 817-824.]
6	季珏, 高晓路. 2012. 基于居民日常出行的生活空间单元的划分[J]. 地理科学进展, 31(2): 248-254. doi: 10.11820/dlkxjz.2012.02.014
	[Ji J, Gao X L.2012. Identifying the scope of daily life in urban areas based on residents’ travel behaviors[J]. Progress in Geography, 31(2): 248-254.] doi: 10.11820/dlkxjz.2012.02.014
7	马静, 柴彦威, 刘志林. 2011. 基于居民出行行为的北京市交通碳排放影响机理[J]. 地理学报, 66(8): 1023-1032.
	[Ma J, Chai Y W, Liu Z L.2011. The mechanism of CO2 emissions from urban transport based on individuals’ travel behavior in Beijing[J]. Acta Geographica Sinica, 66(8): 1023-1032.]
8	孟斌. 2009. 北京城市居民职住分离的空间组织特征[J]. 地理学报, 64(12): 1457-1466. doi: 10.1109/CLEOE-EQEC.2009.5194697
	[Meng B.2009. The spatial organization of the separation between jobs and residential locations in Beijing[J]. Acta Geographica Sinica, 64(12): 1457-1466.] doi: 10.1109/CLEOE-EQEC.2009.5194697
9	徐建华. 2006. 现代地理学中的数学方法[M]. 北京: 高等教育出版社: 224-230.
	[Xu J H.2006. Mathematical methods in contemporary geography[M]. Beijing, China: Higher Education Press: 224-230.]
10	张文忠, 尹卫红, 张锦秋, 等. 2006. 中国宜居城市研究报告(北京)[M]. 北京: 社会科学文献出版社.
	[Zhang W Z, Yin W H, Zhang J Q, et al. 2006. A study of livable cities in China (Beijing)[M]. Beijing, China: Social Sciences Academic Press.]
11	张侠, 尚建平, 赵德义, 等. 2009. 基于熵值法的城市土地可持续利用评价: 以石家庄市为例[J]. 国土与自然资源研究, (4): 33-35.
	[Zhang X, Shang J P, Zhao D Y, et al.2009. Urban land sustainable use evaluation based on entropy method: a case of Shijiazhuang city[J]. Territory & Natural Resources Study, (4): 33-35.]
12	郑思齐, 孙聪. 2011. 城市经济的空间结构: 居住、就业及衍生问题[J]. 南方经济, (8): 18-31.
	[Zheng S Q, Sun C.2011. Urban spatial structure: housing, jobs and related urban Issues[J]. South China Journal of Economics, (8): 18-31.]
13	Ji J, Gao X L.2010. Analysis of people’s satisfaction with public transportation in Beijing[J]. Habitat International, 34(4): 464-470. doi: 10.1016/j.habitatint.2009.12.003
14	Kan K.2002. Residential mobility with job location uncertainty[J]. Journal of Urban Economics, 52(3): 501-523. doi: 10.1016/S0094-1190(02)00531-4
15	Krizek J K.2003. Residential relocation and changes in urban travel: Does neighborhood-scale urban form matter[J]. Journal of the American Planning Association, 69(3): 265-281. doi: 10.1080/01944360308978019
16	Kwan M P.2012. Human space-time behavior as the basis of dynamic conceptualizations of geographic context[C]//Paper presented on the 7th Workshop on Spatial Behavior and Planning Research. Beijing: Peking university:1-7.
17	Martínez F J.1995. Access: The transport-land use economic link[J]. Transportation Research Part B: Methodological, 29(6): 456-470. doi: 10.1016/0191-2615(95)00014-5

交通类别	交通方式	碳排放强度/(g/(人?km))
小型汽车类	私家车、出租车、单位配车	135.0
公共汽车类	公共汽车、单位班车、物业和购物巴士	35.0
轨道交通类	地铁/城铁	9.1
个人助动类	电动车、助残助动车、轻型摩托车	8.0
其他	步行、自行车	0.0

类别	房屋主导类型	800 m内站点个数	1 km内地铁站点数	容积率	物业管理费/(元/(m²?月))	二手房价/(万元/m²)	建成时间/a
高档别墅区	高档别墅	7.9	0.4	1.5	3.7	3.6	8.1
外围中档区	商品房	6.9	0.2	1.0	0.9	2.4	13.0
历史老城区	胡同、四合院	25.6	1.8	0.6	0.2	4.9	14.7
高档高密度区	商品房	17.7	0.7	3.7	3.2	3.2	9.6
成熟完善区	商品房	20.9	1.2	1.0	0.5	3.2	17.3

环境类别	交通方式使用比例/%						平均通勤距离/km
环境类别	步行		自行车	地铁	小汽车	公共汽车	其他
高档别墅区	3.0	1.0	10.0	80.0	5.0	1.0	16.8
外围中档区	11.7	9.7	16.8	29.3	30.3	2.2	11.1
历史传统区	7.8	30.2	4.0	5.1	47	5.9	10.1
高档高密度区	12.1	21.0	10.2	15.4	38.3	3.0	13.8
成熟完善区	16.6	21.5	9.4	10.8	38.2	3.5	5.8

变量	项目	估测系数	均方差	t统计量	显著性概率
	常数项	3.041	0.072	42.080	<0.001
X1	低收入人群比例(<3000元)	0.120	0.055	2.190	0.029
X2	公交覆盖面积(800 m范围内)	0.068	0.037	1.830	0.067
X3	地铁覆盖面积(1 km范围内)	0.096	0.024	4.060	<0.001
X4	老龄化比例(>60岁)	-0.261	0.164	-1.590	0.113
X5	企业密度	0.115	0.051	2.240	0.025
X6	道路优势度	0.251	0.086	2.920	0.004

空间环境类别	很低	较低	一般	较高	很高	总计
高档别墅区	100.0	0.0	0.0	0.0	0.0	100.0
外围中档区	0.0	100.0	0.0	0.0	0.0	100.0
历史传统区	0.0	5.8	94.2	0.0	0.0	100.0
高档高密度区	0.0	18.3	81.7	0.0	0.0	100.0
成熟完善区	0.0	0.0	3.9	63.0	33.1	100.0
